2 MENU-SPECIFIC SETTINGS

12. HDD SET

This screen provides information regarding the hard disk.
HDD SET
(1) DISK 1 : 82 GB
DISK 2 : --- GB
(2)
MIRRORING : OFF
(3)
PLAYBACK DRIVE : ***
2
SAVE
1
Change the settings as required.
(1) Hard disk capacity
This item displays the total capacity of the hard disk.
If hard disk expansion is carried out, a value will be
displayed for each disk.
(2) MIRRORING
This item displays in the mirroring-type setting.
Mirroring
When hard disk expansion has been carried out, the
same video can be recorded to both hard disks in a
process known as "mirroring". Even if a problem occurs
in the writing of video data to one of the disks, it will be
possible to extract normal data from the other disk
when this function is turned on.
(3) PLAYBACK DRIVE
This item indicates which of the hard drives will be used to
provide video for playback when mirroring has been turned
on.
[Settings]
Setting
DISK1 Playback data is read from disk1.
DISK2 Playback data is read from disk2.
2
Click [SAVE].
The new settings are saved.
The "***" will be displayed for "PLAYBACK DRIVE"
when only one hard disk is being used or when
"MIRRORING" is set to "OFF". Settings can not be
made in these cases.
Description

13. NETWORK SET

Network settings must be made in advance on the unit
whenever it is to be controlled via a network. Once this has
been done, settings can then be changed from the
controlling PC.
Changing network-related settings
When these settings are modified, connection will be
canceled and control rights will be returned to the unit.
To restore the connection, repeat network settings on
the PC to match the modified unit settings.
NETWORK SET
(1)
IP ADDRESS
(2)
SUBNET MASK
(3)
GATEWAY
PORT
(4)
PASSWORD SETTING
ID
(5)
ID1
ID2
ID3
(6)
NETWORK SPEED
2
1
Change the settings as required.
Item
Allows the unit's IP address to be
(1) IP ADDRESS
modified.
Allows the unit's subnet mask to be
(2) SUBNET MASK
modified.
(3) GATEWAY Allows the unit's gateway to be modified.
Allows the unit's port number to be
(4) PORT modified. Set within the range of 1 to
65535. (default setting: 80)
If a value other than "80" is set as the default value for
the port, when specifying the URL, enter a colon (:) and
then the port number after the IP address.
For example, if the port number was set as "81", you
should enter
http://192.168.0.1:81/
If settings are changed during network control, the
connection will be terminated.
38
:
192 168 0 1
:
255 . 255 . 255 . 0
: . . .
0 0 0 0
:
80
PASSWORD (4-8)
:
1111
:
2222
: 3333
:
NO LIMIT
SAVE
Description
