  • Page 1 Océ User manual Océ CS2024 Quick Start Guide...
  • Page 2 Océ Technologies B.V. Copyright  2005, Océ-Technologies B.V. Venlo, The Netherlands. All rights reserved. No part of this work may be reproduced, copied, adapted, or transmitted in any form or by any means without written permission from Océ. Océ-Technologies B.V. makes no representation or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.

  • Page 3: Table Of Contents

    Contents Contents Chapter 1 Read this first............5 Setup Flow .
  • Page 4 Contents...

  • Page 5: Read This First

    Chapter 1 Read this first...

  • Page 6: Setup Flow

    Setup Flow Setup Flow Overview Make Sure You Have Everything Assembling the Stand Setting Up the Printer Installing the Output Stacker Chapter 1 Read this first...
  • Page 7 Setup Flow Removing the Packing Material Connecting the Power Cord Installing the Printhead Installing the Ink Tanks...
  • Page 8 Setup Flow Loading Roll Media [10] Adjusting the Condition of the Printer Perform the automatic adjustment for the printhead and the amount of media feed. [11] Installing the Software [12] Note: For USB connections, do not connect the cable before installing the printer driver.

  • Page 9: Make Sure You Have Everything

    Make Sure You Have Everything Make Sure You Have Everything Printer Set [14] Printer [15] Power Cord [16] Ink Tanks ■ ■ ■ ■ ■ ■ [17] Roll holder [18] Cleaner Brush [19] Printhead [20] Hex driver Quick Start Guide (This guide)
  • Page 10 Make Sure You Have Everything Reference Guide [21] User Software CD-ROM ■ User Manuals CD-ROM ■ Chapter 1 Read this first...
  • Page 11 Make Sure You Have Everything Stand Set [22] Stand Foot L ■ Stand Foot R ■ [23] Stand Leg L ■ Stand Leg R ■ [24] Stand Stay Hex Screws ×8 [25] ■ M4 Hex Screws ×4 ■ Hex Wrench ■...
  • Page 12 Make Sure You Have Everything Space Requirements When you set up the printer, make sure that there is at least as much space around the printer (more space is recommended) as shown by the dimensions in the drawing. [30] 2000 mm (78.7 in.) [30] Height [31] 600 mm...

  • Page 13: Assembling The Stand

    Assembling the Stand Assembling the Stand Position the stand leg L (a) as shown, then with the stand foot L (b) aligned with the inside groove, insert the projections into the holes and fasten with the 4 hex screws. [32] Position the stand leg R (c) as shown, then with the stand foot R (d) aligned with the inside groove, insert the tabs into the holes and fasten with the 4 hex.
  • Page 14 Assembling the Stand After you use the hex driver (provided) to loosen the hex screws of the stand stay (e), remove the tape from the left and right end of the stay, hold the stay as shown, then insert it into the grooves of stand leg L (a) and stand leg R (c). [34] Secure the stand stay by tightening the left and right hex screws with the provided hex wrench.

  • Page 15: Setting Up The Printer

    Setting Up the Printer Setting Up the Printer Illustration [36] [36] To prevent painful back or other injury [37] [37] Firmly grasp the handles (a)
  • Page 16 Setting Up the Printer Stand Configuration Move the stand to where you want to set up the printer, then lock the front casters. [38] Hold the printer by the handles provided on the bottom of both sides of the printer, align the round part on bottom of the printer (b) with the round part on top of the stand (c), then set the printer onto the stand.
  • Page 17 Setting Up the Printer From the bottom of the stand support plate, attach and tighten two hex screws to both sides of the printer. [40]...

  • Page 18: Installing The Output Stacker

    Installing the Output Stacker Installing the Output Stacker With the front side (the side without lapels) of the output stacker cloth facing up, use the holes on both ends of the cloth to attach the cloth to output stacker arm A (a) and the output stacker arm B (b).
  • Page 19 Installing the Output Stacker From within the left and right of rear output stacker arm B (b), insert firmly into the installation holes of the arm holder (f), then insert the arm securely into the groove. [43] Insert both ends of the output stacker arm A (a) into the center holes (g) of the stand foot.

  • Page 20: Removing The Packing Material

    Removing the Packing Material Removing the Packing Material Remove all tape attached to printer and roll holder. [46] [47] Open the upper cover. [48] Attention: The upper cover stopper (a) is attached to the upper cover. The upper cover stopper is important because it prevents the upper cover from falling unexpectedly.
  • Page 21 Removing the Packing Material Push the release lever toward the rear, remove the protective sheet (b) on the platen, then pull the release lever to the front. [49] Remove the hex screw from the belt stopper (c) then remove a caution card with a strings and the belt stopper.
  • Page 22 Removing the Packing Material Raise the upper cover stopper (a) to release the lock, then close the upper cover. [51] Chapter 1 Read this first...

  • Page 23: Connecting The Power Cord

    Connecting the Power Cord Connecting the Power Cord On the left side of the printer, connect the power cord to the power connector. [52] Insert the plug of the power cord into the power source. [53]...

  • Page 24: Installing The Printhead

    Installing the Printhead Installing the Printhead Press the Power button to switch the printer on. [54] Open the upper cover. [55] Attention: Do not touch any areas other than those indicated. This could damage the printer. Raise and open the carriage cover. [56] Chapter 1 Read this first...
  • Page 25 Installing the Printhead Pull the printhead lock lever completely forward to open it. [57] Raise the printhead lock cover completely to open it. [58] Hold the printhead by the grips (a) and remove it from its case, then remove the orange protective cap 1 (b).
  • Page 26 Installing the Printhead Attention: When handling the printhead, always hold it by the grips (a) on the left and right sides of the printhead. Attention: Never touch the nozzles (e) or the electrical contacts (f). This could damage the printhead, or cause poor print quality. Attention: Never try to re-attach the protective caps or packing material removed from the printhead.
  • Page 27 Installing the Printhead With the nozzles pointing down and the electrical contacts facing the printer, insert the printhead into the carriage. [62] Lower the printhead lock cover toward you to lock the printhead in place. [63]...
  • Page 28 Installing the Printhead Raise the printhead lock lever and push it in until you hear it catch. [64] Pull the carriage cover down and forward until you hear it catch. [65] Raise the upper cover stopper to release the lock then close the upper cover. [66] Chapter 1 Read this first...

  • Page 29: Installing The Ink Tanks

    Installing the Ink Tanks Installing the Ink Tanks Open the right cover. [67] Press the ink tank lever of the color to set, then open the ink tank cover. [68] [69]...
  • Page 30 Installing the Ink Tanks Slowly rotate the ink tank package 7 or 8 times, remove the ink tank from its packing, and with the ink ports pointing down and the label facing in the direction shown in the illustration below, insert the ink tank into the ink tank holder. [70] [71] [71] Attention...
  • Page 31 Installing the Ink Tanks Close the ink tank cover until you hear it catch. [72] Repeat Steps 1 to 4 to install all the other color ink tanks. After all the ink tanks have been installed, close the right cover. [73]...

  • Page 32: Loading Roll Media

    Loading Roll Media Loading Roll Media Attention: You should always wear cloth gloves when you handle roll media to protect the printing surface. Pull the holder stopper lever (a) to the outside to release it, then remove the holder stopper from the roll holder. [74] With the leading edge of the media on the roll facing up, insert the roll holder into the left end of the roll media, and push it in until it stops.
  • Page 33 Loading Roll Media Hold the roll with the leading edge of the roll media facing the printer as shown in the illustration, then align the roll core (b) with the left and right slots of the left and right guides (c) then load carefully. [77] Push the release lever toward the rear to open.
  • Page 34 Loading Roll Media Open the upper cover. [80] While gently pulling out the center of the leading edge of the roll media as far as the cutter groove (e), align the right edge of the media so it is parallel to guideline (f), then pull the release lever to the front to close it.
  • Page 35 Loading Roll Media of media that can be used with the black ink tank installed in the printer are displayed. Océ Media name Name Printer Operating Panel IJM005 Océ Draft Paper Draft Paper IJM020 Océ Standard Paper Standard Paper IJM113 Océ Premium Paper 90g/m2 Premium Paper IJM150 Océ...
  • Page 36 Loading Roll Media When preparation for feeding roll media is finished, Online is displayed and the printer is ready to print. Attention: You must select the setting for Media Type that matches the media loaded in the printer. If the setting does not match the type of media loaded in the printer, this will cause the quality of printing to deteriorate.

  • Page 37: Adjusting The Condition Of The Printer

    Adjusting the Condition of the Printer Adjusting the Condition of the Printer Adjusting the Printhead Position Note: When you align the printhead, use the media most commonly used with the printer. Note: If you are using cut sheets, make sure at least one sheet of unused A3 paper (not the blank sides of used paper) or larger is set for long-edge feed.
  • Page 38 Adjusting the Condition of the Printer Select Advanced Adj. then press [ [89] Auto Head Adj. Advanced Adj. Press [ ] or [ ] to select Yes, then press OK. [90] Advanced Adj. The pattern for printhead adjustment prints. [91] The printer reads the results of a printhead adjustment pattern as it prints and sets the value for adjustment of the printhead automatically.
  • Page 39 Adjusting the Condition of the Printer Adjusting Amount of Media Feed Attention: Before you adjust media feed, you must use the operation panel to select the media type for the media loaded for printing. If the value of the media type selection does not match the media loaded for printing, you will not achieve good print results and the quality of the printing will be poor.
  • Page 40 Adjusting the Condition of the Printer Select Standard Adj. then press [ [95] Adjust Band Standard Adj. Press [ ] or [ ] to select Yes, then press OK. [96] Standard Adj. The pattern for adjusting the amount of media feed prints. [97] The printer reads the results of the pattern as it prints, and then automatically adjusts the amount of media feed for the media that is currently loaded in the printer.

  • Page 41: Installing For Windows

    Attention: Be sure to use a USB 2.0 standard connection cable. Mount the provided User Software CD-ROM in the computer CD-ROM drive. [98] Start the wizard. Double-click setup.exe which you can find on the Océ CS2024 CD-rom. [99] Follow the procedure to complete the installation.
  • Page 42 Installing for Windows When the port connection screen appears, connect the USB cable to the printer and the computer. [100] USB Connection Printer back Computer Connecting the LAN Cable Note: The following operating systems support a TCP/IP network connection: Windows Server 2003, Windows XP, Windows 2000, Windows Me, Windows 98, or Windows NT 4.0 (Service Pack 6 or later).
  • Page 43 Connecting the Printer to a Network for the First Time Mount the provided User Software CD-ROM in the computer CD-ROM drive. [102] Start the wizard. Double-click setup.exe which you can find on the Océ CS2024 CD-rom. [103] Follow the procedure to complete the installation.
