Océ CS2436 Users Guide
Table of Content:
1. Basic Printing Workflow
2. Working With Various Print Jobs
3. Enhanced Printing Options
4. Windows Software
5. Mac OS X Software
6. Handling Paper
7. Adjustments for Better Print Quality
8. Printer Parts
9. Network Setting
10. Maintenance
11. Troubleshooting
12. Error Message
13. Appendix

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS2436 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oce CS2436

Summary of Contents for Oce CS2436

  • Page 1 Océ CS2436 Users Guide Table of Content: 1. Basic Printing Workflow 2. Working With Various Print Jobs 3. Enhanced Printing Options 4. Windows Software 5. Mac OS X Software 6. Handling Paper 7. Adjustments for Better Print Quality 8. Printer Parts 9.

  • Page 2: Table Of Contents

    Basic Printing Workflow (CS2436-1) 1. Basic Printing Workflow 1. 1. Printing procedure Printing Options Using Rolls and Sheets Loading and Printing on Rolls Loading and Printing on Sheets Printing in Windows Printing in Mac OS X Specifying Paper in the Printer Driver (Windows) Specifying Paper in the Printer Driver (Mac OS X) 1.

  • Page 3: Printing Options Using Rolls And Sheets

    Basic Printing Workflow (CS2436-1) 1. 1. 1. Basic Printing Workflow > Printing procedure > Printing Options Using Rolls and Sheets The printer supports both rolls and sheets. This section introduces the main features of each, as well as the main printing methods available. Select rolls or sheets to suit your particular printing application.
  • Page 4 Basic Printing Workflow (CS2436-1) Insert the sheet between the Platen and the Paper Retainer. Enlarged/reduced printing ● You can freely adjust the size of originals by enlarging or reducing originals before printing. (See "Resizing Originals to Match the Paper Size (3.3.1).")

  • Page 5: Loading And Printing On Rolls

    Basic Printing Workflow (CS2436-1) 1. 1. 2. Basic Printing Workflow > Printing procedure > Loading and Printing on Rolls These are the basic steps for loading and printing on rolls. Follow these steps to load and print on rolls. Note For details on supported sizes and types of rolls, see Paper Sizes.
  • Page 6 Basic Printing Workflow (CS2436-1) Select the type of paper. (See "Changing the Type of Paper (6.2.3).")
  • Page 7 Basic Printing Workflow (CS2436-1) Note If no barcode has been printed on the roll and you have set ManageRemainRoll to On, specify the roll length after the type of paper. (See "Specifying the Paper Length (6.2.4).") Complete settings in the printer driver for the type of paper and other details.
  • Page 8 Basic Printing Workflow (CS2436-1) Send the print job. Printing in Windows (1.1.4) ● Printing in Mac OS X (1.1.5) ● The printer now starts printing the print job.

  • Page 9: Loading And Printing On Sheets

    Basic Printing Workflow (CS2436-1) 1. 1. 3. Basic Printing Workflow > Printing procedure > Loading and Printing on Sheets These are the basic steps for loading sheets and then printing. Follow the steps below to load and print on sheets.
  • Page 10 Basic Printing Workflow (CS2436-1) Send the print job. Printing in Windows (1.1.4) ● Printing in Mac OS X (1.1.5) ● Load the sheet. (See "Loading Sheets in the Printer (6.3.1).")
  • Page 11 Basic Printing Workflow (CS2436-1) The printer now starts printing the print job.

  • Page 12: Printing In Windows

    Basic Printing Workflow (CS2436-1) 1. 1. 4. Basic Printing Workflow > Printing procedure > Printing in Windows Print from the application menu. Important The Windows printer driver can be used in the following versions of Windows. Windows 7 Windows 2000 (Professional or Server)
  • Page 13 Basic Printing Workflow (CS2436-1) Note If another printer is selected, select the printer you want to use under Select Printer or in the dialog box displayed after clicking Printer. Settings for many printing methods (including enlarged or reduced printing, borderless printing, and so on) are displayed in the printer driver dialog box.

  • Page 14: Registering The Printer

    Basic Printing Workflow (CS2436-1) 1. 1. 5. Basic Printing Workflow > Printing procedure > Printing in Mac OS X Print from the application menu after registering the printer. Important The Macintosh printer driver can be used in the following versions of Mac OS.
  • Page 15 Basic Printing Workflow (CS2436-1) Click Print to start printing. As shown in the following illustration, you can switch to other panes in this dialog box to complete settings for various methods of printing, including enlarged and reduced printing, borderless printing, and so on.

  • Page 16: Specifying Paper In The Printer Driver (Windows)

    Basic Printing Workflow (CS2436-1) 1. 1. 6. Basic Printing Workflow > Printing procedure > Specifying Paper in the Printer Driver (Windows) If you have replaced the paper, you must complete the following settings in the printer driver. Important Always specify the same type and size of paper in the printer menu and printer driver.
  • Page 17 Basic Printing Workflow (CS2436-1) Get Information button to display the Paper Information on Click the Printer dialog box. On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and configure printer driver settings for the feed source and type of paper.

  • Page 18: Specifying Paper In The Printer Driver (Mac Os X)

    Basic Printing Workflow (CS2436-1) 1. 1. 7. Basic Printing Workflow > Printing procedure > Specifying Paper in the Printer Driver (Mac OS X) If you have replaced the paper, you must complete the following settings in the printer driver. This sets the Format for and Paper Size.
  • Page 19 Basic Printing Workflow (CS2436-1) Printer list. Select the printer in the Paper Size list. Choose the original size in the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 20 Basic Printing Workflow (CS2436-1) In the Paper Source list, select how paper is supplied. If you have selected Manual in Paper Source, make sure the size as selected in Page Setup Page Size. If you have selected Roll Paper in...
  • Page 21 Basic Printing Workflow (CS2436-1) Note A variety of settings are available in the printer driver to suit different printing applications. For details on available printing conditions, see "Printer Driver Settings (5.1.1)"...

  • Page 22: Canceling Print Jobs From The Control Panel

    Basic Printing Workflow (CS2436-1) 1. 2. 1. Basic Printing Workflow > Canceling print jobs > Canceling Print Jobs from the Control Panel To cancel printing or reception of print jobs, press the Stop button on the Control Panel. When you press the Stop button during printing, printer operation varies depending on the current status.

  • Page 23: Canceling Print Jobs From Windows

    Basic Printing Workflow (CS2436-1) 1. 2. 2. Basic Printing Workflow > Canceling print jobs > Canceling Print Jobs from Windows In the printer window, you can cancel jobs that are being sent to the printer. Using Status Monitor, you can cancel print jobs that have already been received by the printer or that are currently being printed.
  • Page 24 Basic Printing Workflow (CS2436-1) Note The screen may differ slightly depending on the model you are using.

  • Page 25: Canceling Print Jobs From Mac Os X

    Basic Printing Workflow (CS2436-1) 1. 2. 3. Basic Printing Workflow > Canceling print jobs > Canceling Print Jobs from Mac OS X In the printer window, you can cancel jobs that are being sent to the printer. Otherwise, you can cancel jobs from Printmonitor if they have been received by the printer or are currently being printed.
  • Page 26 Basic Printing Workflow (CS2436-1) Select the print job to cancel and click to delete the print job.
  • Page 27 Basic Printing Workflow (CS2436-1) Note The screen may differ slightly depending on the model you are using. The job sent to the printer is canceled. Exit Printmonitor. In the printer window, click Start Jobs. Important Always follow these steps if you cancel print jobs from Printmonitor. If you...

  • Page 28: Pausing Printing

    Basic Printing Workflow (CS2436-1) 1. 3. 1. Basic Printing Workflow > Pausing Printing > Pausing Printing During printing, if you set Pause Print in the Control Panel menu to On, printing is stopped at that point and the printer enters a state in which printing is paused. (See "Control Panel Display (8.2.3).") Printing from the job queue is not possible in this state.

  • Page 29: Working With Various Print Jobs

    Working With Various Print Jobs (CS2436-2) 2. Working With Various Print Jobs 2. 1. Printing CAD Drawings Printing CAD Drawings Printing Line Drawings and Text Printing Line Drawings and Text (Windows) Printing Line Drawings and Text (Mac OS X) 2. 2. Printing Photos and Images...

  • Page 30: Printing Cad Drawings

    Working With Various Print Jobs (CS2436-2) 2. 1. 1. Working With Various Print Jobs > Printing CAD Drawings > Printing CAD Drawings Using this printer, you can print fine lines and text clearly and sharply. It's easy to produce highly precise drawings from CAD applications.

  • Page 31: Printing Line Drawings And Text

    Working With Various Print Jobs (CS2436-2) 2. 1. 2. Working With Various Print Jobs > Printing CAD Drawings > Printing Line Drawings and Text Printing is easy when you simply choose the type of original to print. Easy Settings Simply choose the printing application in the list for optimal printing results.
  • Page 32 Working With Various Print Jobs (CS2436-2) Choose this setting to print at high resolution when quality is most important. High Printing takes longer and consumes more ink than in Standard or Draft modes, but this mode offers exceptional printing quality.

  • Page 33: Printing Line Drawings And Text (Windows)

    Working With Various Print Jobs (CS2436-2) 2. 1. 3. Working With Various Print Jobs > Printing CAD Drawings > Printing Line Drawings and Text (Windows) This topic describes how to print line drawings based on the following example. Document: CAD drawing ●...
  • Page 34 Working With Various Print Jobs (CS2436-2) (Monochrome Line Drawing ) in the Print Target list. Note Print Target list by You can check the settings values selected in the View Settings. clicking Click the Page Setup tab to display the Page Setup sheet.
  • Page 35 Working With Various Print Jobs (CS2436-2)

  • Page 36: Printing Line Drawings And Text (Mac Os X)

    Working With Various Print Jobs (CS2436-2) 2. 1. 4. Working With Various Print Jobs > Printing CAD Drawings > Printing Line Drawings and Text (Mac OS X) This topic describes how to print line drawings based on the following example.
  • Page 37 Working With Various Print Jobs (CS2436-2) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click ISO A3. In the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 38 Working With Various Print Jobs (CS2436-2) Easy Settings is selected, click CAD (Color Line Drawing) or CAD After confirming that (Monochrome Line Drawing ) in the Print Target list. Note Print Target list by You can check the settings values selected in the clicking View set..
  • Page 39 Working With Various Print Jobs (CS2436-2) Page Size on the Page Setup pane shows the original size as specified in Paper Make sure Size in the Page Attributes dialog box—in this case, ISO A3.
  • Page 40 Working With Various Print Jobs (CS2436-2) Specify additional printing conditions. For details on available printing conditions, see "Printer Driver Settings (5.1.1)" Print to start printing. Confirm the print settings, and then click Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 41: Printing Photos And Images

    Working With Various Print Jobs (CS2436-2) 2. 2. 1. Working With Various Print Jobs > Printing Photos and Images > Printing Photos and Images Printing is easy when you simply choose the print target. Easy Settings Simply choose the printing application in the list for optimal printing results.
  • Page 42 Working With Various Print Jobs (CS2436-2) A setting for printing at the highest resolution when quality is most Highest important. Printing takes longer and consumes more ink than in other modes, but this mode offers superior printing quality. Choose this setting to print at high resolution when quality is most important.

  • Page 43: Printing Photos And Images (Windows)

    Working With Various Print Jobs (CS2436-2) 2. 2. 2. Working With Various Print Jobs > Printing Photos and Images > Printing Photos and Images (Windows) This topic describes how to print photos based on the following example. Document: Photo image from a digital camera ●...
  • Page 44 Working With Various Print Jobs (CS2436-2) Easy Settings is selected, click Photo (Color) in the Print Target list. After confirming that Note Print Target list by You can check the settings values selected in the View Settings. clicking Click the Page Setup tab to display the Page Setup sheet.
  • Page 45 Working With Various Print Jobs (CS2436-2) For instructions on confirming print settings, see "Confirming Print Settings (4.1.3)"...

  • Page 46: Printing Photos And Images (Mac Os X)

    Working With Various Print Jobs (CS2436-2) 2. 2. 3. Working With Various Print Jobs > Printing Photos and Images > Printing Photos and Images (Mac OS X) This topic describes how to print photos based on the following example. Document: Photo image from a digital camera ●...
  • Page 47 Working With Various Print Jobs (CS2436-2) Printer list. Select the printer in the Paper Size list, click the size of the original. In this case, click 10"x12". In the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 48 Working With Various Print Jobs (CS2436-2) Make sure the paper you select is loaded in the printer. Easy Settings is selected, click Photo (Color) in the Print Target list. After confirming that Note For information on settings optimized for printing photos and images, see "Printing Photos and Images (2.2.1)"...
  • Page 49 Working With Various Print Jobs (CS2436-2) If the width of the roll loaded in the printer is not shown in Roll Width, click Printer Information on the Main pane to update the printer information. Make sure Page Size on the Page Setup pane shows the original size as specified in Paper Size in the Page Attributes dialog box-in this case, 10"x12".
  • Page 50 Working With Various Print Jobs (CS2436-2) Specify additional printing conditions. For details on available printing conditions, see "Printer Driver Settings (5.1.1)" Print to start printing. Confirm the print settings, and then click Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 51: Printing Office Documents

    Working With Various Print Jobs (CS2436-2) 2. 3. 1. Working With Various Print Jobs > Printing Office Documents > Printing Office Documents Printing is easy when you simply choose the type of original to print. Easy Settings Simply choose the printing application in the list for optimal printing results.
  • Page 52 Working With Various Print Jobs (CS2436-2) For instructions on printing office documents, refer to the following topics, as appropriate for your computer and operating system. Printing Office Documents (Windows) (2.3.2) ● Printing Office Documents (Mac OS X) (2.3.3) ●...

  • Page 53: Printing Office Documents (Windows)

    Working With Various Print Jobs (CS2436-2) 2. 3. 2. Working With Various Print Jobs > Printing Office Documents > Printing Office Documents (Windows) This topic describes how to print office documents based on the following example. Document: Office document created using word-processing or spreadsheet programs ●...
  • Page 54 Working With Various Print Jobs (CS2436-2) Note You can check the settings values selected in the Print Target list by clicking View Settings. Click the Page Setup tab to display the Page Setup sheet. In the Page Size list, click the size of the original as specified in the application. In this case, click ISO A4.
  • Page 55 Working With Various Print Jobs (CS2436-2) For tips on confirming print settings, see "Confirming Print Settings (4.1.3)"...

  • Page 56: Printing Office Documents (Mac Os X)

    Working With Various Print Jobs (CS2436-2) 2. 3. 3. Working With Various Print Jobs > Printing Office Documents > Printing Office Documents (Mac OS X) This topic describes how to print office documents based on the following example. Document: Office document created using word-processing or spreadsheet programs ●...
  • Page 57 Working With Various Print Jobs (CS2436-2) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click ISO A4 - for Paper Tray In the (Large Margins). If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 58 Working With Various Print Jobs (CS2436-2) Paper. After confirming that Easy Settings is selected, click Office Document in the Print Target list. Note You can check the settings values selected in the Print Target list by clicking View set.. Print Quality list.
  • Page 59 Working With Various Print Jobs (CS2436-2) Specify additional printing conditions. For details on available printing conditions, see "Printer Driver Settings (5.1.1)" Confirm the print settings, and then click Print to start printing. Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 60: Enhanced Printing Options

    Enhanced Printing Options (CS2436-3) 3. Enhanced Printing Options 3. 1. Adjusting Images Adjusting the Color in the Printer Driver Fine-Tuning Colors of Photos and Images (Windows) Fine-Tuning Colors of Photos and Images (Mac OS X) Giving Priority to Particular Graphic Elements and Colors for Printing...
  • Page 61 Enhanced Printing Options (CS2436-3) Borderless Printing by Resizing Originals to Fit the Roll Width (Mac OS X) Borderless Printing at Actual Size Borderless Printing at Actual Size (Windows) Borderless Printing at Actual Size (Mac OS X) 3. 6. Printing banners or at other non-standard sizes Printing Vertical or Horizontal Banners (Large-Format Printing) Printing Vertical or Horizontal Banners (Large-Format Printing;...
  • Page 62 Enhanced Printing Options (CS2436-3) Using Favorites (Mac OS X) Cutting Roll Paper After Printing (Windows) Cutting Roll Paper After Printing (Mac OS X)

  • Page 63: Adjusting The Color In The Printer Driver

    Enhanced Printing Options (CS2436-3) 3. 1. 1. Enhanced Printing Options > Adjusting Images > Adjusting the Color in the Printer Driver Color settings specified in the application for your documents are essentially given priority over other settings for each print job, but further color adjustment is possible in the printer driver.
  • Page 64 Enhanced Printing Options (CS2436-3) Adjust the contrast of the darkest and lightest portions relative to each other. Contrast For soft gradation, decrease the contrast. For hard gradation, increase the contrast. Adjust the level of color saturation, in a range from subdued Saturation to vivid.
  • Page 65 Enhanced Printing Options (CS2436-3) Choose this option for color-matching by the software application or with your own color Off (No Adjustment) No color-matching profile, when you want to disable color- matching by the printer driver. Matching Method Description Remarks Color-matching...
  • Page 66 Enhanced Printing Options (CS2436-3) Fine-Tuning Colors of Photos and Images (Windows) (3.1.2) ● Fine-Tuning Colors of Photos and Images (Mac OS X) (3.1.3) ●...

  • Page 67: Fine-Tuning Colors Of Photos And Images (Windows)

    Enhanced Printing Options (CS2436-3) 3. 1. 2. Enhanced Printing Options > Adjusting Images > Fine-Tuning Colors of Photos and Images (Windows) You can specify your own print settings instead of using the Print Target presets. This topic describes how to fine-tune the color tone of photos before printing.
  • Page 68 Enhanced Printing Options (CS2436-3) Click Color in the Color Mode list. Click Color Settings to display the Color Settings dialog box.
  • Page 69 Enhanced Printing Options (CS2436-3) On the Color Adjustment sheet, adjust the color tones, brightness, and so on as desired. Adjustment Item Description Cyan Fine-tune color tones by adjusting the levels of Cyan, Magenta Magenta, and Yellow. Yellow Adjust the gray tone to suit the images of monochrome photos.
  • Page 70 Enhanced Printing Options (CS2436-3) Note Click Object Adjustment to open the Object Adjustment dialog box, which allows you to select the color adjustment target from Image, Graphics, and Text. Close the Color Settings dialog box. Click the Page Setup tab to display the Page Setup sheet.

  • Page 71: Fine-Tuning Colors Of Photos And Images (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 1. 3. Enhanced Printing Options > Adjusting Images > Fine-Tuning Colors of Photos and Images (Mac OS X) You can specify your own print settings instead of using the Print Target presets. This topic describes how to fine-tune the color tone of photos before printing.
  • Page 72 Enhanced Printing Options (CS2436-3) Printer list. Select the printer in the Paper Size list. Choose the original size in the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 73 Enhanced Printing Options (CS2436-3) Advanced Settings to switch the print mode. Click Click Color in the Color Mode list. Set to display the Color Settings dialog box. Click...
  • Page 74 Enhanced Printing Options (CS2436-3) On the Color Adjustment pane, adjust the color tones, brightness, and so on as desired. Adjustment Item Description Cyan Fine-tune color tones by adjusting the levels of Cyan, Magenta Magenta, and Yellow. Yellow Adjust the gray tone to suit the images of monochrome photos.
  • Page 75 Enhanced Printing Options (CS2436-3) Adjust the level of color saturation, in a range from Saturation subdued to vivid. Note Click Object Adjustment to open the Object Adjustment dialog box, which allows you to select the color adjustment target from Images, Graphics, and Text.

  • Page 76: Print Quality

    Enhanced Printing Options (CS2436-3) 3. 1. 4. Enhanced Printing Options > Adjusting Images > Giving Priority to Particular Graphic Elements and Colors for Printing You can specify detailed print settings as desired for the quality level, colors, and other criteria.
  • Page 77 Enhanced Printing Options (CS2436-3) A setting for printing at the highest resolution when quality is most important. Printing takes longer and Highest Image consumes more ink than in other modes, but this mode offers superior printing quality. Choose this setting to print at high resolution when quality is most important.

  • Page 78: Enhancing Printing Quality

    Enhanced Printing Options (CS2436-3) options. (In Windows and Mac OS X 10.5 only.) Driver Matching Mode ICC Matching Mode Choose the color-matching Driver ICM Mode mode. Other color- Host ICM Mode matching modes may be Color-Matching Modes ColorSync (Mac OS provided by the computer 10.3.9-10.4)
  • Page 79 Enhanced Printing Options (CS2436-3) Choosing the Document Type and Printing Conditions (Mac OS X) (3.1.6) ●...

  • Page 80: Choosing The Document Type And Printing Conditions (Windows)

    Enhanced Printing Options (CS2436-3) 3. 1. 5. Enhanced Printing Options > Adjusting Images > Choosing the Document Type and Printing Conditions (Windows) You can specify your own print settings instead of using the Print Target presets. As an example, this topic describes how to print CAD drawings as clearly as possible, with sharp lines and text.
  • Page 81 Enhanced Printing Options (CS2436-3) Click Line Drawing/Text in the Print Priority list. Click High (1200dpi) in the Print Quality list. Note Print Quality list vary depending on the paper Options displayed in the type. Click Color (CAD) in the Color Mode list.
  • Page 82 Enhanced Printing Options (CS2436-3) Page Size, Paper Source, and so on. Confirm the settings of Confirm the print settings and print as desired. Note For tips on confirming print settings, see "Confirming Print Settings (4.1.3)"...
  • Page 83 Enhanced Printing Options (CS2436-3) 3. 1. 6. Enhanced Printing Options > Adjusting Images > Choosing the Document Type and Printing Conditions (Mac OS You can specify your own print settings instead of using the Print Target presets. As an example, this topic describes how to print CAD drawings as clearly as possible, with sharp lines and text.
  • Page 84 Enhanced Printing Options (CS2436-3) Printer list. Select the printer in the Choose the original size in the Paper Size list. If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 85 Enhanced Printing Options (CS2436-3) Advanced Settings to switch the print mode. Click Click Line Drawing in the Print Priority list. Click High(1200dpi) in the Print Quality list. Note Print Quality list vary depending on the type of Options displayed in the paper.
  • Page 86 Enhanced Printing Options (CS2436-3) Paper Source and Page Size. Confirm the settings of Confirm the print settings, and then click Print to start printing. Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 87: Choosing A Paper For Printing

    Enhanced Printing Options (CS2436-3) 3. 2. 1. Enhanced Printing Options > Choosing Paper for Printing > Choosing a Paper for Printing Choosing the right paper for your particular printing application will give you the best printing results. Media Type The printer and printer driver offer print settings optimized for various paper characteristics.

  • Page 88: Changing The Type Of Paper

    Enhanced Printing Options (CS2436-3) 3. 2. 2. Enhanced Printing Options > Choosing Paper for Printing > Changing the Type of Paper Follow these steps to change the type of paper specified on the printer after you have loaded paper. If you will continue using this type of paper later, selecting Keep Paper Type >On will save the time and effort of configuring the media type setting when you load the paper again.
  • Page 89 Enhanced Printing Options (CS2436-3) Press to select the type of paper loaded ( Roll Paper or Cut Sheet ), and then press the OK button. to select the type of paper loaded in the printer, and then press the OK button.
  • Page 90 Enhanced Printing Options (CS2436-3)

  • Page 91: Specifying Paper In The Printer Driver

    Enhanced Printing Options (CS2436-3) 3. 2. 3. Enhanced Printing Options > Choosing Paper for Printing > Specifying Paper in the Printer Driver If you replace the paper, complete the printer driver settings for the paper type and size. For instructions on configuring paper settings in the printer driver, refer to the following topics, as appropriate for your computer and operating system.
  • Page 92 Enhanced Printing Options (CS2436-3) 3. 2. 4. Enhanced Printing Options > Choosing Paper for Printing > Specifying Paper in the Printer Driver (Windows) If you have replaced the paper, you must complete the following settings in the printer driver. Important Always specify the same type and size of paper in the printer menu and printer driver.
  • Page 93 Enhanced Printing Options (CS2436-3) Click the Get Information button to display the Paper Information on Printer dialog box. On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and configure printer driver settings for the feed source and type of paper.
  • Page 94 Enhanced Printing Options (CS2436-3) 3. 2. 5. Enhanced Printing Options > Choosing Paper for Printing > Specifying Paper in the Printer Driver (Mac OS X) If you have replaced the paper, you must complete the following settings in the printer driver.
  • Page 95 Enhanced Printing Options (CS2436-3) Printer list. Select the printer in the Paper Size list. Choose the original size in the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 96 Enhanced Printing Options (CS2436-3) In the Paper Source list, select how paper is supplied. If you have selected Manual in Paper Source, make sure the size as selected in Page Setup Page Size. If you have selected Roll Paper in...
  • Page 97 Enhanced Printing Options (CS2436-3) Note A variety of settings are available in the printer driver to suit different printing applications. For details on available printing conditions, see "Printer Driver Settings (5.1.1)"...

  • Page 98: Resizing Originals To Match The Paper Size

    Enhanced Printing Options (CS2436-3) 3. 3. 1. Enhanced Printing Options > Printing enlargements or reductions > Resizing Originals to Match the Paper Size You can freely adjust the size of originals by enlarging or reducing them as desired. Enlarged/Reduced Printing Enlarge or reduce the original in the printer driver, as desired.

  • Page 99: Resizing Originals To Match The Paper Size (Windows)

    Enhanced Printing Options (CS2436-3) 3. 3. 2. Enhanced Printing Options > Printing enlargements or reductions > Resizing Originals to Match the Paper Size (Windows) This topic describes how to enlarge originals before printing to match the paper size, based on the following example.
  • Page 100 Enhanced Printing Options (CS2436-3) Click the Page Setup tab to display the Page Setup sheet. Click Roll Paper in the Paper Source list. Roll Paper Width list-in this case, ISO A2/A3 Roll Select the width of the loaded roll in the (420.0mm).

  • Page 101: Resizing Originals To Match The Paper Size (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 3. 3. Enhanced Printing Options > Printing enlargements or reductions > Resizing Originals to Match the Paper Size (Mac OS X) This topic describes how to enlarge originals before printing to match the paper size, based on the following example.
  • Page 102 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click ISO A4. In the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 103 Enhanced Printing Options (CS2436-3) Print Target list. Make your selection in the Print Quality list. Make your selection in the Access the Page Setup pane. Click Roll Paper in the Paper Source list. Roll Width list-in this case, ISO A2/ Make sure the width of the loaded roll is displayed in the A3 (420.0mm).
  • Page 104 Enhanced Printing Options (CS2436-3) Page Size on the Page Setup pane shows the original size as specified in Paper Make sure Size in the Page Attributes dialog box-in this case, ISO A4.
  • Page 105 Enhanced Printing Options (CS2436-3) Select the Enlarged/Reduced Printing check box. Fit Paper Size is selected. Make sure Click ISO A3 in the Paper Size list. Confirm the print settings, and then click Print to start printing. Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 106: Resizing Originals To Fit The Roll Width

    Enhanced Printing Options (CS2436-3) 3. 3. 4. Enhanced Printing Options > Printing enlargements or reductions > Resizing Originals to Fit the Roll Width You can freely adjust the size of originals by enlarging or reducing them as desired. Enlarged/Reduced Printing Enlarge or reduce the original in the printer driver, as desired.

  • Page 107: Resizing Originals To Fit The Roll Width (Windows)

    Enhanced Printing Options (CS2436-3) 3. 3. 5. Enhanced Printing Options > Printing enlargements or reductions > Resizing Originals to Fit the Roll Width (Windows) This topic describes how to enlarge originals before printing to match the roll width, based on the following example.
  • Page 108 Enhanced Printing Options (CS2436-3) Click the Page Setup tab to display the Page Setup sheet. Click Roll Paper in the Paper Source list. Page Size list, click the size of the original as specified in the application. In this case, In the click ISO A4 or Letter (8.5"x11").
  • Page 109 Enhanced Printing Options (CS2436-3) Fit Roll Paper Width. Click Note Fit Roll Paper Width, the Information dialog box is After you click displayed. Select the width of the loaded roll in the Roll Paper Width list and click OK. Make sure the roll paper width you specify matches the width of the loaded roll.

  • Page 110: Resizing Originals To Fit The Roll Width (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 3. 6. Enhanced Printing Options > Printing enlargements or reductions > Resizing Originals to Fit the Roll Width (Mac OS X) This topic describes how to enlarge originals before printing to match the roll width, based on the following example.
  • Page 111 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click ISO A4. In the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 112 Enhanced Printing Options (CS2436-3) Print Target list. Make your selection in the Print Quality list. Make your selection in the Access the Page Setup pane. Click Roll Paper in the Paper Source list. Roll Width list-in this case, 16 in.
  • Page 113 Enhanced Printing Options (CS2436-3) Enlarged/Reduced Printing check box. Select the Click Fit Roll Paper Width. Print to start printing. Confirm the print settings, and then click Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 114: Resizing Originals By Entering A Scaling Value

    Enhanced Printing Options (CS2436-3) 3. 3. 7. Enhanced Printing Options > Printing enlargements or reductions > Resizing Originals by Entering a Scaling Value You can freely adjust the size of originals by enlarging or reducing them as desired. Enlarged/Reduced Printing Enlarge or reduce the original in the printer driver, as desired.

  • Page 115: Resizing Originals By Entering A Scaling Value (Windows)

    Enhanced Printing Options (CS2436-3) 3. 3. 8. Enhanced Printing Options > Printing enlargements or reductions > Resizing Originals by Entering a Scaling Value (Windows) This topic describes how to enlarge originals before printing by entering a scaling value, based on the following example.
  • Page 116 Enhanced Printing Options (CS2436-3) In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Select the printing application in the Print Target list. Click the Page Setup tab to display the Page Setup sheet.
  • Page 117 Enhanced Printing Options (CS2436-3) You can specify enlargement that exceeds the paper size, but in this case, the portions off the bottom and right edges of the paper will not be printed. If the original size after enlargement or reduction is smaller than the paper size, the original is printed in the upper-left corner.

  • Page 118: Resizing Originals By Entering A Scaling Value (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 3. 9. Enhanced Printing Options > Printing enlargements or reductions > Resizing Originals by Entering a Scaling Value (Mac OS X) This topic describes how to enlarge originals before printing by entering a scaling value, based on the following example.
  • Page 119 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click ISO A4. In the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 120 Enhanced Printing Options (CS2436-3) Print Target list. Make your selection in the Print Quality list. Make your selection in the Access the Page Setup pane. Click Roll Paper in the Paper Source list. Roll Width list-in this case, ISO A2/ Make sure the width of the loaded roll is displayed in the A3 (420.0mm).
  • Page 121 Enhanced Printing Options (CS2436-3) Page Size setting matches the original size as selected in Paper Size in the Make sure the Page Attributes dialog box—in this case, ISO A4.
  • Page 122 Enhanced Printing Options (CS2436-3) Select the Enlarged/Reduced Printing check box. Scaling and enter 120. Click Note You can specify enlargement that exceeds the paper size, but in this case, the portion off the edge of the paper will not be printed.

  • Page 123: Printing On Oversized Paper

    Enhanced Printing Options (CS2436-3) 3. 4. 1. Enhanced Printing Options > Printing at full size > Printing on Oversized Paper Except in borderless printing, the actual printing area corresponds to your selected paper size minus the space for a margin. (See "Print Area (8.4.2)") To print documents or images you prepare without a margin at actual size, use an oversized paper size.
  • Page 124 Enhanced Printing Options (CS2436-3) Paper larger than the maximum size supported by the printer cannot be used as paper for oversized printing.(See "Paper Sizes (6.1.2)") To specify a non-standard paper size in oversized printing, register the paper size as a Custom Paper Size. Oversized printing is not available with Custom Size.

  • Page 125: Printing At Full Size (Windows)

    Enhanced Printing Options (CS2436-3) 3. 4. 2. Enhanced Printing Options > Printing at full size > Printing at Full Size (Windows) This topic describes how to print at full size based on the following example. (Oversized Printing) Document: Any Type ●...
  • Page 126 Enhanced Printing Options (CS2436-3) Size Options to display the Paper Size Options dialog box. Click In the Paper Size Options dialog box, select the Oversize check box in Display Series. Click OK to close the Paper Size Options dialog box.

  • Page 127: Printing At Full Size (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 4. 3. Enhanced Printing Options > Printing at full size > Printing at Full Size (Mac OS X) This topic describes how to print at full size based on the following example. (Oversized Printing) Document: Any Type ●...
  • Page 128 Enhanced Printing Options (CS2436-3) Printer list. Select the printer in the Paper Size, click the size of the original. In this case, click ISO A4 - Oversize. If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 129 Enhanced Printing Options (CS2436-3) Print Target list. Make your selection in the Print Quality list. Make your selection in the Access the Page Setup pane. Click Roll Paper in the Paper Source list. Roll Width list-in this case, ISO A2/ Make sure the width of the loaded roll is displayed in the A3 (420.0mm).
  • Page 130 Enhanced Printing Options (CS2436-3) Page Size shows the original size as specified in Paper Size in the Page Make sure Attributes dialog box—in this case, ISO A4 - Oversize.
  • Page 131 Enhanced Printing Options (CS2436-3) Confirm the print settings, and then click Print to start printing. Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 132: Borderless Printing At Actual Size

    Enhanced Printing Options (CS2436-3) 3. 4. 4. Enhanced Printing Options > Printing at full size > Borderless Printing at Actual Size Take advantage of borderless printing to print documents such as posters (made up mainly of photos or images) without a surrounding margin, or border.
  • Page 133 Enhanced Printing Options (CS2436-3) Note Not all page sizes are available. Even if you prepare originals of the same size as the paper size, the originals are automatically enlarged when you print borderlessly in combination with resizing originals to match the paper size. This may affect image quality. When image quality is most important, make the original 3 mm longer on each side than the paper size so that the image can be printed at actual size in borderless printing.
  • Page 134 Enhanced Printing Options (CS2436-3) 3. 4. 5. Enhanced Printing Options > Printing at full size > Borderless Printing at Actual Size (Windows) This topic describes how to print borderlessly at actual size based on the following example. Document: Any type ●...
  • Page 135 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Heavyweight In the Coated Paper. Print Target list. Select the print target in the Click the Page Setup tab to display the Page Setup sheet.
  • Page 136 Enhanced Printing Options (CS2436-3) Page Size list, click the size of the original as specified in the source application. In this In the case, click 10"x12". Click Roll Paper in the Paper Source list. Borderless Printing check box to display the Information dialog box.
  • Page 137 Enhanced Printing Options (CS2436-3) Select the width of the loaded roll in the Roll Paper Width list-in this case, click 10-in. Roll (254.0mm). Click OK to close the Information dialog box. Borderless Printing Method, click Print Image with Actual Size.
  • Page 138 Enhanced Printing Options (CS2436-3) 3. 4. 6. Enhanced Printing Options > Printing at full size > Borderless Printing at Actual Size (Mac OS X) This topic describes how to print borderlessly at actual size based on the following example. Document: Any Type ●...
  • Page 139 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list, choose a paper size supported for borderless printing. Here, click In the 10"x12" - Borderless. Note Paper sizes supported for borderless printing are indicated by -Borderless.
  • Page 140 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Heavyweight In the Coated Paper. Print Target list. Make your selection in the Make your selection in the Print Quality list.
  • Page 141 Enhanced Printing Options (CS2436-3) Click Roll Paper in the Paper Source list. Confirm that the roll paper width matches the paper size. Roll Width list-in this case, 10 in. Make sure the width of the loaded roll is displayed in the (254.0mm).
  • Page 142 Enhanced Printing Options (CS2436-3) Make sure the Page Size setting matches the original size as selected in Paper Size in the Page Attributes dialog box—in this case, 10"x12" - Borderless.
  • Page 143 Enhanced Printing Options (CS2436-3) Confirm the print settings, and then click Print to start printing. Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 144: Borderless Printing On Paper Of Equivalent Size

    Enhanced Printing Options (CS2436-3) 3. 5. 1. Enhanced Printing Options > Borderless Printing > Borderless Printing on Paper of Equivalent Size Take advantage of borderless printing to print documents such as posters (made up mainly of photos or images) without a surrounding margin, or border.
  • Page 145 Enhanced Printing Options (CS2436-3) Note The printer driver automatically enlarges originals 3 mm (0.12 in) past the dimensions of the paper on each side. The 3 mm portion beyond the edge on each side is not printed. For instructions on borderless printing of photos, images, and other documents to match the paper size, refer to the following topics, as appropriate for your computer and operating system.

  • Page 146: Borderless Printing By Resizing Originals To Match The Paper Size (Windows)

    Enhanced Printing Options (CS2436-3) 3. 5. 2. Enhanced Printing Options > Borderless Printing > Borderless Printing by Resizing Originals to Match the Paper Size (Windows) This topic describes how to enlarge originals before borderless printing to match the paper size, based on the following example.
  • Page 147 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Heavyweight In the Coated Paper. Print Target list. Select the print target in the Click the Page Setup tab to display the Page Setup sheet.
  • Page 148 Enhanced Printing Options (CS2436-3) Page Size list, click the size of the original as specified in the application. In this case, In the click 10"x12". Click Roll Paper in the Paper Source list. Borderless Printing check box to display the Information dialog box.
  • Page 149 Enhanced Printing Options (CS2436-3) Select the width of the loaded roll in the Roll Paper Width list-in this case, click 10-in. Roll (254.0mm). Click OK to close the Information dialog box. Borderless Printing Method, click Fit Paper Size. Click Match Page Size in the Paper Size list.

  • Page 150: Borderless Printing By Resizing Originals To Match The Paper Size (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 5. 3. Enhanced Printing Options > Borderless Printing > Borderless Printing by Resizing Originals to Match the Paper Size (Mac OS X) This topic describes how to enlarge originals before borderless printing to match the paper size, based on the following example.
  • Page 151 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click 10"x12". In the Note All sizes are available in borderless printing if you resize originals to match the paper size.
  • Page 152 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Heavyweight In the Coated Paper. Print Target list. Make your selection in the Make your selection in the Print Quality list.
  • Page 153 Enhanced Printing Options (CS2436-3) Click Roll Paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list-in this case, 10 in. (254.0mm). Note If the width of the roll loaded in the printer is not shown in...
  • Page 154 Enhanced Printing Options (CS2436-3) Page Size setting matches the original size as selected in Paper Size in the Make sure the Page Attributes dialog box-in this case, 10"x12".
  • Page 155 Enhanced Printing Options (CS2436-3) On the Page Setup pane, select the Enlarged/Reduced Printing check box. Borderless Printing check box. Select the Fit Paper Size under Enlarged/Reduced Printing. Click Paper Size, click the paper size. In this case, click 10"x12" - Borderless.

  • Page 156: Borderless Printing By Resizing Originals To Fit The Roll Width

    Enhanced Printing Options (CS2436-3) 3. 5. 4. Enhanced Printing Options > Borderless Printing > Borderless Printing by Resizing Originals to Fit the Roll Width Take advantage of borderless printing to print documents such as posters (made up mainly of photos or images) without a surrounding margin, or border.
  • Page 157 Enhanced Printing Options (CS2436-3) Note You can combine this function with rotating pages 90 degrees before printing so that the original width (relative to portrait orientation) matches the roll paper width in borderless printing. For instructions on borderless printing of photos, images, and other documents to match the roll paper width, refer to the following topics, as appropriate for your computer and operating system.
  • Page 158 Enhanced Printing Options (CS2436-3) 3. 5. 5. Enhanced Printing Options > Borderless Printing > Borderless Printing by Resizing Originals to Fit the Roll Width (Windows) This topic describes how to enlarge originals before borderless printing to match the roll width, based on the following example.
  • Page 159 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Heavyweight In the Coated Paper. Print Target list. Select the print target in the Click the Page Setup tab to display the Page Setup sheet.
  • Page 160 Enhanced Printing Options (CS2436-3) Page Size list, click the size of the original as specified in the application. In this case, In the click ISO A4 or Letter (8.5"x11"). Click Roll Paper in the Paper Source list. Borderless Printing check box to display the Information dialog box.
  • Page 161 Enhanced Printing Options (CS2436-3) Select the width of the loaded roll in the Roll Paper Width list-in this case, click 10-in. Roll (254.0mm). Click OK to close the Information dialog box. Borderless Printing Method, make sure Scale to fit Roll Paper Width is selected.

  • Page 162: Mac Os X

    Enhanced Printing Options (CS2436-3) 3. 5. 6. Enhanced Printing Options > Borderless Printing > Borderless Printing by Resizing Originals to Fit the Roll Width (Mac OS X) This topic describes how to enlarge originals before borderless printing to match the roll width, based on the following example.
  • Page 163 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click ISO A4. In the Note All sizes are available in borderless printing if you resize originals to fit the roll width.
  • Page 164 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Heavyweight In the Coated Paper. Print Target list. Make your selection in the Make your selection in the Print Quality list.
  • Page 165 Enhanced Printing Options (CS2436-3) Click Roll Paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list-in this case, 10 in. (254.0mm). Note If the width of the roll loaded in the printer is not shown in...
  • Page 166 Enhanced Printing Options (CS2436-3) Page Size setting matches the original size as selected in Paper Size in the Make sure the Page Attributes dialog box—in this case, ISO A4.
  • Page 167 Enhanced Printing Options (CS2436-3) Select the Enlarged/Reduced Printing check box. Borderless Printing check box. Select the Fit Roll Paper Width is automatically selected in Enlarged/Reduced This ensures that Printing. Print to start printing. Confirm the print settings, and then click Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...
  • Page 168 Enhanced Printing Options (CS2436-3) 3. 5. 7. Enhanced Printing Options > Borderless Printing > Borderless Printing at Actual Size Take advantage of borderless printing to print documents such as posters (made up mainly of photos or images) without a surrounding margin, or border.
  • Page 169 Enhanced Printing Options (CS2436-3) Note Not all page sizes are available. Even if you prepare originals of the same size as the paper size, the originals are automatically enlarged when you print borderlessly in combination with resizing originals to match the paper size. This may affect image quality. When image quality is most important, make the original 3 mm longer on each side than the paper size so that the image can be printed at actual size in borderless printing.
  • Page 170 Enhanced Printing Options (CS2436-3) 3. 5. 8. Enhanced Printing Options > Borderless Printing > Borderless Printing at Actual Size (Windows) This topic describes how to print borderlessly at actual size based on the following example. Document: Any type ● Page size: 10×12 inches (254.0×304.8 mm) ●...
  • Page 171 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Heavyweight In the Coated Paper. Print Target list. Select the print target in the Click the Page Setup tab to display the Page Setup sheet.
  • Page 172 Enhanced Printing Options (CS2436-3) Page Size list, click the size of the original as specified in the source application. In this In the case, click 10"x12". Click Roll Paper in the Paper Source list. Borderless Printing check box to display the Information dialog box.
  • Page 173 Enhanced Printing Options (CS2436-3) Select the width of the loaded roll in the Roll Paper Width list-in this case, click 10-in. Roll (254.0mm). Click OK to close the Information dialog box. Borderless Printing Method, click Print Image with Actual Size.
  • Page 174 Enhanced Printing Options (CS2436-3) 3. 5. 9. Enhanced Printing Options > Borderless Printing > Borderless Printing at Actual Size (Mac OS X) This topic describes how to print borderlessly at actual size based on the following example. Document: Any Type ●...
  • Page 175 Enhanced Printing Options (CS2436-3) Printer list. Select the printer in the In the Paper Size list, choose a paper size supported for borderless printing. Here, click 10"x12" - Borderless. Note Paper sizes supported for borderless printing are indicated by -Borderless.
  • Page 176 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Heavyweight In the Coated Paper. Print Target list. Make your selection in the Make your selection in the Print Quality list.
  • Page 177 Enhanced Printing Options (CS2436-3) Click Roll Paper in the Paper Source list. Confirm that the roll paper width matches the paper size. Roll Width list-in this case, 10 in. Make sure the width of the loaded roll is displayed in the (254.0mm).
  • Page 178 Enhanced Printing Options (CS2436-3) Page Size setting matches the original size as selected in Paper Size in the Make sure the Page Attributes dialog box—in this case, 10"x12" - Borderless.
  • Page 179 Enhanced Printing Options (CS2436-3) Confirm the print settings, and then click Print to start printing. Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...
  • Page 180 Enhanced Printing Options (CS2436-3) 3. 6. 1. Enhanced Printing Options > Printing banners or at other non-standard sizes > Printing Vertical or Horizontal Banners (Large-Format Printing) You can create vertical or horizontal banners by printing originals that are in banner format on rolls.
  • Page 181 Enhanced Printing Options (CS2436-3) Before printing, check how much of the roll paper is left. If you have activated automatic detection of the remaining roll paper, a warning message is displayed when there is not enough roll paper left. If not much ink is left, prepare replacement ink tanks.
  • Page 182 Enhanced Printing Options (CS2436-3) 3. 6. 2. Enhanced Printing Options > Printing banners or at other non-standard sizes > Printing Vertical or Horizontal Banners (Large-Format Printing; Windows) This topic describes how to print a banner about five times as long as the roll width based on the following example.

  • Page 183: Creating The Banner In The Application

    Enhanced Printing Options (CS2436-3) Click Roll Paper in the Paper Source list. Size Options to display the Paper Size Options dialog box. Click Enter a desired paper name in Custom Paper Size Name. My Horizontal Banner is used in this example.

  • Page 184: Printing The Banner

    Enhanced Printing Options (CS2436-3) Start Microsoft Word. Choose Page Setup from the File menu to display the Page Setup dialog box. Under Paper Size, click the Custom Paper Size you registered-My Horizontal Banner in this example. Important If My Horizontal Banner is not listed, make sure this printer is selected as the printer to use.
  • Page 185 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. In the After confirming that Easy Settings is selected, click Poster in the Print Target list. Click the Page Setup tab to display the Page Setup sheet.
  • Page 186 Enhanced Printing Options (CS2436-3) Page Size list, click the size you registered, My Horizontal Banner. In the Enlarged/Reduced Printing check box. Select the Note If the Enlarged/Reduced Printing check box is not displayed on the Page Setup sheet, clear the...
  • Page 187 Enhanced Printing Options (CS2436-3) Click Roll Paper in the Paper Source list. After you click Fit Roll Paper Width, the Information dialog box is displayed. Select the width of the loaded roll in the Roll Paper Width list. In this case, click 16-in. Roll (406.4mm), and then click OK.
  • Page 188 Enhanced Printing Options (CS2436-3) In the FineZoom Settings list, click Yes.
  • Page 189 Enhanced Printing Options (CS2436-3) 3. 6. 3. Enhanced Printing Options > Printing banners or at other non-standard sizes > Printing Vertical or Horizontal Banners (Large-Format Printing; Mac OS X) This topic describes how to print a banner about five times as long as the roll width based on the following example.
  • Page 190 Enhanced Printing Options (CS2436-3) Select the printer in the Format for list. Click Manage Custom Sizes in the Paper Size list to display the Custom Page Sizes dialog box.
  • Page 191 Enhanced Printing Options (CS2436-3) Double-click Untitled in the list at left, and then enter a name for the page size you want to register. Here, enter 100*500. If the Untitled size is not listed at left, click + below the list.
  • Page 192 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. In the Print Target list. Make your selection in the Make your selection in the Print Quality list. Access the Page Setup pane.
  • Page 193 Enhanced Printing Options (CS2436-3) Click Roll Paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list-in this case, 16 in. (406.4mm). Note If the width of the loaded roll is not displayed in Roll Width, click Printer Information on the Main pane and update the printer information.
  • Page 194 Enhanced Printing Options (CS2436-3) Page Size, make sure 100*500 is displayed, as registered in Page Setup. Select the Enlarged/Reduced Printing check box. Fit Roll Paper Width. Click Confirm the print settings, and click Print to start printing. Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 195: Printing On Non-Standard Paper Sizes

    Enhanced Printing Options (CS2436-3) 3. 6. 4. Enhanced Printing Options > Printing banners or at other non-standard sizes > Printing on Non-Standard Paper Sizes By specifying the paper size, you can print on non-standard sizes of paper. There are two ways to print on non-standard paper sizes, as follows.

  • Page 196: Printing On Non-Standard Paper Sizes (Windows)

    Enhanced Printing Options (CS2436-3) 3. 6. 5. Enhanced Printing Options > Printing banners or at other non-standard sizes > Printing on Non-Standard Paper Sizes (Windows) This topic describes two ways to print on non-standard paper sizes. Printing by using Custom Size ●...
  • Page 197 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In the After confirming that Easy Settings is selected, select from the Print Target list. Click the Page Setup tab to display the Page Setup sheet.
  • Page 198 Enhanced Printing Options (CS2436-3) Click Manual in the Paper Source list. Click Custom Size in the Page Size list to display the Custom Size Settings dialog box. Confirm that mm is selected in Units. Enter 430 (16.9 in) in both Width and Height.
  • Page 199 Enhanced Printing Options (CS2436-3) Paper Size: A square sheet (430 × 430 mm [16.9 × 16.9 in]) ● Load the square paper (430 × 430 mm [16.9 × 16.9 in]) in the printer. Choose Print in the application menu. Select the printer in the dialog box, and then display the printer driver dialog box.(See "Accessing the Printer Driver Dialog Box from Applications (4.1.6)")
  • Page 200 Enhanced Printing Options (CS2436-3) Size Options to display the Paper Size Options dialog box. Click Enter a desired paper name in Custom Paper Size Name. 430 mm Square is used in this example. Select mm in Units. Enter 430 (16.9 in) in both Width and Height.
  • Page 201 Enhanced Printing Options (CS2436-3) For tips on confirming print settings, see "Confirming Print Settings (4.1.3)"...

  • Page 202: Printing On Non-Standard Paper Sizes (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 6. 6. Enhanced Printing Options > Printing banners or at other non-standard sizes > Printing on Non-Standard Paper Sizes (Mac OS X) This section describes how to register and print Custom Page Sizes based on the following example.
  • Page 203 Enhanced Printing Options (CS2436-3) If it is not displayed, the settings are configured in the upper part of the printer driver displayed when you select Print from the application software menu. Printer list. Select the printer in the Click Manage Custom Sizes in the Paper Size list to display the Custom Page Sizes dialog box.
  • Page 204 Enhanced Printing Options (CS2436-3) In Page Size, enter the height and width of the original. Here, enter 43.00 cm in Height and Width. In Printer Margins, enter 0.5 for the top and side margins and 2.3 for the bottom margin. Here, measurements are entered in centimeters.
  • Page 205 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In the After confirming that Easy Settings is selected, select from the Print Target list. Print Quality list. Make your selection in the Access the Page Setup pane.
  • Page 206 Enhanced Printing Options (CS2436-3) Click Manual in the Paper Source list. Page Size, make sure 430*430 is displayed, as registered in Page Setup. Print to start printing. Confirm the print settings, and then click Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...
  • Page 207 Enhanced Printing Options (CS2436-3)

  • Page 208: Printing Multiple Pages Per Sheet

    Enhanced Printing Options (CS2436-3) 3. 7. 1. Enhanced Printing Options > Tiling and multiple pages per sheet > Printing Multiple Pages Per Sheet To conserve paper, you can print several pages of the original on a single sheet by reducing the original and dividing the sheet into areas for each page.

  • Page 209: Printing Multiple Pages Per Sheet (Windows)

    Enhanced Printing Options (CS2436-3) 3. 7. 2. Enhanced Printing Options > Tiling and multiple pages per sheet > Printing Multiple Pages Per Sheet (Windows) This topic describes how to print four pages of originals together on a single sheet based on the following example.
  • Page 210 Enhanced Printing Options (CS2436-3) Print Quality list. Make your selection in the Click the Page Setup tab to display the Page Setup sheet. Page Size, click the size of the original as specified in the application software. In this case, click ISO A3 or Letter (8.5"x11").
  • Page 211 Enhanced Printing Options (CS2436-3) Page Layout check box. Select the Click 4 Pages/Sheet in the Page Layout list. Note You can select the layout order for placing four pages on a sheet and a frame border in the Page Layout Printing dialog box by clicking Set.

  • Page 212: Printing Multiple Pages Per Sheet (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 7. 3. Enhanced Printing Options > Tiling and multiple pages per sheet > Printing Multiple Pages Per Sheet (Mac OS X) This topic describes how to print four pages of an original on a single sheet, based on the following example.
  • Page 213 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click ISO A3. In the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 214 Enhanced Printing Options (CS2436-3) In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Print Target list. Make your selection in the Print Quality list. Make your selection in the Access the Page Setup pane.
  • Page 215 Enhanced Printing Options (CS2436-3) Click Roll Paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list-in this case, ISO A2/ A3 (420.0mm). Note If the width of the roll loaded in the printer is not shown in...
  • Page 216 Enhanced Printing Options (CS2436-3) Page Size shows the original size as specified in Paper Size in the Page Make sure Attributes dialog box—in this case, ISO A3.
  • Page 217 Enhanced Printing Options (CS2436-3) Confirm the print settings, and then click Print to start printing. Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 218: Printing Posters In Sections

    Enhanced Printing Options (CS2436-3) 3. 7. 4. Enhanced Printing Options > Tiling and multiple pages per sheet > Printing Posters in Sections You can enlarge an original to print it in sections on several sheets. By assembling the printed sheets, you can create a poster larger than the maximum supported paper size of the printer.

  • Page 219: Printing Large Posters (Windows)

    Enhanced Printing Options (CS2436-3) 3. 7. 5. Enhanced Printing Options > Tiling and multiple pages per sheet > Printing Large Posters (Windows) You can enlarge an original to print it in sections on several sheets. By assembling the printed sheets, you can create a poster larger than the maximum supported paper size of the printer.
  • Page 220 Enhanced Printing Options (CS2436-3) Click the Page Setup tab to display the Page Setup sheet. Page Size, click the size of the original as specified in the application. In this case, click ISO Click Manual in the Paper Source list.
  • Page 221 Enhanced Printing Options (CS2436-3) Page Layout check box. Select the Click Poster (2 x 2) in the Page Layout list. Note Follow the steps below to print only a portion of the poster as divided for printing. Click Set under Page Layout to display the Pages to Print dialog box.

  • Page 222: Printing Originals Centered On Rolls

    Enhanced Printing Options (CS2436-3) 3. 8. 1. Enhanced Printing Options > Centering originals > Printing Originals Centered on Rolls You can print originals centered on a page—for example, if the paper is larger than the original, or if you are reducing the original.

  • Page 223: Printing Originals Centered On Rolls (Windows)

    Enhanced Printing Options (CS2436-3) 3. 8. 2. Enhanced Printing Options > Centering originals > Printing Originals Centered on Rolls (Windows) This topic describes how to center originals before printing on rolls based on the following example. Document: Any type ●...
  • Page 224 Enhanced Printing Options (CS2436-3) In the Page Size list, click the size of the original as specified in the application. In this case, click ISO A4 or Letter (8.5"x11"). Click Roll Paper in the Paper Source list. Roll Paper Width list-in this case, ISO A3/A4 Roll Select the width of the loaded roll in the (297.0mm).
  • Page 225 Enhanced Printing Options (CS2436-3) Print Centered check box. Select the Confirm the print settings and print as desired. Note For tips on confirming print settings, see "Confirming Print Settings (4.1.3)"...

  • Page 226: Printing Originals Centered On Rolls (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 8. 3. Enhanced Printing Options > Centering originals > Printing Originals Centered on Rolls (Mac OS X) This topic describes how to center originals before printing on rolls based on the following example. Document: Any Type ●...
  • Page 227 Enhanced Printing Options (CS2436-3) Printer list. Select the printer in the Paper Size list, click the size of the original. In this case, click ISO A4. In the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 228 Enhanced Printing Options (CS2436-3) Print Target list. Make your selection in the Print Quality list. Make your selection in the Access the Page Setup pane. Click Roll Paper in the Paper Source list. Roll Width -in this case, ISO A3/A4 Make sure the width of the loaded roll is displayed in (297.0mm).
  • Page 229 Enhanced Printing Options (CS2436-3) Page Size setting matches the original size as selected in Paper Size in the Make sure the Page Attributes dialog box—in this case, ISO A4.
  • Page 230 Enhanced Printing Options (CS2436-3) Select the Print Centered check box. Print to start printing. Confirm the print settings, and then click Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 231: Printing Originals Centered On Sheets

    Enhanced Printing Options (CS2436-3) 3. 8. 4. Enhanced Printing Options > Centering originals > Printing Originals Centered on Sheets You can print originals centered on a page—for example, if the paper is larger than the original, or if you are reducing the original.

  • Page 232: Printing Originals Centered On Sheets (Windows)

    Enhanced Printing Options (CS2436-3) 3. 8. 5. Enhanced Printing Options > Centering originals > Printing Originals Centered on Sheets (Windows) This topic describes how to reduce an original 50% for printing centered on a sheet. Document: Any Type ● Page size: A4 (210.0 × 297.0 mm [8.3 × 11.7 in]) ●...
  • Page 233 Enhanced Printing Options (CS2436-3) In the Page Size list, click the size of the original as specified in the application. In this case, click ISO A4. Select the Enlarged/Reduced Printing check box. Click Match Page Size in the Paper Size list.
  • Page 234 Enhanced Printing Options (CS2436-3) Select the Print Centered check box. Confirm the print settings and print as desired. Note For tips on confirming print settings, see "Confirming Print Settings (4.1.3)" Important If you have selected Manual as the paper source, follow the instructions on...

  • Page 235: Printing Originals Centered On Sheets (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 8. 6. Enhanced Printing Options > Centering originals > Printing Originals Centered on Sheets (Mac OS X) This topic describes how to center originals for printing on sheets, based on the following example. Document: Any Type ●...
  • Page 236 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click ISO A4 - for Paper Tray In the (Large Margins). If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 237 Enhanced Printing Options (CS2436-3) Print Target list. Make your selection in the Print Quality list. Make your selection in the Access the Page Setup pane. Click Manual in the Paper Source list. Page Size setting matches the original size as selected in...
  • Page 238 Enhanced Printing Options (CS2436-3) Select the Print Centered check box. Print to start printing. Confirm the print settings, and then click Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)" Important If you have selected Manual as the paper source, follow the instructions on the...

  • Page 239: Conserving Roll Paper By Rotating Originals 90 Degrees

    Enhanced Printing Options (CS2436-3) 3. 9. 1. Enhanced Printing Options > Conserving roll paper > Conserving Roll Paper by Rotating Originals 90 Degrees You can conserve roll paper by specifying particular settings as suitable for your original. Rotate Page 90 degrees (Conserve Paper) When originals are printed in portrait orientation, the original is rotated 90 degrees before printing if it fits within the roll width.
  • Page 240 Enhanced Printing Options (CS2436-3) 3. 9. 2. Enhanced Printing Options > Conserving roll paper > Conserving Roll Paper by Rotating Originals 90 Degrees (Windows) This topic describes how to conserve paper by rotating originals 90 degrees before printing, based on the following example.
  • Page 241 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. In the Click the Page Setup tab to display the Page Setup sheet.
  • Page 242 Enhanced Printing Options (CS2436-3) Page Size list, click the size of the original as specified in the application. In this case, In the click ISO A4 or Letter (8.5"x11"). Click Roll Paper in the Paper Source list. Roll Paper Width list-in this case, ISO A3/A4 Roll Select the width of the loaded roll in the (297.0mm).
  • Page 243 Enhanced Printing Options (CS2436-3) 3. 9. 3. Enhanced Printing Options > Conserving roll paper > Conserving Roll Paper by Rotating Originals 90 Degrees (Mac OS X) This topic describes how to conserve roll paper by rotating originals 90 degrees before printing, based on the following example.
  • Page 244 Enhanced Printing Options (CS2436-3) If it is not displayed, the settings are configured in the upper part of the printer driver displayed when you select Print from the application software menu. Printer list. Select the printer in the Paper Size list, click the size of the original. In this case, click ISO A4.
  • Page 245 Enhanced Printing Options (CS2436-3) In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Access the Page Setup pane.
  • Page 246 Enhanced Printing Options (CS2436-3) Click Roll Paper in the Paper Source list. Make sure the width of the loaded roll is displayed in Roll Width -in this case, ISO A3/A4 (297.0mm). Note If the width of the roll loaded in the printer is not shown in...
  • Page 247 Enhanced Printing Options (CS2436-3) Page Size setting matches the original size as selected in Paper Size in the Make sure the Page Attributes dialog box—in this case, ISO A4.
  • Page 248 Enhanced Printing Options (CS2436-3) Select the Rotate Page 90 degrees check box. Print to start printing. Confirm the print settings, and then click Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...
  • Page 249 Enhanced Printing Options (CS2436-3) 3. 9. 4. Enhanced Printing Options > Conserving roll paper > Conserving Roll Paper by Printing Originals Without Top and Bottom Margins You can conserve roll paper by specifying particular settings as suitable for your original.
  • Page 250 Enhanced Printing Options (CS2436-3) 3. 9. 5. Enhanced Printing Options > Conserving roll paper > Conserving Roll Paper by Printing Originals Without Top and Bottom Margins (Windows) This topic describes how to conserve roll paper when printing originals that have a top and bottom margin, based on the following example.
  • Page 251 Enhanced Printing Options (CS2436-3) Click the Page Setup tab to display the Page Setup sheet. In the Page Size list, click the size of the original as specified in the application. In this case, click ISO A4 or Letter (8.5"x11").
  • Page 252 Enhanced Printing Options (CS2436-3) No Spaces at Top or Bottom (Conserve Paper) check box. Select the Confirm the print settings and print as desired. Note For tips on confirming print settings, see "Confirming Print Settings (4.1.3)"...
  • Page 253 Enhanced Printing Options (CS2436-3) 3. 9. 6. Enhanced Printing Options > Conserving roll paper > Conserving Roll Paper by Printing Originals Without Top and Bottom Margins (Mac OS X) This topic describes how to conserve roll paper when printing originals that have a top and bottom margin, based on the following example.
  • Page 254 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click ISO A4. In the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 255 Enhanced Printing Options (CS2436-3) Click Roll Paper in the Paper Source list. Make sure the width of the loaded roll is displayed in Roll Width -in this case, ISO A3/A4 (297.0mm). Note If the width of the roll loaded in the printer is not shown in...
  • Page 256 Enhanced Printing Options (CS2436-3) Page Size setting matches the original size as selected in Paper Size in the Make sure the Page Attributes dialog box—in this case, ISO A4.
  • Page 257 Enhanced Printing Options (CS2436-3) Select the No Spaces at Top or Bottom check box. Print to start printing. Confirm the print settings, and then click Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 258: Printing With Watermarks

    Enhanced Printing Options (CS2436-3) 3. 10. 1. Enhanced Printing Options > Other useful settings > Printing With Watermarks You can add watermarks (background images) to documents that require special handling. Watermark Watermarks are applied to all pages of your document.
  • Page 259 Enhanced Printing Options (CS2436-3) Watermarks are supported in Windows. In addition to the provided watermarks, you can create up to 50 original watermarks in Windows. For detailed instructions on printing with watermarks, refer to the following topics: Printing with Watermarks- COPY, FILE COPY, and so on (Windows) (3.11.2)

  • Page 260: Printing With Watermarks- Copy, File Copy, And So On

    Enhanced Printing Options (CS2436-3) 3. 10. 2. Enhanced Printing Options > Other useful settings > Printing with Watermarks- COPY, FILE COPY, and so on (Windows) This topic describes how to print with watermarks, based on the following example of printing with a FILE COPY watermark.
  • Page 261 Enhanced Printing Options (CS2436-3) Print Target list. Make your selection in the Note Print Target list by You can check the settings values selected in the View Settings. clicking Click the Page Setup tab to display the Page Setup sheet.
  • Page 262 Enhanced Printing Options (CS2436-3) Watermark check box. Select the Click FILE COPY in the Watermarks list. Note Edit Watermark to open the Edit Watermark dialog box. In the Click Edit Watermark dialog box, you can create custom watermarks and change the position and angle of watermarks.

  • Page 263: Making The Original Orientation Match The Paper Orientation

    Enhanced Printing Options (CS2436-3) 3. 10. 3. Enhanced Printing Options > Other useful settings > Making the Original Orientation Match the Paper Orientation You can specify the original orientation to match the orientation of the paper for printing. Orientation Paper is usually loaded in the printer in portrait orientation. When you have an original in landscape orientation, you can specify the printing orientation so that the original is printed in landscape orientation.
  • Page 264 Enhanced Printing Options (CS2436-3) 3. 10. 4. Enhanced Printing Options > Other useful settings > Making the Original Orientation Match the Paper Orientation (Windows) This topic describes how to print an original in landscape orientation after matching the paper orientation, based on the following example.
  • Page 265 Enhanced Printing Options (CS2436-3) Print Target list. Make your selection in the Print Quality list. Make your selection in the Click the Page Setup tab to display the Page Setup sheet. In the Page Size list, click the size of the original as specified in the application. In this case, click ISO A4 or Letter (8.5"x11").
  • Page 266 Enhanced Printing Options (CS2436-3) 3. 10. 5. Enhanced Printing Options > Other useful settings > Making the Original Orientation Match the Paper Orientation (Mac OS X) This topic describes how to print an original in landscape orientation after matching the paper orientation, based on the following example.
  • Page 267 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list, click the size of the original. In this case, click ISO A4. In the Orientation, click the icon of the document in landscape orientation. If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 268 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. In the Print Target list. Make your selection in the Make your selection in the Print Quality list. Access the Page Setup pane.
  • Page 269 Enhanced Printing Options (CS2436-3) Page Size setting matches the original size as selected in Paper Size in the Make sure the Page Attributes dialog box—in this case, ISO A4.
  • Page 270 Enhanced Printing Options (CS2436-3) Confirm the print settings, and then click Print to start printing. Note For tips on confirming print settings, see "Confirming Print Settings (5.1.3)"...

  • Page 271: Using Favorites

    Enhanced Printing Options (CS2436-3) 3. 10. 6. Enhanced Printing Options > Other useful settings > Using Favorites You can register print settings as Favorites to reuse settings from a particular job that met your expectations, or settings for a particular page size that you will use repeatedly.

  • Page 272: Using Favorites (Windows)

    Enhanced Printing Options (CS2436-3) 3. 10. 7. Enhanced Printing Options > Other useful settings > Using Favorites (Windows) This topic describes how to register favorites and print using favorite settings. Registering a favorite Follow the steps below to save the current print settings as a favorite.
  • Page 273 Enhanced Printing Options (CS2436-3) Enter a desired name in Name, such as Photos for Presentations or Monthly Report. Choose a fitting icon for these print settings in the Icon list. In Comment, enter a description of the favorite to be added, as desired.
  • Page 274 Enhanced Printing Options (CS2436-3) In the Favorites, choose the favorite you registered. Note To import a favorite, click Import and specify the favorite file. Apply Favorite to replace the favorite settings with the current print settings. Click Confirm the print settings and print as desired.

  • Page 275: Using Favorites (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 10. 8. Enhanced Printing Options > Other useful settings > Using Favorites (Mac OS X) You can use the Presets function in Mac OS X for favorite-based printing. Note In the printing dialog box, click Save As in the Presets list to save the current print settings.
  • Page 276 Enhanced Printing Options (CS2436-3)

  • Page 277: Cutting Roll Paper After Printing (Windows)

    Enhanced Printing Options (CS2436-3) 3. 10. 9. Enhanced Printing Options > Other useful settings > Cutting Roll Paper After Printing (Windows) This topic describes how to cut roll paper automatically after printing (using the auto cut function), as well as how to print a cut line for manual cutting.
  • Page 278 Enhanced Printing Options (CS2436-3) To enable automatic cutting, click Yes in the Automatic Cutting list. If you prefer to cut the paper later yourself, click Print Cut Guideline. Click OK to close the Roll Paper Options dialog box. Confirm the print settings and print as desired.

  • Page 279: Cutting Roll Paper After Printing (Mac Os X)

    Enhanced Printing Options (CS2436-3) 3. 10. 10. Enhanced Printing Options > Other useful settings > Cutting Roll Paper After Printing (Mac OS X) This topic describes how to cut roll paper automatically after printing (using the auto cut function), as well as how to print a cut line for manual cutting.
  • Page 280 Enhanced Printing Options (CS2436-3) Select the printer in the Printer list. Paper Size list. Choose the original size in the If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 281 Enhanced Printing Options (CS2436-3) Media Type list, select the type of paper that is loaded. In the Click Set to display the Paper Detailed Settings dialog box.
  • Page 282 Enhanced Printing Options (CS2436-3) To enable automatic cutting, click Printer Default in the Automatic Cutting list. If you prefer to cut the paper later yourself, click Print Cut Guideline. Important If the automatic cut function has been deactivated on the printer, change the auto cut setting on the printer Control Panel.

  • Page 283: Windows Software

    Windows Software (CS2436-4) 4. Windows Software 4. 1. Printer Driver Printer Driver Settings Specifying Paper in the Printer Driver Confirming Print Settings Using Favorites Accessing the Printer Driver Dialog Box from Applications Accessing the Printer Driver Dialog Box from the Operating System Menu...
  • Page 284 Windows Software (CS2436-4) Automatically Acquiring Print Job Logs at Regular Intervals Canceling Regular Print Job Log Acquisition Switching Between Displaying Jobs on Printer and Regularly Acquired Jobs Exporting Print Job Data as a CSV File Showing Job Properties Showing, Saving and Loading Selected Unit Cost Data Showing the Total Amount of Ink and Paper Consumed 4.

  • Page 285: Printer Driver Settings

    Windows Software (CS2436-4) 4. 1. 1. Windows Software > Printer Driver > Printer Driver Settings For instructions on accessing the Windows printer driver, refer to the following topics. Accessing the Printer Driver Dialog Box from Applications (4.1.6) ● Accessing the Printer Driver Dialog Box from the Operating System Menu (4.1.7) ●...
  • Page 286 Windows Software (CS2436-4) Color Adjustment Sheet: Monochrome (4.1.15) ● Page Setup Sheet (4.1.17) ● You can specify the page size of the original, borderless printing, enlargement or reduction, the orientation, the paper size and feed source, and automatic cutting. Paper Size Options Dialog Box (4.1.18) ●...
  • Page 287 Windows Software (CS2436-4) information for the printer driver.
  • Page 288 Windows Software (CS2436-4) 4. 1. 2. Windows Software > Printer Driver > Specifying Paper in the Printer Driver If you have replaced the paper, you must complete the following settings in the printer driver. Important Always specify the same type and size of paper in the printer menu and printer driver.
  • Page 289 Windows Software (CS2436-4) Get Information button to display the Paper Click the Information on Printer dialog box. On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and configure printer driver settings for the feed source and type of paper.
  • Page 290 Windows Software (CS2436-4) A variety of settings are available in the printer driver to suit different printing applications. For details on available printing conditions, see "Printer Driver Settings (4.1.1)"...

  • Page 291: Confirming Print Settings

    Windows Software (CS2436-4) 4. 1. 3. Windows Software > Printer Driver > Confirming Print Settings There are two ways to confirm the print settings, as follows. Checking a preview of the settings ● Checking a print preview ● Checking a preview of the settings A preview of the settings is displayed on the left side of the Main, Page Setup, and Layout sheets.
  • Page 292 Windows Software (CS2436-4) The page size, paper size, and method and percentage of enlargement or reduction are Middle, bordered area indicated. Illustrations indicate the feed source, orientation, borderless printing selection, and Bottom illustrations other settings information. Note To confirm the Print Target specified in Easy Settings, click View Settings on the Main sheet to display the View Settings dialog box.
  • Page 293 Windows Software (CS2436-4) 4. 1. 4. Windows Software > Printer Driver > Using Favorites This topic describes how to register favorites and print using favorite settings. Registering a favorite Follow the steps below to save the current print settings as a favorite.
  • Page 294 Windows Software (CS2436-4) Enter a desired name in Name, such as Photos for Presentations or Monthly Report. Choose a fitting icon for these print settings in the Icon list. In Comment, enter a description of the favorite to be added, as desired.
  • Page 295 Windows Software (CS2436-4) In the Favorites, choose the favorite you registered. Note Import and specify the favorite file. To import a favorite, click Apply Favorite to replace the favorite settings with the current print settings. Click Confirm the print settings and print as desired.

  • Page 296: Accessing The Printer Driver Dialog Box From Applications (4.1.6)

    Windows Software (CS2436-4) 4. 1. 5. Windows Software > Printer Driver > Accessing the Printer Driver Dialog Box from Applications Choose Print from the File menu to display the dialog box for printing conditions. Select the printer, and then display the printer driver dialog box.
  • Page 297 Windows Software (CS2436-4) Note The titles of dialog boxes may vary depending on the application, and sheets other than these six sheets may be displayed. Important If you access the printer driver dialog box from the source application, changes you make to the settings will only apply temporarily to that application.

  • Page 298: Accessing The Printer Driver Dialog Box From The Operating System Menu (4.1.7)

    Windows Software (CS2436-4) 4. 1. 6. Windows Software > Printer Driver > Accessing the Printer Driver Dialog Box from the Operating System Menu Click start > Printers and Faxes (or Printers ). Select the printer, and then display the printer properties dialog box.
  • Page 299 Windows Software (CS2436-4) Note The Device Settings sheet is also an extension of the printer driver. (See "Device Settings Sheet (4.1.26)") Six sheets of print settings are displayed by the printer driver: Main, Page Setup, Layout, Favorites, Utility, and Support.
  • Page 300 Windows Software (CS2436-4) Important If you access the printer driver dialog box from the operating system menu, changes you make to the settings will apply to all applications you use for printing. You can also access the printer driver dialog box from applications.

  • Page 301: Main Sheet (4.1.8)

    Windows Software (CS2436-4) 4. 1. 7. Windows Software > Printer Driver > Main Sheet The following settings are available on the Main sheet. For details on settings items, refer to the printer driver help file. Note On the Main sheet, choose Easy Settings to specify basic print settings based on the particular printing application, or switch to Advanced Settings to complete more detailed settings as desired.

  • Page 302: Advanced Settings

    Windows Software (CS2436-4) Displays Paper Information on Printer. You can update the printer driver settings for the feed source, media type, and roll width by selecting the feed source. Paper Information on Printer Dialog Box (4.1.9) ● Advanced Settings Displays Paper Detailed Settings. You can configure the printing settings to match the type of media, such as the ink drying time.

  • Page 303: View Settings

    Windows Software (CS2436-4) Print Target Choose presets that match the type of document to be printed. Printing Photos and Images (2.2.1) ● Printing Line Drawings and Text (2.1.2) ● Printing Office Documents (2.3.1) ● Depending on the Media Type setting, some Print Target options may not be available.

  • Page 304: Color Mode

    Windows Software (CS2436-4) Configuration using Advanced Settings Print Priority Choose the graphic elements that you want to emphasize for printing. Giving Priority to Particular Graphic Elements and Colors for Printing (3.1.4) ● Print Quality Choose the level of print quality.

  • Page 305: Color Settings

    Windows Software (CS2436-4) Color Settings Click to display the Color Settings dialog box for more advanced color settings. Adjusting the Color in the Printer Driver (3.1.1) ● Thicken Fine Lines Activate this option to print fine lines more distinctly. Unidirectional Printing Select this checkbox to prevent problems such as misaligned lines and improve the print quality.

  • Page 306: Paper Information On Printer Dialog Box

    Windows Software (CS2436-4) 4. 1. 8. Windows Software > Printer Driver > Paper Information on Printer Dialog Box On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and configure printer driver settings for the paper source and media type.

  • Page 307: Paper Detailed Settings Dialog Box (4.1.10)

    Windows Software (CS2436-4) 4. 1. 9. Windows Software > Printer Driver > Paper Detailed Settings Dialog Box The Paper Detailed Settings dialog box offers the following settings. For details on settings items, refer to the printer driver help. Note To display the Paper Detailed Settings dialog box, on the Main sheet, click Settings by Media Type.(See "Main Sheet (4.1.8)")
  • Page 308 Windows Software (CS2436-4) needed. Roll Paper Margin for Safety You can specify the length of a margin on the leading edge of paper to ensure that paper susceptible to curling is held firmly against the Platen. Near End Margin Specify the length of the Near End Margin (the leading edge margin) of the roll, as needed.

  • Page 309: View Settings Dialog Box For The Printing Application (4.1.11)

    Windows Software (CS2436-4) 4. 1. 10. Windows Software > Printer Driver > View Settings Dialog Box for the Printing Application In the View Settings dialog box, you can check details of the selected printing application. Note To display the View Settings dialog box, on the Main sheet, click View Settings by Print Target.(See "Main Sheet (4.1.8)")
  • Page 310 Windows Software (CS2436-4)

  • Page 311: Color Adjustment Sheet: Color (4.1.12)

    Windows Software (CS2436-4) 4. 1. 11. Windows Software > Printer Driver > Color Adjustment Sheet: Color If the color tone as printed is not as you expected, you can adjust it on the Color Adjustment sheet. Note To display the Color Adjustment sheet, on the Main sheet, click Color Settings by Color Mode in Advanced Settings.(See "Main Sheet (4.1.8)")
  • Page 312 Windows Software (CS2436-4) Apply to Sample Select this checkbox to apply the changed settings to the sample image. Cyan / Magenta / Yellow Fine-tune color tones by adjusting the levels of each color. Gray Tone Adjust the color tone of grays as desired. Choose Cool Black (tinged with blue) or Warm Black (tinged with red).
  • Page 313 Windows Software (CS2436-4) 4. 1. 12. Windows Software > Printer Driver > Object Adjustment dialog box: Color In the Object Adjustment dialog box, you can specify what type of print jobs to apply color adjustment to. If an original comprises images, graphics, and text, you can specify which portion to apply color adjustment to.

  • Page 314: Matching Sheet (4.1.14)

    Windows Software (CS2436-4) 4. 1. 13. Windows Software > Printer Driver > Matching Sheet On the Matching sheet, you can specify color matching to compensate for differences in the appearance of colors on various devices. Driver Matching Mode The following options are available when you select Driver Matching Mode in the Matching Mode list.

  • Page 315: Matching Method

    Windows Software (CS2436-4) Normally, select Driver Matching Mode. For color matching based on ICC profiles, select ICC Matching Mode, Driver ICM Mode, or Host ICM Mode, depending on your color matching system. If you prefer not to use the printer driver for color matching, select No.
  • Page 316 Windows Software (CS2436-4) Note To display the Matching sheet, on the Main sheet, click Color Settings by Color Mode in Advanced Settings, and then click the Matching sheet. (See "Main Sheet (4.1.8)") Matching Mode Select the color matching mode to use, as desired.

  • Page 317: Color Adjustment Sheet: Monochrome (4.1.15)

    Windows Software (CS2436-4) 4. 1. 14. Windows Software > Printer Driver > Color Adjustment Sheet: Monochrome On the Color Adjustment sheet for monochrome printing, you can adjust the brightness and contrast. Note To display the Color Adjustment sheet, on the Main sheet, click Color Settings by Color Mode in Advanced Settings.(See "Main Sheet (4.1.8)")
  • Page 318 Windows Software (CS2436-4) Apply to Sample Select this checkbox to apply the changed settings to the sample image. Cyan / Magenta / Yellow Not available. Gray Tone Not available. Brightness Adjust the overall image brightness as desired. You can adjust the brightness if the printed document is lighter or darker than the original image (that is, the original photo that was scanned or the original graphic as it appears on the computer screen).
  • Page 319 Windows Software (CS2436-4) 4. 1. 15. Windows Software > Printer Driver > Object Adjustment dialog box: Monochrome In the Object Adjustment dialog box, you can specify what type of print jobs to apply color adjustment to. If an original comprises images, graphics, and text, you can specify which portion to apply color adjustment to.

  • Page 320: Page Setup Sheet (4.1.17)

    Windows Software (CS2436-4) 4. 1. 16. Windows Software > Printer Driver > Page Setup Sheet The following settings are available on the Page Setup sheet. For details on settings items, refer to the printer driver help file. Page Size Select the page size as specified in the source application.

  • Page 321: Paper Size

    Windows Software (CS2436-4) Borderless printing is available if Roll Paper is selected in the Paper Source list. Choose from the following options when this setting is activated. Borderless Printing on Paper of Equivalent Size (3.5.1) ● Borderless Printing by Resizing Originals to Fit the Roll Width (3.5.4) ●...
  • Page 322 Windows Software (CS2436-4) Choose from the following options when this setting is activated. Resizing Originals to Match the Paper Size (3.3.1) ● Resizing Originals to Fit the Roll Width (3.3.4) ● Resizing Originals by Entering a Scaling Value (3.3.7) ●...
  • Page 323 Windows Software (CS2436-4) For details on available roll widths, see "Paper Sizes (6.1.2)" Roll Paper Options Complete optional roll paper settings. Click to display the Roll Paper Options dialog box. Automatic Cutting, you can specify Yes or No and Print Cut Guideline.

  • Page 324: Paper Size Options Dialog Box (4.1.18)

    Windows Software (CS2436-4) 4. 1. 17. Windows Software > Printer Driver > Paper Size Options Dialog Box In the Paper Size Options dialog box, you can create and register your own Custom Paper Size. The sizes you define are listed with standard paper sizes for selection later as needed.
  • Page 325 Windows Software (CS2436-4) Units Specify the desired unit of measure for the Custom Paper Size height and width. Paper Size Specify the desired Width and Height. You can make your selection from sizes that are compatible with Borderless Printing by selecting Borderless Printing Size. To maintain the aspect ratio of the Width and Height as you resize the paper, select Fix the Ratio of the Width to Height.

  • Page 326: Layout Sheet (4.1.19)

    Windows Software (CS2436-4) 4. 1. 18. Windows Software > Printer Driver > Layout Sheet The following settings are available on the Layout sheet. For details on settings items, refer to the printer driver help. Page Layout Activate this setting to select a particular page layout.

  • Page 327: Edit Watermark

    Windows Software (CS2436-4) Pages to Print ● Watermark Activating this option makes two settings available, Watermarks and Edit Watermark. Printing With Watermarks (3.11.1) ● Watermarks Lists the provided watermarks. Choose the watermark to print. Edit Watermark Click to display the Edit Watermark dialog box for creating your own, original watermark.
  • Page 328 Windows Software (CS2436-4)

  • Page 329: Special Settings Dialog Box (4.1.21)

    Windows Software (CS2436-4) 4. 1. 19. Windows Software > Printer Driver > Special Settings Dialog Box If the printing results are not as you expected, you can change how printing is processed in the Special Settings dialog box. Note To display the Special Settings dialog box, on the Layout sheet, click Special Settings.(See "Layout Sheet (4.1.19)")
  • Page 330 Windows Software (CS2436-4) this option. However, printing may take longer for some images.

  • Page 331: Favorites Sheet (4.1.22)

    Windows Software (CS2436-4) 4. 1. 21. Windows Software > Printer Driver > Favorites Sheet The following settings are available on the Favorites sheet. For details on settings items, refer to the printer driver help. Favorites Printing favorites you have created are listed with Default Settings favorites.
  • Page 332 Windows Software (CS2436-4) Click to change the current print settings to those of the favorite selected in the Favorites. Application Settings Priority Activate this setting to use settings values specified in the source application in preference to Favorites, when clicking Apply Favorite.
  • Page 333 Windows Software (CS2436-4) Down Click to move the selected favorite down in the Favorites list.

  • Page 334: Utility Sheet (4.1.23)

    Windows Software (CS2436-4) 4. 1. 22. Windows Software > Printer Driver > Utility Sheet The following items can be executed on the Utility sheet. For details on the utilities, refer to the relevant utility help. Maintenance Click to start the Status Monitor, which offers the following maintenance for the printer.

  • Page 335: The Features Of Status Monitor

    Windows Software (CS2436-4) 4. 2. 1. Windows Software > Status Monitor > The Features of Status Monitor Status Monitor is a utility for checking the printer status and managing print jobs. Two screens are available in Status Monitor : Printer List shows a list of printers, and Status...
  • Page 336 Windows Software (CS2436-4) You can view a list of the printers for which printer drivers have been installed on your ● computer, printers connected to your computer, and printers found on the network. If a printer error occurs, you can investigate the corrective action immediately.
  • Page 337 Windows Software (CS2436-4)

  • Page 338: Job Management Using Status Monitor

    Windows Software (CS2436-4) 4. 2. 2. Windows Software > Status Monitor > Job Management Using Status Monitor You can use the Job sheet in Status Monitor for operations such as pausing and canceling print jobs. Pausing/Resuming Print Jobs Selecting a print job and clicking the Pause button pauses printing of the selected job.
  • Page 339 Windows Software (CS2436-4) Note You cannot cancel other users' print jobs.

  • Page 340: Accounting Manager

    Windows Software (CS2436-4) 4. 3. 1. Windows Software > Accounting > Accounting Manager The Accounting Manager stores the printer's print job logs so that you can use the information for checking printing costs, etc. The benefits of using the Accounting Manager are outlined below.

  • Page 341: Launching The Accounting Manager

    Windows Software (CS2436-4) 4. 3. 2. Windows Software > Accounting > Launching the Accounting Manager The procedure for launching the Accounting Manager is shown below. Open the Status Monitor window. Select Accounting in the Accounting menu. Or, open the Accounting sheet and click the Accounting button.

  • Page 342: Accounting Manager Main Window

    Windows Software (CS2436-4) 4. 3. 3. Windows Software > Accounting > Accounting Manager Main Window The Accounting Manager main window consists of a title bar, menu bar, toolbars, listed job selection area, job list area, totals area and status bar.

  • Page 343: Job List Area

    Windows Software (CS2436-4) If you are using regular data acquisition, this area allows you to view the collective job logs for each specified period. For more information on how to select the job logs displayed, see Switching Between Displaying Jobs on Printer and Regularly Acquired Jobs (4.8.12).

  • Page 344: Totals Area

    Windows Software (CS2436-4) Note If the Unit Cost of Ink or Paper have not been set, **** is displayed in the Job Cost field. Totals Area Displays the total costs for the selected job and the amounts of paper and ink consumed.

  • Page 345: Status Bar

    Windows Software (CS2436-4) Note If you are viewing regularly acquired print jobs, selecting a period on the left side of the window displays the total costs for that period and the amounts of paper and ink consumed. Status Bar Displays messages and other information.

  • Page 346: Accounting Manager Basic Procedures

    Windows Software (CS2436-4) 4. 3. 4. Windows Software > Accounting > Accounting Manager Basic Procedures The first time you use the Accounting Manager, use the following procedures to configure the settings. Configure unit costs, including the costs of ink and paper.

  • Page 347: Configuring Unit Costs In Accounting Manager

    Windows Software (CS2436-4) 4. 3. 5. Windows Software > Accounting > Configuring Unit Costs in Accounting Manager Select Unit Costs in the Settings menu to open the Unit Costs dialog box. Configure the unit cost settings in this dialog box.

  • Page 348: Setting The Unit Cost For Ink

    Windows Software (CS2436-4) 4. 3. 6. Windows Software > Accounting > Setting the Unit Cost for Ink Open the Ink sheet. Set the unit cost for ink in this sheet. To set the same unit cost for all the inks...
  • Page 349 Windows Software (CS2436-4) Enter the Tank Capacity and Price. Click the OK button. Important Your settings are not applied until you click the OK button. To set different unit costs for each ink color Select the ink color to be costed.

  • Page 350: Setting The Unit Cost For Paper

    Windows Software (CS2436-4) 4. 3. 7. Windows Software > Accounting > Setting the Unit Cost for Paper Open the Paper sheet. Set the unit cost for paper in this sheet. Select a media type from the Media Type list. Enter the Width, Length and Price.
  • Page 351 Windows Software (CS2436-4) Click the Add button. To change the unit cost for a media type you have already set, click the Overwrite button. Click the OK button. Important Your settings are not applied until you click the OK button.

  • Page 352: Setting The Unit Cost For Items Other Than Ink And Paper

    Windows Software (CS2436-4) 4. 3. 8. Windows Software > Accounting > Setting the Unit Cost for Items Other Than Ink and Paper Open the Other sheet. Use this sheet to set any price for items other than inks and paper.
  • Page 353 Windows Software (CS2436-4) Use Allocated to specify whether the costs are allocated as being incurred by the print job. Click the Add button. To change the unit cost for a media type you have already set, click the Overwrite button.
  • Page 354 Windows Software (CS2436-4) 4. 3. 9. Windows Software > Accounting > Configuring Units and Display Settings in Accounting Manager Select Units and Display in the Settings menu to open the Units and Display dialog box. Use this dialog box to configure the display settings.

  • Page 355: Paper Width

    Windows Software (CS2436-4) Ink Consumed Use this option to select the unit used for ink consumption. Paper Width Use this to select the unit used for paper width. Paper Length Use this to select the unit used for paper length.

  • Page 356: Automatically Acquiring Print Job Logs At Regular Intervals

    Windows Software (CS2436-4) 4. 3. 10. Windows Software > Accounting > Automatically Acquiring Print Job Logs at Regular Intervals This feature collects print job logs from the printer at regular intervals and saves the logs on your computer. Select Regular Data Acquisition in the Settings menu.

  • Page 357: Canceling Regular Print Job Log Acquisition

    Windows Software (CS2436-4) 4. 3. 11. Windows Software > Accounting > Canceling Regular Print Job Log Acquisition You can use this procedure to cancel the regular acquisition of print job logs from printers. Select Regular Data Acquisition in the Settings menu.

  • Page 358: Switching Between Displaying Jobs On Printer And Regularly Acquired Jobs

    Windows Software (CS2436-4) 4. 3. 12. Windows Software > Accounting > Switching Between Displaying Jobs on Printer and Regularly Acquired Jobs The print job logs displayed by the Status Monitor Accounting Manager contain two types of job: Jobs on Printer and Regularly Acquired Jobs.

  • Page 359: Exporting Print Job Data As A Csv File

    Windows Software (CS2436-4) 4. 3. 13. Windows Software > Accounting > Exporting Print Job Data as a CSV File You can export the collected print job data in the form of a CSV file by selecting Export Job Cost Data in the File menu.

  • Page 360: Showing Job Properties

    Windows Software (CS2436-4) 4. 3. 14. Windows Software > Accounting > Showing Job Properties If you select a job in the job list and then select Show Job Properties in the File menu, the Job Properties dialog box appears, allowing you to check information such as detailed cost data.

  • Page 361: Showing, Saving And Loading Selected Unit Cost Data

    Windows Software (CS2436-4) 4. 3. 15. Windows Software > Accounting > Showing, Saving and Loading Selected Unit Cost Data Show Unit Cost Data Select Show Unit Cost Data in the File menu to open the Unit Cost Data dialog box. This lists the unit costs for items such as the selected ink and paper.

  • Page 362: Showing The Total Amount Of Ink And Paper Consumed

    Windows Software (CS2436-4) 4. 3. 16. Windows Software > Accounting > Showing the Total Amount of Ink and Paper Consumed Select Show Ink and Paper Consumed in the File menu to open the Show Ink and Paper Consumed dialog box.

  • Page 363: Device Setup Utility

    Windows Software (CS2436-4) 4. 4. 1. Windows Software > Device Setup Utility > Device Setup Utility Device Setup Utility is a utility to establish communication between the printer and your computer by completing relevant settings. After the printer is installed, for example, you can use Device Setup Utility to complete the network settings initially.
  • Page 364 Windows Software (CS2436-4) 4. 4. 2. Windows Software > Device Setup Utility > Installing Device Setup Utility Install Device Setup Utility from the User Software CD-ROM provided with the printer as follows: Important In Windows 2000/Windows XP/Windows Server 2003/Windows Vista/ Windows Server 2008, you must log on with administrative rights equivalent to the Administrator account.
  • Page 365 Windows Software (CS2436-4) 4. 4. 3. Windows Software > Device Setup Utility > Configuring the IP Address Using Device Setup Utility On a computer running Windows, you can use Device Setup Utility provided with the printer to configure the printer's IP address. This topic describes how to configure the IP address using Device Setup Utility.
  • Page 366 Windows Software (CS2436-4) When there is an IPv6-compatible router in the network environment, select On in Stateless Address. Additionally, when there is an DHCPv6-compatible server in the network environment, select On in DHCPv6. Note When there is no IPv6-compatible router or DHCPv6-compatible server, select On in Manual and enter the IPv6 Address and Prefix Length.
  • Page 367 Windows Software (CS2436-4)

  • Page 368: Mac Os X Software

    Mac OS X Software (CS2436-5) 5. Mac OS X Software 5. 1. Printer Driver Printer Driver Settings Specifying Paper in the Printer Driver Confirming Print Settings Using Favorites Accessing the Printer Driver Dialog Box from Applications Main Pane Paper Information on Printer Dialog Box...
  • Page 369 Mac OS X Software (CS2436-5) 5. 1. 1. Mac OS X Software > Printer Driver > Printer Driver Settings For instructions on accessing the Mac OS X printer driver, refer to the following topics. Accessing the Printer Driver Dialog Box from Applications (5.1.6) ●...
  • Page 370 Mac OS X Software (CS2436-5)
  • Page 371 Mac OS X Software (CS2436-5) 5. 1. 2. Mac OS X Software > Printer Driver > Specifying Paper in the Printer Driver If you have replaced the paper, you must complete the following settings in the printer driver. This sets the Format for and Paper Size.
  • Page 372 Mac OS X Software (CS2436-5) Printer list. Select the printer in the Choose the original size in the Paper Size list. If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
  • Page 373 Mac OS X Software (CS2436-5) In the Paper Source list, select how paper is supplied. If you have selected Manual in Paper Source, make sure the size as selected in Page Setup Page Size. If you have selected Roll Paper in...
  • Page 374 Mac OS X Software (CS2436-5) Note A variety of settings are available in the printer driver to suit different printing applications. For details on available printing conditions, see "Printer Driver Settings (5.1.1)"...
  • Page 375 Mac OS X Software (CS2436-5) 5. 1. 3. Mac OS X Software > Printer Driver > Confirming Print Settings There are two ways to confirm what printing conditions have been specified, as follows. Checking a preview of the settings ●...
  • Page 376 Mac OS X Software (CS2436-5) Paper size details are indicated Size tab is Pane displayed when the numerically. clicked Illustrations indicate the paper source, Pane with printer and paper orientation, borderless printing selection, illustrations and other settings information. Note To confirm the Print Target specified in Easy Settings, click View set.
  • Page 377 Mac OS X Software (CS2436-5)
  • Page 378 Mac OS X Software (CS2436-5) 5. 1. 4. Mac OS X Software > Printer Driver > Using Favorites You can use the Presets function in Mac OS X for favorite-based printing. Note In the printing dialog box, click Save As in the Presets list to save the current print settings.

  • Page 379: Accessing The Printer Driver Dialog Box From Applications (5.1.6)

    Mac OS X Software (CS2436-5) 5. 1. 5. Mac OS X Software > Printer Driver > Accessing the Printer Driver Dialog Box from Applications In the application software, select Print from the File menu to display the dialog box for printing conditions.
  • Page 380 Mac OS X Software (CS2436-5)

  • Page 381: Main Pane (5.1.7)

    Mac OS X Software (CS2436-5) 5. 1. 6. Mac OS X Software > Printer Driver > Main Pane The following settings are available on the Main pane. For details on settings items, refer to the printer driver help. Note On the Main pane, choose Easy Settings to specify basic print settings based on the print target, or switch to Advanced Settings to complete more detailed settings as desired.
  • Page 382 Mac OS X Software (CS2436-5) Displays Paper Detailed Settings. You can configure the printing settings to match the type of media, such as the ink drying time. Paper Detailed Settings Dialog Box (5.1.9) ● Printer Displays Printer. You can display printer information such as the remaining ink levels.
  • Page 383 Mac OS X Software (CS2436-5) Click to display the View settings dialog box, which enables you to confirm the settings for the selected item from the Print Target list or change the order of items listed in Print Target. View settings Dialog Box for the Printing Application (5.1.10) ●...

  • Page 384: Unidirectional Printing

    Mac OS X Software (CS2436-5) Adjusting the Color in the Printer Driver (3.1.1) ● Unidirectional Printing Select this checkbox to prevent problems such as misaligned lines and improve the print quality. However, the printing speed becomes slower. Thicken Fine Lines Activate this option to print fine lines more distinctly.
  • Page 385 Mac OS X Software (CS2436-5) 5. 1. 7. Mac OS X Software > Printer Driver > Paper Information on Printer Dialog Box On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and configure printer driver media type setting.

  • Page 386: Paper Detailed Settings Dialog Box (5.1.9)

    Mac OS X Software (CS2436-5) 5. 1. 8. Mac OS X Software > Printer Driver > Paper Detailed Settings Dialog Box The Paper Detailed Settings dialog box offers the following settings. For details on settings items, refer to the printer driver help.
  • Page 387 Mac OS X Software (CS2436-5) (See "Specifying the Ink Drying Time for Rolls (6.2.12)") ● Between Pages Specify the time the printer waits after printing a page until ejecting the paper, as needed. Between Scans Specify the time the printer waits after printing a line on the page until printing the next line, as needed.

  • Page 388: View Settings Dialog Box For The Printing Application (5.1.10)

    Mac OS X Software (CS2436-5) 5. 1. 9. Mac OS X Software > Printer Driver > View settings Dialog Box for the Printing Application In the View settings dialog box, you can check details of the selected printing application. Note To display the View settings dialog box, on the Main pane, click View settings by Print Target.(See "Main Pane (5.1.7)")

  • Page 389: Color Settings Pane: Color (5.1.11)

    Mac OS X Software (CS2436-5) 5. 1. 10. Mac OS X Software > Printer Driver > Color Settings Pane: Color In general, make any needed adjustments to the color of documents in the application used to create them. However, if the color tone as printed is not as you expected, you can also adjust the color in the printer driver.

  • Page 390: Matching Pane

    Mac OS X Software (CS2436-5) Apply to Sample Select this checkbox to apply the changed settings to the sample image. Cyan / Magenta / Yellow Correct color tones by adjusting the levels of each color. Gray Tone Adjust the color tone of grays as desired. Choose Cool (tinged with blue) or Warm (tinged with red).
  • Page 391 Mac OS X Software (CS2436-5) Note To display the Matching pane, on the Main pane click Color Settings by Color Mode in Advanced Settings, and then click Matching.(See "Main Pane (5.1.7)") Matching Mode Select the color matching mode to use, as desired.
  • Page 392 Mac OS X Software (CS2436-5) 5. 1. 11. Mac OS X Software > Printer Driver > Object Adjustment dialog box: Color In the Object Adjustment dialog box, you can specify what type of print jobs to apply color adjustment to. If an original comprises images, graphics, and text, you can specify which portion to apply color adjustment to.

  • Page 393: Color Settings Pane: Monochrome (5.1.13)

    Mac OS X Software (CS2436-5) 5. 1. 12. Mac OS X Software > Printer Driver > Color Settings Pane: Monochrome The following settings are available on the Color Settings pane for monochrome printing. Color Adjustment pane: Monochrome On the Color Adjustment pane for monochrome printing, you can adjust the brightness and contrast.
  • Page 394 Mac OS X Software (CS2436-5) Select this checkbox to apply the changed settings to the sample image. Cyan / Magenta / Yellow Not available. Gray Tone Not available. Brightness Adjust the overall image brightness as desired. You can adjust the brightness if the printed document is lighter or darker than the original image (that is, the original photo that was scanned or the original graphic as it appears on the computer screen).
  • Page 395 Mac OS X Software (CS2436-5) 5. 1. 13. Mac OS X Software > Printer Driver > Object Adjustment dialog box: Monochrome In the Object Adjustment dialog box, you can specify what type of print jobs to apply color adjustment to. If an original comprises images, graphics, and text, you can specify which portion to apply color adjustment to.

  • Page 396: Page Setup Pane (5.1.15)

    Mac OS X Software (CS2436-5) 5. 1. 14. Mac OS X Software > Printer Driver > Page Setup Pane The following settings are available on the Page Setup pane. For details on settings items, refer to the printer driver help.
  • Page 397 Mac OS X Software (CS2436-5) Resizing Originals to Fit the Roll Width (3.3.4) ● Resizing Originals by Entering a Scaling Value (3.3.7) ● Fit Paper Size Resizes the document image to match the paper size. Fit Roll Paper Width Resizes the document image to match the roll width.

  • Page 398: Utility Pane (5.1.16)

    Mac OS X Software (CS2436-5) 5. 1. 15. Mac OS X Software > Printer Driver > Utility Pane The following settings are available on the Utility pane. Click to display the Printer dialog box, which offers the following maintenance for the printer.

  • Page 399: Additional Settings Pane (5.1.17)

    Mac OS X Software (CS2436-5) 5. 1. 16. Mac OS X Software > Printer Driver > Additional Settings Pane The following settings are available on the Additional Settings pane. Data Send Method Choose how print data is sent to the printer.

  • Page 400: Support Pane (5.1.18)

    Mac OS X Software (CS2436-5) 5. 1. 17. Mac OS X Software > Printer Driver > Support Pane On the Support pane, you can view support information and the user's manual. Support Information Click to access the Océ support webpage, where you can find the latest information on the printer and consumables, check for printer driver updates, and browse other information.

  • Page 401: The Features Of Printmonitor

    Mac OS X Software (CS2436-5) 5. 2. 1. Mac OS X Software > Printmonitor > The Features of Printmonitor Printmonitor is a utility for checking the printer status and managing print jobs. Printer status can be checked in real time on a computer monitor.
  • Page 402 Mac OS X Software (CS2436-5) If the status of the desired printer is not shown in Printmonitor, select the printer again as follows. 1. Make sure the printer is on and connected to the network or to a local port.

  • Page 403: Job Management Using Printmonitor

    Mac OS X Software (CS2436-5) 5. 2. 2. Mac OS X Software > Printmonitor > Job Management Using Printmonitor You can use the Driver Panel in Printmonitor for operations such as pausing and canceling print jobs. Pausing/Resuming Print Jobs Selecting a print job and clicking the button pauses printing of the selected job.

  • Page 404: Printing Held Jobs

    Mac OS X Software (CS2436-5) You cannot cancel other users' print jobs. Printing Held Jobs Printing of the job with a Status of Holding is paused because the paper specified by the driver does not match the paper currently loaded in the printer.
  • Page 405 Mac OS X Software (CS2436-5)

  • Page 406: Handling Paper

    Handling Paper (CS2436-6) 6. Handling Paper 6. 1. Paper Types of Paper Paper Sizes 6. 2. Handling rolls Attaching the Roll Holder to Rolls Loading Rolls in the Printer Changing the Type of Paper Specifying the Paper Length Printing From a Desired Starting Point...

  • Page 407: Types Of Paper

    Handling Paper > Paper > Types of Paper For information on the types of paper the printer supports (such as plain paper, coated paper, glossy photo paper, proofing paper, and CAD paper), refer to www.mediaguide.oce.com Media Plain Paper - Océ Draft Paper (IJM005) - Océ...

  • Page 408: Paper Sizes

    Handling Paper (CS2436-6) 6. 1. 2. Handling Paper > Paper > Paper Sizes Rolls Rolls that meet the following conditions are supported. Outer diameter: Up to 150 mm (6 in) ● Inner diameter of paper core: 2 or 3 inches ●...
  • Page 409 Handling Paper (CS2436-6) ISO A4 210.0 × 297.0 mm (8.27 × 11.69 in) ISO B1 707.0 × 1000.0 mm (27.83 × 39.37 in) ISO B2 500.0 × 707.0 mm (19.69 × 27.83 in) ISO B3 353.0 × 500.0 mm (13.90 × 19.69 in) ISO B4 250.0 ×...
  • Page 410 Handling Paper (CS2436-6) 10"x15" 254.0 × 381.0 mm (10.00 × 15.00 in) US Photo 16"x20" 406.4 × 508.0 mm (16.00 × 20.00 in) Poster 20"x30" 508.0 × 762.0 mm (20.00 × 30.00 in) Poster 30"x40" 762.0 × 1016.0 mm (30.00 × 40.00 in) 13"x22"...

  • Page 411: Attaching The Roll Holder To Rolls

    Handling Paper (CS2436-6) 6. 2. 1. Handling Paper > Handling rolls > Attaching the Roll Holder to Rolls When printing on rolls, attach the Roll Holder to the roll. Rolls have a two- or three-inch paper core. Use the correct attachment for the paper core. The printer comes equipped with the 2-Inch Paper Core Attachment installed.
  • Page 412 Handling Paper (CS2436-6) For details on supported sizes and types of rolls, see Paper Sizes (See "Paper Sizes (6.1.2).") (See "Types of Paper (6.1.1).") To view instructions as you attach the Roll Holder, press the Navigate button. (See "How to View Instructions With Navigate (8.2.4).") Lift the Holder Stopper lever (a) from the shaft side to unlock it.
  • Page 413 Handling Paper (CS2436-6) Align the tips (a) of 3-Inch Paper Core Attachment R with the holes Align the tips (a) of the 3-Inch (b) of the Roll Holder and insert it Paper Core Attachment L with the firmly. holes (b) of the Holder Stopper and insert it firmly.
  • Page 414 Handling Paper (CS2436-6)

  • Page 415: Loading Rolls In The Printer

    Handling Paper (CS2436-6) 6. 2. 2. Handling Paper > Handling rolls > Loading Rolls in the Printer Follow these steps to load rolls in the printer. Note Before loading rolls, make sure the printer is clean inside the Top Cover and around the Ejection Guide.
  • Page 416 Handling Paper (CS2436-6) At this time, position the holder so that the R label (c) on the Roll Holder flange is aligned with the R label (d) on the printer . Holding the Roll Holder flange (a), guide the holder along the Roll Loading Slots (b) on both ends, keeping the holder level as you load it in the Roll Holder Slot.
  • Page 417 Handling Paper (CS2436-6) Do not force the Roll Holder into the printer with the right and left ends reversed. This may damage the printer and Roll Holder. Do not release the flanges until the holder is loaded in the Roll Holder Slot.
  • Page 418 Handling Paper (CS2436-6) The type and amount of paper left is automatically detected based on the Printed barcode printed on the roll. There is no need to specify the type and length of the paper. A menu for selection of the paper type and length is automatically shown on the Display Screen.
  • Page 419 Handling Paper (CS2436-6) 6. 2. 3. Handling Paper > Handling rolls > Changing the Type of Paper Follow these steps to change the type of paper specified on the printer after you have loaded paper. If you will continue using this type of paper later, selecting Keep Paper Type >On will save the time and effort of configuring the media type setting when you load the paper again.
  • Page 420 Handling Paper (CS2436-6) For details on types of paper. (See "Types of Paper (6.1.1).") By default, Plain Paper is selected. If you move the Release Lever, the setting automatically reverts to the previously selected paper. Be sure to select the correct paper type. If this setting does not match the loaded paper, it may cause feed errors and affect printing quality.

  • Page 421: Specifying The Paper Length

    Handling Paper (CS2436-6) 6. 2. 4. Handling Paper > Handling rolls > Specifying the Paper Length When changing the length of paper after the paper has been advanced, specify the length as follows. Note Specify the paper length when you have set ManageRemainRoll to On. (See "Keeping Track of the Amount of Roll Paper Left (6.2.11).")

  • Page 422: Printing From A Desired Starting Point

    Handling Paper (CS2436-6) 6. 2. 5. Handling Paper > Handling rolls > Printing From a Desired Starting Point When printing inside boundaries or in other situations when you want to specify a particular position to start printing from, set Width Detection to Off in the printer menu for the type of paper used.
  • Page 423 Handling Paper (CS2436-6) To start printing from the current position, close the Top Cover. To reposition the paper, push the Release Lever back. Keeping the right edge of the paper aligned with the extended line of the Paper Alignment Line (a) to the right of the ejection guide and the leading edge aligned with the groove (b) at the far end of the Platen, load the paper at the position from which to start printing.
  • Page 424 Handling Paper (CS2436-6) Pull the Release Lever forward and close the Top Cover.

  • Page 425: Removing The Roll From The Printer

    Handling Paper (CS2436-6) 6. 2. 6. Handling Paper > Handling rolls > Removing the Roll from the Printer Remove rolls from the printer as follows. Note If you need to cut the roll, see "Specifying the Cutting Method for Rolls (6.2.13)."...
  • Page 426 Handling Paper (CS2436-6) Using both hands, rotate the Roll Holder toward the back to rewind the roll. Holding the Roll Holder flange (a), remove the holder from the Roll Holder Slot. Note For instructions on removing the Roll Holder from rolls, see "Removing the Roll...
  • Page 427 Handling Paper (CS2436-6) Holding it at the positions indicated, close the Roll Cover. Note To load new paper in the printer at this point, see "Loading Rolls in the Printer (6.2.2)."...

  • Page 428: Removing The Roll Holder From Rolls

    Handling Paper (CS2436-6) 6. 2. 7. Handling Paper > Handling rolls > Removing the Roll Holder from Rolls Lift the Holder Stopper lever (a) from the shaft side to unlock it. Holding the Holder Stopper at the position indicated (b), remove it from the Roll Holder.
  • Page 429 Handling Paper (CS2436-6) 2-Inch Paper Core Attachment Important Store the roll in the original bag or box, away from high temperature, humidity, and direct sunlight. If paper is not stored properly, the printing surface may become scratched, which may affect the printing quality when you use it again.

  • Page 430: Clearing Jammed Roll Paper

    Handling Paper (CS2436-6) 6. 2. 8. Handling Paper > Handling rolls > Clearing Jammed Roll Paper If paper from a roll becomes jammed, "Paper jam." is shown on the Display Screen of the Control Panel. Remove the jammed paper as follows.
  • Page 431 Handling Paper (CS2436-6) Clear any jammed paper from inside the Top Cover. After removing the paper, make sure there are no other scraps of paper in the printer. Close the Top Cover. Important Do not move the Carriage over jammed paper. This may damage the Printhead.
  • Page 432 Handling Paper (CS2436-6) If paper from a roll is jammed by the Paper Feed Slot ● Open the Roll Cover. Remove the jammed paper from the Paper Feed Slot. After removing the paper, make sure there are no other scraps of paper in the printer.
  • Page 433 Handling Paper (CS2436-6) Pull the Release Lever forward. ●...
  • Page 434 Handling Paper (CS2436-6) 6. 2. 9. Handling Paper > Handling rolls > Clearing Jammed Paper (Paper Feed Slot) Follow these steps to remove any scraps left in the Paper Feed Slot after you clear jammed sheets or roll paper. Turn the printer off. (See "Turning the Printer On and Off (8.2.2).") Push the Release Lever back.
  • Page 435 Handling Paper (CS2436-6) Remove the scrap when it is pushed out onto the Platen. If any scraps remain inside the paper feed slot, repeat steps 4 and 5. Holding it at the positions indicated, close the Roll Cover. Pull the Release Lever forward.

  • Page 436: Feeding Roll Paper Manually

    Handling Paper (CS2436-6) 6. 2. 10. Handling Paper > Handling rolls > Feeding Roll Paper Manually After a roll has been advanced, you can press the Feed button to feed or retract the roll with the buttons. Press the Feed button.

  • Page 437: Keeping Track Of The Amount Of Roll Paper Left

    Handling Paper (CS2436-6) 6. 2. 11. Handling Paper > Handling rolls > Keeping Track of the Amount of Roll Paper Left Setting ManageRemainRoll to On in the Paper Menu of the Control Panel will print a barcode with text on the roll when the roll is removed that identifies the type of paper and amount left.

  • Page 438: Specifying The Ink Drying Time For Rolls

    Handling Paper (CS2436-6) 6. 2. 12. Handling Paper > Handling rolls > Specifying the Ink Drying Time for Rolls When you are using paper that takes longer for ink to adhere, if the Cutter touches printed surfaces that are still wet, it may damage the paper or cause rough cut edges.
  • Page 439 Handling Paper (CS2436-6) Mac OS X Choose Print in the application menu. Select the Main pane and click Settings in Media Type.
  • Page 440 Handling Paper (CS2436-6) In the Paper Detailed Settings dialog box displayed next, select the desired settings values in Between Pages and Between Scans in Drying Time, and then click OK. (See "Paper Detailed Settings Dialog Box (Mac OS X) (5.1.9).")
  • Page 441 Handling Paper (CS2436-6) Note By factory default, Drying Time is deactivated ( Off ) for all paper types. To have the printer wait for ink to dry immediately after printing without releasing paper, set Cutting Mode to Eject in the printer menu.

  • Page 442: Specifying The Cutting Method For Rolls

    Handling Paper (CS2436-6) 6. 2. 13. Handling Paper > Handling rolls > Specifying the Cutting Method for Rolls How rolls are cut after ejection varies depending on printer settings. Cutting Method Printer Setting Driver Setting The roll is automatically cut by...
  • Page 443 Handling Paper (CS2436-6) want to cut the roll edge after loading a roll. Note Automatic and Eject are valid only when you have selected Auto Cut >Yes in the printer driver. With Eject, printing does not resume after a series of jobs have been printed continuously until the roll is cut.
  • Page 444 Handling Paper (CS2436-6) Press the OK button. The Paper Menu is displayed. to select Paper Details, and then press the OK button. Press to select the type of paper, and then press the OK button. Press to select Cutting Mode, and then press the OK button.
  • Page 445 Handling Paper (CS2436-6) to select the type of paper, and then press the OK button. Press to select Cutting Mode, and then press the OK button. Press Press to select Manual, and then press the OK button. Starts printing. The printer stops advancing the paper after printing.
  • Page 446 Handling Paper (CS2436-6) Press the Feed button. Press the button to advance the roll to the position for cutting. Press the Cut button. to select Yes, and then press the OK button. Press After the roll paper is cut, it is rewound automatically.

  • Page 447: Cutting The Leading Edge Of Roll Paper Automatically

    Handling Paper (CS2436-6) 6. 2. 14. Handling Paper > Handling rolls > Cutting the Leading Edge of Roll Paper Automatically If the leading edge of a roll is crooked or warped, it may cause an error message or printing problems. In this case, set Trim Edge First to Automatic or On in the Paper Menu on the Control Panel to have the printer cut the leading edge to make the edge straight after you load a roll.
  • Page 448 Handling Paper (CS2436-6) Press the OK button. The Paper Menu is displayed. Press to select Paper Details, and then press the OK button. Press to select the type of paper, and then press the OK button. to select Trim Edge First, and then press the OK button.

  • Page 449: Reducing Dust From Cutting Rolls

    Handling Paper (CS2436-6) 6. 2. 15. Handling Paper > Handling rolls > Reducing Dust from Cutting Rolls For media such as Backlit Film that are more likely to generate debris when cut, select CutDustReduct. >On in the Paper Menu of the Control Panel. This option reduces debris from cutting by printing black lines at the leading and trailing edges of documents.

  • Page 450: Roll Holder Set

    Handling Paper (CS2436-6) 6. 2. 16. Handling Paper > Handling rolls > Roll Holder Set Load a roll on the roll holder and then load the holder in the printer. The Roll Holder in the Roll Holder Set 29951312 is for use with both 2-inch and 3-inch paper cores. Use the correct attachment for the particular paper core.

  • Page 451: Loading Sheets In The Printer

    Handling Paper (CS2436-6) 6. 3. 1. Handling Paper > Handling sheets > Loading Sheets in the Printer Follow these steps to load sheets in the printer. Important One sheet of paper can be loaded in the Paper Feed Slot at a time. Do not load more than one sheet at a time.
  • Page 452 Handling Paper (CS2436-6) Load a single sheet printing-side up in the Paper Feed Slot, with the right edge aligned with the Paper Alignment ● Guide (a) to the right of the Roll Cover. Insert the paper until the leading edge makes contact and you hear a tone.
  • Page 453 Handling Paper (CS2436-6) Press the OK button. ● If a print job was received ● The printer now starts printing the print job. If no print job was received ● A menu for selection of the type of paper is automatically shown on the Display Screen.
  • Page 454 Handling Paper (CS2436-6) 6. 3. 2. Handling Paper > Handling sheets > Changing the Type of Paper Follow these steps to change the type of paper specified on the printer after you have loaded paper. If you will continue using this type of paper later, selecting Keep Paper Type >On will save the time and effort of configuring the media type setting when you load the paper again.
  • Page 455 Handling Paper (CS2436-6) For details on types of paper (See "Types of Paper (6.1.1).") By default, Plain Paper is selected. If you move the Release Lever, the setting automatically reverts to the previously selected paper. Be sure to select the correct paper type. If this setting does not match the loaded paper, it may cause feed errors and affect printing quality.
  • Page 456 Handling Paper (CS2436-6) 6. 3. 3. Handling Paper > Handling sheets > Printing From a Desired Starting Point When printing inside boundaries or in other situations when you want to specify a particular position to start printing from, set Width Detection to Off in the printer menu for the type of paper used.
  • Page 457 Handling Paper (CS2436-6) To start printing from the current position, close the Top Cover. To reposition the paper, push the Release Lever back. Keeping the right edge of the paper aligned with the extended line of the Paper Alignment Line (a) to the right of the ejection guide and the leading edge aligned with the groove (b) at the far end of the Platen, load the paper at the position from which to start printing.
  • Page 458 Handling Paper (CS2436-6) Pull the Release Lever forward and close the Top Cover.

  • Page 459: Removing Sheets

    Handling Paper (CS2436-6) 6. 3. 4. Handling Paper > Handling sheets > Removing Sheets Remove sheets from the printer as follows. On the Tab Selection screen of the Control Panel, press to select the Paper tab ( Note If the Tab Selection screen is not displayed, press the Menu button.
  • Page 460 Handling Paper (CS2436-6)

  • Page 461: Clearing A Jammed Sheet

    Handling Paper (CS2436-6) 6. 3. 5. Handling Paper > Handling sheets > Clearing a Jammed Sheet If a sheet becomes jammed, "Paper jam." is shown on the Display Screen of the Control Panel. Remove the jammed paper as follows. Push the Release Lever back.
  • Page 462 Handling Paper (CS2436-6) Important Do not move the Carriage over jammed paper. This may damage the Printhead. Do not touch the Linear Scale (a) or Carriage Shaft (b). This may stain your hands and damage the printer. If the paper is jammed by the Paper Feed Slot ●...
  • Page 463 Handling Paper (CS2436-6) If the paper is jammed by the Ejection Guide ● Remove the jammed paper from the Output Tray. After removing the paper, make sure there are no other scraps of paper in the printer. Pull the Release Lever forward.
  • Page 464 Handling Paper (CS2436-6) 6. 3. 6. Handling Paper > Handling sheets > Clearing Jammed Paper (Paper Feed Slot) Follow these steps to remove any scraps left in the Paper Feed Slot after you clear jammed sheets or roll paper. Turn the printer off. (See "Turning the Printer On and Off (8.2.2).") Push the Release Lever back.
  • Page 465 Handling Paper (CS2436-6) Remove the scrap when it is pushed out onto the Platen. If any scraps remain inside the paper feed slot, repeat steps 4 and 5. Holding it at the positions indicated, close the Roll Cover. Pull the Release Lever forward.

  • Page 466: Using The Output Stacker

    Handling Paper (CS2436-6) 6. 4. 1. Handling Paper > Output Stacker > Using the Output Stacker The Output Stacker can be held at two positions, as shown. When storing printed documents on the Output Stacker ● Use position (1). When the Output Stacker is not used, or when moving the printer ●...

  • Page 467: Note Regarding The Extended Position

    Handling Paper (CS2436-6) When storing printed documents on the Output Stacker, always use it in position (1). If you do not, printed documents may not be dropped into the Output Stacker, and the printed surface may become soiled. When moving the printer, always lift the Support Rod to the Extended position before use in position (2).
  • Page 468 Handling Paper (CS2436-6) When using rolls larger than A1 or 24 inches wide, pull out the Adjustable Stopper.

  • Page 469: Adjustments For Better Print Quality

    Adjustments for Better Print Quality (CS2436-7) 7. Adjustments for Better Print Quality 7. 1. Adjusting the Printhead Adjusting the Printhead Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.) Manual Adjustment to Straighten Lines and Colors (Head Posi. Adj.) Adjusting Line Misalignment (Head Inc.
  • Page 470 Adjustments for Better Print Quality (CS2436-7) 7. 1. 1. Adjustments for Better Print Quality > Adjusting the Printhead > Adjusting the Printhead If printed documents are affected by the following problems, try adjusting the printhead. Printing is faint or affected by banding in different colors ●...

  • Page 471: Automatic Adjustment To Straighten Lines And Colors (Head Posi. Adj)

    Adjustments for Better Print Quality (CS2436-7) 7. 1. 2. Adjustments for Better Print Quality > Adjusting the Printhead > Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.) If printed vertical lines are warped or colors are out of alignment, execute Head Posi. Adj. to adjust the Printhead alignment.
  • Page 472 Adjustments for Better Print Quality (CS2436-7) When printing on special paper, or if printing is not improved after Auto (Advanced), try Manual. (See "Manual Adjustment to Straighten Lines and Colors (Head Posi. Adj.) (7.1.3).") Use Auto(Standard) if you have switched to another type of paper or if you want the boundaries between colors to appear as clear as possible.
  • Page 473 Adjustments for Better Print Quality (CS2436-7) to select Adjust Printer, and then press the OK button. Press Press to select Head Posi. Adj., and then press the OK button. to select Auto(Standard) or Auto(Advanced), and then press the OK Press button.

  • Page 474: Manual Adjustment To Straighten Lines And Colors (Head Posi. Adj)

    Adjustments for Better Print Quality (CS2436-7) 7. 1. 3. Adjustments for Better Print Quality > Adjusting the Printhead > Manual Adjustment to Straighten Lines and Colors (Head Posi. Adj.) If printed vertical lines are warped or colors are out of alignment, execute Head Posi. Adj. to adjust the Printhead alignment.
  • Page 475 Adjustments for Better Print Quality (CS2436-7) Attaching the Roll Holder to Rolls (6.2.1) ● Loading Rolls in the Printer (6.2.2) ● Loading Sheets in the Printer (6.3.1) ● On the Tab Selection screen of the Control Panel, press to select the Settings/ Adj.
  • Page 476 Adjustments for Better Print Quality (CS2436-7) Note If two patterns seem equally good and you cannot decide which one is better, choose an intermediate value. For example, choose 11 if you cannot decide whether pattern 10 or 12 is better.

  • Page 477: Adjusting Line Misalignment (Head Inc. Adj)

    Adjustments for Better Print Quality (CS2436-7) 7. 1. 4. Adjustments for Better Print Quality > Adjusting the Printhead > Adjusting Line Misalignment (Head Inc. Adj.) If printed lines are misaligned, execute Head Inc. Adj. to adjust the angle of inclination of the Printhead.
  • Page 478 Adjustments for Better Print Quality (CS2436-7) to select Adjust Printer, and then press the OK button. Press to select Head Inc. Adj., and then press the OK button. Press After the Carriage is moved, a message is displayed requesting you to open the Top Cover.
  • Page 479 Adjustments for Better Print Quality (CS2436-7) If you accidentally move the Carriage, you will hear a warning tone. In this case, close the Top Cover. Examine the test pattern for adjustment. Determine the straightest set of lines. Open the Top Cover and move the Angle Adjustment Lever to match the number (or the square) of the straightest set of lines.
  • Page 480 Adjustments for Better Print Quality (CS2436-7) Close the Top Cover. The Printhead is now straight, and adjustment is complete.
  • Page 481 Adjustments for Better Print Quality (CS2436-7) 7. 1. 5. Adjustments for Better Print Quality > Adjusting the Printhead > Troubleshooting Paper Abrasion and Blurry Images (Head Height) If the Printhead rubs against paper during printing, adjusting the Printhead height may improve results.
  • Page 482 Adjustments for Better Print Quality (CS2436-7)

  • Page 483: Adjusting The Feed Amount

    Adjustments for Better Print Quality (CS2436-7) 7. 2. 1. Adjustments for Better Print Quality > Adjusting the feed amount > Adjusting the Feed Amount If printed documents are affected by the following problems, try adjusting the feed amount. Banding in different colors ●...

  • Page 484: Selecting A Feed Amount Adjustment Method (Feed Priority)

    Adjustments for Better Print Quality (CS2436-7) 7. 2. 2. Adjustments for Better Print Quality > Adjusting the feed amount > Selecting a Feed Amount Adjustment Method (Feed Priority) Methods of adjusting the amount paper is fed are set in Adj. Priority.
  • Page 485 Adjustments for Better Print Quality (CS2436-7) Note If the Tab Selection screen is not displayed, press the Menu button. Press the OK button. The Set./Adj. Menu is displayed. to select Adjust Printer, and then press the OK button. Press to select Feed Priority, and then press the OK button.

  • Page 486: Manual Banding Adjustment (Adj. Quality)

    Adjustments for Better Print Quality (CS2436-7) 7. 2. 3. Adjustments for Better Print Quality > Adjusting the feed amount > Manual Banding Adjustment (Adj. Quality) If printed images are affected by banding in different colors, execute Adj. Quality for adjustment of the paper feed amount.
  • Page 487 Adjustments for Better Print Quality (CS2436-7) On the Tab Selection screen of the Control Panel, press to select the Settings/ Adj. tab ( Note If the Tab Selection screen is not displayed, press the Menu button. Press the OK button.
  • Page 488 Adjustments for Better Print Quality (CS2436-7) Press to select the pattern number you have decided, and then press the OK button. Test pattern B is printed for adjustment. Note If you printed test pattern A on a sheet, follow the instructions on the Display Screen and use another sheet of the same type of paper.

  • Page 489: Fine-Tuning The Paper Feed Amount (Adj. Fine Feed)

    Adjustments for Better Print Quality (CS2436-7) 7. 2. 4. Adjustments for Better Print Quality > Adjusting the feed amount > Fine-Tuning the Paper Feed Amount (Adj. Fine Feed) If the contrast is uneven or banding in different colors appears at 50 mm (2.0 in) intervals in printed documents, try executing Adj.

  • Page 490: Adjusting Line Length (Adjust Length)

    Adjustments for Better Print Quality (CS2436-7) 7. 2. 5. Adjustments for Better Print Quality > Adjusting the feed amount > Adjusting Line Length (Adjust Length) To ensure that lines in CAD drawings are printed at exactly the right length, use Adjust Length to adjust the amount that paper is advanced.
  • Page 491 Adjustments for Better Print Quality (CS2436-7) Loading Rolls in the Printer (6.2.2) ● Loading Sheets in the Printer (6.3.1) ● Note Always make sure the loaded paper matches the type of paper specified. Adjustment cannot be completed correctly unless the loaded paper matches the settings.
  • Page 492 Adjustments for Better Print Quality (CS2436-7) Note A test pattern is printed in black when you choose A:High or in magenta if you choose B:Standard/Draft. To cancel printing the test pattern for adjustment, hold down the Stop button. When "Stop printing?" is displayed, press select "Yes", and then press the OK button.

  • Page 493: Adjusting The Vacuum Strength (Vacuumstrngth)

    Adjustments for Better Print Quality (CS2436-7) 7. 2. 6. Adjustments for Better Print Quality > Adjusting the feed amount > Adjusting the Vacuum Strength (VacuumStrngth) When printing on heavyweight paper or paper that curls or wrinkles easily, if the Printhead rubs against paper, adjusting the level of suction against paper on the Platen may improve results.

  • Page 494: Printer Parts

    Printer Parts (CS2436-8) 8. Printer Parts 8. 1. Printer parts Front Side Top Cover (Inside) Roll Cover (Inside) Carriage Ink Tank Cover (Inside) Stand Control Panel 8. 2. Control Panel Control Panel Turning the Printer On and Off Control Panel Display...
  • Page 495 Printer Parts (CS2436-8) 8. 1. 1. Printer Parts > Printer parts > Front Roll Cover Open this cover to load rolls. (See "Roll Cover (Inside) (8.1.4).") Paper Feed Slot When loading paper, insert it here. Roll Ledge When loading rolls, rest the Roll Holder here before loading it in the Roll Holder Slot.
  • Page 496 Printer Parts (CS2436-8) Top Cover Open this cover to install the Printhead and remove any jammed paper from inside the printer, as needed. (See "Top Cover (Inside) (8.1.3).") Width Guide When loading the sheets , move the guide to match the paper size.
  • Page 497 Printer Parts (CS2436-8) 8. 1. 2. Printer Parts > Printer parts > Side Manual Pocket Store printer manuals in this pocket. Ethernet Port Connect an Ethernet cable to this port. The lamp is lit if the Ethernet cable is connected correctly and communication is possible between the computer and printer.

  • Page 498: Top Cover (Inside)

    Printer Parts (CS2436-8) 8. 1. 3. Printer Parts > Printer parts > Top Cover (Inside) Carriage Moves the Printhead. The carriage serves a key role in printing. (See "Carriage (8.1.5).") Carriage Shaft The Carriage slides along this shaft. Paper Retainer Important in supplying the paper.

  • Page 499: Roll Cover (Inside)

    Printer Parts (CS2436-8) 8. 1. 4. Printer Parts > Printer parts > Roll Cover (Inside) Roll Holder Load the roll on this holder. Holder Stopper Secure rolls on the Roll Holder with this part. Roll Loading Slots Slide the Roll Holder along these slots.
  • Page 500 Printer Parts (CS2436-8) 8. 1. 5. Printer Parts > Printer parts > Carriage Angle Adjustment Lever Use this lever to fine-tune the printer to correct misalignment of printed lines. Printhead The printhead is equipped with ink nozzles. The carriage serves a key role in printing.

  • Page 501: Ink Tank Cover (Inside)

    Printer Parts (CS2436-8) 8. 1. 6. Printer Parts > Printer parts > Ink Tank Cover (Inside) Left Side Right Side Ink Tank Lock Lever A lever that locks the Ink Tank in place and protects it. Lift and press down the lever when replacing an Ink Tank.
  • Page 502 Printer Parts (CS2436-8) 8. 1. 7. Printer Parts > Printer parts > Stand Accessory Pocket Stores printer accessories. Output Stacker Printed documents are ejected into the output tray. Locking Caster Lock to immobilize the caster. Before moving the printer, always unlock all four casters. Moving the printer while casters are locked may scratch the casters or the floor.

  • Page 503: Control Panel

    Printer Parts (CS2436-8) 8. 1. 8. Printer Parts > Printer parts > Control Panel Display Screen Shows printer menus, as well as the printer status and messages. Data Lamp (green) Flashing ● During printing, the Data lamp flashes when the printer is receiving or processing print jobs. Otherwise, this lamp flashes when the print job is paused or the printer is updating the firmware.
  • Page 504 Printer Parts (CS2436-8) item, enabling you to execute menu commands or set menu values. Also press this button if the Display Screen indicates to press the OK button. Back button Displays the screen before the current screen. Menu button Displays the Tab Selection screen. (See "Menu Settings (8.2.8).") Load button Press this button when loading or replacing paper.
  • Page 505 Printer Parts (CS2436-8) 8. 2. 1. Printer Parts > Control Panel > Control Panel Display Screen Shows printer menus, as well as the printer status and messages. Data Lamp (green) Flashing ● During printing, the Data lamp flashes when the printer is receiving or processing print jobs. Otherwise, this lamp flashes when the print job is paused or the printer is updating the firmware.
  • Page 506 Printer Parts (CS2436-8) item, enabling you to execute menu commands or set menu values. Also press this button if the Display Screen indicates to press the OK button. Back button Displays the screen before the current screen. Menu button Displays the Tab Selection screen. (See "Menu Settings (8.2.8).") Load button Press this button when loading or replacing paper.

  • Page 507: Turning The Printer On And Off

    Printer Parts (CS2436-8) 8. 2. 2. Printer Parts > Control Panel > Turning the Printer On and Off Turning the printer on Press the Power button to turn on the printer. The printer will now start up. After the Display Screen shows the Océ logo, "Starting up... Please wait." is displayed.
  • Page 508 Printer Parts (CS2436-8) Important Never disconnect the printer's power supply or unplug it during a print job. This may damage the printer. Make sure no print jobs are in progress. If the Message Lamp is flashing, check the message on the Display Screen and take action as necessary. (See "Error Messages.")

  • Page 509: Control Panel Display

    Printer Parts (CS2436-8) 8. 2. 3. Printer Parts > Control Panel > Control Panel Display After the printer starts up, the Tab Selection screen is displayed. Each of the four tabs presents status, menus, and error information related to the particular tab.

  • Page 510: Mode Transition

    Printer Parts (CS2436-8) Printing is paused on the printer. Any jobs sent from the computer are held without being printed. Printing Printing is in progress on the printer. Jobs sent from the computer are printed after the current job. The time left until printing is finished is indicated in the upper-right corner of the screen.
  • Page 511 Printer Parts (CS2436-8) *1: The printer automatically enters Sleep mode when idle for a specific period (by default, five minutes), that is, if no print jobs are received or buttons are pressed while all covers are closed. However, it does not enter Sleep mode while error messages are displayed.

  • Page 512: How To View Instructions With Navigate

    Printer Parts (CS2436-8) 8. 2. 4. Printer Parts > Control Panel > How to View Instructions With Navigate You can refer to instructions for loading paper, replacing ink tanks, and performing other operations on the printer control panel. Press the Navigate button.

  • Page 513: Printer Menu Operations

    Printer Parts (CS2436-8) 8. 2. 5. Printer Parts > Control Panel > Printer Menu Operations The printer menu is classified into menu items available when no print job is in progress and menu items only available during printing. Menu operations when no print job is in progress ●...

  • Page 514: Menu Operations

    Printer Parts (CS2436-8) 8. 2. 6. Printer Parts > Control Panel > Menu Operations To view available menus organized on tabs, select a tab on the Tab Selection screen and press the OK button. For details, see "Menu Settings (8.2.8)."...
  • Page 515 Printer Parts (CS2436-8) Specifying menu items Menu items can be set as follows. Press to select the desired setting, and then press the OK button. After two seconds, the display reverts to the upper level menu. Note If a confirmation message is displayed regarding the setting you entered, press the OK button. The setting is applied, and the printer is now in Standby.
  • Page 516 Printer Parts (CS2436-8) to select the action to execute, and then press the OK button. Press The menu command is now executed.

  • Page 517: Menu Structure

    Printer Parts (CS2436-8) 8. 2. 7. Printer Parts > Control Panel > Menu Structure The menu structure is organized by tabs, as follows. Values at right indicated by an asterisk are the defaults. Paper Menu ● Ink Menu ● Job Menu ●...
  • Page 518 Printer Parts (CS2436-8) CutDustReduct. VacuumStrngth Automatic * Strongest Strong Standard Weak Weakest Scan Wait Time 1 sec. 3 sec. 5 sec. 7 sec. 9 sec. Roll DryingTime 30 sec. 1 min. 3 min. 5 min. 10 min. 30 min. 60 min.
  • Page 519 Printer Parts (CS2436-8) Job Menu First Level Second Level Third Level Fourth Level Fifth Level (Choose from information Job Log about the latest three Document Name print jobs.) User Name Page Count Job Status CANCELED Print Start Time yyyy/mm/dd hh:mm:ss...
  • Page 520 Printer Parts (CS2436-8) Adjust Length (*3) AdjustmentPrint A:High Standard/ Draft Change Settings A:High Standard/ Draft Adj. Fine Feed (*2) Maintenance Head Cleaning Head Cleaning A Head Cleaning B Nozzle Check Replace P.head Repl. maint cart Head Info ProductName: s/n: Days elapsed:...
  • Page 521 Printer Parts (CS2436-8) Line & Pen Enable merge Off * Manager Software Pen Setup Select Palette Palette A Palette B Factory (Select (Indicates Define Palette Palette A Width the pen the value of Width ) number) Color 0-255 Line No Setting...
  • Page 522 Printer Parts (CS2436-8) 10 min. * 30 min. 60 min. TCP/IP (*8) IPv4 IPv4 Mode Automatic Manual * Protocol (*4) DHCP Off * BOOTP Off * RARP Off * IPv4 Settings xxx.xxx. (*9) Address xxx.xxx Subnet xxx.xxx. Mask xxx.xxx Default G/ xxx.xxx.
  • Page 523 Printer Parts (CS2436-8) Spanning Tree Not Use * MAC Address xxxxxxxxxxxx Interface Print (*8) Return Defaults (*8) System Sleep Timer 5 min. * Setup 10 min. 15 min. 20 min. 30 min. 40 min. 50 min. 60 min. 240 min.
  • Page 524 Printer Parts (CS2436-8) +9:Tokyo,Seoul +10:Canberra +11NewCaledonia +12:Wellington -12:Eniwetok -11:Midway is. -10Hawaii(AHST) -9:Alaska(AKST) -8:Oregon (PST) -7:Arizona(MST) -6:Texas (CST) -5:NewYork(EST) -4:Santiago -3:Buenos Aires -1:Cape Verde Length Unit meter * feet/inch Detect Mismatch Pause Warning None * ISO A3 Paper Size Basis Roll Selection 1...
  • Page 525 Printer Parts (CS2436-8) Admin. Change Menu (*8) Password (*9) Init.Admin.Pswd (*9) Printer Info Paper Info Ink Info Head Info System Info Error Log Other Counter *1: Available after you have used Auto(Advanced) in Head Posi. Adj. once. *2: Available if Adj. Priority is Automatic or Print Quality.

  • Page 526: Menu Settings

    Printer Parts (CS2436-8) 8. 2. 8. Printer Parts > Control Panel > Menu Settings Menu items are as follows. For instructions on selecting menu items, see "Menu Operations (8.2.6)." For details on menu levels and values, see "Menu Structure (8.2.7)."...
  • Page 527 Printer Parts (CS2436-8) Paper Details (The type of Specify the time to wait for the ink to dry between paper is displayed each scan in bidirectional printing, in consideration Scan Wait Time here.)(*1) of how quickly the ink dries. Note that printing will take longer if you specify a wait time.
  • Page 528 Printer Parts (CS2436-8) Indicates the document name in the last Document Name print job. Indicates the name of the user who sent User Name the print job. Page Count Indicates the number of pages in the job. Job Status Indicates the printing results.
  • Page 529 Printer Parts (CS2436-8) The printer prints and reads a test pattern for the automatic adjustment of Printhead alignment relative to the Head Posi. Adj. printing direction and spacing Auto(Advanced) between nozzles and colors. (See "Automatic Adjustment to Straighten Lines and Colors (Head Posi.
  • Page 530 Printer Parts (CS2436-8) Standard/ Draft Adjust Displayed when you have selected Length Feed Priority >Adj. Priority >Print A:High Length. Adjustment relative to the amount of stretching or shrinkage of the current paper. Enter either the adjustment results from AdjustmentPrint or the...
  • Page 531 Printer Parts (CS2436-8) Print emulating the following printers, Color in colors resembling colors produced Mode by these printers: Océ iPF500, iPF600, Color (CAD) 3 iPF700, iPF510, iPF610, iPF710, iPF605, iPF720, iPF810, and iPF820. (*2) Quality Manager Print emulating the HP Designjet...
  • Page 532 Printer Parts (CS2436-8) GL2 Settings Specify the Width, Color, and Line Attributes in the palette Pen no.. Choose Factory to confirm the values when Factory is selected in Select Palette. Setup In Line Attributes, choose No Setting or Circle Setting as the processing for the ends and junctions of lines.
  • Page 533 Printer Parts (CS2436-8) If fine lines are printed in colors that do not match the colors of other shapes, selecting Off may help AdjustFaintLines produce the expected results. However, lines in some colors may appear broken. Select On to have any GL2-related Warning warnings displayed.
  • Page 534 Printer Parts (CS2436-8) Choose the LAN communication Comm.Mode method. Ethernet Type Choose the LAN transfer rate. Choose whether spanning-tree Spanning Tree packets are supported over the LAN. MAC Address Indicates the MAC address. Interface Print Print interface settings information. Choose OK to restore Interface Return Defaults Setup settings to the default values.
  • Page 535 Printer Parts (CS2436-8) Setup Choose On to use the paper size setting as the basis for printing instead of other settings. The margin setting of the printer menu will be used instead of the margin setting of the printer driver if the latter is...
  • Page 536 Printer Parts (CS2436-8) Select this option when transferring the printer to another location. Follow the instructions displayed to complete the required procedure. (See "Preparing to Transfer the Prep.MovePrinter Printer (10.5.1).") Not displayed during a warning message that the remaining Maintenance Cartridge capacity is low.

  • Page 537: Menu Settings (During Printing)

    Printer Parts (CS2436-8) 8. 2. 9. Printer Parts > Control Panel > Menu Settings (During Printing) Menu items are described in the following tables. For instructions on selecting menu items, see "Menu Operations (8.2.6)." For details on menu levels and values, see "Menu Structure (8.2.7)."...
  • Page 538 Printer Parts (CS2436-8) Indicates the model name, serial number, number of days used, and dot count Printer Info Head Info of the current printhead. System Info Indicates the firmware version, serial number, and interface information. Error Log Indicates the most recent error messages (up to five).

  • Page 539: Status Print

    Printer Parts (CS2436-8) 8. 2. 10. Printer Parts > Control Panel > Status Print You can print a Status Print report indicating the current status of the printer. With Status Print, information is printed regarding the printer firmware version, various settings, and the status of consumables.
  • Page 540 Printer Parts (CS2436-8) Set./Adj. Menu System settings. System Setup Sleep Timer Buzzer Contrast Adj. Date Format Language Printer system settings, as well as settings Time Zone regarding warnings and errors. Length Unit Detect Mismatch Paper Size Basis Roll Selection 1...

  • Page 541: Printing Interface Setting Reports

    Printer Parts (CS2436-8) 8. 2. 11. Printer Parts > Control Panel > Printing Interface Setting Reports You can print an Interface Print report indicating the current interface settings values of the printer. Interface Print reports indicate settings values for TCP/IP, NetWare, and other settings.
  • Page 542 Printer Parts (CS2436-8) Subnet Mask Gateway Address LPD Printing IPP Printing IPv4 settings IPP Printer URI TCP/IPv4 values. RAW Printing Raw Mode Bi-direction FTP Printing Use Discovery Scope Primary DNS Server Address Secondary DNS Server Address DNS Host Name DNS Domain Name...
  • Page 543 Printer Parts (CS2436-8) IP Address Prefix Length Default Router Address Use a manual Prefix Length address Primary DNS Server Address Secondary DNS Server Address Use the same DNS Host Name host name DNS Domain and domain Name name as IPv4...
  • Page 544 Printer Parts (CS2436-8) AppleTalk settings values. Network Number Zone Physical Interface Transmission Rate Settings values MAC Address regarding the Auto Detect communication Network path used for Communication Interface sending and Ethernet Type receiving messages. Spanning Tree Use the Jumbo Frame...

  • Page 545: Checking Instructions During Printer Operations

    Printer Parts (CS2436-8) 8. 2. 12. Printer Parts > Control Panel > Checking Instructions During Printer Operations You can refer to instructions on the printer control panel when loading paper, replacing ink tanks, or performing other operations. How to view instructions Once you complete an action described in the instructions, the printer detects the action and switches to the next instruction screen.
  • Page 546 Printer Parts (CS2436-8) 8. 3. 1. Printer Parts > Optional accessories > Roll Holder Set Load a roll on the roll holder and then load the holder in the printer. The Roll Holder in the Roll Holder Set 29951312 is for use with both 2-inch and 3-inch paper cores. Use the correct attachment for the particular paper core. (See "Attaching the Roll Holder to Rolls (6.2.1).")

  • Page 547: Specifications

    Printer Parts (CS2436-8) 8. 4. 1. Printer Parts > Printer Specifications > Specifications Important This information is subject to change as the printer is updated. The following values may vary depending on the operating environment. Printer 100–120 V AC (50/60 Hz), 220–240 V AC...
  • Page 548 Printer Parts (CS2436-8) IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX/Auto-Negotiation, IEEE Specification 802.3ab1000Base-T/Auto-Negotiation, IEEE 802.3x Full Duplex Protocols IPX/SPX (Netware 4.2, 5.1, 6.0), SNMP, TCP/IP, AppleTalk, HTTP *1: Use in USB 2.0 High Speed mode requires the following environment: Computer: USB 2.0 High-Speed–compatible ●...
  • Page 549 Printer Parts (CS2436-8) Printable area Rolls 3 mm (0.12 in) from each side Sheets Normal size 3 mm (0.12 in) from the top, 23 mm (0.91 in) from the bottom, and 3mm (0.12 in) from the left and right sides Print area For information on the recommended print area, see "Print...

  • Page 550: Print Area

    Printer Parts (CS2436-8) 8. 4. 2. Printer Parts > Printer Specifications > Print Area A margin required by the printer is added with respect to the size of paper loaded in the printer. Except in borderless printing, the actual printing area corresponds to the paper size minus the space for this margin.

  • Page 551: Network Setting

    Network Setting (CS2436-9) 9. Network Setting 9. 1. Network Setting Network Environment Configuring the IP Address on the Printer Configuring the IP Address Using Device Setup Utility Configuring the IP Address Using the Printer Control Panel Configuring the IP Address Using ARP and PING Commands...

  • Page 552: Network Environment

    Network Setting (CS2436-9) 9. 1. 1. Network Setting > Network Setting > Network Environment System requirements The system requirements, which vary depending on your network, are as follows. Printing over a TCP/IP network (when using IPv4) ● Compatible operating systems ●...
  • Page 553 Network Setting (CS2436-9) Printing over an AppleTalk network ● Compatible operating systems ● Mac OS X 10.2.8–10.4 ● Compatible computer ● A computer that runs one of the above operating systems ● Note The printer cannot be used over a LocalTalk network.
  • Page 554 Network Setting (CS2436-9) Note NetBIOS is not supported. Example of a Macintosh network ● In Macintosh networks, print over AppleTalk (EtherTalk) or TCP/IP, using Bonjour (Zeroconf) functions. Note The printer driver is not compatible with AppleTalk. Example of a NetWare network ●...

  • Page 555: Configuring The Ip Address On The Printer

    Network Setting (CS2436-9) 9. 1. 2. Network Setting > Network Setting > Configuring the IP Address on the Printer You must configure the printer's IP address before using the printer in a TCP/IP network. The printer's IP address is configured automatically when you install the printer driver following the instructions in the Setup Guide.
  • Page 556 Network Setting (CS2436-9) 9. 1. 3. Network Setting > Network Setting > Configuring the IP Address Using Device Setup Utility On a computer running Windows, you can use Device Setup Utility provided with the printer to configure the printer's IP address. This topic describes how to configure the IP address using Device Setup Utility.
  • Page 557 Network Setting (CS2436-9) When there is an IPv6-compatible router in the network environment, select On in Stateless Address. Additionally, when there is an DHCPv6-compatible server in the network environment, select On in DHCPv6. Note When there is no IPv6-compatible router or DHCPv6-compatible server, select On in Manual and enter the IPv6 Address and Prefix Length.

  • Page 558: Configuring The Ip Address Using The Printer Control Panel

    Network Setting (CS2436-9) 9. 1. 4. Network Setting > Network Setting > Configuring the IP Address Using the Printer Control Panel This topic describes how to configure the printer's IP address on the Control Panel. On the Tab Selection screen of the Control Panel, press to select the Settings/ Adj.
  • Page 559 Network Setting (CS2436-9) Press the Menu button. If you have changed the settings, a confirmation message is displayed. Press select Yes, and then press the OK button. Important Be sure to complete step 11. This will activate the values you have entered.

  • Page 560: Configuring The Ip Address Using Arp And Ping Commands

    Network Setting (CS2436-9) 9. 1. 5. Network Setting > Network Setting > Configuring the IP Address Using ARP and PING Commands This topic describes how to configure the IP address using ARP and PING commands. To use the ARP and PING commands, you will need to know the printer's MAC address. You can confirm the MAC address on the Control Panel.
  • Page 561 Network Setting (CS2436-9) Execute the following command to send the IP address to the printer and configure it. ● ping [IP address as specified in the ARP command] -l 479 Example: ping xxx.xxx.xxx.xxx -l 479 Note In -l, the l is the letter l .

  • Page 562: Configuring Tcp/Ipv6 Network Settings

    Network Setting (CS2436-9) 9. 1. 6. Network Setting > Network Setting > Configuring TCP/IPv6 Network Settings When printing in a TCP/IPv6 network, you must configure the TCP/IPv6 settings on the Control Panel. Follow the steps below to configure the TCP/IPv6 network settings.

  • Page 563: Using Remoteui

    Network Setting (CS2436-9) 9. 1. 7. Network Setting > Network Setting > Using RemoteUI Enter the printer's IP address in a web browser to display the RemoteUI page. After you log on to RemoteUI from the page, you can check and change the status of the printer and print jobs, and configure network settings.

  • Page 564: Configuring The Printer's Tcp/Ip Network Settings

    Network Setting (CS2436-9) 9. 1. 8. Network Setting > Network Setting > Configuring the Printer's TCP/IP Network Settings Follow the steps below to configure the TCP/IP network settings. When using an IPv4 IP address Start the web browser and enter the following URL in the Location (or Address ) box to display the RemoteUI page.
  • Page 565 Network Setting (CS2436-9) Specify the printer's IP IP Address 0.0.0.0 address. Specify the printer's Subnet Mask 0.0.0.0 subnet mask. Gateway Specify the printer's 0.0.0.0 Address default gateway. Activate this setting to LPD Printing use LDP Printing. Activate this setting to IPP Printing use IPP Printing.
  • Page 566 Network Setting (CS2436-9) Specify the IP address Primary DNS of the primary DNS 0.0.0.0 Server Address server. Specify the IP address Secondary DNS of the secondary DNS 0.0.0.0 Server Address server. Specify the printer host name, up to 63 characters (1–63 characters).
  • Page 567 Network Setting (CS2436-9) If you specify to configure the IP address using DHCP, BOOTP, or RARP, there must be a server that supports such protocol running in the network. If you specify to configure the IP address using DHCP, BOOTP, or RARP, the IP address obtained by this method is used first.
  • Page 568 Network Setting (CS2436-9) Enter the printer's IP IP Address blank address. Enter the IP address Prefix Length blank prefix length. Default Router Enter the default blank Address router address. Enter the prefix length Prefix Length of the default router blank address.
  • Page 569 Network Setting (CS2436-9) Perform dynamic Activate when updating of stateful assigning a stateful addresses address dynamically. Activate when Dynamically update assigning a stateless the stateless address address dynamically. Activate when Dynamically update assigning a manual the manual address address dynamically.
  • Page 570 Network Setting (CS2436-9) 9. 1. 9. Network Setting > Network Setting > Configuring the Printer's AppleTalk Network Settings Follow the steps below to configure the AppleTalk network settings. Start the web browser and enter the following URL in the Location (or Address ) box to display the RemoteUI page.
  • Page 571 Network Setting (CS2436-9) *1: The object name you have specified in Name is displayed in Printer Setup Utility (or Print Center ) in Mac OS X 10.2.8– 10.4. If you use multiple printers in the same zone, assign a unique name to each printer.
  • Page 572 Network Setting (CS2436-9) 9. 1. 10. Network Setting > Network Setting > Configuring the Printer's NetWare Network Settings Follow the steps below to configure the NetWare network settings. Start the web browser and enter the following URL in the Location (or Address ) box to display the RemoteUI page.
  • Page 573 Network Setting (CS2436-9) Select If Requested by If Requested Packet Signature Server to use by Server packet signature. Specify the name of a file server Bindery File Server that has a — PServer Name NetWare print server. (0–47 characters) Specify the name...
  • Page 574 Network Setting (CS2436-9) Specify the name Print Server of a NetWare print — Name server. (0–64 characters) Set a password for Print Server the print server. — Password (0–20 characters) Specify the Polling interval to confirm Interval jobs. (1–255 seconds)

  • Page 575: Specifying Printer-Related Information

    Network Setting (CS2436-9) 9. 1. 11. Network Setting > Network Setting > Specifying Printer-Related Information Specify device information, security, and email notification settings as follows. Start the web browser and enter the following URL in the Location (or Address ) box to display the RemoteUI page.
  • Page 576 Network Setting (CS2436-9) Item Details Default Setting Enter the new password. New Password blank (0-9999999) Enter the new password again to Confirm confirm it. blank (0-9999999) On the Security settings screen, besides entering a password, you can specify other security-related information, such as IP address- based SNMP or TCP usage restrictions, MAC address-based access restrictions, or IPP and FTP authentication settings.

  • Page 577: Configuring The Communication Mode Manually

    Network Setting (CS2436-9) 9. 1. 12. Network Setting > Network Setting > Configuring the Communication Mode Manually This topic gives instructions for configuring the communication mode manually. On the Tab Selection screen of the Control Panel, press to select the Settings/ Adj.
  • Page 578 Network Setting (CS2436-9)

  • Page 579: Email Notification When Printing Is Finished Or Errors Occur

    Network Setting (CS2436-9) 9. 1. 13. Network Setting > Network Setting > Email Notification When Printing is Finished or Errors Occur The printer can notify you of the printer status by email. Even when you are away from the printer, you can know when printing is finished or if errors occur. Receive notification via email on your mobile phone or at your computer.

  • Page 580: Initializing The Network Settings

    Network Setting (CS2436-9) 9. 1. 14. Network Setting > Network Setting > Initializing the Network Settings Use RemoteUI to restore the network settings to the default values as follows. Important Initializing the network settings will also restore the default value of the printer's IP address.

  • Page 581: Configuring The Printer Driver Destination

    Network Setting (CS2436-9) 9. 2. 1. Network Setting > Network Setting (Windows) > Configuring the Printer Driver Destination This topic describes how to specify the printer driver destination if the printer's IP address is changed, or if you will use the printer over a network connection instead of via USB connection.

  • Page 582: Sharing The Printer In Windows

    Network Setting (CS2436-9) 9. 2. 2. Network Setting > Network Setting (Windows) > Sharing the Printer in Windows If you set up a computer as a print server in Windows 2000, Windows XP, Windows Server 2003, Windows Vista, or Windows Server 2008, the computer can receive print jobs sent from other computers (clients) connected to it for printing.
  • Page 583 Network Setting (CS2436-9) On the Sharing sheet, click Share this printer and enter the shared name.
  • Page 584 Network Setting (CS2436-9) To print jobs from clients running other versions of Windows, click Additional Drivers and follow the instructions to install the printer driver of the corresponding version. If you are prompted to choose the location of the printer driver file, insert the provided User Software CD-ROM in the CD-ROM drive and specify the folder where the printer driver is located.
  • Page 585 Network Setting (CS2436-9) 9. 2. 3. Network Setting > Network Setting (Windows) > Configuring the Printer's NetWare Network Settings Follow the steps below to configure the NetWare network settings. Start the web browser and enter the following URL in the Location (or Address ) box to display the RemoteUI page.
  • Page 586 Network Setting (CS2436-9) Select If Requested by If Requested Packet Signature Server to use by Server packet signature. Specify the name of a file server Bindery File Server that has a — PServer Name NetWare print server. (0–47 characters) Specify the name...
  • Page 587 Network Setting (CS2436-9) Specify the name Print Server of a NetWare print — Name server. (0–64 characters) Set a password for Print Server the print server. — Password (0–20 characters) Specify the Polling interval to confirm Interval jobs. (1–255 seconds)

  • Page 588: Specifying The Printer's Frame Type

    Network Setting (CS2436-9) 9. 2. 4. Network Setting > Network Setting (Windows) > Specifying the Printer's Frame Type To enable communication between the printer and computers on your network, specify the Ethernet frame type in your NetWare environment. Follow these steps to specify the frame type by using Device Setup Utility or the printer Control Panel.
  • Page 589 Network Setting (CS2436-9) On the Tab Selection screen of the Control Panel, press to select the Settings/ Adj. tab ( Note If the Tab Selection screen is not displayed, press the Menu button. Press the OK button. The Set./Adj. Menu is displayed.
  • Page 590 Network Setting (CS2436-9) Be sure to complete step 11. This will activate the values you have entered. Note If an error message is displayed, check the settings and correct any invalid values. To cancel this process, press the Stop button.

  • Page 591: Specifying Netware Print Services

    Network Setting (CS2436-9) 9. 2. 5. Network Setting > Network Setting (Windows) > Specifying NetWare Print Services Before printing in a NetWare network, you must configure print services such as print servers, print queues, and so on. You can configure the print service settings from a computer using any of the following Novell software provided with NetWare.
  • Page 592 Network Setting (CS2436-9) In remote printer mode, the printer is controlled by the NetWare print server. Thus, a NetWare print server is required. In NDS remote printer mode (NPrinter), the NDS print server is used for printing, and in bindery remote printer mode (RPrinter), the bindery print server is used for printing.
  • Page 593 Network Setting (CS2436-9) To use the NetWare file server as the print server, enter LOAD PSERVER.NLM at the file server and press the Enter key. Note This procedure is not required when using queue server mode. Use PCONSOLE to set up the print server if bindery queue server mode or remote printer mode is used.

  • Page 594: Specifying Netware Protocols

    Network Setting (CS2436-9) 9. 2. 6. Network Setting > Network Setting (Windows) > Specifying NetWare Protocols Follow the steps below to configure NetWare protocol settings other than the frame type by using RemoteUI. Note For details on RemoteUI, see "Using RemoteUI (9.1.7)."...
  • Page 595 Network Setting (CS2436-9) "Specifying NetWare Print Services (9.2.5)." In Print Server Password, enter the password of the print server created in "Specifying NetWare Print Services (9.2.5)." In Polling Interval, specify the interval at which the printer checks the NetWare print queue.

  • Page 596: Configuring Netware Network Settings

    Network Setting (CS2436-9) 9. 2. 7. Network Setting > Network Setting (Windows) > Configuring NetWare Network Settings To print over a NetWare network, configure the network environment as follows. Important To configure network settings, you must be logged in with administrative rights such as Administrator account.
  • Page 597 Network Setting (CS2436-9) 9. 2. 8. Network Setting > Network Setting (Windows) > Installing Device Setup Utility Install Device Setup Utility from the User Software CD-ROM provided with the printer as follows: Important In Windows 2000/Windows XP/Windows Server 2003/Windows Vista/ Windows Server 2008, you must log on with administrative rights equivalent to the Administrator account.
  • Page 598 Network Setting (CS2436-9) 9. 2. 9. Network Setting > Network Setting (Windows) > Configuring the IP Address Using Device Setup Utility On a computer running Windows, you can use Device Setup Utility provided with the printer to configure the printer's IP address. This topic describes how to configure the IP address using Device Setup Utility.
  • Page 599 Network Setting (CS2436-9) When there is an IPv6-compatible router in the network environment, select On in Stateless Address. Additionally, when there is an DHCPv6-compatible server in the network environment, select On in DHCPv6. Note When there is no IPv6-compatible router or DHCPv6-compatible server, select On in Manual and enter the IPv6 Address and Prefix Length.
  • Page 600 Network Setting (CS2436-9) 9. 3. 1. Network Setting > Network Setting (Mac OS X) > Configuring the Printer Driver Destination Specify the printer driver destination as follows if the printer's IP address is changed, or if you will use the printer over a network connection instead of via USB connection.
  • Page 601 Network Setting (CS2436-9) 9. 3. 2. Network Setting > Network Setting (Mac OS X) > Configuring the Printer's AppleTalk Network Settings Follow the steps below to configure the AppleTalk network settings. Start the web browser and enter the following URL in the Location (or Address ) box to display the RemoteUI page.
  • Page 602 Network Setting (CS2436-9) *1: The object name you have specified in Name is displayed in Printer Setup Utility (or Print Center ) in Mac OS X 10.2.8– 10.4. If you use multiple printers in the same zone, assign a unique name to each printer.

  • Page 603: Configuring The Destination For Appletalk Networks

    Network Setting (CS2436-9) 9. 3. 3. Network Setting > Network Setting (Mac OS X) > Configuring the Destination for AppleTalk Networks To print over an AppleTalk network, activate the AppleTalk protocol and configure the destination as follows. Activating AppleTalk on the printer Important By factory default, the AppleTalk protocol is disabled on the printer.
  • Page 604 Network Setting (CS2436-9) Important Be sure to complete step 6. This will activate the values you have entered. Note By using RemoteUI, you can also specify the object name used for AppleTalk, as well as the printer zone name. For details on RemoteUI, see "Using RemoteUI (9.1.7)."...
  • Page 605 Network Setting (CS2436-9) Close the Network window and save the settings.

  • Page 606: Configuring The Destination In Tcp/Ip Networks

    Network Setting (CS2436-9) 9. 3. 4. Network Setting > Network Setting (Mac OS X) > Configuring the Destination in TCP/IP Networks Follow these steps to configure the destination when using the printer in a TCP/IP network. Important If you use the printer in a TCP/IP network, make sure the printer's IP address is configured correctly.
  • Page 607 Network Setting (CS2436-9) Select the model and type and then enter the IP address before clicking the Next button. Complete Printer Name and Location as desired and click Register.
  • Page 608 Network Setting (CS2436-9) Click Finish.

  • Page 609: Configuring The Destination For Bonjour Network

    Network Setting (CS2436-9) 9. 3. 5. Network Setting > Network Setting (Mac OS X) > Configuring the Destination for Bonjour Network In Mac OS X 10.2.8 and later, use Bonjour functions to easily connect the printer to the network. Follow the steps below to configure the destination if you use the printer on TCP/IP network.
  • Page 610 Network Setting (CS2436-9)
  • Page 611 Maintenance (CS2436-10) 10. Maintenance 10. 1. Ink Tanks Ink Tanks Replacing Ink Tanks Checking Ink Tank Levels When to Replace Ink Tanks 10. 2. Printheads Printhead Checking for Nozzle Clogging Cleaning the Printhead Replacing the Printhead 10. 3. Maintenance Cartridge...

  • Page 612: Ink Tanks

    Maintenance (CS2436-10) 10. 1. 1. Maintenance > Ink Tanks > Ink Tanks When purchasing ink tanks along with the following Ink Tank serial numbers. 130 ml (4.4 fl oz) per color ● BK Ink Tank 0029952265 ● MBK Ink Tank 00299522264 ●...

  • Page 613: Replacing Ink Tanks

    Maintenance (CS2436-10) 10. 1. 2. Maintenance > Ink Tanks > Replacing Ink Tanks Compatible ink tanks Ink tanks that can be used in the printer are labeled with a white letter J in a black circle on the side. Request ink tanks with the same label when you purchase new ones. For details, see "Ink Tanks (10.1.1)."...
  • Page 614 Maintenance (CS2436-10) Important Do not remove an Ink Tank during initialization immediately after turning on the printer, or during printhead cleaning. Note Ink Tank replacement is possible even during printing, when print jobs are being canceled, or when paper is being advanced.
  • Page 615 Maintenance (CS2436-10) Ink lamps flash when there is little ink left. Press the tip of the Ink Tank Lock Lever of the color for replacement horizontally and pull the Ink Tank Lock Lever up to open it. Hold the Ink Tank by the grips and remove it. Press the OK button.

  • Page 616: Install The Ink Tanks

    Maintenance (CS2436-10) If there is still ink in the Ink Tank you removed, store it with the ink holes (a) facing up. Otherwise, ink may leak and cause stains. Put the Ink Tank in a plastic bag and seal it.
  • Page 617 Maintenance (CS2436-10) Open the pouch and remove the Ink Tank. Caution Never touch the ink holes or electrical contacts. This may cause stains, damage the Ink Tank, and affect printing quality. Press the OK button and insert the Ink Tank into the holder facing as shown, with the ink holes down.
  • Page 618 Maintenance (CS2436-10) Make sure the Ink Lamp is lit in red. Note If the Ink Lamp is not lit, reload the tank. Close the Ink Tank Cover.

  • Page 619: Checking Ink Tank Levels

    Maintenance (CS2436-10) 10. 1. 3. Maintenance > Ink Tanks > Checking Ink Tank Levels On the Display Screen, you can check how much ink is left in the ink tanks. To check remaining Ink Tank levels, access the Tab Selection screen on the Control Panel and...
  • Page 620 Maintenance (CS2436-10)

  • Page 621: When To Replace Ink Tanks

    Maintenance (CS2436-10) 10. 1. 4. Maintenance > Ink Tanks > When to Replace Ink Tanks Replace or prepare to replace ink tanks in the following situations. If a message for checking the ink is shown on the Display Screen When there is little ink left, the Message Lamp is lit and "Not much ink is left." is shown on the Display Screen.
  • Page 622 Maintenance (CS2436-10) 10. 2. 1. Maintenance > Printheads > Printhead A replacement Printhead. Printhead 299511267 ● Note For instructions on replacing the Printhead, see "Replacing the Printhead (10.2.4)."...

  • Page 623: Checking For Nozzle Clogging

    Maintenance (CS2436-10) 10. 2. 2. Maintenance > Printheads > Checking for Nozzle Clogging If printing is faint or affected by banding in different colors, make sure the Printhead nozzles are clear by printing a test pattern to check the nozzles.
  • Page 624 Maintenance (CS2436-10) If some sections of the horizontal lines are faint or incomplete, the nozzles for those colors are clogged. If horizontal lines are faint or incomplete, follow the steps below and check again for nozzle clogging. Clean the Printhead. (See "Cleaning the Printhead (10.2.3).") Print a test pattern to check the nozzles.

  • Page 625: Cleaning The Printhead

    Maintenance (CS2436-10) 10. 2. 3. Maintenance > Printheads > Cleaning the Printhead If printing is faint, cleaning the Printhead may improve results. Choose one of two Printhead cleaning modes ( Head Cleaning A or Head Cleaning B ), depending on the problem to resolve.
  • Page 626 Maintenance (CS2436-10) Note If the Tab Selection screen is not displayed, press the Menu button. Press the OK button. The Set./Adj. Menu is displayed. to select Maintenance, and then press the OK button. Press to select Head Cleaning, and then press the OK button.

  • Page 627: Replacing The Printhead

    Maintenance (CS2436-10) 10. 2. 4. Maintenance > Printheads > Replacing the Printhead When to replace the Printhead Replace the Printhead in the following situations. If the printing quality does not improve even after one or two cycles of Head ●...

  • Page 628: Replace The Printhead

    Maintenance (CS2436-10) Prepare a new Ink Tank when ink levels are low. Your hands may become dirty during Printhead replacement. Use the gloves provided with the new Printhead for replacement. If the roll is not ejected because of the cutting method selected, cut it manually and remove it.
  • Page 629 Maintenance (CS2436-10) Instructions are now shown on the Display Screen regarding Printhead replacement. Important During Printhead replacement, do not move the Carriage from the position indicated. If you accidentally move the Carriage, you will hear a warning tone, and Printhead replacement is no longer possible.
  • Page 630 Maintenance (CS2436-10) Do not touch the Linear Scale (a) or Carriage Shaft (b). Touching these parts may damage them. Never touch the metal contacts of the Carriage. This may damage the printer. Pull the Printhead Fixer Lever forward all the way to open it completely.
  • Page 631 Maintenance (CS2436-10) Remove the Printhead and press the OK button. Note Dispose of the used Printhead in accordance with local regulations. Holding the new Printhead by the grips (a), remove it from the pouch. Important...
  • Page 632 Maintenance (CS2436-10) When handling the Printhead, always hold it by the grips (a). Never touch the nozzles (b) or metal contacts (c). This may damage the Printhead and affect printing quality. Never touch the ink supply section (d). This may cause printing problems.
  • Page 633 Maintenance (CS2436-10) With the nozzles facing down and the metal contacts toward the back, insert the Printhead into the Carriage. Carefully push the printhead firmly into the Carriage, ensuring that the nozzles and metal contacts do not touch the carriage.
  • Page 634 Maintenance (CS2436-10) Ink now fills the system. It takes about seven minutes to complete. Important Never remove an Ink Tank while the system is filling with ink. After Printhead has been replaced and filled with ink, Head Posi. Adj. ( Auto(Advanced) ) is performed if you have selected Rep.P.

  • Page 635: Maintenance Cartridge

    Maintenance (CS2436-10) 10. 3. 1. Maintenance > Maintenance Cartridge > Maintenance Cartridge A replacement Maintenance Cartridge. Maintenance Cartridge 0029951310 ● Note For instructions on replacing the Maintenance Cartridge, see "Replacing the Maintenance Cartridge (10.3.2)."...

  • Page 636: Replacing The Maintenance Cartridge

    Maintenance (CS2436-10) 10. 3. 2. Maintenance > Maintenance Cartridge > Replacing the Maintenance Cartridge Compatible maintenance cartridges For information on compatible maintenance cartridges, see "Maintenance Cartridge (10.3.1)." Precautions when handling the Maintenance Cartridge Take the following precautions when handling the Maintenance Cartridge.

  • Page 637: Replace The Maintenance Cartridge

    Maintenance (CS2436-10) Caution Do not replace the Maintenance Cartridge during initialization immediately after turning on the printer, during Printhead cleaning, or when ink is being absorbed. Ink may leak out. Access the menu for Maintenance Cartridge replacement On the Tab Selection screen of the Control Panel, press to select the Settings/ Adj.
  • Page 638 Maintenance (CS2436-10) Important Never touch the metal contacts (a). This may damage the Maintenance Cartridge. At this point, open the Maintenance Cartridge Cover. Hold the used Maintenance Cartridge by the grip (a) with one hand and put your other hand under the Maintenance Cartridge to hold it firmly on the bottom, keeping it level as...
  • Page 639 Maintenance (CS2436-10) Caution Used maintenance cartridges are heavy. Always grasp the cartridge firmly and keep the cartridge level during removal and storage. If you drop a used Maintenance Cartridge or store it at an angle, ink may leak and cause stains.
  • Page 640 Maintenance (CS2436-10) Caution Always put the used Maintenance Cartridge back in the box and store the box on a flat surface. Otherwise, ink may leak and cause stains. Note In accordance with active and ongoing environmental programs, Océ supports recycling of used maintenance cartridges. Follow the instructions provided with the new Maintenance Cartridge that describe how to process the used Maintenance Cartridge.
  • Page 641 Maintenance (CS2436-10) Press the OK button. The printer now initializes the Maintenance Cartridge.

  • Page 642: Checking The Remaining Maintenance Cartridge Capacity

    Maintenance (CS2436-10) 10. 3. 3. Maintenance > Maintenance Cartridge > Checking the Remaining Maintenance Cartridge Capacity The Maintenance Cartridge absorbs excess ink from borderless printing, printhead cleaning, and other processes. You can confirm the remaining capacity of the Maintenance Cartridge by checking the Maintenance Cartridge capacity shown on the Display Screen.

  • Page 643: When To Replace The Maintenance Cartridge

    Maintenance (CS2436-10) 10. 3. 4. Maintenance > Maintenance Cartridge > When to Replace the Maintenance Cartridge Replace or prepare to replace the Maintenance Cartridge in the following situations. If a message for checking the Maintenance Cartridge is shown on the Display Screen When the Maintenance Cartridge is almost full, the Message Lamp is lit and "The level is low"...
  • Page 644 Maintenance (CS2436-10)

  • Page 645: Cleaning The Printer Exterior

    Maintenance (CS2436-10) 10. 4. 1. Maintenance > Cleaning the Printer > Cleaning the Printer Exterior Clean the printer regularly to maintain better printing quality and help prevent problems. To ensure a comfortable working environment, clean the printer exterior about once a month.

  • Page 646: Cleaning Inside The Top Cover

    Maintenance (CS2436-10) 10. 4. 2. Maintenance > Cleaning the Printer > Cleaning Inside the Top Cover Clean inside the Top Cover about once a month to maintain better printing quality and help prevent problems. Also clean inside the Top Cover in the following situations to ensure optimal operation.
  • Page 647 Maintenance (CS2436-10) Note If the Cleaning Brush is dirty, rinse it in water. Using a damp cloth that you have wrung out completely, wipe inside the Top Cover to clean it. Wipe away any ink residue on the Platen as a whole (a), the Paper Retainer (b),...
  • Page 648 Maintenance (CS2436-10) Important Do not use a dry cloth to wipe inside the Top Cover. This may create a static charge, which may attract dust and affect the printing quality. Never use flammable solvents such as alcohol, benzene, or thinner. If these substances come into contact with electrical components inside the printer, there is a risk of fire or electrical shock.
  • Page 649 Maintenance (CS2436-10) Note When cleaning between the Platen and Ejection Guide, use a damp cloth that you have wrung out completely to wipe over the Output Tray and along grooves. Close the Top Cover.
  • Page 650 Maintenance (CS2436-10)
  • Page 651 Maintenance (CS2436-10) 10. 4. 3. Maintenance > Cleaning the Printer > Cleaning the Printhead If printing is faint, cleaning the Printhead may improve results. Choose one of two Printhead cleaning modes ( Head Cleaning A or Head Cleaning B ), depending on the problem to resolve.
  • Page 652 Maintenance (CS2436-10) Note If the Tab Selection screen is not displayed, press the Menu button. Press the OK button. The Set./Adj. Menu is displayed. to select Maintenance, and then press the OK button. Press to select Head Cleaning, and then press the OK button.

  • Page 653: Preparing To Transfer The Printer

    Maintenance (CS2436-10) 10. 5. 1. Maintenance > Other Maintenance > Preparing to Transfer the Printer To protect the internal parts in transit, always follow these steps before transferring the printer to a new location. Refer to the Setup Guide for details on packing the printer and installing it after transfer.
  • Page 654 Maintenance (CS2436-10) Note If the Tab Selection screen is not displayed, press the Menu button. Press the OK button. The Set./Adj. Menu is displayed. Press to select Prep.MovePrinter, and then press the OK button. Once preparations are finished, a message on the Display Screen requests you to open the Ink Tank Cover.
  • Page 655 Maintenance (CS2436-10) Note Store the ink tanks you removed with the ink holes (a) facing up. Otherwise, ink may leak and cause stains. Repeat steps 2 and 3 to remove all ink tanks. Push all ink tank lock levers closed until they click into place.

  • Page 656: Pack The Printer

    Maintenance (CS2436-10) Close the Ink Tank Cover. At this point, ink is drawn out from inside the tubes. Important Do not remove the Maintenance Cartridge during this process. When the process is finished, "Completed! Turn Power Off!!" is displayed. Pack the printer Press the Power button and turn off the printer.
  • Page 657 Maintenance (CS2436-10) them in a shipping box.

  • Page 658: Updating The Firmware

    Maintenance (CS2436-10) 10. 5. 2. Maintenance > Other Maintenance > Updating the Firmware Update the printer firmware to take advantage of new and improved printer functions. Confirming the firmware version On the Tab Selection screen of the Control Panel, press to select the Settings/ Adj.
  • Page 659 Troubleshooting (CS2436-11) 11. Troubleshooting 11. 1. Frequently Asked Questions Frequently Asked Questions 11. 2. Problems Regarding Paper Clearing Jammed Paper (Paper Feed Slot) Clearing Jammed Roll Paper Clearing a Jammed Sheet Roll Paper Cannot be Inserted into the Paper Feed Slot...
  • Page 660 Troubleshooting (CS2436-11) The length of printed images is inaccurate in the feeding direction Images are printed crooked Documents are printed in monochrome Line thickness is not uniform Lines are misaligned Problems with the printing quality caused by the type of paper 11.

  • Page 661: Frequently Asked Questions

    Troubleshooting (CS2436-11) 11. 1. 1. Troubleshooting > Frequently Asked Questions > Frequently Asked Questions This section presents frequently asked questions and answers. To view more detailed explanations, click the hyperlinks in the answer column. Question Answer When printing on rolls, after loading the...
  • Page 662 Troubleshooting (CS2436-11) Borderless printing is possible on rolls. You can also specify borderless printing in the printer driver by adjusting the original size to match the paper size. Borderless printing is not supported on How do I print without sheets.
  • Page 663 Troubleshooting (CS2436-11) You can specify custom sizes temporarily in the printer driver. How do I print on a custom ⇒"Printing on Non-Standard Paper paper size? Sizes (3.6.4)" You can add desired sizes (Custom Media Sizes) in the Size Options dialog box of How do I register custom the printer driver.
  • Page 664 Troubleshooting (CS2436-11) 11. 2. 1. Troubleshooting > Problems Regarding Paper > Clearing Jammed Paper (Paper Feed Slot) Follow these steps to remove any scraps left in the Paper Feed Slot after you clear jammed sheets or roll paper. Turn the printer off. (See "Turning the Printer On and Off (8.2.2).") Push the Release Lever back.
  • Page 665 Troubleshooting (CS2436-11) Fold an A4 sheet lengthwise four times and insert it through the gap of the Paper Feed Slot. Push the scrap out toward the Platen. Remove the scrap when it is pushed out onto the Platen. If any scraps remain inside the paper feed slot, repeat steps 4 and 5.
  • Page 666 Troubleshooting (CS2436-11) Pull the Release Lever forward.
  • Page 667 Troubleshooting (CS2436-11) 11. 2. 2. Troubleshooting > Problems Regarding Paper > Clearing Jammed Roll Paper If paper from a roll becomes jammed, "Paper jam." is shown on the Display Screen of the Control Panel. Remove the jammed paper as follows.
  • Page 668 Troubleshooting (CS2436-11) manually, away from the jam. Clear any jammed paper from inside the Top Cover. After removing the paper, make sure there are no other scraps of paper in the printer. Close the Top Cover. Important...
  • Page 669 Troubleshooting (CS2436-11) Do not move the Carriage over jammed paper. This may damage the Printhead. Do not touch the Linear Scale (a) or Carriage Shaft (b). This may stain your hands and damage the printer. If paper from a roll is jammed by the Paper Feed Slot ●...
  • Page 670 Troubleshooting (CS2436-11) If the paper is jammed by the Ejection Guide ● Remove the jammed paper from the Output Tray. After removing the paper, make sure there are no other scraps of paper in the printer. Pull the Release Lever forward.
  • Page 671 Troubleshooting (CS2436-11)
  • Page 672 Troubleshooting (CS2436-11) 11. 2. 3. Troubleshooting > Problems Regarding Paper > Clearing a Jammed Sheet If a sheet becomes jammed, "Paper jam." is shown on the Display Screen of the Control Panel. Remove the jammed paper as follows. Push the Release Lever back.
  • Page 673 Troubleshooting (CS2436-11) Clear any jammed paper from inside the Top Cover. After removing the paper, make sure there are no other scraps of paper in the printer. Close the Top Cover. Important Do not move the Carriage over jammed paper. This may damage the Printhead.
  • Page 674 Troubleshooting (CS2436-11) If the paper is jammed by the Paper Feed Slot ● Remove the jammed paper from the Paper Feed Slot. After removing the paper, make sure there are no other scraps of paper in the printer. If the paper is jammed by the Ejection Guide ●...
  • Page 675 Troubleshooting (CS2436-11) Pull the Release Lever forward. ●...

  • Page 676: Roll Paper Cannot Be Inserted Into The Paper Feed Slot

    Troubleshooting (CS2436-11) 11. 2. 4. Troubleshooting > Problems Regarding Paper > Roll Paper Cannot be Inserted into the Paper Feed Slot Cause Corrective Action The roll paper is warped. Straighten out curls and reload the roll. Remove the jammed paper.

  • Page 677: Cannot Load Sheets

    Troubleshooting (CS2436-11) 11. 2. 5. Troubleshooting > Problems Regarding Paper > Cannot load sheets Cause Corrective Action The paper source selection is Press the Load button and select the incorrect. paper source.

  • Page 678: Paper Is Not Cut Straight

    Troubleshooting (CS2436-11) 11. 2. 6. Troubleshooting > Problems Regarding Paper > Paper is not cut straight Cause Corrective Action The paper is bent or Straighten out any curling by the edges of the curled at the cut position. paper. Paper rises by the ends of the cut position before it Reload the paper correctly.

  • Page 679: Paper Is Not Cut

    Troubleshooting (CS2436-11) 11. 2. 7. Troubleshooting > Problems Regarding Paper > Paper is not cut Cause Corrective Action In the printer driver, No or Print Specify Yes in Auto Cut in the Cut Guideline is specified in Auto printer driver.

  • Page 680: Depression On The Leading Edge Is Left

    Troubleshooting (CS2436-11) 11. 2. 8. Troubleshooting > Problems Regarding Paper > Depression on the leading edge is left Cause Corrective Action When printing quality is most important, we Keeping a roll in the recommend setting TrimEdge Reload to On printer for a long time...

  • Page 681: The Size Of Clear Film Cannot Be Detected

    Troubleshooting (CS2436-11) 11. 2. 9. Troubleshooting > Problems Regarding Paper > The size of clear film cannot be detected Cause Corrective Action Open the Top Cover and clean the entire Platen. The Platen is soiled with ink (See "Cleaning Inside the Top or other substances.

  • Page 682: Roll Paper Is Continuously Ejected

    Troubleshooting (CS2436-11) 11. 2. 10. Troubleshooting > Problems Regarding Paper > Roll Paper is Continuously Ejected Cause Corrective Action After roll ejection stops, follow these steps to reload the roll. 1. Push the Release Lever back. 2. Open the Roll Cover.
  • Page 683 Troubleshooting (CS2436-11) 11. 3. 1. Troubleshooting > Printing does not start > The Data Reception Lamp on the Control Panel does not light up Cause Corrective Action Make sure the power cord is securely plugged in, all the way. Press the Power The printer is not on.

  • Page 684: The Printer Does Not Respond Even If Print Jobs Are Sent

    Troubleshooting (CS2436-11) 11. 3. 2. Troubleshooting > Printing does not start > The printer does not respond even if print jobs are sent Cause Corrective Action Set Pause Print to Off. In the Control Panel menu, Pause (See "Pausing Printing (1.3.1).")

  • Page 685: Ink Filling.. Is Displayed

    Troubleshooting (CS2436-11) 11. 3. 3. Troubleshooting > Printing does not start > Ink Filling.. is displayed Cause Corrective Action Wait until the system has been The printer was forced off during filled with ink. This process may operation. take about seven and a half...

  • Page 686: The Display Screen Indicates Agitating

    Troubleshooting (CS2436-11) 11. 3. 4. Troubleshooting > Printing does not start > The display screen indicates Agitating Cause Corrective Action Please wait until ink agitation is finished. The time for agitation varies depending on Ink agitation is in progress. how long the printer has been off. (Between...

  • Page 687: An Error Message Is Shown On The Display Screen

    Troubleshooting (CS2436-11) 11. 4. 1. Troubleshooting > The printer stops during a print job > An error message is shown on the Display Screen Status Corrective Action Check the error message and take action as An error message is necessary.

  • Page 688: The Printer Ejects Blank, Unprinted Paper

    Troubleshooting (CS2436-11) 11. 4. 2. Troubleshooting > The printer stops during a print job > The printer ejects blank, unprinted paper Status Corrective Action The leading edge of rolls may be cut to straighten it if you have selected Trim Edge The leading edge of the First >On or Automatic in the Control Panel...
  • Page 689 Troubleshooting (CS2436-11) 11. 4. 3. Troubleshooting > The printer stops during a print job > The printer stops when printing a HP-GL/2 job (the carriage stops moving) Cause Corrective Action The printer is analyzing the Please wait a while until printing is finished.

  • Page 690: Printing Is Faint

    Troubleshooting (CS2436-11) 11. 5. 1. Troubleshooting > Problems with the printing quality > Printing is faint Cause Corrective Action You may be printing on the wrong side of the Print on the printing surface. paper. Print a test pattern to check the nozzles and The Printhead nozzles are see if they are clogged.

  • Page 691: Paper Rubs Against The Printhead

    Troubleshooting (CS2436-11) 11. 5. 2. Troubleshooting > Problems with the printing quality > Paper rubs against the Printhead Cause Corrective Action Load paper of the same type as you have specified in the printer driver. (See "Loading Rolls in the Printer (6.2.2).") (See "Loading Sheets in the Printer (6.3.1).")
  • Page 692 Troubleshooting (CS2436-11) When printing on CAD Tracing Paper or other film-based media, choose a VacuumStrngth setting of Standard, Strong, or Strongest in the Control Panel menu. If the paper still rubs, set Head Height to Highest in the Control Panel menu.

  • Page 693: The Edges Of The Paper Are Dirty

    Troubleshooting (CS2436-11) 11. 5. 3. Troubleshooting > Problems with the printing quality > The edges of the paper are dirty Cause Corrective Action Open the Top Cover and clean the Platen. The Platen has become dirty (See "Cleaning Inside the Top after borderless printing or Cover (10.4.2).")
  • Page 694 Troubleshooting (CS2436-11) When printing on Heavyweight Coated Paper or other paper-based media, choose a VacuumStrngth setting of Strong or Strongest in the Control Panel menu. If the paper still rubs, set Head Height to Highest in the Control Panel menu.

  • Page 695: The Surface Of The Paper Is Dirty

    Troubleshooting (CS2436-11) 11. 5. 4. Troubleshooting > Problems with the printing quality > The surface of the paper is dirty Cause Corrective Action Clean the Paper Retainer. The Paper Retainer is (See "Cleaning Inside the Top Cover (10.4.2).") soiled. In the Control Panel menu, set Roll DryingTime to at least 1 min.

  • Page 696: The Back Side Of The Paper Is Dirty

    Troubleshooting (CS2436-11) 11. 5. 5. Troubleshooting > Problems with the printing quality > The back side of the paper is dirty Cause Corrective Action The Platen has become Open the Top Cover and clean the Platen. dirty after borderless (See "Cleaning Inside the Top printing or printing on Cover (10.4.2).")

  • Page 697: Printed Colors Are Inaccurate

    Troubleshooting (CS2436-11) 11. 5. 6. Troubleshooting > Problems with the printing quality > Printed colors are inaccurate Cause Corrective Action Color adjustment has not In the Advanced Settings of the printer been activated in the driver, access Color Settings in Color Advanced Settings of the Mode to adjust colors.

  • Page 698: Banding In Different Colors Occurs

    Troubleshooting (CS2436-11) 11. 5. 7. Troubleshooting > Problems with the printing quality > Banding in different colors occurs Cause Corrective Action Adjust the feed amount. The paper feed amount is (See "Adjusting the Feed Amount (7.2.1).") out of adjustment. Printing does not proceed...
  • Page 699 Troubleshooting (CS2436-11) Make sure the same type of paper is specified in the printer driver as you have loaded in the printer. 1. Press the Stop button and stop printing. 2. Change the type of paper in the printer driver and try printing again.

  • Page 700: Colors In Printed Images Are Uneven

    Troubleshooting (CS2436-11) 11. 5. 8. Troubleshooting > Problems with the printing quality > Colors in printed images are uneven Cause Corrective Action Line Drawing/Text In Print Priority in the Advanced Settings of is selected when printing images in the printer driver, choose Image.
  • Page 701 Troubleshooting (CS2436-11) Allowing printed documents to dry on To avoid uneven colors, we recommend drying top of each other each sheet separately. may cause uneven colors. Density may be In Advanced Settings of the printer driver, uneven if you use choose Highest or High in Print Quality.

  • Page 702: Image Edges Are Blurred Or White Banding Occurs

    Troubleshooting (CS2436-11) 11. 5. 9. Troubleshooting > Problems with the printing quality > Image edges are blurred or white banding occurs Cause Corrective Action In the Control Panel menu, set VacuumStrngth to Weakest. The Platen suction (See "Adjusting the Vacuum Strength is too strong.

  • Page 703: The Contrast Becomes Uneven During Printing

    Troubleshooting (CS2436-11) 11. 5. 10. Troubleshooting > Problems with the printing quality > The contrast becomes uneven during printing Cause Corrective Action Adjust the feed amount. The paper feed amount is (See "Adjusting the Feed out of adjustment. Amount (7.2.1).") Load paper of the same type as you have specified in the printer driver.
  • Page 704 Troubleshooting (CS2436-11) 11. 5. 11. Troubleshooting > Problems with the printing quality > The length of printed images is inaccurate in the feeding direction Cause Corrective Action Set Adj. Priority to Print Length in the In the Control Panel Control Panel menu, and then execute Adjust menu, Adj.

  • Page 705: Images Are Printed Crooked

    Troubleshooting (CS2436-11) 11. 5. 12. Troubleshooting > Problems with the printing quality > Images are printed crooked Cause Corrective Action In the Control Panel menu, Skew In the Control Panel menu, set Check Lv. is set to Loose or Off.

  • Page 706: Documents Are Printed In Monochrome

    Troubleshooting (CS2436-11) 11. 5. 13. Troubleshooting > Problems with the printing quality > Documents are printed in monochrome Cause Corrective Action In the Advanced Settings of the printer driver, In the Advanced Settings of the Monochrome, Monochrome printer driver, specify Color in Color (BK ink), or Monochrome Mode and try printing again.

  • Page 707: Line Thickness Is Not Uniform

    Troubleshooting (CS2436-11) 11. 5. 14. Troubleshooting > Problems with the printing quality > Line thickness is not uniform Cause Corrective Action Access the printer driver Properties dialog box from Print in the File menu of the source application, and follow these steps to print.

  • Page 708: Lines Are Misaligned

    Troubleshooting (CS2436-11) 11. 5. 15. Troubleshooting > Problems with the printing quality > Lines are misaligned Cause Corrective Action Adjust the Printhead alignment. (See "Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.) (7.1.2).") The Printhead alignment is (See "Manual Adjustment to Straighten not adjusted.
  • Page 709 Troubleshooting (CS2436-11) 11. 5. 16. Troubleshooting > Problems with the printing quality > Problems with the printing quality caused by the type of paper For paper-specific troubleshooting tips to improve the printing quality (See "Types of Paper (6.1.1).")

  • Page 710: Cannot Connect The Printer To The Network

    Troubleshooting (CS2436-11) 11. 6. 1. Troubleshooting > Cannot print over a network > Cannot connect the printer to the network Cause Corrective Action 1. Make sure the printer is connected to the network with the correct Ethernet cable, and then turn the printer on. For instructions on connecting the cable, refer to the Setup Guide.

  • Page 711: Cannot Print Over A Tcp/Ip Network

    Troubleshooting (CS2436-11) 11. 6. 2. Troubleshooting > Cannot print over a network > Cannot print over a TCP/IP network Cause Corrective Action Make sure the printer's IP address is configured correctly. The printer's IP address (See "Configuring the IP Address Using Device is not configured Setup Utility (4.10.3).")

  • Page 712: Cannot Print Over A Netware Network

    Troubleshooting (CS2436-11) 11. 6. 3. Troubleshooting > Cannot print over a network > Cannot print over a NetWare network Cause Corrective Action Make sure the printer's NetWare settings are configured correctly. In particular, make sure The printer's NetWare a valid frame type is selected.

  • Page 713: Cannot Print Over Appletalk Or Bonjour Networks

    Troubleshooting (CS2436-11) 11. 6. 4. Troubleshooting > Cannot print over a network > Cannot print over AppleTalk or Bonjour networks Cause Corrective Action Activate AppleTalk on the printer. The AppleTalk protocol is (See "Configuring the Printer's AppleTalk not enabled on the printer.

  • Page 714: Removing Installed Printer Drivers

    Troubleshooting (CS2436-11) 11. 7. 1. Troubleshooting > Installation problems > Removing Installed Printer Drivers Follow these steps to remove installed printer drivers and utilities. Removing printer drivers (Windows) Remove the printer driver as follows. Note In Windows 2000/Windows XP/Windows Server 2003/Windows Vista/ Windows Server 2008, you must log on with administrative rights, such as those of the Administrator account.
  • Page 715 Troubleshooting (CS2436-11) Removing Device Setup Utility (Windows) Remove Device Setup Utility as follows. From the Windows start menu, select Programs > Device Setup Utility >Uninstaller ( Device Setup Utility) to start the wizard. In the wizard window, click Delete, and then click Next.

  • Page 716: With Hp-Gl/2, Printing Is Misaligned

    Troubleshooting (CS2436-11) 11. 8. 1. Troubleshooting > HP-GL/2 problems > With HP-GL/2, printing is misaligned Cause Corrective Action The plotter origin is incorrect. Check the printing commands. The Margin setting in the Adjust the Margin setting values in the Control Panel menu is incorrect.

  • Page 717: Lines Or Images Are Missing In Printed Hp-Gl/2 Jobs

    Troubleshooting (CS2436-11) 11. 8. 2. Troubleshooting > HP-GL/2 problems > Lines or images are missing in printed HP-GL/2 jobs. Cause Corrective Action The memory is full. Check the size of the data in the print job. An HP-GL/2 command not supported by this printer Check the print job and settings.

  • Page 718: Lines Are Printed Too Thick Or Thin In Hp-Gl/2 Print Jobs

    Troubleshooting (CS2436-11) 11. 8. 3. Troubleshooting > HP-GL/2 problems > Lines are printed too thick or thin in HP-GL/2 print jobs Cause Corrective Action Check the Width setting value specified for Pen no. in Palette A or Palette B in the The Width setting in Control Panel menu.

  • Page 719: Hp-Gl/2 Jobs Are Printed In Monochrome (Or Color)

    Troubleshooting (CS2436-11) 11. 8. 4. Troubleshooting > HP-GL/2 problems > HP-GL/2 jobs are printed in monochrome (or color) Cause Corrective Action Check the Color Mode setting in the Control Panel menu. (See "Menu Settings (8.2.8).") The Color Mode setting in the Control Panel However, for optimal Printhead performance, menu is incorrect.
  • Page 720 Troubleshooting (CS2436-11) 11. 8. 5. Troubleshooting > HP-GL/2 problems > Printed colors of lines are inaccurate during HP-GL/2 printing Cause Corrective Action Setting AdjustFaintLines to Off in the Control Panel menu may help AdjustFaintLines is On in the produce the expected results.

  • Page 721: Hp-Gl/2 Jobs Are Printed 6 Mm Larger Than Specified

    Troubleshooting (CS2436-11) 11. 8. 6. Troubleshooting > HP-GL/2 problems > HP-GL/2 jobs are printed 6 mm larger than specified Cause Corrective Action The page size of the HP- In the Control Panel menu, set GL/2 print job, as created PageSizeProcess1 to On.
  • Page 722 Troubleshooting (CS2436-11) 11. 8. 7. Troubleshooting > HP-GL/2 problems > HP-GL/2 jobs are printed at maximum size, even if a standard size is specified Cause Corrective Action In the Control Panel menu, set PageSizeProcess2 or Conserve Paper to The page size of the HP-...

  • Page 723: Hp-Gl/2 Printing Takes A Long Time

    Troubleshooting (CS2436-11) 11. 8. 8. Troubleshooting > HP-GL/2 problems > HP-GL/2 printing takes a long time Cause Corrective Action Large print jobs with a lot of Please wait a while until printing is finished. data take longer to print. A job was printed when...

  • Page 724: Replotting With Hp-Gl/2 Jobs Is Not Possible

    Troubleshooting (CS2436-11) 11. 8. 9. Troubleshooting > HP-GL/2 problems > Replotting with HP-GL/2 jobs is not possible. Cause Corrective Action Data for replotting is lost after the following operations. In this case, send the print job again. The memory buffer was cleared The data was lost because of from the Control Panel.
  • Page 725 Troubleshooting (CS2436-11) 11. 8. 10. Troubleshooting > HP-GL/2 problems > The printer stops when printing a HP-GL/2 job (the carriage stops moving) Cause Corrective Action The printer is analyzing the Please wait a while until printing is finished. print job.

  • Page 726: The Printer Does Not Go On

    Troubleshooting (CS2436-11) 11. 9. 1. Troubleshooting > Other problems > The printer does not go on Cause Corrective Action The printer is Plug the power cord into the outlet, and then unplugged. turn on the printer. Check the voltage of the outlet and breaker. Use...

  • Page 727: If The Printer Makes A Strange Sound

    Troubleshooting (CS2436-11) 11. 9. 2. Troubleshooting > Other problems > If the Printer Makes a Strange Sound Cause Corrective Action The following sounds do not indicate a problem with the printer. There is a sound of suction from the Platen...
  • Page 728 Troubleshooting (CS2436-11) the following conditions. Note that other operations are not possible while "Agitating" is displayed on the control panel. After the printer is turned on. (The time for agitation varies depending on how long the printer was off—between about 30 seconds and two minutes.) After data transmission.
  • Page 729 Troubleshooting (CS2436-11) 11. 9. 3. Troubleshooting > Other problems > Messages advising to check the maintenance cartridge are not cleared Cause Corrective Action Remove the new Maintenance The printer has not detected the Cartridge you have just installed new Maintenance Cartridge that and insert it again firmly.

  • Page 730: The Printer Consumes A Lot Of Ink

    Troubleshooting (CS2436-11) 11. 9. 4. Troubleshooting > Other problems > The printer consumes a lot of ink Cause Corrective Action In print jobs such as photos, images are filled Many full-page color with color. This consumes a lot of ink. This images are printed.

  • Page 731: Ink Level Detection

    Troubleshooting (CS2436-11) 11. 9. 5. Troubleshooting > Other problems > Ink Level Detection Ink level detection will be deactivated if you load ink tanks once emptied. Ink level detection Ink tanks specified for this printer feature an ink level detection function to prevent the ink from running out during printing, which prevents printer damage.
  • Page 732 Troubleshooting (CS2436-11) After checking the message, press the button. After checking the message, press the button. to select Yes, and then press the OK button. Press Check the message and press the button. Check the message and press the button.
  • Page 733 Troubleshooting (CS2436-11) Press to select Yes, and then press the OK button. A confirmation message about updating ink information is shown on the Display Screen. After checking the message, press the button. to select Yes, and then press the OK button.

  • Page 734: Error Message

    Error Message (CS2436-12) 12. Error Message 12. 1. Error Messages Borderless printng not possible. Cannot adjust paper feed. Cannot adjust printhead. Cannot detect papr Check printed document. Close Ink Tank Cover Do not pull out ink tank. End of paper feed.

  • Page 735: Messages Regarding Paper

    Error Message (CS2436-12) Parts replacement time has passed. Prepare for parts replacement. Printhead error Regular printing is selected, but a roll is loaded. Rel lever is in wrong position. Remaining level of the ink cannot be correctly detected. Roll paper is not securely in contact with roll holder.

  • Page 736: Messages Regarding Ink

    Error Message (CS2436-12) Rel lever is in wrong position. Borderless printng not possible. Paper position not suitable for borderless printing. Roll paper is not securely in contact with roll holder. 12. 3. Messages regarding ink Ink insufficient. No ink left.

  • Page 737: Other Messages

    Error Message (CS2436-12) GL2: W0502 The parameter is out of range. GL2: W0504 This command is not supported. 12. 8. Other Messages GARO Wxxxx (x represents a number) ERROR Exxx-xxxx (x represents a letter or number) Hardware error. xxxxxxxx-xxxx (x represents a letter or number) Top cover is open.

  • Page 738: Borderless Printng Not Possible

    Error Message (CS2436-12) 12. 1. 1. Error Message > Error Messages > Borderless printng not possible. Cause Corrective Action Follow these steps to change the settings of the print job to enable borderless printing. 1. Press to select Stop Printing, and then press the OK button.
  • Page 739 Error Message (CS2436-12) "Types of Paper (6.1.1).") to select Print With Border, Press and then press the OK button to continue printing. The document will be printed with a border.

  • Page 740: Cannot Adjust Paper Feed

    Error Message (CS2436-12) 12. 1. 2. Error Message > Error Messages > Cannot adjust paper feed. Cause Corrective Action Execute Adj. Quality again, as follows. 1. Press the OK button to clear the error. 2. Print a test pattern to check the nozzles.

  • Page 741: Cannot Adjust Printhead

    Error Message (CS2436-12) 12. 1. 3. Error Message > Error Messages > Cannot adjust printhead. Cause Corrective Action Execute Head Posi. Adj. again, as follows. 1. Press the OK button to clear the error. 2. Print a test pattern to check the nozzles.

  • Page 742: Cannot Detect Papr

    Error Message (CS2436-12) 12. 1. 4. Error Message > Error Messages > Cannot detect papr Cause Corrective Action Follow these step to reload a sheet. 1. Remove the paper and press the OK button. 2. Reload the sheet, aligning it with the guide on the right.

  • Page 743: Check Printed Document

    Error Message (CS2436-12) 12. 1. 5. Error Message > Error Messages > Check printed document. Cause Corrective Action If printing is faint, clean the Printhead. The Printhead nozzles are (See "Cleaning the Printhead (10.2.3).") becoming clogged.

  • Page 744: Close Ink Tank Cover

    Error Message (CS2436-12) 12. 1. 6. Error Message > Error Messages > Close Ink Tank Cover Cause Corrective Action The Ink Tank Cover is open. Close the Ink Tank Cover. The buzzer will stop once the error is cleared.

  • Page 745: Do Not Pull Out Ink Tank

    Error Message (CS2436-12) 12. 1. 7. Error Message > Error Messages > Do not pull out ink tank. Cause Corrective Action Install the Ink Tank that was The remaining ink level could not removed. be correctly detected. The buzzer will stop once the error...

  • Page 746: End Of Paper Feed

    Error Message (CS2436-12) 12. 1. 8. Error Message > Error Messages > End of paper feed. Cause Corrective Action You are pressing the button on the Control Release the button. Panel and trying to rewind the roll to the edge.
  • Page 747 Error Message (CS2436-12) 12. 1. 9. Error Message > Error Messages > ERROR Exxx-xxxx (x represents a letter or number) Cause Corrective Action An error requiring service may have occurred. Write down the error code and message, turn off the printer, and contact your Océ...

  • Page 748: Error In Cutter Position

    Error Message (CS2436-12) 12. 1. 10. Error Message > Error Messages > Error in cutter position. Cause Corrective Action 1. Push the Release Lever back and The Cutter Unit stops in the remove the paper. middle of cutting. 2. Pull the Release Lever forward.

  • Page 749: Execute Printhead Cleaning

    Error Message (CS2436-12) 12. 1. 11. Error Message > Error Messages > Execute printhead cleaning. Cause Corrective Action Follow these steps to clean the Printhead. 1. Stop printing by pressing to select Stop Printing. 2. Clean the Printhead. (See "Cleaning the Printhead (10.2.3).") If this message is still displayed, replace the Printhead.
  • Page 750 Error Message (CS2436-12) 12. 1. 12. Error Message > Error Messages > GARO Wxxxx (x represents a number) Cause Corrective Action Try printing again, using the correct printer driver. There is a problem with the print It is also possible to continue printing job.
  • Page 751 Error Message (CS2436-12) 12. 1. 13. Error Message > Error Messages > GL2: W0502 The parameter is out of range. Cause Corrective Action Check the print job. A parameter specified in a HP-GL/2 command is If you have specified ProcessingOption out of the supported >Warning >On in the Control Panel menu,...
  • Page 752 Error Message (CS2436-12) 12. 1. 14. Error Message > Error Messages > GL2: W0504 This command is not supported. Cause Corrective Action Check the print job. The printer has received an If you have specified ProcessingOption unsupported HP-GL/2 >Warning >On in the Control Panel menu, command.
  • Page 753 Error Message (CS2436-12) 12. 1. 15. Error Message > Error Messages > GL2: Wxxxx The memory is full. (xxxx is 0501, 0903, or 0904) Cause Corrective Action Because the entire print job could not be The printer memory is full.
  • Page 754 Error Message (CS2436-12) 12. 1. 16. Error Message > Error Messages > Hardware error. xxxxxxxx-xxxx (x represents a letter or number) Cause Corrective Action Turn off the printer and The last portion of roll paper was used during a remove the roll from print job.

  • Page 755: Ink Insufficient

    Error Message (CS2436-12) 12. 1. 17. Error Message > Error Messages > Ink insufficient. Cause Corrective Action Press to select Rep. Ink Tank, and then press the The ink level is low, so you cannot OK button. Replace the Ink...

  • Page 756: Ink Tank Is Empty

    Error Message (CS2436-12) 12. 1. 18. Error Message > Error Messages > Ink tank is empty. Cause Corrective Action There is no ink left in an ink tank. Open the Ink Tank Cover and replace the Ink Tank for which the Ink Lamp is flashing.

  • Page 757: Insert The Maintenance Cartridge

    Error Message (CS2436-12) 12. 1. 19. Error Message > Error Messages > Insert the maintenance cartridge. Cause Corrective Action Install the Maintenance Cartridge. The Maintenance Cartridge (See "Replacing the Maintenance is not installed. Cartridge (10.3.2).")

  • Page 758: Insufficient Paper For Job

    Error Message (CS2436-12) 12. 1. 20. Error Message > Error Messages > Insufficient paper for job Cause Corrective Action Press select Print, and then press the OK button to resume printing. However, the roll paper may run out during the print job...
  • Page 759 Error Message (CS2436-12) 12. 1. 21. Error Message > Error Messages > Maint. cart. The level is low Cause Corrective Action You can continue to print, but The Maintenance Cartridge is prepare a new Maintenance almost full. Cartridge to use when the message...

  • Page 760: Maintenance Cartridge Full

    Error Message (CS2436-12) 12. 1. 22. Error Message > Error Messages > Maintenance cartridge full. Cause Corrective Action After confirming that the printer has stopped operating, replace the Maintenance The Maintenance Cartridge Cartridge. is full. (See "Replacing the Maintenance Cartridge (10.3.2).")

  • Page 761: Maintenance Cartridge Problem

    Error Message (CS2436-12) 12. 1. 23. Error Message > Error Messages > Maintenance cartridge problem. Cause Corrective Action Install an unused Maintenance Cartridge An incompatible or used specified for use with the printer. Maintenance Cartridge has (See "Replacing the Maintenance been installed.

  • Page 762: Mediatype Mismatch

    Error Message (CS2436-12) 12. 1. 24. Error Message > Error Messages > MediaType Mismatch Cause Corrective Action Follow these steps to ensure the paper type matches on the printer and in the printer driver. 1. Press to select Stop Printing, When Detect Mismatch and then press the OK button.
  • Page 763 Error Message (CS2436-12) 12. 1. 25. Error Message > Error Messages > Multi-sensor error Cause Corrective Action Direct sunlight or strong lighting may Take steps to ensure the printer be shining on the printer and causing is not used when exposed to the sensor to malfunction.

  • Page 764: No Ink Left

    Error Message (CS2436-12) 12. 1. 26. Error Message > Error Messages > No ink left. Cause Corrective Action Open the Ink Tank Cover and replace the Ink Tank for which the Ink Lamp is flashing. There is no ink left.

  • Page 765: No Ink Tank Loaded

    Error Message (CS2436-12) 12. 1. 27. Error Message > Error Messages > No ink tank loaded. Cause Corrective Action There is no Ink Tank of the indicated color in the printer. Load or reload the Ink Tank. (See "Replacing Ink Tanks (10.1.2).")

  • Page 766: No Maintenance Cartridge Capacity

    Error Message (CS2436-12) 12. 1. 28. Error Message > Error Messages > No Maintenance Cartridge capacity. Cause Corrective Action After confirming that the printer has The Maintenance Cartridge stopped operating, replace the Maintenance cannot absorb enough ink Cartridge. for Printhead cleaning or (See "Replacing the Maintenance...
  • Page 767 Error Message (CS2436-12) 12. 1. 29. Error Message > Error Messages > No printhead Cause Corrective Action Install the Printhead. No Printhead is installed. (See "Replacing the Printhead (10.2.4).")

  • Page 768: Not Much Ink Is Left

    Error Message (CS2436-12) 12. 1. 30. Error Message > Error Messages > Not much ink is left. Cause Corrective Action Not much ink is left. Prepare a new Ink Tank. We recommend replacing the Ink Tank with a new Ink Tank at this point if you plan to print large-...

  • Page 769: Paper Cutting Failed

    Error Message (CS2436-12) 12. 1. 31. Error Message > Error Messages > Paper cutting failed. Cause Corrective Action 1. Push the Release Lever back and remove the paper. 2. Load the paper. 3. Pull the Release Lever forward. 4. If "Not finished printing. Finish There are sheets left on the printing remaining jobs?"...
  • Page 770 Error Message (CS2436-12) 1. Specify Manual as the cutting method and use scissors or a cutting tool to cut the roll. (See "Specifying the Cutting Method You are using paper that is not for Rolls (6.2.13).") compatible with automatic For information about paper that is cutting.

  • Page 771: Paper Is Crooked

    Error Message (CS2436-12) 12. 1. 32. Error Message > Error Messages > Paper is crooked. Cause Corrective Action Follow these steps to reload the roll. 1. Push the Release Lever back. 2. Adjust the right edge of the roll to make it...
  • Page 772 Error Message (CS2436-12) Follow these step to reload a sheet. 1. Push the Release Lever back. 2. Pull out the sheet. 3. Pull the Release Lever forward. 4. Reload the sheet, aligning it with the guide on the right. (See "Loading Sheets in the Printer (6.3.1).")

  • Page 773: Paper Jam

    Error Message (CS2436-12) 12. 1. 33. Error Message > Error Messages > Paper jam "Push the release lever back." Cause Corrective Action 1. Push the Release Lever back and remove the jammed paper. (See "Clearing Jammed Roll Paper (11.2.2).") (See "Clearing a Jammed Sheet (11.2.3).") 2.

  • Page 774: Paper Not Aligned With Right Guide

    Error Message (CS2436-12) 12. 1. 34. Error Message > Error Messages > Paper not aligned with right guide. Cause Corrective Action Follow these step to reload a sheet. 1. Push the Release Lever back. When paper was loaded, it 2. Pull out the sheet.

  • Page 775: Paper Position Not Suitable For Borderless Printing

    Error Message (CS2436-12) 12. 1. 35. Error Message > Error Messages > Paper position not suitable for borderless printing. Cause Corrective Action Press to select Stop Printing, and then press the OK button. Use each type of paper only where the...

  • Page 776: Paper Size Not Detected

    Error Message (CS2436-12) 12. 1. 36. Error Message > Error Messages > Paper size not detected. Cause Corrective Action Follow these steps to reload the roll. 1. Push the Release Lever back. 2. Adjust the right edge of the roll to make it...
  • Page 777 Error Message (CS2436-12) If this error recurs after you reload the roll, remove the Roll Holder from the printer, push the roll firmly in until it touches the Roll Holder flange, and reload the Roll Holder in the printer. (See "Attaching the Roll Holder to Rolls (6.2.1).")
  • Page 778 Error Message (CS2436-12) Open the Top Cover and clean the entire Because the Platen is soiled with ink or other Platen. substances, the size of the clear film cannot be (See "Cleaning detected. Inside the Top Cover (10.4.2).")

  • Page 779: Paprwidth Mismatch

    Error Message (CS2436-12) 12. 1. 37. Error Message > Error Messages > PaprWidth Mismatch Cause Corrective Action Press to select Print, and then press the OK button to resume printing. However, note that this error may cause paper jams and affect the printing quality.

  • Page 780: Parts Replacement Time Has Passed

    Error Message (CS2436-12) 12. 1. 38. Error Message > Error Messages > Parts replacement time has passed. Cause Corrective Action It is past the recommended time to Contact your Océ dealer for replace consumables for which service is assistance. required.

  • Page 781: Prepare For Parts Replacement

    Error Message (CS2436-12) 12. 1. 39. Error Message > Error Messages > Prepare for parts replacement. Cause Corrective Action You can continue to use the printer for some time until "Parts It is almost time to replace replacement time has passed."...

  • Page 782: Printhead Error

    Error Message (CS2436-12) 12. 1. 40. Error Message > Error Messages > Printhead error Cause Corrective Action Open the Top Cover and replace the Printhead There is a problem with with a new one. the Printhead. (See "Replacing the Printhead (10.2.4).")
  • Page 783 Error Message (CS2436-12) 12. 1. 41. Error Message > Error Messages > Regular printing is selected, but a roll is loaded. Cause Corrective Action 1. Press to select Remove Roll Paper, and then press the OK button to stop printing.

  • Page 784: Rel Lever Is In Wrong Position

    Error Message (CS2436-12) 12. 1. 42. Error Message > Error Messages > Rel lever is in wrong position. Cause Corrective Action Pull the Release Lever forward. The Release Lever is pushed Turn off the printer and wait a while back.

  • Page 785: Remaining Level Of The Ink Cannot Be Correctly Detected

    Error Message (CS2436-12) 12. 1. 43. Error Message > Error Messages > Remaining level of the ink cannot be correctly detected. Cause Corrective Action The refill ink tank can no longer be used. See the Ink level detection section Ink level detection and take the cannot work correctly appropriate action.

  • Page 786: Roll Paper Is Not Securely In Contact With Roll Holder

    Error Message (CS2436-12) 12. 1. 44. Error Message > Error Messages > Roll paper is not securely in contact with roll holder. Cause Corrective Action Follow these steps to reload the roll. 1. Press the OK button and remove the roll When the roll was holder from the printer.
  • Page 787 Error Message (CS2436-12) 12. 1. 45. Error Message > Error Messages > Roll printing is selected, but sheets are loaded. Cause Corrective Action Follow these steps to load and print on a roll. 1. Press to select Eject Cut Sheet, press the OK button, and remove the sheet.

  • Page 788: Roll Printing Is Selected

    Error Message (CS2436-12) 12. 1. 46. Error Message > Error Messages > Roll printing is selected. Cause Corrective Action Press to select Load Roll Paper, and then press the OK button. Load the roll, and then print. (See "Attaching the Roll Holder to Rolls (6.2.1).")

  • Page 789: Sheet Printing Is Selected

    Error Message (CS2436-12) 12. 1. 47. Error Message > Error Messages > Sheet printing is selected. Cause Corrective Action Press to select Load Cut Sheet, and then press the OK button. Load the sheet, and then print. (See "Loading and Printing on Sheets (1.1.3).")

  • Page 790: The Paper Is Too Small

    Error Message (CS2436-12) 12. 1. 48. Error Message > Error Messages > The paper is too small. Cause Corrective Action Press to select Print, and then press the OK button to resume printing. However, note that this error may cause paper jams and affect the printing quality.
  • Page 791 Error Message (CS2436-12) 12. 1. 49. Error Message > Error Messages > The paper is too small. "Replace paper with A4/LTR (vertical) or larger" Cause Corrective Action Replace the paper with paper of A4/Letter (vertical) size or larger as follows.
  • Page 792 Error Message (CS2436-12) 1. Press the Release Lever back and remove the paper. 2. Reload the sheet, aligning it with the guide on the right. A sheet has come out of the printer during 3. Pull the Release printing. Lever forward.

  • Page 793: The Roll Is Empty

    Error Message (CS2436-12) 12. 1. 50. Error Message > Error Messages > The roll is empty. Cause Corrective Action Follow these steps to replace the used roll with a new roll of the same type and size. 1. Press the Release Lever back and remove the roll.

  • Page 794: This Paper Cannot Be Used

    Error Message (CS2436-12) 12. 1. 51. Error Message > Error Messages > This paper cannot be used. Cause Corrective Action Push the Release Lever back and load Paper smaller than the printer's paper of the correct size. minimum supported size has (See "Paper Sizes (6.1.2).")
  • Page 795 Error Message (CS2436-12) 12. 1. 52. Error Message > Error Messages > This type of paper is not compatible with HP-GL/2. Cause Corrective Action Follow these steps to replace the type of paper in the printer. 1. Press to select Stop Printing, and then press the OK button.

  • Page 796: Top Cover Is Open

    Error Message (CS2436-12) 12. 1. 53. Error Message > Error Messages > Top cover is open. Cause Corrective Action Open the Top Cover fully, remove any foreign objects, and close the Top Cover again. The printer has detected that the Top Cover is open.

  • Page 797: Unable To Detect Ink Level Correctly

    Error Message (CS2436-12) 12. 1. 54. Error Message > Error Messages > Unable to detect ink level correctly. Cause Corrective Action Close the Ink Tank Cover. The remaining ink level could not The buzzer will stop once the error be correctly detected.

  • Page 798: Unknown File

    Error Message (CS2436-12) 12. 1. 55. Error Message > Error Messages > Unknown file. Cause Corrective Action Check the data. Turn off the Data sent to keep the printer up to printer and wait a while before date (such as paper information) is in restoring power, and then resend the wrong format.

  • Page 799: Wrong Ink Tank

    Error Message (CS2436-12) 12. 1. 56. Error Message > Error Messages > Wrong ink tank. Cause Corrective Action Load an Ink Tank specified for use with The Ink Tank in the printer is the printer. incompatible. (See "Replacing Ink Tanks (10.1.2).")

  • Page 800: Wrong Maintenance Cartridge

    Error Message (CS2436-12) 12. 1. 57. Error Message > Error Messages > Wrong maintenance cartridge. Cause Corrective Action A Maintenance Cartridge for a Replace it with the Maintenance different model of printer is installed. Cartridge for your particular model.

  • Page 801: Wrong Printhead

    Error Message (CS2436-12) 12. 1. 58. Error Message > Error Messages > Wrong printhead. Cause Corrective Action Open the Top Cover and replace the An incompatible Printhead Printhead with a new one. has been installed. (See "Replacing the Printhead (10.2.4).")
  • Page 802 Error Message (CS2436-12) 12. 2. 1. Error Message > Messages regarding paper > MediaType Mismatch Cause Corrective Action Follow these steps to ensure the paper type matches on the printer and in the printer driver. 1. Press to select Stop Printing, When Detect Mismatch and then press the OK button.
  • Page 803 Error Message (CS2436-12) 12. 2. 2. Error Message > Messages regarding paper > The paper is too small. Cause Corrective Action Press to select Print, and then press the OK button to resume printing. However, note that this error may cause paper jams and affect the printing quality.
  • Page 804 Error Message (CS2436-12) 12. 2. 3. Error Message > Messages regarding paper > The paper is too small. "Replace paper with A4/LTR (vertical) or larger" Cause Corrective Action Replace the paper with paper of A4/Letter (vertical) size or larger as follows.
  • Page 805 Error Message (CS2436-12) 1. Press the Release Lever back and remove the paper. 2. Reload the sheet, aligning it with the guide on the right. A sheet has come out of the printer during 3. Pull the Release printing. Lever forward.
  • Page 806 Error Message (CS2436-12) 12. 2. 4. Error Message > Messages regarding paper > PaprWidth Mismatch Cause Corrective Action Press to select Print, and then press the OK button to resume printing. However, note that this error may cause paper jams and affect the printing quality.
  • Page 807 Error Message (CS2436-12) 12. 2. 5. Error Message > Messages regarding paper > Paper size not detected. Cause Corrective Action Follow these steps to reload the roll. 1. Push the Release Lever back. 2. Adjust the right edge of the...
  • Page 808 Error Message (CS2436-12) If this error recurs after you reload the roll, remove the Roll Holder from the printer, push the roll firmly in until it touches the Roll Holder flange, and reload the Roll Holder in the printer. (See "Attaching the Roll Holder to Rolls (6.2.1).")
  • Page 809 Error Message (CS2436-12) Open the Top Cover and clean the entire Because the Platen is soiled with ink or other Platen. substances, the size of the clear film cannot be (See "Cleaning detected. Inside the Top Cover (10.4.2).")
  • Page 810 Error Message (CS2436-12) 12. 2. 6. Error Message > Messages regarding paper > Insufficient paper for job Cause Corrective Action Press select Print, and then press the OK button to resume printing. However, the roll paper may run out during the print job...
  • Page 811 Error Message (CS2436-12) 12. 2. 7. Error Message > Messages regarding paper > This paper cannot be used. Cause Corrective Action Push the Release Lever back and load Paper smaller than the printer's paper of the correct size. minimum supported size has (See "Paper Sizes (6.1.2).")
  • Page 812 Error Message (CS2436-12) 12. 2. 8. Error Message > Messages regarding paper > Roll printing is selected. Cause Corrective Action Press to select Load Roll Paper, and then press the OK button. Load the roll, and then print. (See "Attaching the Roll Holder to Rolls (6.2.1).")
  • Page 813 Error Message (CS2436-12) 12. 2. 9. Error Message > Messages regarding paper > Roll printing is selected, but sheets are loaded. Cause Corrective Action Follow these steps to load and print on a roll. 1. Press to select Eject Cut Sheet, press the OK button, and remove the sheet.
  • Page 814 Error Message (CS2436-12) 12. 2. 10. Error Message > Messages regarding paper > The roll is empty. Cause Corrective Action Follow these steps to replace the used roll with a new roll of the same type and size. 1. Press the Release Lever back and remove the roll.
  • Page 815 Error Message (CS2436-12) 12. 2. 11. Error Message > Messages regarding paper > Sheet printing is selected. Cause Corrective Action Press to select Load Cut Sheet, and then press the OK button. Load the sheet, and then print. (See "Loading and Printing on Sheets (1.1.3).")
  • Page 816 Error Message (CS2436-12) 12. 2. 12. Error Message > Messages regarding paper > Regular printing is selected, but a roll is loaded. Cause Corrective Action 1. Press to select Remove Roll Paper, and then press the OK button to stop printing.
  • Page 817 Error Message (CS2436-12) 12. 2. 13. Error Message > Messages regarding paper > Paper jam "Push the release lever back." Cause Corrective Action 1. Push the Release Lever back and remove the jammed paper. (See "Clearing Jammed Roll Paper (11.2.2).") (See "Clearing a Jammed Sheet (11.2.3).")
  • Page 818 Error Message (CS2436-12) 12. 2. 14. Error Message > Messages regarding paper > Paper is crooked. Cause Corrective Action Follow these steps to reload the roll. 1. Push the Release Lever back. 2. Adjust the right edge of the roll to make it...
  • Page 819 Error Message (CS2436-12) Follow these step to reload a sheet. 1. Push the Release Lever back. 2. Pull out the sheet. 3. Pull the Release Lever forward. 4. Reload the sheet, aligning it with the guide on the right. (See "Loading Sheets in the Printer (6.3.1).")
  • Page 820 Error Message (CS2436-12) 12. 2. 15. Error Message > Messages regarding paper > Paper not aligned with right guide. Cause Corrective Action Follow these step to reload a sheet. 1. Push the Release Lever back. When paper was loaded, it 2.
  • Page 821 Error Message (CS2436-12) 12. 2. 16. Error Message > Messages regarding paper > Cannot detect papr Cause Corrective Action Follow these step to reload a sheet. 1. Remove the paper and press the OK button. 2. Reload the sheet, aligning it with the guide on the right.
  • Page 822 Error Message (CS2436-12) 12. 2. 17. Error Message > Messages regarding paper > Paper cutting failed. Cause Corrective Action 1. Push the Release Lever back and remove the paper. 2. Load the paper. 3. Pull the Release Lever forward. 4. If "Not finished printing. Finish There are sheets left on the printing remaining jobs?"...
  • Page 823 Error Message (CS2436-12) 1. Specify Manual as the cutting method and use scissors or a cutting tool to cut the roll. (See "Specifying the Cutting Method You are using paper that is not for Rolls (6.2.13).") compatible with automatic For information about paper that is cutting.
  • Page 824 Error Message (CS2436-12) 12. 2. 18. Error Message > Messages regarding paper > End of paper feed. Cause Corrective Action You are pressing the button on the Control Release the button. Panel and trying to rewind the roll to the edge.
  • Page 825 Error Message (CS2436-12) 12. 2. 19. Error Message > Messages regarding paper > Rel lever is in wrong position. Cause Corrective Action Pull the Release Lever forward. The Release Lever is pushed Turn off the printer and wait a while back.
  • Page 826 Error Message (CS2436-12) 12. 2. 20. Error Message > Messages regarding paper > Borderless printing not possible. Cause Corrective Action Follow these steps to change the settings of the print job to enable borderless printing. 1. Press to select Stop Printing, and then press the OK button.
  • Page 827 Error Message (CS2436-12) (See "Types of Paper (6.1.1).") to select Print With Border, Press and then press the OK button to continue printing. The document will be printed with a border.
  • Page 828 Error Message (CS2436-12) 12. 2. 21. Error Message > Messages regarding paper > Paper position not suitable for borderless printing. Cause Corrective Action Press to select Stop Printing, and then press the OK button. Use each type of paper only where the...
  • Page 829 Error Message (CS2436-12) 12. 2. 22. Error Message > Messages regarding paper > Roll paper is not securely in contact with roll holder. Cause Corrective Action Follow these steps to reload the roll. 1. Press the OK button and remove the roll When the roll was holder from the printer.
  • Page 830 Error Message (CS2436-12) 12. 3. 1. Error Message > Messages regarding ink > Ink insufficient. Cause Corrective Action Press to select Rep. Ink Tank, and then press the The ink level is low, so you cannot OK button. Replace the Ink...
  • Page 831 Error Message (CS2436-12) 12. 3. 2. Error Message > Messages regarding ink > No ink left. Cause Corrective Action Open the Ink Tank Cover and replace the Ink Tank for which the Ink Lamp is flashing. There is no ink left.
  • Page 832 Error Message (CS2436-12) 12. 3. 3. Error Message > Messages regarding ink > Remaining level of the ink cannot be correctly detected. Cause Corrective Action The refill ink tank can no longer be used. See the Ink level detection section Ink level detection and take the cannot work correctly appropriate action.
  • Page 833 Error Message (CS2436-12) 12. 3. 4. Error Message > Messages regarding ink > Unable to detect ink level correctly. Cause Corrective Action Close the Ink Tank Cover. The remaining ink level could not The buzzer will stop once the error be correctly detected.
  • Page 834 Error Message (CS2436-12) 12. 3. 5. Error Message > Messages regarding ink > Close Ink Tank Cover Cause Corrective Action The Ink Tank Cover is open. Close the Ink Tank Cover. The buzzer will stop once the error is cleared.
  • Page 835 Error Message (CS2436-12) 12. 3. 6. Error Message > Messages regarding ink > Ink tank is empty. Cause Corrective Action There is no ink left in an ink tank. Open the Ink Tank Cover and replace the Ink Tank for which the Ink Lamp is flashing.
  • Page 836 Error Message (CS2436-12) 12. 3. 7. Error Message > Messages regarding ink > Not much ink is left. Cause Corrective Action Not much ink is left. Prepare a new Ink Tank. We recommend replacing the Ink Tank with a new Ink Tank at this point if you plan to print large- format or high-quantity jobs.
  • Page 837 Error Message (CS2436-12) 12. 3. 8. Error Message > Messages regarding ink > No ink tank loaded. Cause Corrective Action There is no Ink Tank of the indicated color in the printer. Load or reload the Ink Tank. (See "Replacing Ink Tanks (10.1.2).")
  • Page 838 Error Message (CS2436-12) 12. 3. 9. Error Message > Messages regarding ink > Wrong ink tank. Cause Corrective Action Load an Ink Tank specified for use with The Ink Tank in the printer is the printer. incompatible. (See "Replacing Ink Tanks (10.1.2).")
  • Page 839 Error Message (CS2436-12) 12. 3. 10. Error Message > Messages regarding ink > Do not pull out ink tank. Cause Corrective Action Install the Ink Tank that was The remaining ink level could not removed. be correctly detected. The buzzer will stop once the error...
  • Page 840 Error Message (CS2436-12) 12. 4. 1. Error Message > Messages regarding printing or adjustment > Cannot adjust printhead. Cause Corrective Action Execute Head Posi. Adj. again, as follows. 1. Press the OK button to clear the error. 2. Print a test pattern to check the nozzles.
  • Page 841 Error Message (CS2436-12) 12. 4. 2. Error Message > Messages regarding printing or adjustment > Cannot adjust paper feed. Cause Corrective Action Execute Adj. Quality again, as follows. 1. Press the OK button to clear the error. 2. Print a test pattern to check the nozzles.
  • Page 842 Error Message (CS2436-12) 12. 4. 3. Error Message > Messages regarding printing or adjustment > Check printed document. Cause Corrective Action If printing is faint, clean the Printhead. The Printhead nozzles are (See "Cleaning the Printhead (10.2.3).") becoming clogged.
  • Page 843 Error Message (CS2436-12) 12. 5. 1. Error Message > Messages regarding printheads > Cannot adjust printhead. Cause Corrective Action Execute Head Posi. Adj. again, as follows. 1. Press the OK button to clear the error. 2. Print a test pattern to check the nozzles.
  • Page 844 Error Message (CS2436-12) 12. 5. 2. Error Message > Messages regarding printheads > Wrong printhead. Cause Corrective Action Open the Top Cover and replace the An incompatible Printhead Printhead with a new one. has been installed. (See "Replacing the Printhead (10.2.4).")
  • Page 845 Error Message (CS2436-12) 12. 5. 3. Error Message > Messages regarding printheads > Printhead error Cause Corrective Action Open the Top Cover and replace the Printhead There is a problem with with a new one. the Printhead. (See "Replacing the Printhead (10.2.4).")
  • Page 846 Error Message (CS2436-12) 12. 5. 4. Error Message > Messages regarding printheads > No printhead Cause Corrective Action Install the Printhead. No Printhead is installed. (See "Replacing the Printhead (10.2.4).")
  • Page 847 Error Message (CS2436-12) 12. 5. 5. Error Message > Messages regarding printheads > Execute printhead cleaning. Cause Corrective Action Follow these steps to clean the Printhead. 1. Stop printing by pressing to select Stop Printing. 2. Clean the Printhead. (See "Cleaning the Printhead (10.2.3).") If this message is still displayed, replace the Printhead.
  • Page 848 Error Message (CS2436-12) 12. 6. 1. Error Message > Messages regarding the maintenance cartridge > Insert the maintenance cartridge. Cause Corrective Action Install the Maintenance Cartridge. The Maintenance Cartridge (See "Replacing the Maintenance is not installed. Cartridge (10.3.2).")
  • Page 849 Error Message (CS2436-12) 12. 6. 2. Error Message > Messages regarding the maintenance cartridge > Wrong maintenance cartridge. Cause Corrective Action A Maintenance Cartridge for a Replace it with the Maintenance different model of printer is installed. Cartridge for your particular model.
  • Page 850 Error Message (CS2436-12) 12. 6. 3. Error Message > Messages regarding the maintenance cartridge > Maint. cart. The level is low Cause Corrective Action You can continue to print, but The Maintenance Cartridge is prepare a new Maintenance almost full.
  • Page 851 Error Message (CS2436-12) 12. 6. 4. Error Message > Messages regarding the maintenance cartridge > No Maintenance Cartridge capacity. Cause Corrective Action After confirming that the printer has The Maintenance Cartridge stopped operating, replace the Maintenance cannot absorb enough ink Cartridge.
  • Page 852 Error Message (CS2436-12) 12. 6. 5. Error Message > Messages regarding the maintenance cartridge > Maintenance cartridge full. Cause Corrective Action After confirming that the printer has stopped operating, replace the Maintenance The Maintenance Cartridge Cartridge. is full. (See "Replacing the Maintenance...
  • Page 853 Error Message (CS2436-12) 12. 6. 6. Error Message > Messages regarding the maintenance cartridge > Maintenance cartridge problem. Cause Corrective Action Install an unused Maintenance Cartridge An incompatible or used specified for use with the printer. Maintenance Cartridge has (See "Replacing the Maintenance been installed.
  • Page 854 Error Message (CS2436-12) 12. 7. 1. Error Message > Messages regarding HP-GL/2 > This type of paper is not compatible with HP-GL/2. Cause Corrective Action Follow these steps to replace the type of paper in the printer. 1. Press to select Stop Printing, and then press the OK button.
  • Page 855 Error Message (CS2436-12) 12. 7. 2. Error Message > Messages regarding HP-GL/2 > GL2: Wxxxx The memory is full. (xxxx is 0501, 0903, or 0904) Cause Corrective Action Because the entire print job could not be The printer memory is full.
  • Page 856 Error Message (CS2436-12) 12. 7. 3. Error Message > Messages regarding HP-GL/2 > GL2: W0502 The parameter is out of range. Cause Corrective Action Check the print job. A parameter specified in a HP-GL/2 command is If you have specified ProcessingOption out of the supported >Warning >On in the Control Panel menu,...
  • Page 857 Error Message (CS2436-12) 12. 7. 4. Error Message > Messages regarding HP-GL/2 > GL2: W0504 This command is not supported. Cause Corrective Action Check the print job. The printer has received an If you have specified ProcessingOption unsupported HP-GL/2 >Warning >On in the Control Panel menu, command.
  • Page 858 Error Message (CS2436-12) 12. 8. 1. Error Message > Other Messages > GARO Wxxxx (x represents a number) Cause Corrective Action Try printing again, using the correct printer driver. There is a problem with the print It is also possible to continue printing job.
  • Page 859 Error Message (CS2436-12) 12. 8. 2. Error Message > Other Messages > ERROR Exxx-xxxx (x represents a letter or number) Cause Corrective Action An error requiring service may have occurred. Write down the error code and message, turn off the printer, and contact your Océ...
  • Page 860 Error Message (CS2436-12) 12. 8. 3. Error Message > Other Messages > Hardware error. xxxxxxxx-xxxx (x represents a letter or number) Cause Corrective Action Turn off the printer and The last portion of roll paper was used during a remove the roll from print job.
  • Page 861 Error Message (CS2436-12) 12. 8. 4. Error Message > Other Messages > Top cover is open. Cause Corrective Action Open the Top Cover fully, remove any foreign objects, and close the Top Cover again. The printer has detected that the Top Cover is open.
  • Page 862 Error Message (CS2436-12) 12. 8. 5. Error Message > Other Messages > Prepare for parts replacement. Cause Corrective Action You can continue to use the printer for some time until "Parts It is almost time to replace replacement time has passed."...
  • Page 863 Error Message (CS2436-12) 12. 8. 6. Error Message > Other Messages > Parts replacement time has passed. Cause Corrective Action It is past the recommended time to Contact your Océ dealer for replace consumables for which service is assistance. required.
  • Page 864 Error Message (CS2436-12) 12. 8. 7. Error Message > Other Messages > Unknown file. Cause Corrective Action Check the data. Turn off the Data sent to keep the printer up to printer and wait a while before date (such as paper information) is in restoring power, and then resend the wrong format.
  • Page 865 Error Message (CS2436-12) 12. 8. 8. Error Message > Other Messages > Multi-sensor error Cause Corrective Action Direct sunlight or strong lighting may Take steps to ensure the printer be shining on the printer and causing is not used when exposed to the sensor to malfunction.
  • Page 866 Error Message (CS2436-12) 12. 8. 9. Error Message > Other Messages > Error in cutter position. Cause Corrective Action 1. Push the Release Lever back and The Cutter Unit stops in the remove the paper. middle of cutting. 2. Pull the Release Lever forward.

  • Page 867: How To Use This Manual

    Appendix (CS2436-13) 13. Appendix 13. 1. How to use this manual About This User Manual...

  • Page 868: About This User Manual

    Appendix (CS2436-13) 13. 1. 1. Appendix > How to use this manual > About This User Manual Symbols ● The following symbols are used in this User Manual to indicate safety information and explanations on restrictions or precautions in use.
  • Page 869 Appendix (CS2436-13) Other cross-reference Example: See the printer driver help. Figures and software screens ● Figures in this User Manual may be different from the actual appearance of the ● printer in some cases. Screens depicted in this User Manual for the printer driver or other software may ●...
  • Page 870 Appendix (CS2436-13)

Table of Contents

Save PDF
