Setup Flow Setup Flow Overview Unpack and Make Sure You Have Everything Assembling the Stand Installing the Printer Attaching the Output Stacker Chapter 1 Read this first...
Page 7
Setup Flow Removing the Packing Material Connecting the Power Stowing the Output Stacker Installing the Printhead Installing the Ink Tanks PC C PM M Loading Roll Media...
Setup Flow Adjusting the Print Status Run an automatic adjustment of the printhead and media feed amount. [10] Information Power Data MAIN MENU Adjust Printer Message Cleaning (3sec) Stop/Eject Online Offline Menu Attention: For USB connections, do not connect the cable before installing the printer driver.
Unpack and Make Sure You Have Everything Unpack and Make Sure You Have Everything Printer Set [12] Printer [13] Power Cable [14] Ink Tanks ■ ■ ■ ■ ■ ■ [15] Roll holder [16] Spool Prevention Stays (x 4) [17] Cleaning Brush [18] Printhead...
Page 10
Unpack and Make Sure You Have Everything [20] Quick Start Guide (This guide) [21] Reference Guide [22] User Software CD-ROM ■ User Manuals CD-ROM ■ Consumables Guide ■ Guide to Mounting the Spool Prevention Stay ■ Warantee ■ Guide to Service and Support ■...
Page 11
Unpack and Make Sure You Have Everything [26] Output Stacker Arms L and R [27] Output Stacker [28] Rod Holders (x 2) [29] M4 Hex Driver ■ M8 Hex Driver ■ [30] Stand Extension Boards L and R [31] M4 Hex Screws (x 18)
Page 12
Unpack and Make Sure You Have Everything Installation Space When you are installing the printer, reserve a space of the following dimensions or larger. [32] 2042 mm [32] Height [33] [33] Width and Depth Chapter 1 Read this first...
Assembling the Stand Assembling the Stand Caution: Have at least 2 people work on assembling the stand. Attempting this work alone may cause personal injuries or warp the stand. Insert the right side of Stand Lower Stay (b) all the way into the hole in the side of Stand Leg R (a), and insert the left side of Stand Lower Stay all the way into the hold in the side of Stand Leg L (c).
Page 14
Assembling the Stand Remove the tape that is attached the left and right sides of Stand Upper Stay (d). [37] Arrange the Stand Upper Stay so that the bends in the brackets on the left and right side (e) are facing up, and the side marked with an R is facing the Stand Leg R (a). Insert the Stand Upper Stay into the groove between Stand Leg R (a) and Stand Leg L (c).
Page 15
Assembling the Stand Place the Stand in the installation location and lock the front casters. [40]...
Installing the Printer Installing the Printer Illustration [41] [42] Remove the box from the printer body and clear out the packing material from above the printer, then lift up the base of the printer one side at a time and clear out the packing material from under the printer.
Page 17
Installing the Printer Have 4 people grasp the handholds in the base of the printer body, then align the side of the printer body (h) with the line on the Stand Extension Board (i) and put the printer on the stand. [45] Remove Stand Extension Board (e) and (g) from the Stand Legs.
Attaching the Output Stacker Attaching the Output Stacker Insert the Rod Holders (c) into holes on the back of Stand Leg L (a) and Stand Leg R (b). [47] Insert Output Stacker Arm L (e) and Output Stacker Arm R (f) into the grooves (d) in the left and right ends of the Stand Upper Stay, then attach them using 2 hex screws.
Page 19
Attaching the Output Stacker Attach the Output Stacker Rod (j) in the center of the Output Stacker fabric to the Rod Holder (i), and loop the hole in the fabric (k) over the hook (l) above the Rod Holder. [50] Attention: Attach the Output Stacker Rods to the Rod Holders in front of the Output Stacker Arm and at the very back of the Rod Holder.
Removing the Packing Material Removing the Packing Material Removing the tape and packing material that is attached to the printer body. [52] Open the top cover. [53] Lift up Release Lever (a) and remove the protective sheet (b) from the Platen, then lower the Release Lever.
Page 21
Removing the Packing Material Remove the belt stopper (c) screws, and then remove the warning card that is attached by string, and the belt stopper. [55] Note: The Belt Stopper, screw and hex driver are needed for transporting the printer.Store the Belt Stopper that you removed and the tools, etc. carefully in a safe place.
Page 22
Removing the Packing Material Remove the Roll Holder and remove the tape and packing material that is attached to the Roll Holder. [57] Attach the four spool prevention stays (d) to the back of the ejection guide. [58] Close the ejection guide, and then close the top cover. [59] Chapter 1 Read this first...
Page 23
Removing the Packing Material Attach the Accessory Pocket to the left side of the rear surface of the printer. [60] This completes the printer assembly.
Connecting the Power Connecting the Power Connect the power cable to the power supply connector in the left side of the printer. [61] Insert the power plug into the outlet. The shape of the power cable varies from country to country. [62] Chapter 1 Read this first...
Installing the Printhead Installing the Printhead If the printer is off, press the Power button to switch the printer on. [63] Information Power Printer Setup Open UpperCover Cleaning (3sec) Open the top cover. [64] Attention: Do not touch any areas other than as directed under any circumstances.
Page 26
Installing the Printhead Hold the printhead by the grips (a) and remove it from the case, then remove the protective orange cap 1 (b). [67] Push the tabs (d) on either side of printhead protective cap 2 (c) as shown in the diagram, and pull down to remove the cap.
Page 27
Installing the Printhead Attention: When you are handling the printhead, always hold it by the grips (a) on the left and right sides. Attention: Do not touch the nozzles (e) or the electrical contacts (f) under any circumstances. Doing so may damage the printhead or cause printing problems. Attention: Never try to re-attach the protective caps or packing material that you removed from the printhead.Dispose of these parts in accordance with local garbage disposal regulations.
Page 28
Installing the Printhead Push the printhead fixer lever toward the back of the printer and then press down until you hear it click. [72] Close the top cover. [73] Chapter 1 Read this first...
Installing the Ink Tanks Installing the Ink Tanks Open the right back cover. [74] Press the ink tank lever of the color you are loading to open the ink tank cover. [75] Gently shake the ink tank 7 or 8 times while it is still in the bag before removing it from the bag.
Page 30
Installing the Ink Tanks Attention: When you are handling an ink tank, always hold it by the grips (a) on the left and right sides. Attention: Do not touch the ink supply port (b) or the electrical contacts (c) under any circumstances. Doing so may cause printing problems or stain the surrounding.
Page 31
Installing the Ink Tanks Close the ink tank cover until you hear a click. [78] Repeat steps 1 to 4 to install the other ink tank colors. Close the right back cover after you have installed all of the ink tank colors. [79]...
Loading Roll Media Loading Roll Media Attention: When you are handling roll media, it is recommended that you wear clean fabric gloves to protect the printing surface. Raise the holder stopper lever (a) from the axle to unlock the holder stopper, and then remove the holder stopper from the roll holder.
Page 33
Loading Roll Media Open the top cover and then open the ejection guide. [83] Orient the roll holder with the front edge of the roll media facing you, then align the roll holder (b) with the left and right guide grooves (c) in the roll holder slot and insert the roll holder.
Page 34
Loading Roll Media Pull out the leading edge of the roll media keeping both left and right sides level, and insert the media into the paper feed slot (d), and feed the paper until it reaches the paperweight (e). [85] Once the media reaches the paperweight, it is automatically fed through to the platen.
Page 35
Loading Roll Media Gently pull on the center of the leading edge of the roll media as far as the ejection guide (f) and align the right edge of the media with the right edge of the paper alignment line (g), then lower the release lever. [88] Attention: Do not pull strongly on the roll media when you align it with the paper alignment line.
Page 36
Loading Roll Media Océ Media name Name Printer Operating Panel IJM005 Océ Draft Paper Draft Paper IJM020 Océ Standard Paper Standard Paper IJM113 Océ Premium Paper 90g/m2 Premium Paper IJM150 Océ SmartMatt Paper SmartMatt Paper IJM215 Océ SmartFitPlus PhotoGloss SmartFit Photo IJM250 Océ...
Page 37
Loading Roll Media Attention: Always set the Media Type setting to the type of roll media loaded in the printer.If the media type setting does not match the loaded roll media, printing quality may be reduced. Press the [ ] or [ ] button to select the setting for the roll media length, and then press the OK button.
Adjusting the Print Status Adjusting the Print Status Adjusting the Printhead Position Note: It is recommended that you run the printhead adjustment using the type of media that you use most frequently. Note: If you are using cut sheets, load at least one sheet of unused A3 or larger paper (not the blank side of used paper) in landscape orientation.
Page 39
Adjusting the Print Status Select Advanced Adj. then press the [ ] button. [101] [102] Printhead Adj Advanced Adj. Press the [ ] or [ ] button to select Yes, then press the OK button. [103] [104] Advanced Adj. The printhead adjustment pattern is printed. [105] The printer scans the resulting printout as it is printed, and automatically calibrates the printhead adjustment values.
Page 40
Adjusting the Print Status Media Feed Adjustment Attention: Before you adjust the amount of media feed, you need to configure the media type setting using the operation panel to match the media loaded in the printer. If the media type selection does not match the media loaded in the printer, you will not achieve the correct print results and the printing quality will be reduced.
Page 41
Adjusting the Print Status Select Standard Adj. then press the [ ] button. [112] [113] Adjust Band Standard Adj. Press the [ ] or [ ] button to select Yes, then press the OK button. [114] [115] Standard Adj. The media feed adjustment pattern is printed. [116] The printer scans the printout as it is printing and automatically calibrates the media feed settings for the currently selected media type.
Attention: Be sure to use a USB 2.0 standard connection cable. Mount the provided User Software CD-ROM in the computer CD-ROM drive. [117] Start the wizard. Double-click setup.exe which you can find on the Océ CS2044 CD-rom. [118] Chapter 1 Read this first...
Page 43
Installing for Windows Follow the procedure to complete the installation. When the port connection screen appears, connect the USB cable to the printer and the computer. [119] USB Connection Printer back Computer Connecting the LAN Cable Note: The following operating systems support a TCP/IP network connection: Windows Server 2003, Windows XP, Windows 2000, Windows Me, Windows 98, or Windows NT 4.0 (Service Pack 6 or later).
Page 44
Connecting the Printer to a Network for the First Time Mount the provided User Software CD-ROM in the computer CD-ROM drive. [121] Start the wizard. Double-click setup.exe which you can find on the Océ CS2044 CD-rom. [122] Follow the procedure to complete the installation.
Stowing the Output Stacker Stowing the Output Stacker Grasp the centre of the front output stacker rod (a) and pull it up slightly. [123] Then simply pull the output stacker rod (a) out towards you. [124]...
Page 46
Stowing the Output Stacker Lower the output stacker rod (a). [125] Note: To reattach the output stacker, perform the steps above in reverse. Chapter 1 Read this first...
If the output stacker arm disengages If the output stacker arm disengages Illustration [126] [127] Turn the output stacker arm (a) in the direction indicated by the arrow. [128]...
Page 48
If the output stacker arm disengages Slide the rotated output stacker arm (b) in until it clicks into the 2 holes (c). If the rear output stacker rod (d) has dropped down, fit the output stacker arm (b) in place before re-attaching the output stacker rod.
