Page 1: User Manual
K R A ME R E LE CT R O N IC S L T D . USER MANUAL MODEL: VP-480 CV to 3G HD-SDI Scaler P/N: 2900-000762 Rev 3... -
Page 3: Table Of Contents
Introduction Getting Started Achieving the Best Performance Recycling Kramer Products Overview Defining the VP-480 CV to 3G HD-SDI Scaler Connecting the VP-480 Operating the VP-480 CV to 3G HD-SDI Scaler Using the Front Panel Buttons Using the OSD Technical Specifications... -
Page 4: Introduction
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Congratulations on purchasing your Kramer VP-480 CV to 3G HD-SDI Scaler, which is ideal for the following typical applications: •... -
Page 5: Getting Started
Avoid interference from neighboring electrical appliances that may adversely influence signal quality • Position your Kramer VP-480 away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 6: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Overview
Overview The Kramer VP-480 CV to 3G HD-SDI Scaler is a high-performance digital scaler for composite video signals. It up-scales to SDI, HD-SDI and 3G HD-SDI signals. The following output resolutions are supported: • SDTV: 480i and 576i • HDTV: 720p @60, 1080p SF30/29/25, 1080p 30/29/25/24/23, 1080p @59,... -
Page 8: Defining The Vp-480 Cv To 3G Hd-Sdi Scaler
Connector equalized SDI OUT 2 BNC Connect to SDI acceptor 2. The signal is re-clocked and Connector equalized 5V DC Connect to the +5V DC power adapter, center pin positive VP-480 - Defining the VP-480 CV to 3G HD-SDI Scaler... -
Page 9: Connecting The Vp-480
Connecting the VP-480 Always switch off the power to each device before connecting it to your VP-480. After connecting your VP-480, connect its power and then switch on the power to each device. Figure 2: Connecting the VP-480 CV to 3G HD-SDI Scaler... - Page 10 4. Connect the SDI OUT 2 BNC connector to an SDI acceptor (for example, an SDI display with speakers). 5. Connect the 5V DC power adapter to the 5V DC power socket and to the mains electricity (not shown in the illustration). VP-480 - Connecting the VP-480...
-
Page 11: Operating The Vp-480 Cv To 3G Hd-Sdi Scaler
Operating the VP-480 CV to 3G HD-SDI Scaler The VP-480 is operated directly via the front panel buttons and via the OSD menu. Using the Front Panel Buttons During normal operation (without the OSD), the front panel buttons operate in the following manner: •... - Page 12 10. To return to normal operation, select EXIT from the main menu and press ENTER. To exit from the OSD at any point, press the MENU button. Unsaved values return to their previous value. VP-480 - Operating the VP-480 CV to 3G HD-SDI Scaler...
- Page 13 Finetune Sub-menu Options Function Value Range Factory Default Sets the output hue 0-100 SATURATION Sets the output saturation 0-100 SHARPNESS Sets the output sharpness 0-100 EXIT Returns to the main menu VP-480 - Operating the VP-480 CV to 3G HD-SDI Scaler...
- Page 14 Sets the darkness of the OSD background 0-100 DISPLAY Displays the input signal state and current INFO, ON, INFO output resolution on the output EXIT Returns to the main menu VP-480 - Operating the VP-480 CV to 3G HD-SDI Scaler...
-
Page 15: Technical Specifications
1 composite video on a BNC connector 1 unbalanced stereo audio on 2 RCA connectors OUTPUTS: 2 3G HD-SDI on BNC connectors INPUT See the document “Kramer Scalers Input Output Resolutions” RESOLUTIONS: available for download from http://www.kramerelectronics.com OUTPUT 720p @60, 1080p SF30/29/25, 1080p @30/29/25/24/23, 1080p... - Page 17 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
