Page 1: User Manual
K R A ME R E LE CT R O N IC S L T D . USER MANUAL MODEL: VP-482 HDMI to 3G HD-SDI Scaler P/N: 2900-000763 Rev 1... -
Page 3: Table Of Contents
Operating the VP-482 HDMI to 3G HD-SDI Scaler Using the Front Panel Buttons Using the OSD Technical Specifications Figures F igure 1: VP-482 HDMI to 3G HD-SDI Scaler F igure 2: Connecting the VP-482 HDMI to 3G HD-SDI Scaler VP-482 – Contents... -
Page 4: Introduction
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products Congratulations on purchasing your Kramer VP-482 HDMI to 3G HD-SDI Scaler, which is ideal for the following typical applications: •... -
Page 5: Getting Started
• Avoid interference from neighboring electrical appliances that may adversely influence signal quality • Position your Kramer VP-482 away from moisture, excessive sunlight and dust Caution: No operator serviceable parts inside the unit Use only the Kramer Electronics input power wall... -
Page 6: Overview
Overview The Kramer VP-482 HDMI to 3G HD-SDI Scaler is a high-performance digital scaler for signals up to 3G HD-SDI. It up-scales and down-scales 3G HD-SDI signals to resolutions up to WUXGA and 1080p. The following output resolutions are supported: •... -
Page 7: Defining The Vp-482 Hdmi To 3G Hd-Sdi Scaler
SDI OUT 2 BNC Connect to the SDI acceptor 2. The signal is reclocked and Connector equalized 5V DC Connect to the +5V DC power adapter, center pin positive VP-482 - Defining the VP-482 HDMI to 3G HD-SDI Scaler... -
Page 8: Connecting The Vp-482
1. Connect an HDMI source (for example, an HD video camera) to the HDMI connector. Note: If the HDMI signal is HDCP protected, it cannot be displayed on a non-HDCP compliant display and therefore the VP-482 will not output the picture. VP-482 - Connecting the VP-482... - Page 9 3. Connect the SDI OUT 2 BNC connector to an SDI acceptor (for example, a display with speakers). 4. Connect the 5V DC power adapter to the 5V DC power socket and to the mains electricity (not shown in the illustration). VP-482 - Connecting the VP-482...
-
Page 10: Operating The Vp-482 Hdmi To 3G Hd-Sdi Scaler
Operating the VP-482 HDMI to 3G HD-SDI Scaler The VP-482 is operated directly via the front panel buttons and via the OSD menu. Using the Front Panel Buttons During normal operation (without the OSD), the front panel buttons operate in the following manner: •... - Page 11 10. To return to normal operation, select EXIT from the main menu and press ENTER. To exit from the OSD at any point, press the MENU button. Any unsaved parameters return to their previous values. VP-482 - Operating the VP-482 HDMI to 3G HD-SDI Scaler...
- Page 12 Returns to the main menu 6.2.1 Finetune Sub-menu Main Menu Submenu Function Value Factory Range Default COLOR FILTER Sets the color filter on or off ON/OFF FINETUNE EXIT Returns to the main menu VP-482 - Operating the VP-482 HDMI to 3G HD-SDI Scaler...
- Page 13 Sets the length of time (in 0-100 seconds) that the OSD remains visible on the screen BACKGROUND Sets the darkness of the 0-100 OSD background EXIT Returns to the main menu VP-482 - Operating the VP-482 HDMI to 3G HD-SDI Scaler...
-
Page 14: Technical Specifications
Technical Specifications INPUT: 1 HDMI on an HDMI connector (non-HDCP) OUTPUTS: 2 3G HD-SDI on BNC connectors INPUT See the document “Kramer Scalers Input Output Resolutions” RESOLUTIONS: available for download from http://www.kramerelectronics.com AUDIO INPUT 48kHz SAMPLE RATE: OUTPUT 720p, 1080p SF30/29/25, 1080p @30/29/25/24/23/59, 1080i... - Page 15 1. Any product which is not distributed by us or which is not purchased from an authorized Kramer dealer. If you are uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site www.kramerelectronics.com.
- Page 16 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
