Summary of Contents for Kramer VP-481
- Page 1 K R A ME R E LE CT R O N IC S L T D . USER MANUAL MODEL: VP-481 DVI to 3G HD-SDI Scaler P/N: 2900-300008 Rev 4...
-
Page 3: Table Of Contents
Using the OSD Technical Specifications Figures F igure 1: VP-481 DVI to 3G HD-SDI Scaler Front Panel F igure 2: VP-481 DVI to 3G HD-SDI Scaler Rear Panel F igure 3: Connecting the VP-481 DVI to 3G HD-SDI Scaler VP-481 – Contents... -
Page 4: Introduction
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Congratulations on purchasing your Kramer VP-481 DVI to 3G HD-SDI Scaler which is ideal for the following typical applications: •... -
Page 5: Getting Started
• Avoid interference from neighboring electrical appliances that may adversely influence signal quality • Position your Kramer VP-481 away from moisture, excessive sunlight and dust Caution: No operator serviceable parts inside the unit Use only the Kramer Electronics input power wall... -
Page 6: Overview
Overview The Kramer VP-481 DVI to 3G HD-SDI Scaler is a high-performance digital scaler for signals up to 3G HD-SDI. It up-scales and down-scales DVI/HDMI signals up to WUXGA and 1080p resolutions to SDI, HD-SDI and 3G HD-SDI. The following input resolutions are supported: •... -
Page 7: Defining The Vp-481 Dvi To 3G Hd-Sdi Scaler
Defining the VP-481 DVI to 3G HD-SDI Scaler Figure 1 defines the front panel of the VP-481. Figure 1: VP-481 DVI to 3G HD-SDI Scaler Front Panel VP-481 Front Panel Features Feature Function ON LED Lights green when the unit is powered on... -
Page 8: F Igure 2: Vp-481 Dvi To 3G Hd-Sdi Scaler Rear Panel
Figure 2 defines the rear panel of the VP-481. Figure 2: VP-481 DVI to 3G HD-SDI Scaler Rear Panel VP-481 Rear Panel Features Feature Function DVI/HDMI Connector Connect to the DVI/HDMI source The HDMI source must not have HDCP encryption. When... -
Page 9: Connecting The Vp-481 Dvi To 3G Hd-Sdi Scaler
Scaler Always switch off the power to each device before connecting it to your VP-481. After connecting your VP-481, connect its power and then switch on the power to each device. Figure 3: Connecting the VP-481 DVI to 3G HD-SDI Scaler... -
Page 10: Operating The Vp-481 Dvi To 3G Hd-Sdi Scaler
Operating the VP-481 DVI to 3G HD-SDI Scaler The VP-481 is operated directly via the front panel buttons and via the OSD menu. Using the Front Panel Buttons During normal operation (without the OSD), the front panel buttons perform in the following manner: •... - Page 11 ON, OFF FILTER or off for best results in applications where there is colored tinting within detailed picture areas (for example, text) COLOR Sets the output color parameters (see Section 6.2.2) VP-481 - Operating the VP-481 DVI to 3G HD-SDI Scaler...
- Page 12 Function Value Range Factory Default Sets the output red value 0-100 GREEN Sets the output green value 0-100 BLUE Sets the output blue value 0-100 EXIT Exits the Color submenu VP-481 - Operating the VP-481 DVI to 3G HD-SDI Scaler...
- Page 13 Sets the transparency of the OSD 0, 13, 25, 38, 50, background 63, 75, 88, 100 DISPLAY Sets the input resolution notification INFO, OFF, ON INFO pop-up EXIT Exits the Display menu VP-481 - Operating the VP-481 DVI to 3G HD-SDI Scaler...
-
Page 14: Technical Specifications
1 S/PDIF digital audio on an RCA connector 1 Unbalanced stereo audio on 2 RCA connectors OUTPUTS: VIDEO: 2 SDI/HD-SDI/3G HD-SDI on BNC connectors INPUT RESOLUTIONS: See the document “Kramer Scalers Input Output Resolutions” available for download from http://www.kramerelectronics.com AUDIO INPUT SAMPLE 48kHz RATE:... - Page 16 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
