Table 1: Front Panel VS-3232A 32x32 Audio Matrix Switcher Features

# Feature
1 IR Receiver
2 POWER Switch
3 Keypad
4 FOLLOW Button
5 BREAKAWAY Button
6 DEFAULT SETUP Button
7 INPUTS/OUTPUTS LCD
Display
8 LOCK Button
9 MENU Button
10 TAKE Button
1 Press and hold the LOCK button for about two seconds to toggle
Your Balanced Stereo Audio Matrix Switcher
The red LED is illuminated when receiving signals from the Kramer infrared
remote control transmitter
Illuminated switch for turning the unit ON or OFF
See Figure 2 and Table 2
Press to enter the Follow mode in the multi-switcher configuration
Press to enter the Standalone mode in the multi-switcher configuration
Press to recall the default setup (UNITY setting), see section 9.6
Displays the outputs (in the upper row) switched to the selected inputs (in the
lower row).
Displays user interface messages and configuration menu items
1
Toggle to lock/unlock the front panel buttons
Press once to enable the ALL, OFF STO and RCL buttons
Press twice to enter the audio input/output volume control menu
Press three times to enter the configuration menu
When in the configuration menu, press to browse through the menu items
Used to confirm and complete setup and switching
Function
5
