- Page 1 AD-76 Aquatex Parts Manual 1995 thru 1999 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 e-mail: techsupport@amdry.com ADC Part No. 450197 060899/DX/cms...
- Page 2 Retain This Manual In A Safe Place For Future Reference American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble-free operation. ONLY properly licensed technicians should service this equipment. OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation/operator's manual included with the dryer.
-
Page 3: Table Of Contents
Table of Contents SSEMBLY ECURITY ONTROL ICROPROCESSOR ONTROL ... 5 RONT ANEL SSEMBLY WITCH OUSING ... 7 SSEMBLY ... 8 SSEMBLY ASKET UMBLER UPPORT UMBLER EARING SSEMBLY ... 11 DLER EARING SSEMBLY OTALLY NCLOSED UMBLER IMIT ENSOR UMIDITY RANSMITTER SSEMBLY LECTRIC SSEMBLY WITCH... -
Page 4: Drop Lint Door Assembly
Illus. No. Part No. Qty. Description 800150 160200 160003 160008 160009 150425 157000 881318 881317 150201 117604 117603 102307 180212 150419 108120 — 150418 * Specify color when ordering. American Dryer Corporation Knob Latch Kit Assembly (includes illus. nos.1 and 2) Knob Latch ONLY with 2 Screws (without cam) Dummy Lock ONLY Lock Cam for AD-100 and Dummy Lock... -
Page 5: Ssembly
High Security Control Door Assembly Illus. No. Part No. Qty. Description 160017 Special Dummy Lock Only 160104 Lock Cam ONLY 160016 Lock Cam ONLY 881053 ADC Logo with Tape 881315* AD-76AQ Control Door Assembly (includes illus. nos. 4 through 7) 881316* AD-76AQ Stainless Steel Control Door Assembly (includes illus. -
Page 6: Microprocessor Control Panel
Illus. No. Part No. Qty. Description 112535 801255 881319 137108 153010 150005 150415 American Dryer Corporation OPL English Keyboard Label Assembly Phase 5 Microprocessor Control Panel Only Aquatex Microprocessor Control Panel Assembly Complete (includes illus. nos. 1 through 6) Aquatex Microprocessor Board # 6 Star Washer # 6-32 x 1/4"... -
Page 7: Front Panel Assembly
Front Panel Assembly Illus. No. Part No. Qty. Description 881326* Left Hand Front Panel (includes illus. nos. 1 through 3, 5) 881327* Stainless Steel Left Hand Front Panel (includes illus. nos. 1, 2, 3, 5) 154215 5/32" Pop Rivet 170330 Friction Door Latch 150415 #10-16 x 1/2"... -
Page 8: Main Door Switch Housing
Illus. No. Part No. Qty. Description 152013 153008 137005 121028 154281 800448 153565 313218 150201 121405 American Dryer Corporation # 6-32 Hex Nut # 6 Lock Washer Single Pole Door Switch Insulated Female Terminal 3/8" Standard Nylon Spacers 12 1/2" Stainless Steel Main Door Hinge Assembly (includes illus. -
Page 9: Main Door Assembly
Main Door Assembly Illus. No. Part No. Qty. Description 800285 Gray Main Door Assembly Complete (includes illus. nos. 1,5,6 and 7) 800448 12 1/2" Stainless Steel Main Door Hinge Assembly 150410 # 10-24 X 3/8" Phillips Pan Head Taptite Screw 152014 1/4-20 Free Spin Wash Nut 102353... -
Page 10: Lint Trap Assembly
Illus. No. Part No. Qty. Description 800420 800421 154200 304101 150300 800506 150419 108120 — 150418 American Dryer Corporation AD-76AQ Lint Trap Assembly Complete (includes illus. nos. 1,3,4 and 5) AD-76AQ Lint Trap Only 5/32" Pop Rivet Lint Screen Holder # 10 x 1/2"... -
Page 11: Ssembly
Basket (Tumbler) / Support Assembly Illus. No. Part No. Qty. Description 800708 AD-76AQ Basket (Tumbler) ONLY without Felt Collar 800857 AD-76AQ Stainless Steel Basket (Tumbler) ONLY without Felt Collar 800816* AD-76AQ (1-3/4") Basket (Tumbler) and Support Assembly Complete (includes illus. nos. 1 through 10) 800873* AD-76AQ Stainless Steel (1-3/4") Basket (Tumbler) and Support Assembly Complete... -
Page 12: Tumbler Bearing Assembly
Illus. No. Part No. Qty. Description 880220 153025 152050 150508 153005 152005 150600 153004 153005 152005 150501 153002 153001 150621 152004 801101 801103 801105 801104 880202 152004 150610 101100 154301 100713 100106 American Dryer Corporation 1-3/4" Flange Bearing 9/16" Lock Washer #9/16-12 Hex Nut #3/8-16 x 3/4"... -
Page 13: Idler Bearing Assembly
Idler Bearing Assembly Illus. No. Part No. Qty. Description 100106 5L 690 "V" Belt (idler to basket [tumbler]) 101140 14" x 3" Compound Pulley 100117 4L 620 "V" Belt (idler to motor) 154301 #5/16-18 x 5/16" Allen Set Screw 100705 3/16'"... -
Page 14: Motor Mount Asembly
Totally Enclosed, Fan-Cooled Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... - Page 15 Totally Enclosed, Fan-Cooled Motor Mount Assembly Illus. No. Part No. Qty. Description 100117 4L 620 "V" Belt (to idler assembly) 100701 3/16" x 3/16" x 1" Key 101133 5/8" x 2-1/4" Motor Pulley (60 Hz ONLY) 101130 5/8" x 2-1/2" Motor Pulley (50 Hz ONLY) 150501 5/16-18 x 3/4"...
-
Page 16: Tumbler Hi-Limit Sensor Bracket
Illus. No. Part No. Qty. Description 305007 130301 153010 152000 881354 150005 American Dryer Corporation Universal Sensor Bracket L225 Hi-Limit Thermostat Manual Reset #6 Star Washer #6-32 Hex Nut Aquatex Microprocessor Sensor Bracket Harness #6-32 X 1/4" Phillips Round Head Machine Screw 88 Currant Road / Fall River, MA 02720-4781 Tumbler Hi-Limit Sensor Bracket... -
Page 17: Humidity Transmitter Assembly
Humidity Transmitter Assembly Illus. No. Part No. Qty. Description 851155 Humidity Controller Mounting Bracket 319741 Humidity Bracket Cover 151001 #8-32 Pal Nut 136989 Humidity Sensor Board with Filter 150020 #4-40 Screw 153032 #4 Nylon Washer 121401 Rubber Grommet 117602 A/R 1/4T Neoprene Sponge Tape 117603 A/R 1/8T Noise Supressor Tape Telephone: (508) 678-9000... -
Page 18: Electric Oven Assembly
Electric Oven Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 19: A Ssembly 16
Electric Oven Assembly Illus. No. Part No. Qty. Description 851151 Aquatex Oven Box ONLY 830210 Electric Oven Assembly Complete (416V) 120013 – Heating Element 150300 #10 x 1/2" Hex Washer TEK Screw 802800 Sail Switch Box with Bracket and Cover ONLY 802801 Sail Switch Assembly Complete (includes illus. -
Page 20: Sail Switch /High Limit Assemblies
Illus. No. Part No. Qty. Description 154004 150415 802799 150303 122200 105500 319202 154002 802800 802801 824534 143000 142809 318700 150415 150415 824533 319704 150001 130401 151000 American Dryer Corporation Twin Speed Nut #10-16 x 1/2" Phillips Round Head Crimptite Screw Sail Switch Box Cover and Bracket ONLY #4 x 3/4"... -
Page 21: Burner Box /Gas
Burner Box Assembly / Gas & L.P. Illus. No. Part No. Qty. Description 150415 #10-16 x 1/2" Phillips Round Head Crimptite Screw 150300 #10 x 1/2" Hex Washer TEK Screw 141105 Large Burner Tube 128915 DSI Ignitor/Flame Probe Assembly 150103 #8-32 x 3/4"... -
Page 22: 115V Gas
Illus. No. Part No. Qty. Description 132451 137060 137013 120765 120766 150301 136019 136017 136103 120758 120995 120994 829037 319757 American Dryer Corporation Double Pole Contactor Arc Suppressor Board PC Board Mounting Standoff Standard End Stop Small End Section #8-18 x 7/16" Phillips Pan Head TEK Screw 5 x 20mm 1.0 Amp Fuse 5 x 20mm 3.15 Amp Fuse 5 x 20mm Fuse Holder... -
Page 23: 208-240V Gas
Rear Electrical Panel Assembly 208-240V Gas Illus. No. Part No. Qty. Description 132451 Double Pole Contactor 137060 Arc Suppressor Board 137013 PC Board Mounting Standoff 120765 Standard End Stop 120766 Small End Section 150301 #8-18 x 7/16" Phillips Pan Head TEK Screw 136019 5 x 20mm 1.0 Amp Fuse 136017... -
Page 24: 208-240V Electric
Illus. No. Part No. Qty. Description 851157 132486 131369 132451 120994 137060 829042 120995 136103 120765 137013 153012 152001 120766 136019 136017 150009 120701 319724 151000 American Dryer Corporation Rear Electrical Panel Assembly 208-240V Electric CE Electrical Panel Power Disconnect Oven Contactor (for 208-240V) Blower Motor Contactor Bus Bar... -
Page 25: 416V Electric
Rear Electrical Panel Assembly 416V Electric Illus. No. Part No. Qty. Description 851157 CE Electrical Panel 132486 Power Disconnect 131357 Oven Contactor (for 416V) 132451 Blower Motor Contactor 120994 Bus Bar 137060 Arc Suppressor Board 829041 Transformer with Terminals (for 416V) 120995 Bus Bar Screws 136103... -
Page 26: 115V Gas
Illus. No. Part No. Qty. Description 319756 120716 137489 136019 136103 150009 151000 120766 120765 120758 American Dryer Corporation CE Disconnect Panel Power Distribution Block Power Disconnect 5 x 20mm 1.0 Amp Fuse 5 x 20mm Fuse Holder 6-32 x 1-1/2" Phillips Round Head Machine Screw #6-32 Pal Nut End Section End Stop... -
Page 27: 208-240V Gas
Disconnect Panel Assembly 208-240V Gas Illus. No. Part No. Qty. Description 319756 CE Disconnect Panel 120716 Power Distribution Block 137489 Power Disconnect 136019 5 x 20mm 1.0 Amp Fuse 136103 5 x 20mm Fuse Holder 150009 6-32 x 1-1/2" Phillips Round Head Machine Screw 151000 #6-32 Pal Nut 120766... -
Page 28: Disconnect Panel Cover Gas
Illus. No. Part No. Qty. Description 143153 141007 143240 141008 182522 143238 100520 829020 143268 319750 121400 ——— 150512 153007 153018 150300 319769 American Dryer Corporation 1/4" Poly x 1/4" MPT Elbow Air Jet Pre Filter 1/4' Close Nipple Air Jet Pre Filter 1/4"... -
Page 29: Ssembly E Lectric
Main Electrical Disconnect / Air Filter Assembly Electric Illus. No. Part No. Qty. Description 143153 1/4" Poly x 1/4" MPT Elbow 141007 Air Jet Pre Filter 143240 1/4' Close Nipple 141008 Air Jet Pre Filter 182522 1/4" x 1/8" Reducing Bushing 143238 1/8"... -
Page 30: Rear View Electric
Illus. No. Part No. Qty. Description 103500 152001 153018 121488 150300 851182 143110 66" 1/4" Poly Flo Tubing 100472 143259 319753 * Not Sold Separately Specific Resistive Calibration American Dryer Corporation Electric Oven Assembly. See Page 16, 17 Humidity Transmitter Assembly. See Page 15 Disconnect Panel Cover. -
Page 31: Rear Veiw Gas
Rear View Gas Illus. No. Part No. Qty. Description Gas Burner Assembly. See Page 19 Disconnect Panel Cover. See Page 26 Humidity Transmitter Assembly. See Page 15 Tumbler Bearing Assembly. See Page 10 Idler Bearing Assembly. See Page 11 Motor Mount Assembly. See Page 12,13 103500 Leveling Leg 152001... - Page 32 Illus. No. Part No. Qty. Description 319788 150301 319769 150301 319787 150301 312527 150301 851183 121488 136989 153012 152001 150309 American Dryer Corporation Lower Backguard #8-18 x 7/16" Phillips Pan Head TEK Screw Disconnect Cover ONLY #8-18 x 7/16" Phillips Pan Head TEK Screw Top Backguard #8-18 x 7/16"...
-
Page 33: Lectric
Rear & Top Panel Assembly Electric Illus. No. Part No. Qty. Description 314514 Plain Backguard 150301 #8-18 x 7/16" Phillips Pan Head TEK Screw 319781 Disconnect Panel ONLY 150301 #8-18 x 7/16" Phillips Pan Head TEK Screw 319776 Upper Backguard 150301 #8-18 x 7/16"... -
Page 34: Pplication Chart
Ø Ø Ø Ø... -
Page 35: Available
Additional Parts Available Part No. Description 114094 Mop Head Warning Label 114006 "Warning Fire Hazard" Label 112280 "Clean Lint Screen" Label 114001 "Caution Exhaust/Lint Screen" Label 112534 "Phase 5 OPL Program Location Summary" Label 120100 3/8" Straight (BX) Connector 120300 3/8"... - Page 36 ADC 450197 1* 08/03/99-25...
