- Page 1 AD-75THS Parts Manual American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com 031099MFM/cj ADC Part No. 450416...
- Page 2 These instructions must be posted in a prominent location near the dryer. POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de yout autre appareil. Important MODEL NO. __________________________________________ AD-75THS...
-
Page 3: Table Of Contents
Control Door Assembly Without Trim ... 2 Control Door Assembly With Trim ... 3 Phase 5 OPL Microprocessor Control Panel Assembly ... 4 Phase 5 Coin Microprocessor Control Panel Assembly ... 5 Phase 5 Coin and OPL Microprocessor Control Box Assembly ... 6 Coin Vault Assembly ... -
Page 4: Control Door Assembly Without Trim
Illus. No. Part No. Qty. Description 882052 ADC Logo ONLY 870011 Logo Double Adhesive Tape Kit ONLY 881045* Control Door (includes illus. nos. 2 and 3) 881046 Stainless Steel Control Door (includes illus. nos. 2 and 3) 117604 Neoprene Sponge Tape (sold by the foot) 150300 #10 x 1/2”... -
Page 5: Control Door Assembly With Trim
Control Door Assembly With Trim Illus. No. Part No. Qty. Description 160015 High Security MK-100 Lock Assembly with Key (for Coin Models Only) 160017 Special Dummy Lock ONLY (for non-Coin Models Only) 160104 MK-100 Key ONLY 160016 Lock Cam ONLY 882052 ADC Logo ONLY 870011... -
Page 6: Phase 5 Opl Microprocessor Control Panel Assembly
Phase 5 OPL Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112535 OPL English Keyboard Label Assembly 112276 OPL Stick-on Labels (English ONLY) ... Not Illustrated 112275 OPL Stick-on Labels ... Not Illustrated (Spanish, Italian, and Hebrew) 112277 3-Language OPL Stick-on Labels ... -
Page 7: Phase 5 Coin Microprocessor Control Panel Assembly
Phase 5 Coin Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112526 Coin Keyboard Label Assembly 801213 Phase 5 Coin Control Panel Assembly (includes illus. nos. 1, 2, 4, 5, and 6) 801229 Phase 5 Coin Control Panel Assembly with Battery Option (includes illus. -
Page 8: Phase 5 Coin And Opl Microprocessor Control Box Assembly
Phase 5 Coin and OPL Microprocessor Control Box Assembly Illus. No. Part No. Qty. Description 141403 Transformer - 24 VAC (for ALL 380/416/480 volt Gas and Steam Models) -------- Transformer - 24 VAC (for Electric Models Only) (Refer to Transformer Usage Listing on page 44) 150300 #10 x 1/2”... -
Page 9: Coin Vault Assembly
Coin Vault Assembly Illus. No. Part No. Qty. Description 802112 Microprocessor Coin Vault Assembly Complete (includes illus. nos. 1 through 6) 802117 Microprocessor Coin Vault ONLY 160028 Cam for 1/4 Turn Lock ONLY 875061 1/4 Turn Lock with Key and Cam 160105* 1/4 Turn Mer-Pel Key ONLY 802020... - Page 10 Dual Timer Control Panel Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
-
Page 11: Dual Timer Control Panel Assembly
Dual Timer Control Panel Assembly Illus. No. Part No. Qty. Description 123005 Red Indicator Light - 24 VAC 122400 Rocker Heat Selector Switch 824015 Dual Timer Control Panel Assembly Complete - 24 VAC (includes illus. nos. 1 through 21) 800051 Dual Timer Control Panel ONLY 131917 Push-to-Start Relay - 24 VAC... -
Page 12: Dual Timer Control Box Assembly
Illus. No. Part No. Qty. Description 122603 9-Pin Socket Connector 122701 Socket Terminal ONLY 122801 Pin/Socket Extraction Tool 315010 9-Pin Connector Bracket 150300 #10 x 1/2” Hex Washer TEK Screw 150300 #10 x 1/2” Hex Washer TEK Screw 141403 Transformer - 24 VAC (for ALL 380/416/480 volt Gas and Steam Models) -------- Transformer - 24 VAC... -
Page 13: Front Panel Assembly
Front Panel Assembly Illus. No. Part No. Qty. Description 875302* Right Hand Insulated Front Panel Assembly Complete (includes illus. nos. 1, 2, 3, and 6) 875313 Stainless Steel Right Hand Insulated Front Panel Assembly Complete (includes illus. nos. 1, 2, 3, and 6) 154215 5/32”... -
Page 14: Main Door Assembly
Illus. No. Part No. Qty. Description 881421 Gray Plastic Main Door Assembly Complete with Mechanical Fasteners (includes illus. nos. 1 and 5 through 9) 800448 12-1/2” Stainless Steel Main Door Hinge Assembly 150410 #10-24 x 3/8” Phillips Pan Head Taptite Screw 152014 1/4-20 Free Spin Wash Nut 102349... -
Page 15: Main Door Switch Housing
Main Door Switch Housing Illus. No. Part No. Qty. Description 152013 #6-32 Hex Nut 153008 #6 Lock Washer 137005 Single-Pole Door Switch 121028 Insulated Female Terminal 154281 3/8” Standard Nylon Spacer 800448 12-1/2” Stainless Steel Main Door Hinge Assembly (includes illus. nos. 6 and 7) 153565 #6-32 x 1”... - Page 16 Basket (Tumbler)/Support Assemblies American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
-
Page 17: Basket (Tumbler)/Support Assemblies
Basket (Tumbler)/Support Assemblies Illus. No. Part No. Qty. Description 800708 Basket (Tumbler) ONLY without Felt Collar 800857 Stainless Steel Basket (Tumbler) ONLY without Felt Collar 800816 Non-Reversing Basket (Tumbler) and Support Assembly Complete (includes illus. nos. 1 through 10) 800873 Stainless Steel Non-Reversing Basket (Tumbler) and Support Assembly Complete (includes illus. -
Page 18: Drop Lint Door Assembly Without Trim
Illus. No. Part No. Qty. Description 160001 AD-100 Lock Assembly with Key (for Coin Models Only) 160103 AD-100 Key ONLY 800150 Knob Latch Kit Assembly (includes illus. nos. 1 and 2) 160200 Knob Latch ONLY with 2 Screws (without cam) 160003 Dummy Lock ONLY (for Non-Coin Models) 160104... -
Page 19: Drop Lint Door Assembly With Trim
Drop Lint Door Assembly With Trim Illus. No. Part No. Qty. Description 160001 AD-100 Lock Assembly with Key (for Coin Models Only) 160103 AD-100 Key ONLY 800150 Knob Latch Kit Assembly (includes illus. nos. 1 and 2) 160200 Knob Latch ONLY with 2 Screws (without cam) 160003 Dummy Lock ONLY (for Non-Coin Models) 160104... -
Page 20: Lint Trap Assembly
Illus. No. Part No. Qty. Description 800420 Non-Reversing and Reversing Lint Trap Assembly Complete (includes illus. nos. 1, 3, 4, and 5) 850181 Non-Reversing and Reversing Lint Trap ONLY 154200 5/32” Pop Rivet 304101 Lint Screen Holder ONLY 150300 #10 x 1/2” Hex Washer TEK Screw 800506 Lint Screen ONLY 150419... -
Page 21: Idler Bearing Assembly
Idler Bearing Assembly Illus. No. Part No. Qty. Description 100108 5L-680 V-Belt (idler to basket [tumbler]) 101140 14” x 3” Compound Pulley 100117 4L-620 V-Belt (idler to motor) For Non-Reversing Models ONLY 100114 4L-630 V-Belt (idler to motor) For Reversing Models ONLY 154301 5/16-18 x 1”... - Page 22 Tumbler Bearing Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
-
Page 23: Tumbler Bearing Assembly
Tumbler Bearing Assembly Illus. No. Part No. Qty. Description 880220 1-3/4” Flange Bearing 153025 9/16” Lock Washer 152050 9/16-12 Hex Nut 150508 3/8-16 x 3/4” Hex Head Machine Bolt 153005 3/8” Lock Washer 152005 3/8-16 Hex Nut 150600 3/8-16 x 1-1/2” Hex Head Machine Bolt 153004 3/8”... -
Page 24: Non-Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly
Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 25: Non-Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly
Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly Illus. No. Part No. Qty. Description 100117 4L-620 V-Belt (motor to idler) 100701 3/16” x 3/16” x 1” Key 101133 5/8” x 2-1/4” Motor Pulley (60 Hz Only) 101130 5/8” x 2-1/2” Motor Pulley (50 Hz Only) 150501 5/16-18 x 3/4”... -
Page 26: Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly
Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly for ALL Gas and Electric Models ONLY American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 27: Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly For All Gas And Electric Models Only
Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly for ALL Gas and Electric Models ONLY Illus. No. Part No. Qty. Description 100114 4L-630 V-Belt (to idler assembly) 100701 3/16” x 3/16” x 1” Key 101130 5/8” x 2-1/2” Motor Pulley (60 Hz Only) 101139 5/8”... -
Page 28: For Steam Models Only
Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly for Steam Models ONLY American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... - Page 29 Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly for Steam Models ONLY Illus. No. Part No. Qty. Description 100114 4L-630 V-Belt (motor to idler) 100701 3/16” x 3/16” x 1” Key 101130 5/8” x 2-1/2” Motor Pulley (60 Hz Only) 101139 5/8”...
-
Page 30: Sensor Bracket Assemblies
Sensor Bracket Assemblies Microprocessor Sensor Bracket Assembly MAN0238 Non-Computer Sensor Bracket Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 31: Sensor Bracket Assemblies
Sensor Bracket Assemblies Illus. No. Part No. Qty. Description 880251 1/4” Temperature Sensor Probe Assembly (includes illus. nos. 1 and 5 through 8) 130103 225° Large Automatic Reset Thermostat 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Terminal ONLY 122701 Socket Terminal ONLY 112801... -
Page 32: Hot Surface Ignition (Hsi) Burner Assembly
Hot Surface Ignition (HSI) Burner Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 33: Hot Surface Ignition (Hsi) Burner Assembly
Hot Surface Ignition (HSI) Burner Assembly Illus. No. Part No. Qty. Description 881781* Natural Gas Burner Assembly Complete Less Orifices (includes illus. nos 1 through 9 and 11 through 29) For models mfd. with Natural Gas ONLY 881784* L.P. (liquid propane) Gas Burner Assembly Complete Less Orifices (includes illus. - Page 34 Electric Oven Assembly ELECTRIC OVEN (FRONT VIEW) ELECTRIC OVEN (REAR VIEW) American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
-
Page 35: Electric Oven Assembly
Electric Oven Assembly Illus. No. Part No. Qty. Description 803005 Large Electric Oven Box ONLY --------* Electric Oven Assembly Complete --------* Electric Element 150300 #10 x 1/2” Hex Washer TEK Screw 802800 Sail Switch Box with Bracket and Cover ONLY 802801 Sail Switch Box Assembly Complete (includes illus. - Page 36 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 1 ø 1 ø 3 * Oven assembly complete does not include oven relay. This item must be ordered separately. When ordering Oven Assembly Complete, specify 3 wire or 4 wire when applicable, as well as if dryer has microprocessor (computer) or non-microprocessor controls.
-
Page 37: Sail Switch Assembly
Sail Switch Assembly Illus. No. Part No. Qty. Description 319203 Sail Switch Mounting Bracket 319202 Sail Switch Damper (flat) 319201 Sail Switch Box Cover 319200 Sail Switch Box 154004 Twin Speed Nut 154002 1/8" Push-on Fastener 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 150303 #4 x 3/4"... -
Page 38: Non-Reversing Electric Relay Panel Assembly
Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 132445 12-Amp Contactor Single-Phase (1ø) and 3-Phase (3ø) - 24 VAC 137015 RC Network (for microprocessor [computer] models ONLY) 150103 #8-32 x 3/4” Phillips Round Head Machine Screw 151001 #8-32 Pal Nut 153002... -
Page 39: Microprocessor Reversing Rear Control Box Assembly
Microprocessor Reversing Rear Control Box Assembly Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 137060 Arc Suppressor Board 137013 Nylon Standoff 132431 Reversing Contactor (208/230/240v, 50/60 Hz) - 24 VAC 132432 Reversing Contactor Replacement Coil (208/230/240v, 50/60 Hz) - 24 VAC 150103 8-32 x 3/4”... -
Page 41: Air Operated Steam Damper Assembly
Air Operated Steam Damper Assembly Illus. No. Part No. Qty. Description 165009 Steam Coil Assembly 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4” Lock Washer 820321 Steam Damper Hinge Assembly 803415 Steam Damper Assembly (includes illus. -
Page 42: Dual Timer Reversing Rear Control Box Assembly
Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 132198 Reversing Timer (50/60 Hz) - 24 VAC 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 132431 Reversing Contactor (208/230/240v, 50/60 Hz) - 24 VAC 132432 Reversing Contactor Replacement Coil (208/230/240v, 50/60 Hz) - 24 VAC 150103 #8-32 x 3/4”... -
Page 43: Outer Top/Back Guard Assemblies For Gas And Electric Models Only
Outer Top/Back Guard Assemblies for Gas and Electric Models ONLY Illus. No. Part No. Qty. Description 322809 Rear Electrical Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 323738 Top Back Guard 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 150301 #8-18 x 7/16”... -
Page 44: Back Guard Assembly For Steam Models Only
Illus. No. Part No. Qty. Description 314511 Bottom Back Guard 150300 #10 x 1/2” Hex Washer TEK Screw 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 322809 Rear Electrical Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 103500 Leveling Leg American Dryer Corporation... -
Page 45: Coin Acceptors Listing
Coin Acceptors Listing NOTE: Coin Acceptors listed included Optical Switch (ADC Part No. 137056). ADC Part No. Nation 125100 U.S. and Canada 125101 United Kingdom 125114 United Kingdom 125120 France 125124 France 125107 Australia 125130 Australia 125123 New Zealand 881604 Japan 125103 125121... -
Page 46: Transformer Usage Listing
RANSFORMER Voltage Phase Wire 460/480 460/480 460/480 American Dryer Corporation Transformer Usage Listing SAGE ISTING (for Electric Models Only) Transformer Part No. Control 3ø 3 or 4 132070 3ø 132070 3ø 132070 3ø 3 or 4 132063 3ø 3 or 4 132070 3ø... -
Page 47: Step Down Transformer Usage Listing
Step Down Transformer Usage Listing Heat LECTRIC TEAM Telephone: (508) 678-9000 RANSFORMER ISTING Wire Voltage Service 460/480 460/480 SAGE Transformer Part No. 132059 132059 132062 132062 132053 132053 132050 Fax: (508) 678-9447... -
Page 48: Additional Parts Available
Part No. Description 112039 “Black/White/Green Ground” Label 112280 “Clean Lint Screen” Label 112041 “CAUTION - Exhaust/Lint Screen” Label 112534 “Phase 5 OPL Program Location Summary” Label 114006 “WARNING - Fire Hazards” Label 114094 “MOP HEAD WARNING” Label 117505 Aluminum Duct Tape (sold by the foot) 120100 3/8”... - Page 49 ADC 450416 1 - 08/06/99-50 2 * 04/13/01-25...
