- Page 1 AD-75D II Parts Manual American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com 073100MFM/tcosta ADC Part No. 450432...
- Page 2 These instructions must be posted in a prominent location near the dryer. POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de yout autre appareil. Important MODEL NO. __________________________________________ AD-75D II...
-
Page 3: Table Of Contents
Table of Contents Control Door Assembly Without Trim For OPL (Non-Coin) Models Mfd. as of July 13, 1998 ... 2 Control Door Assembly With Trim For ALL Coin Models and ONLY OPL Models Mfd. prior to July 13, 1998 ... 3 Phase 5 Coin Microprocessor Control Panel Assembly ... -
Page 4: Control Door Assembly Without Trim
Illus. No. Part No. Qty. Description 881053 ADC Logo ONLY (with double adhesive tape) 870011 Logo Double Tape Kit 881045* Control Door (includes illus. nos. 2 and 3) 881046 Stainless Steel Control Door (includes illus. nos. 2 and 3) 117604 Neoprene Sponge Tape (sold by the foot) 150300 #10 x 1/2”... -
Page 5: Control Door Assembly With Trim
Control Door Assembly With Trim For ALL Coin Models and ONLY OPL Models Mfd. prior to July 13, 1998 Illus. No. Part No. Qty. Description 160015 High Security MK-100 Lock Assembly with Key (for coin models Only) 160017 Special Dummy Lock ONLY (for non-coin models Only) 160104 MK-100 Key ONLY (for dummy lock also) -
Page 6: Phase 5 Coin Microprocessor Control Panel Assembly
Phase 5 Coin Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112526 Coin Keyboard Label Assembly 801213 Phase 5 Coin Control Panel Assembly (includes illus. nos. 1, 2, 4, 5, and 6) 801229 Phase 5 Coin Control Panel Assembly with Battery Option (includes illus. -
Page 7: Phase 5 Opl Microprocessor Control Panel Assembly
Phase 5 OPL Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112535 OPL English Keyboard Label Assembly 112276 OPL Stick-On Labels (English Only) ... Not Illustrated 112275 OPL Stick-On Labels ... Not Illustrated (Spanish, Italian, and Hebrew) 112277 3-Language OPL Stick-On Labels ... -
Page 8: Phase 5 Coin And Opl Microprocessor Control Box Assembly
Phase 5 Coin and OPL Microprocessor Control Box Assembly Illus. No. Part No. Qty. Description 141403 Transformer - 24 VAC (for ALL 120/208/240/380/416/480 volt gas and steam models) (for 380/416/480 volt electric models) 132070 Transformer - 24 VAC (for 208/240 volt electric models) 150300 #10 x 1/2”... -
Page 9: Coin Vault Assembly
Coin Vault Assembly Illus. No. Part No. Qty. Description 802112 Microprocessor Coin Vault Assembly Complete (includes illus. nos. 1 through 6) 802117 Microprocessor Coin Vault ONLY 160028 Cam For 1/4 Turn Lock ONLY 875061 1/4 Turn Lock with Key and Cam 160105* 1/4 Turn Mer-Pel Key ONLY 802020... -
Page 10: Dual Timer Control Panel Assembly
Dual Timer Control Panel Assembly For Models Mfd. prior to November 3, 2000 American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... - Page 11 Dual Timer Control Panel Assembly For Models Mfd. prior to November 3, 2000 Illus. No. Part No. Qty. Description 123005 Red Indicator Light - 24 VAC 122400 Rocker Heat Selector Switch 824015 Dual Timer Control Panel Assembly Complete - 24 VAC (includes illus.
-
Page 12: Dual Timer "Tap Touch" Controls
Illus. No. Part No. Qty. Description 124030 15 Minute Timer - 24 VAC 124025 60 Minute Timer - 24 VAC 824175 Red Pilot Light - 24 VAC 122301 “Tap Touch” Switch 131932 Relay SPST 24v 120730 30-Position Terminal Block 151000 #6-32 Pal Nut 882903 Dual Timer Panel Complete... -
Page 13: Dual Timer Control Box Assembly
Dual Timer Control Box Assembly Illus. No. Part No. Qty. Description 122603 9-Pin Socket Connector 122701 Socket Terminal ONLY 122801 Pin/Socket Extraction Tool 315010 9-Pin Connector Bracket 150300 #10 x 1/2” Hex Washer TEK Screw 150300 #10 x 1/2” Hex Washer TEK Screw 141403 Transformer - 24 VAC (for ALL 120/208/240/380/416/480 volt gas and steam models) -
Page 14: Plastic" Door Front Panel Assembly
Illus. No. Part No. Qty. Description 875302* Right Hand Insulated Front Panel Assembly Complete (includes illus. nos. 1, 2, 3, and 6) 875313 Stainless Steel Right Hand Insulated Front Panel Assembly Complete (includes illus. nos. 1, 2, 3, and 6) 154215 5/32 x 1/4”... -
Page 15: Cold Rolled Steel (Crs) Door Front Panel
Cold Rolled Steel (CRS) Door Front Panel Illus. No. Part No. Qty. Description 881273* Front Panel Assembly (cold rolled steel [CRS] door) (includes illus. nos. 1 through 3) 881289 Stainless Steel Front Panel Assembly (cold rolled steel [CRS] door) (includes illus. nos. 1 through 3) 154215 5/32 x 1/4”... -
Page 16: Plastic" Door Main Door Switch Housing
Illus. No. Part No. Qty. Description 152013 #6-32 Hex Nut 1/4” ATF Zinc Plated 153008 #6 Lock Washer 137005 Single-Pole Door Switch (SDS) 121028 Insulated Terminal ONLY 154281 3/8” Standard Nylon Spacer 800448 12-1/2” Stainless Steel Main Door Hinge Assembly (includes illus. -
Page 17: Main Door Switch Assembly Cold Rolled Steel (Crs) Door
Main Door Switch Assembly Cold Rolled Steel (CRS) Door Illus. No. Part No. Qty. Description 153566 #6-32 x 7/8” Clinch Stud 152013 #6-32 Hex Nut 1/4” ATF Zinc Plated 153010 #6 Star Washer 137005 Single-Pole Door Switch (SDS) 122636 Flag Terminal 881211 Main Door Switch Housing 150301... - Page 18 Cold Rolled Steel (CRS) Main Door Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
-
Page 19: Cold Rolled Steel (Crs) Main Door Assembly
Cold Rolled Steel (CRS) Main Door Assembly Illus. No. Part No. Qty. Description 881150 Black Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 881207 Stainless Steel Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 102354 Door Gasket 170730... -
Page 20: Plastic" Main Door Assembly
Illus. No. Part No. Qty. Description 881421 Gray Plastic Main Door Assembly Complete with Mechanical Fasteners (includes illus. nos. 1 and 5 through 9) 800448 12-1/2” Stainless Steel Main Door Hinge Assembly 150410 #10-24 x 3/8” Phillips Pan Head Taptite Screw 152014 1/4-20 Free Spin Wash Nut 102349... -
Page 21: Basket (Tumbler)/Support Assemblies
Basket (Tumbler)/Support Assemblies Illus. No. Part No. Qty. Description 800708 Basket (tumbler) ONLY without Felt Collar 800857 Stainless Steel Basket (tumbler) ONLY without Felt Collar 800816 Non-Reversing Basket (tumbler) and Support Assembly Complete (includes illus. nos. 1 through 10) 800873 Stainless Steel Non-Reversing Basket (tumbler) and Support Assembly Complete (includes illus. -
Page 22: Drop Lint Door Assembly Without Trim
Illus. No. Part No. Qty. Description 160001 AD-100 Lock Assembly with Key (for coin models Only) 160103 AD-100 Key ONLY 800150 Knob Latch Kit Assembly (includes illus. nos. 1 and 2) 160003 Dummy Lock ONLY (for non-coin models) 160104 MK-100 Key ONLY (for dummy lock) 160008 Lock Cam For AD-100 and Dummy Lock 160009... -
Page 23: Drop Lint Door Assembly With Trim
Drop Lint Door Assembly With Trim For ALL Coin Models Illus. No. Part No. Qty. Description 160001 AD-100 Lock Assembly with Key (for coin models Only) 160103 AD-100 Key ONLY 800150 Knob Latch Kit Assembly (includes illus. nos. 1 and 2) 160003 Dummy Lock ONLY (for non-coin models) 160104... -
Page 25: Basket (Tumbler) Bearing Assembly
Basket (Tumbler) Bearing Assembly Illus. No. Part No. Qty. Description 880220 1-3/4” Flange Bearing 153025 9/16” Lock Washer 152050 9/16-12 Hex Nut 882544 Pillow Block Bearing Assembly Complete (includes illus. nos. 4 through 17) 882545 Pillow Block Bearing Assembly Complete with Rotational Sensor (includes illus. -
Page 26: Lint Trap Assembly
Illus. No. Part No. Qty. Description 800440 Non-Reversing Lint Trap Assembly Complete (includes illus. nos. 1, 3, 4, and 5) 800433 Non-Reversing Lint Trap ONLY 800441 Reversing Lint Trap Assembly Complete (includes illus. nos. 1, 3, 4, and 5) 800434 Reversing Lint Trap ONLY 154200 5/32”... -
Page 27: Idler Bearing Assembly
Idler Bearing Assembly Illus. No. Part No. Qty. Description 100108 5L-680 V-Belt 100106 5L-690 V-Belt (for reversing gas and electric models Only) 101140 14” x 3” Compound Pulley 100114 4L-630 V-Belt 100109 4L-650 V-Belt (for reversing steam models Only) 154301 5/16-18 x 1”... - Page 28 Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
-
Page 29: Non-Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly
Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly Illus. No. Part No. Qty. Description 100114 4L-630 V-Belt (motor to idler) 100701 3/16” x 3/16” x 1” Key 101133 5/8” x 2-1/4” Motor Pulley (60 Hz Only) 101130 5/8” x 2-1/2” Motor Pulley (60 Hz Only) 150501 5/16-18 x 3/4”... -
Page 30: Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly
Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 31: Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly
Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly Illus. No. Part No. Qty. Description 100114 4L-630 V-Belt (motor to idler) For Reversing Gas and Electric Models ONLY 100109 4L-650 V-Belt (motor to idler) For Reversing Steam Models ONLY 100701 3/16” x 3/16” x 1” Key 101130 5/8”... - Page 32 Sensor Bracket Assemblies American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
-
Page 33: Sensor Bracket Assemblies
Sensor Bracket Assemblies Illus. No. Part No. Qty. Description 880251 1/4” Temperature Sensor Probe Assembly (includes illus. nos. 1 and 5 through 8) 130301 225° Large Manual Reset Thermostat 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Terminal ONLY 122701 Socket Terminal ONLY 122605... -
Page 34: Electric Oven Assembly
Electric Oven Assembly ELECTRIC OVEN (FRONT VIEW) ELECTRIC OVEN (REAR VIEW) American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... - Page 35 Electric Oven Assembly Illus. No. Part No. Qty. Description 803005 Large Electric Oven Box ONLY ---------* Electric Oven Assembly Complete ---------* Electric Element 150300 #10 x 1/2” Hex Washer TEK Screw 802800 Sail Switch Box with Bracket and Cover ONLY 802801 Sail Switch Box Assembly Complete (includes illus.
-
Page 36: 4-Tube Burner Assembly
4-Tube Burner Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 37: Tube Burner Assembly
1/8” Push On Fastener 142809 1/2” x 29-1/8” Pipe 881231 AD-75D II Liquid Propane (L.P.) Conversion Kit ... Not Illustrated Orifices are at sea level for elevations above 2,000 feet. Consult the factory. ** Orifices are not included. Telephone: (508) 678-9000... -
Page 38: Single-Phase (1Ø) Motor, Electric Relay Panel Assembly
Single-Phase (1Ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 132475 2-Pole Contactor - 24 VAC 150299 #10 x 1” Hex Head TEK Screw 824828 RC Network with Connectors (for microprocessor controller [computer] models Only) 322809 Back Electrical Box Cover ... Not Illustrated 150301 #8-18 x 7/16”... -
Page 39: 3-Phase (3Ø) Motor, Electric Relay Panel Assembly
3-Phase (3Ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 132430 Impellor Contactor (208/230/240v, 50/60 Hz) - 24 VAC 137015 RC Network (for microprocessor controller [computer] models Only) 150103 #8-32 x 3/4” Phillips Round Head Machine Screw 151001 #8-32 Pal Nut 153002... -
Page 40: Microprocessor Reversing Rear Control Box Assembly
Microprocessor Reversing Rear Control Box Assembly Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 137060 Arc Suppressor (A.S.) Board 137013 Nylon Standoff 882386 Reversing Contactor (208/230/240v, 50/60 Hz) - 24 VAC 150103 #8-32 x 3/4” Phillips Round Head Machine Screw 151001 #8-32 Pal Nut 153002... -
Page 41: Dual Timer Reversing Rear Control Box Assembly
Dual Timer Reversing Rear Control Box Assembly For Gas, Electric, and Steam Models Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 132198 Reversing Timer (50/60 Hz) - 24 VAC 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 882386 Reversing Contactor (208/230/240v, 50/60 Hz) - 24 VAC 150103... -
Page 43: Air Operated Steam Damper Assembly
Air Operated Steam Damper Assembly Illus. No. Part No. Qty. Description 165009 Steam Coil Assembly 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4” Lock Washer 820321 Steam Damper Hinge Assembly 803415 Steam Damper Assembly (includes illus. -
Page 44: Outer Top/Back Guard Assemblies
Illus. No. Part No. Qty. Description 322809 Back Electrical Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 323738 Top Back Guard 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 312527 Outer Top Guard 314526... -
Page 45: Back Guard Assembly
Back Guard Assembly For Steam Models ONLY Illus. No. Part No. Qty. Description 314511 Bottom Back Guard 150300 #10 x 1/2” Hex Washer TEK Screw 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 322809 Back Electrical Box Cover 150301 #8-18 x 7/16”... -
Page 46: Microprocessor Coin Acceptors Listing
NOTE: Coin acceptors listed include optical switch. Replacement optic switch for Hanke acceptors is Part No. 881143. Replacement optic switch for Greenwald acceptors is Part No. 137056. ADC Part No. Nation 882689 United States 125100 U.S. and Canada 125107 Australia 881768 Australia 881604... -
Page 47: Electric Oven Component Application Chart
ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 3 ø 1 ø 1 ø 3 Oven assembly complete does not include oven relay. This item must be ordered separately. When ordering Oven Assembly Complete, specify 3 wire or 4 wire when applicable, as well as if dryer has microprocessor controller (computer) or non-microprocessor controls. -
Page 48: Step Down Transformer Usage Listing
Heat LECTRIC TEAM American Dryer Corporation Step Down Transformer Usage Listing OW N RANSFORM ER SAGE ISTING Wire Voltage Service 460/480 460/480 88 Currant Road / Fall River, MA 02720-4781 Transformer Part No. 132059 132059 132062 132062 132053 132053 132050... -
Page 49: Additional Parts Available
Additional Parts Available Part No. Description 112039 “Black/White/Green Ground” Label 112280 “Clean Lint Screen” Label 112041 “CAUTION - Exhaust” Label 112534 “Phase 5 OPL Program Location Summary” Label 114006 “WARNING - Fire Hazards” Label 120100 3/8” Straight (BX) Connector 120300 3/8”... - Page 50 ADC 450432 1 - 12/11/00-25 2 * 09/10/01-25...
