AD-235D/AD-235ED
Installation Manual
WARNING: For your safety the
information in this manual must be
followed to minimize the risk of fire or
explosion or to prevent property damage,
personal injury or death.
Do not store or use gasoline or other flammable
vapor and liquids in the vicinity of this or any
other appliance.
WHAT DO YOU DO IF YOU SMELL GAS
* Do not try to light any appliance.
* Do not touch any electrical switch; do not use
any phone in your building.
* Clear the room, building or area of all
occupants.
* Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
* If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
110199JEV/tcosta
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
* Ne pas tenter d'allumer d'appareil.
* Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant dans
le bâtiment où vous vous trouvez..
* Évacuez la pièce, le bâtiment ou la zone.
* Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
* Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
L'installation et l'entretien doivent être assurés
par un installateur ou un service d'entretien
qualifié ou par le fournisseur de gaz.
For replacement parts, contact the reseller from which the dryer
was purchased or
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
e-mail: techsupport@amdry.com
ADC Part No. 113118

Advertisement

Table of Contents
loading

Related Manuals for American Dryer Corp. AD-235D

Summary of Contents for American Dryer Corp. AD-235D

  • Page 1 AD-235D/AD-235ED Installation Manual WARNING: For your safety the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or death. Do not store or use gasoline or other flammable vapor and liquids in the vicinity of this or any other appliance.
  • Page 2 Retain This Manual In A Safe Place For Future Reference American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble-free operation. ONLY qualified technicians should service this equipment. OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with the dryer.

  • Page 3: For Your Safety

    YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration) STANDARDS.
  • Page 4 The dryer must never be operated with any of the back guards, outer tops, or service panels removed. PERSONAL INJURY or FIRE COULD RESULT. DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN IN PLACE, EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED. PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment and/or specified in the installation manual included with the dryer.

  • Page 5: Table Of Contents

    Table of Contents SECTION I IMPORTANT INFORMATION ... 3 A. RECEIVING and HANDLING ... 3 B. SAFETY PRECAUTIONS ... 4 SECTION II SPECIFICATIONS ... 6 A. Specifications ... 6 SECTION III INSTALLATION PROCEDURES ... 9 A. UNPACKING/SETTING UP ... 9 B.
  • Page 6 SECTION VIII TROUBLESHOOTING ... 36 SECTION IX DATA LABEL LOCATION/INFORMATION ... 42 A. Data Label ... 42 SECTION X PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS ... 44 SECTION XI BURNER/TUMBLER HI-LIMIT MANUAL RESET INSTRUCTIONS ... 47...

  • Page 7: Important Information

    IMPORTANT INFORMATION A. RECEIVING and HANDLING The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or optional box) as a means of preventing damage in transit. Upon delivery, the dryer and/or packaging, and wooden skid should be visually inspected for shipping damage.

  • Page 8: Safety Precautions

    B. SAFETY PRECAUTIONS WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. WARNING: The dryer must never be operated with any of the back guards, outer tops, or service panels removed.
  • Page 9 WARNING: DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured rubberlike materials. Drying in a heated basket (tumbler) may damage plastics or rubber and also may be a fire hazard. 7. A program should be established for the inspection and cleaning of lint in the heating unit area, exhaust duct work, and inside the dryer.

  • Page 10: Specifications

    A. SPECIFICATIONS AXIMUM APACITY DRY WEIGHT ASKET UMBLER IAMETER ASKET TUMBLER EPTH ASKET TUMBLER MOTOR Door Opening (D IAMETER ASKET TUMBLER OLUME OLTAGE VAILABLE PPROX EIGHT NCRATED PPROX EIGHT RATED NPUT IRFLOW NLET XHAUST UTLET Shaded areas are stated in metric equivalents * Per basket (tumbler).
  • Page 11 ADG-235D (Gas) NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation.
  • Page 12 ADG-235ED (Gas) NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation.

  • Page 13: Installation Procedures

    INSTALLATION PROCEDURES Installation should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1- LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70-LATEST EDITION (National Electrical Code) or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P.
  • Page 14 2. The dryer must not be installed or stored in an area where it will be exposed to water and/or weather. 3. The dryer is for use in noncombustible locations. 4. Provisions for adequate air supply must be provided as noted in this manual (refer to Fresh Air Supply in Section D).

  • Page 15: Dryer Enclosure Requirements

    C. DRYER ENCLOSURE REQUIREMENTS Bulkheads and partitions should be made of noncombustible materials and must be located a minimum of 12-inches (30.48 cm), 18-inches (45.72 cm) or more is recommended for ease of installation, maintenance, and service) above the dryer’s outer top, except along the front of the dryer which may be closed in if desired. NOTE: Even though a minimum of 12-inches (30.48 cm) above the dryer’s outer top is accept able, a clearance of 18-inches (45.72 cm) or more is suggested for ease of installation and service (electrical power connections).
  • Page 16 IMPORTANT: Make-up air openings should not be located near duct work exhaust outlets. If make-up air opening(s) are too close to the exhaust outlet, lint and fumes may be drawn back into the dryer area through these openings. NOTE: Component failure due to dry cleaning solvent fumes will VOID THE WARRANTY.

  • Page 17: Exhaust Requirements

    E. EXHAUST REQUIREMENTS Exhaust duct work should be designed and installed by a qualified professional. Improperly sized duct work will create excessive back pressure which results in slow drying, increased use of energy, overheating of the dryer, and shutdown of the burner by the airflow (sail) switches, burner hi-limits, or basket (tumbler) hi-heat thermostats.
  • Page 18 NOTE: When the exhaust duct work passes through a wall, ceiling, or roof made of combustible materials, the opening must be 2-inches (5.08 cm) larger than the duct (ALL the way around). The duct must be centered within this opening. To protect the outside end of the horizontal duct work from the weather, a 90º...
  • Page 19 2. Multiple Dryer (common) Venting If it is not feasible to provide separate exhaust ducts for each dryer, ducts from individual dryers may be channeled into a “common main duct.” The individual ducts should enter the bottom or side of the main duct at an angle not more than 45º...
  • Page 20 IMPORTANT: DO NOT use screens or caps on the outside opening of the exhaust duct work.

  • Page 21: Electrical Information

    F. ELECTRICAL INFORMATION 1. Electrical Requirements It is your responsibility to have ALL electrical connections made by a properly licensed and competent electrician to assure that the electrical installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL electrical connections, materials, and workmanship must conform to the applicable requirements of the National Electrical Code ANSI/NFPA NO.
  • Page 22 2. Grounding A ground (earth) connections must be provided and installed in accordance with state and local codes. In the absence of these codes, grounding must conform to applicable requirements of the National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION, or in Canada, the installation must conform to applicable Canada Standards: Canadian Electrical Codes Parts 1 &...
  • Page 23 INGLE HASE Black Positive Providing local codes permit, power to the dryer can be made by use of a flexible U.L. listed power cord/pigtail (wire size must conform to the rating of the dryer), or the dryer can be hard wired directly to the service breaker panel.
  • Page 24 ADG-230D (Gas) ADG-235ED (Gas) LECTRICAL IMPORTANT: 208 VAC 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage. NOTE: A. Circuit breakers are thermal magnetic (industrial) type ONLY. For others, calculate/verify correct breaker size according to appliance amp draw rating and type of breaker used. B.

  • Page 25: Gas Information

    G. GAS INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the gas plumbing installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL plumbing connections, materials, and workmanship must conform to the applicable requirements of the National Fuel Gas Code ANSI Z223.1-LATEST EDITION, or in Canada, the Canadian Installation Codes CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (liquid propane [L.P.] Gas) or LATEST EDITION.
  • Page 26 2. Technical Gas Data a. Gas Specifications Manifold Pressure* 3.5 inches W.C. Inline Pressure 6.0 - 12.0 inches W.C. Shaded areas are stated in metric equivalents * Measured at gas valve pressure tap when the gas valve in on. b. Gas Connections: Inlet connection -------------- 3/4-inch N.P.T.
  • Page 27 3. Piping Connections ALL components/materials must conform to National Fuel Gas Code Specifications ANSI Z223.1-LATEST EDITION, or in Canada, CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (liquid propane [L.P.] Gas) or LATEST EDITION (for General Installation and Gas Plumbing), as well as local codes and ordinances and must be done by a qualified professional.
  • Page 28 WARNING: NEVER TEST FOR LEAKS WITH A FLAME!!! IMPORTANT: The dryer and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa). NOTE: The dryer must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure test of the gas supply system at test pressures equal to or less than 1/2 psig (3.5 kPa).

  • Page 29: Preparation For Operation

    H. PREPARATION FOR OPERATION The following items should be checked before attempting to operate the dryer: 1. Read ALL “CAUTION,” “WARNING,” and “DIRECTION” labels attached to the dryer. 2. Check incoming supply voltage to be sure that it is the same as indicated on the dryer’s data label affixed on the back of the dryer control (service) door.
  • Page 30 4) Open main door to stop the dryer, and change selection to “PERM PRESS” (medium) setting. Repeat this procedure, but change the selection (setting) to “HI” (high). This will confirm that setting key circuits and door switch circuits are functioning properly. 5) Repeat above procedure for the other basket (tumbler).

  • Page 31: Shut Down Instructions

    4. Make a complete operational check of ALL safety-related circuits (i.e., door switches, hi-limit thermostats, sail switches, basket [tumbler] safety thermostats, etc.). NOTE: The sail switch can be checked for proper operation by opening the control door while the dryer is running and the heating unit (burner) active (on). The heating unit(s) should shut off within a few seconds.

  • Page 32: Operating Instructions

    OPERATING INSTRUCTIONS A. STARTING THE DRYER The dryer is available for use when the appropriate microprocessor controller (computer) light emitting diode (L.E.D.) display reads “FILL” and/or the amount needed to start the dryer (i.e., “25”). Once the load has been put into the dryer and the main door is closed, start the dryer as follows: 1.
  • Page 33 NOTE: When a cycle is interrupted by opening the main door, the cycle time will continue to count downward, regardless if the door is open or closed until a keyboard (touch pad) selection is made. 2) Selection (setting) changes can be made at any time during the drying cycle by opening and closing the main door and then making a new selection.

  • Page 34: Service/Parts Information

    SERVICE/PARTS INFORMATION A. SERVICE 1. Only properly licensed or trained technicians should service the dryer. If service is required, contact the reseller from whom the ADC equipment was purchased. If the reseller cannot be contacted or is unknown, contact the ADC Service Department for a reseller in your area. NOTE: When contacting the ADC Service Department, be sure to give them the correct model number and serial number so that your inquiry is handled in an expeditious manner.

  • Page 35: Warranty Information

    WARRANTY INFORMATION A. RETURNING WARRANTY CARD(S) 1. Before any dryer leaves the ADC factory test area, a warranty card is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you, if you file a warranty claim.
  • Page 36 a. The R.M.A. issued by the factory, as well as any other correspondence pertaining to the returned part(s), must be included inside the package with the failed merchandise. 2. Each part must be tagged with the following information: a. Model number and serial number of the dryer from which part was removed. b.

  • Page 37: Routine Maintenance

    ROUTINE MAINTENANCE A. CLEANING A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the duct work system. The frequency of cleaning can best be determined from experience at each location.
  • Page 38 90 DAYS Remove lint from the motor air vents and surrounding area. IMPORTANT: Lint accumulation will restrict the airflow over the motor(s), causing overheating and irreparable motor damage. Motor failure due to lint accumulation will VOID THE WARRANTY. Remove lint accumulation from around the openings in the dryer’s back panels. Remove lint from gas valve burner train area with a dusting brush or vacuum cleaner attachment.

  • Page 39: Adjustments

    B. ADJUSTMENTS 7 DAYS AFTER INSTALLATION and EVERY 6 MONTHS THEREAFTER Inspect bolts, nuts, screws (bearing set screws), nonpermanent gas connections (unions, shutoff valves, orifices, etc.), electrical terminations, and grounding connections. Motor and drive belts should be examined. A cracked or seriously frayed belt(s) should be replaced. Tighten loose belt(s) when necessary and check the alignment.

  • Page 40: Troubleshooting

    IMPORTANT: YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration) STANDARDS.
  • Page 41 2. Microprocessor controller (computer) indicator is off (and the light emitting diode [L.E.D.] display does not read “door”) ... a. Failed microprocessor controller (computer). C. The dryer will not stop, even with no cycle (L.E.D. display reads “FILL”) in progress... 1.
  • Page 42 G. Microprocessor controller (computer) light emitting diode (L.E.D.) display reads “Hot”... The “Hot” display condition indicates a possible overheating condition. The microprocessor controller (computer) monitors the temperature in the dryer at ALL times. If the microprocessor detects that the temperature in the dryer has exceeded 220º F (104º C), it will disable ALL of the dryer outputs (shut the dryer down), the buzzer (tone) will sound for approximately 5-seconds, and the L.E.D.
  • Page 43 Microprocessor controller (computer) locks up and the light emitting diode (L.E.D.) display reads erroneous message(s) or only partial segments... 1. Transient power voltage (spikes)...disconnect power to the dryer, wait one (1) minute (NOTE: for dryer models with the optional battery backup...disconnect battery), then reestablish power to the dryer. If problem is still evident, proceed to Item J2 thru Item J4 below.
  • Page 44 2. Fault in burner hi-limit circuit or tripped manual reset hi-limit thermostat. 3. Fault in basket (tumbler) hi-limit circuit or tripped manual reset hi-limit thermostat. 4. Failed Direct Spark Ignition (DSI) module (burner control). 5. Failed DSI ignitor and/or flame-probe assembly. N.
  • Page 45 6. Extractors (washers) are not performing properly. 7. Sail switch is fluttering... restriction in exhaust. 8. Failed microprocessor temperature sensor...temperature calibration is inaccurate. 9. Failed microprocessor controller (computer)...temperature calibration is inaccurate. 10. Lint accumulation in location exhaust system. Q. Condensation on main door glass... 1.

  • Page 46: Data Label Location/Information

    SECTION IX DATA LABEL LOCATION/INFORMATION A. DATA LABEL Contact American Dryer Corporation When contacting American Dryer Corporation, certain information is required to insure proper service/parts information from ADC. This information is on the data label that is located in the left inside front side panel (as shown in the illustration above).
  • Page 47 THE DATA LABEL 1. MODEL NUMBER The model number is an ADC number which describes the size of the dryer and the type of heat (gas, electric, or steam). 2. SERIAL NUMBER The serial number allows ADC to gather information on your particular dryer. 3.

  • Page 48: Procedure For Functional Check Of Replacement Components

    PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS 1. Microprocessor Controller (computer) Board a. Upon completing installation of the replacement microprocessor controller (computer) board, reestablish power to the dryer. b. Start the drying cycle. c. Verify that the motors and the heat indicator dots, in the microprocessor controller (computer) light emitting diode (L.E.D.) display are on.
  • Page 49 e. Open main door. The dryer must stop and ALL indicator lights on the back side of the microprocessor controller (computer) board must go out. f. Try to restart the dryer with the main door open. g. The microprocessor controller (computer) board’s light emitting diode (L.E.D.) display must read “DOOR.”...
  • Page 50 3. For Direct Spark Ignition (DSI) System Models Manufactured With ADC Module Part No. 880815 a. Upon completing installation of the replacement DSI module, reestablish power to the dryer. b. Start the drying cycle. c. The ignition DSI module’s light emitting diode (L.E.D.) indicator will light “red”...

  • Page 51: Burner/Tumbler Hi-Limit Manual Reset Instructions

    BURNER/TUMBLER HI-LIMIT MANUAL RESET INSTRUCTIONS Both the top and bottom tumbler of this dryer is equipped/manufactured with a burner manual reset hi-limit and manual reset tumbler/lint chamber hi-limit thermostat. If either manual reset hi-limit thermostat is open prior to the start of the drying cycle, or during the drying cycle, the dryer will not recognize the open (tripped) state of the applicable basket/tumbler hi-limit thermostat and will start or continue through the drying cycle with no heat.
  • Page 52 ADC 113118 1- 11/11/99-50 4- 08/04/00-500 2- 11/29/99-200 3- 01/03/00-500 5* 09/11/00-25...
