Cisco Network Convergence System 6000 Series Unpacking, Moving, And Securing Manual page 30

Attaching the Dolly to the Chassis and Removing the Chassis Pallet
Figure 2-9
Figure 2-10
Figure 2-10
Repeat
Step 5
Attach the dolly to the chassis lift brackets using the M14 x 30 mm screws
Step 6
If the dolly caster brakes are locked, then release them and slide the dolly towards the lift brackets on
Step 7
the chassis
brackets. The dolly and lift brackets must align with each other to easily insert the bolts and secure the
dolly to the lift brackets. Using two people, crank the dolly up
Note
Cisco Network Convergence System 6000 Series Routers Unpacking, Moving, and Securing Guide
2-10
Attaching the Lift Brackets to the Chassis (Oblique View)
shows the top-down view of attaching the lift brackets to the chassis.
Attaching the Lift Brackets to the Chassis (Top-Down View)
Step 4 for the rear side of the chassis.
(Figure 2-11) so that the pins on the upper side of the unit align with the holes on the lift
To make aligning easier, as you slide the dolly, tilt it as needed.
(Figure 2-8).
(Figure 2-12).
Chapter 2
OL-29233-01
