Chapter 1
Figure 1-5
Figure 1-5
9
8
7
3
4
1 Dolly handle label
2 Swing component for dolly (used to change
the dolly configuration)
3 Lift bracket bolts
4 Lift brackets
5 Brakes
OL-29233-01
shows the dolly 90-degree configuration with labels to components.
Chassis Dolly—90-Degree Configuration
9
6
6
5
Cisco Network Convergence System 6000 Series Routers Unpacking, Moving, and Securing Guide
1
5
6 Caster anti-rotation pins
7 Label showing how to attach dolly to chassis
8 Move height calibration label
9 Lifting cranks
Dolly Specifications
2
3
4
3
1-9
