Chapter 2
The drill hole template is attached to the inside of the door
Figure 2-2
1 Drill hole template
Remove the large side panel of the wooden enclosure and set it aside carefully.
Step 3
Note
Disengage the remaining latches from the shipping box. There are two on each side of the shipping box.
Step 4
OL-29233-01
Drill Hole Template Attached to Inside of Crate Door
When setting aside the box, be careful to rest the wood on the floor so that the metal lock latches
are not bent or otherwise damaged. On most of the wooden enclosure, there should be rubber
bands above the bottom lock latches to hold them up so that they do not get damaged when
setting the enclosure down.
Cisco Network Convergence System 6000 Series Routers Unpacking, Moving, and Securing Guide
(Figure 2-2).
1
2-3
