Unpacking the Chassis

The chassis is shipped on a pallet by itself in a plywood box. This chapter describes how to unpack the
chassis from its shipping crate and attach a dolly before moving the chassis to its mounting location.
Unpack the chassis and chassis components in the following order:
•
•
•
•
Note Unpack the chassis and dolly lifting device before all other component shipping boxes. Leave all other
component shipping boxes in the receiving area or in an area, as space allows, at your site, until the
chassis is secured in its final location.
Table 2-1
Table 2-1
Weight (estimated maximum)
Dimensions
Required Tools and Equipment
•
•
•
•
OL-29233-01
Chassis
Power system
Exterior cosmetic components
Cards
lists the physical characteristics of the chassis shipping crate.
Chassis Shipping Crate and Pallet Weight and Dimensions
3/8-inch ratchet wrench
10-mm hex bit
11/16-inch socket (to remove the top wood and frame cushion system)
Ladder or step platform
Cisco Network Convergence System 6000 Series Routers Unpacking, Moving, and Securing Guide
C H A P T E R
Chassis as shipped: 775 lb (352 kg)
Chassis fully loaded with power, fan trays, cards, and
cosmetics: 1450 lb (658 kg)
Height: 88 in. (223.5 cm)
Width: 45 in. (114.3 cm)
Length: 48 in. (121.9 cm)
