- Page 1 PBTA-200 User Manual User Manual / PBTA-200 Issue #1 Issue Date XX/XX/XXXX Revision #1...
- Page 2 PBTA-200 User Manual Contents / Contents Section 1 Introduction Section 2 Power Supply Section 3 Typical Wiring Diagram Section 4 Installation Section 5 Technical Specification Issue #1 Issue Date XX/XX/XXXX Revision #1...
-
Page 3: Power Supply
Section 1 Introduction / Section 2 Power Supply / Section 3 Typical Wiring Diagram / 1 Introduction The PBTA-200 push button temporary fire alarm is activated immediately by pressing the “mushroom” button fixed to the front of the device. Once activated the unit will sound & flash. -
Page 4: Battery Installation
PBTA-200 User Manual 4 Installation Battery Installation Fig.2 Fig.3 Install batteries as shown in figures 2 & 3 above (note that the battery sign is shown on battery box). Alarm Installation Fig.4 Fig.5 It can be installed on boards, walls or wherever it can be hung (these should be places where the unit is easily visible). - Page 5 PBTA-200 User Manual 5 Technical Specification Operating Voltage 8 x AA batteries (12V DC) Average Current 10uA Alarm Current 200mA Sound Output 95 db @ 3m Strobe Colour Operating Temperature -10°C to +50°C Minimum Continuous Temperature 0°C Maximum Humidity 95% RH Non Condensing Alarm Activation Manual (press “mushroom”...
