Premier MX Fire Detection/Alarm Panel and
1. List Of Contents
1. List Of Contents ........................................................................................................ 1
2. Premier MX User Operation - Fire and Fault Conditions ......................................... 3
2.1. If a fire is detected:............................................................................................. 3
2.2. To Silence the fire alarm sounders:.................................................................... 3
2.3. To Resound the fire alarm sounders after they have been silenced: .................. 3
2.4. To Reset the panel from a Fire Alarm:............................................................... 3
2.5. To operate the fire alarm sounders in Evacuate Mode:...................................... 4
2.6. If a fault is detected:........................................................................................... 4
2.7. To Silence the Buzzer: ....................................................................................... 4
3. Premier MX User Indications.................................................................................... 5
3.1. User Indications [showing optional Clock Module] .......................................... 5
3.2. User Controls - [showing optional Clock Module]............................................ 6
4. Premier MX User Controls - Disablement and Test Conditions. ............................. 7
4.1. To Disable/Enable any Zone or Zones............................................................... 7
4.2. To Disable/Enable all Sounders. ........................................................................ 7
4.3. To Disable/Enable the Fire Routing Output....................................................... 8
4.4. To Disable/Enable the Fault Routing Output..................................................... 8
4.5. To Disable/Enable Fire Protection Output[s]..................................................... 9
4.6. To Select/Clear One Man Zone Test................................................................ 10
4.7. To Select/Clear One Man Sounder Test........................................................... 10
4.8. To Enable/Disable Delay Mode ....................................................................... 11
4.9. To Override the Delay Mode ........................................................................... 12
4.10. To Extend the Delay [from 1
4.11. Silencing the Alarms During the Delay: .......................................................... 12
5. User Operating Instructions for Optional Clock Module........................................ 12
5.1. To Display Alarm Event Count: ...................................................................... 12
5.2. To access the User Clock Module Edit Functions ........................................... 13
6.1. If a fire is detected:........................................................................................... 15
6.2. To Silence the fire alarm sounders:.................................................................. 15
6.3. To Resound the fire alarm sounders after they have been silenced: ................ 15
6.4. To Reset the panel & repeater(s) from a Fire Alarm: ...................................... 15
6.5. To operate the fire alarm sounders in Evacuate Mode:.................................... 16
6.6. If a fault is detected:......................................................................................... 16
6.7. To Silence the Buzzer: ..................................................................................... 16
Premier MX Repeater Panel Operation [16 zone version shown] ............................... 17
Checked by: RP
GLT Exports Limited
Premier MX Repeater
User Operation Manual
stage to 2
Approved by JBJ
1
14/12/06
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Zeta Premier MX-16
Summary of Contents for Zeta Premier MX-16
-
Page 1: Table Of Contents
Written by: JBJ Checked by: RP Approved by JBJ GLT Exports Limited Premier MX Fire Detection/Alarm Panel and Premier MX Repeater User Operation Manual 1. List Of Contents 1. List Of Contents ......................1 2. Premier MX User Operation - Fire and Fault Conditions ......... 3 2.1. - Page 2 Written by:.JBJ Checked by: RP 7. Premier MX Repeater Panel User Controls [16 zone panel shown] ....... 18 8. Routine Testing and maintenance ................18 9. User responsibilities ....................18 Premier MX Isolate/De-isolate/Test Mode Select Flowchart ......19 Danger This equipment contains hazardous voltages that can cause death, serious personal injury, or equipment damage.
-
Page 3: Premier Mx User Operation - Fire And Fault Conditions
Written by:.JBJ Checked by: RP 2. Premier MX User Operation - Fire and Fault Conditions 2.1. If a fire is detected: • On the Premier MX Fire Alarm Panel: o The general Fire LED will flash and the buzzer will sound o The relevant zone Fire LED will flash, indicating the location of the fire. -
Page 4: To Operate The Fire Alarm Sounders In Evacuate Mode
Written by:.JBJ Checked by: RP • Set the Access Controls Keyswitch back to position “0” to lock the controls. 2.5. To operate the fire alarm sounders in Evacuate Mode: • Turn the Access Controls Keyswitch on the panel door to position “1”. •... -
Page 5: Premier Mx User Indications
Written by:.JBJ Checked by: RP 3. Premier MX User Indications This section gives an overview of the functions available to the end user. 3.1. User Indications [showing optional Clock Module] General Indicator Section Indication Indicator Description Operating Condition Colour Power Supply On Green Illuminates Steady for Mains or Standby power On. -
Page 6: User Controls - [Showing Optional Clock Module]
Written by:.JBJ Checked by: RP 3.2. User Controls - [showing optional Clock Module] ZONE LOCATION ZONE LOCATION POWER SUPPLY ON EVACUATE TEST DISPLAY FIRE FIRE ROUTING ACTIVE SILENCE/ GENERAL FAULT RESOUND ENABLE ALARMS POWER SUPPLY FAULT SYSTEM FAULT RESET DISABLE EARTH FAULT FUSE FAILED SILENCE... -
Page 7: Premier Mx User Controls - Disablement And Test Conditions
Written by:.JBJ Checked by: RP 4. Premier MX User Controls – Disablement and Test Conditions. 4.1. To Disable/Enable any Zone or Zones. • To Access disable/enable mode: o Turn the Access Controls Keyswitch on the panel door to position “1”. o Press the Select On/Off button to enter the Select Mode: o The Select On LED will light. -
Page 8: To Disable/Enable The Fire Routing Output
Written by:.JBJ Checked by: RP o The general Disablement LED will light. • To enable the sounders: o Press the Enable button to enable the sounders. o The Sounder Fault/Disabled LED will change to the “Off-flash” indication while the cursor is on it, changing to off if the cursor is moved on. -
Page 9: To Disable/Enable Fire Protection Output[S]
Written by:.JBJ Checked by: RP o Press the Select On/Off button to enter the Select Mode: o The Select On LED will light. o The cursor indication will pulse the yellow Zone 1 fault/disabled/test LED. • To select the Fault Routing Output: o Use the Select ↑... -
Page 10: To Select/Clear One Man Zone Test
Written by:.JBJ Checked by: RP o The Fire Protection Fault/Disabled LED will change to the “Off-flash” indication while the cursor is on it, changing to off if the cursor is moved on. o The general Disablement LED will be cleared if no other disablements are present. -
Page 11: To Enable/Disable Delay Mode
Written by:.JBJ Checked by: RP • To select the sounders: o Use the Select ↑ button to move the pulsed cursor indication up through the fault LEDs until it pulses the Sounder Fault/Disabled and Sounder Test LEDs. [The Select ↓ button moves the cursor down]. •... -
Page 12: To Override The Delay Mode
Written by:.JBJ Checked by: RP • To quit delay mode selection: o Set the Access Controls Keyswitch back to position “0” to lock the controls. 4.9. To Override the Delay Mode • When the Delay is running: o The Delay On/Off LED will flash. o The general Fire and zone fire LEDs will flash. -
Page 13: To Access The User Clock Module Edit Functions
Written by:.JBJ Checked by: RP ALARMS:- (0000 to 9999) NNNN Note: If the ZERO DIL switch on the timer module is in the ON position, the alarm counter is cleared to zero and the alarm counter is not functional.. In this condition the normal time will still be displayed and the LCD backlight will illuminate when Test Display is operated but above message will not be displayed. - Page 14 Written by:.JBJ Checked by: RP Time Set Press ENABLE (+) or DISABLE (-) to reset the SS value to zero. Press SELECT ↓, Time Set Display to exit to Day/Night mode On/Off Set Display: D/N ON D/N OFF Change? Change? Pressing SELECT ↓...
-
Page 15: Premier Mx Repeater Panel User Operation - Fire And Fault Conditions
Written by:.JBJ Checked by: RP 6. Premier MX Repeater Panel User Operation - Fire and Fault Conditions 6.1. If a fire is detected: • On the Premier MX Repeater Panel: o The general Fire LED will flash and the buzzer will sound o The relevant zone Fire LED will flash, indicating the location of the fire. -
Page 16: To Operate The Fire Alarm Sounders In Evacuate Mode
Written by:.JBJ Checked by: RP • Set the Access Controls Keyswitch back to position “0” to lock the controls. 6.5. To operate the fire alarm sounders in Evacuate Mode: • Turn the Access Controls Keyswitch on the repeater door to position “1”. •... -
Page 17: Premier Mx Repeater Panel Operation [16 Zone Version Shown]
Written by:.JBJ Checked by: RP Premier MX Repeater Panel Operation [16 zone version shown] General Indicator Section Indication Indicator Description Operating Condition Colour Power Supply On Green Steady indication for Mains or Standby power On. Fire Flashes on any new fire alarm condition, changing to a steady indication on operation of Silence Alarms. -
Page 18: Premier Mx Repeater Panel User Controls [16 Zone Panel Shown]
Written by:.JBJ Checked by: RP 7. Premier MX Repeater Panel User Controls [16 zone panel shown] Access Controls Keyswitch: 0 – Controls Locked 1 – Controls Unlocked Switch Description Functionality Button Availability Evacuate Operates all sounders continuously and lights the Evacuated LED adjacent the When controls are unlocked button until the silence button is operated Silence/Resound... -
Page 19: Premier Mx Isolate/De-Isolate/Test Mode Select Flowchart
Written by: JBJ Checked by: RP Approved by JBJ 10. Premier MX Isolate/De-isolate/Test Mode Select Flowchart Precept Panel CURSOR Sequence: Controls not Enabled Turn ACCESS Zone 1 Fault LED CONTROLS keyswitch to "1" Zone 2 Fault LED Precept Panel Controls Enabled Turn ACCESS Zone n Fault LED (n= 2,4,8,16,32 CONTROLS...
