KitchenAid KGSS907SBL01 Manual page 3

30" freestanding gas oven convection
Hide thumbs

Advertisement

Illus.
No.
Part No. Description
1
Literature Parts
W10118262 Installation Instructions
W10118261 Use & Care Guide
W10112145 Sheet, Tech (English)
W10112146 Sheet, Tech (French)
9757680 Instructions, Anti-Tip
9762761 Tips, Safe Cooking
(English)
9759133 Safer Cooking Tips
(French)
9763467 Guide, Easy Set
2 W10153103 Burner Box
3
9761784 Frame, Cooktop
4
Cooktop
W10106250 Black
W10106270 White
W10106260 Biscuit
5
3196537 Screw
6 W10109920 Gasket (Tape)
7
3400843 Screw
07/31/2013
COOKTOP PARTS
Illus.
No.
Part No. Description
8
8286181 Burner Head, Auxiliary
(6K)
(Right Front & Left Rear)
8286182 Burner Head, Rapid
(12K)
(Right Rear)
9
9763445 Bracket, Burner
10
9756821 Support, Wiring
11
9763436 Cover, Top Rear
12
Grate, Burner Right
9761555CB Coal Black
9761555SD Satin Cumberland
9761555SN Satin Moleskin
13
Grate, Burner Left
9761556CB Matte Black
9761556SD Satin Cumberland
9761556SN Satin Moleskin
14
9759627 Cover, Cooktop Rear
15
3196160 Screw
16
9759944 Thermostat, 70C
3
Illus.
No.
Part No. Description
17
Vent, Center
9760225BL Black
9760225WH White
9760225BT Biscuit
18
Grate, Insert
9761557CB Matte Black
9761557SD Satin Cumberland
9761557SN Satin Moleskin
19
Cap, Burner 6K
(Right Front & Left Rear)
8284669 Coal Black
9761562SD Satin Cumberland
9761562SN Satin Moleskin
Cap, Burner 12.5K
(Right Rear)
9761563CB Coal Black
9761563SD Satin Cumberland
9761563SN Satin Moleskin
20
4449809 Screw
Part No. W10168525 Rev. C
