KitchenAid KGSS907SBL01 Manual page 13

30" freestanding gas oven convection
Hide thumbs

Advertisement

Illus.
No.
Part No. Description
1
9759413 Panel, Door
2
9757706 Glass, Inner
3
4451722 Insulation, Door
4
4457132 Retainer, Glass
5
9760579 Hinge, Door (Right)
9760580 Hinge, Door (Left)
6
9759225 Glass, Inner
7
4457114 Shield, Heat Bottom
8
9759229 Bracket, Side
9
4457103 Heat, Sheild
10
9759225 Glass, Inner
07/31/2013
DOOR PARTS
Illus.
No.
Part No. Description
11
9759230 Bracket, Central
12
9763497 Bracket, Handle (Right)
9763496 Bracket, Handle (Left)
13
8522415 Seal, Window
14
Assembly, Outer Door
W10131888 Black
W10131889 White
W10131890 Biscuit
W10155557 Stainless
13
Illus.
No.
Part No. Description
15
Handle, Door
8303774BL Black
8303774WH White
8303774BT Biscuit
8303774SS Stainless
16
3196184 Screw
17
4448520 Bumper, Door
18
Badge
8304603BL Black
8304603WH White
8304603BT Biscuit
8304603SS Stainless
Part No. W10168525 Rev. C
