TRIPLE CROWN BURNER PARTS
Illus.
No.
Part No. Description
1
9761639 Assembly, Triple Crown
Burner
2
8285250 Plate, Closure
3
8285255 Internal Head, Triple
Crown Burner
4
8285256 External Head, Triple
Crown Burner
5
Cap, Burner External
8285258 Matte Black
8285258SD Satin Cumberland
8285258SN Satin Moleskin
07/31/2013
Illus.
No.
Part No. Description
6
Cap, Burner Internal
9758829CB Matte Black
9758829SD Satin Cumberland
9758829SN Satin Moleskin
7
3400702 Screw
8
3400843 Screw
9
9760519 Valve, Triple Crown
Burner
19
Illus.
No.
Part No. Description
10
Tube, Gas (Triple Crown
Burner)
9761072 Outer
9761071 Inner
11
Orifice
9762443 Internal
9762442 External
12
9763494 Igniter
Part No. W10168525 Rev. C
