Illus.
No.
Part No. Description
1
Trim, Side
W10109540 Black (Right)
W10109570 White (Right)
W10109550 Biscuit (Right)
W10140548 Stainless (Right)
W10109490 Black (Left)
W10109520 White (Left)
W10109500 Biscuit (Left)
W10140547 Stainless (Left)
2
8053971 Brace, Main Back
3
4455606 Receiver, Hinge (Right)
4455605 Receiver, Hinge (Left)
4 W10105790 Bumper & Screw
5
4448444 Grommet, Mounting Rail
6
3400832 Screw
7
8303099 Chassis, Top
8
9759722 Insulation, Body Side
Trim
9
9761666 Tube, Vent
10 W10067870 Lens, Light
11 W10009930 Assembly, Light
12
4452166 Bulb, Light
13
9757732 Shield, Heat
07/31/2013
OVEN PARTS
Illus.
No.
Part No. Description
14 W10130368 Frame, Front
15 W10074200 Gasket, Door
16
Trim, Bottom Vent
W10104890 Black
W10104910 White
W10104900 Biscuit
W10104870 Stainless
17
4452152 Bracket, Bottom Vent
18
9757685 Guide, Side Panel
19
9757461 Bracket,Side Panel
20
Oven, Side Panel
9760723PB Black
9760723PW White
9760723PC Biscuit
21
9757811 Brace, Side Panel
22
9760888 Latch, Motorized
23
9757807 Thermostat SPST
24
9759890 Clip, Side Panel
25
4455641 Side, Panel
26
9759762 Back, Chassis
27
Liner, Oven (Not
serviceable)
28
9759945 Standoff, Rear
11
Illus.
No.
Part No. Description
29 W10131825 Sensor
30
9756454 Bracket, Appliance
Manager
31
9760223 Slide, DSI Module
32 W10083460 Slide, Global Oven
Control
33
9762774 Manager, Appliance
34
3196537 Screw
35
9760481 Washer
36
Vent, Bottom Upper
9756481BL Black
9756481WH White
9756481BT Biscuit
9756481SS Stainless
37
9759242 Thermostat, Thermal
Overload
38
4449809 Screw
39
Cover, Back
40
4448933 Gasket, Retainer
41
4449743 Screw
42 W10110534 Base, Chassis
FOLLOWING PARTS
NOT ILLUSTRATED
9756817 Insulation, Wrap
9756470 Insulation, Back
Part No. W10168525 Rev. C
