KitchenAid KGSS907SBL01 Manual page 15

30" freestanding gas oven convection
Hide thumbs

Advertisement

Illus.
No.
Part No. Description
1
9757687 Support, Drawer Rail
(Right)
9757686 Support, Drawer Rail
(Left)
2
9763501BL Support, Front & Rear
3
4453720 Brace, Drawer (Right)
4453721 Brace, Drawer (Left)
4
9761796 Enclosure, Warming
Drawer
5
9759953 Base, Side (Right)
9759954 Base, Side (Left)
6 W10058460 Foot, Leveling
7 W10153099 Cover, Access
8
3196037 Assembly, Foot
9
3400805 Screw
07/31/2013
DRAWER PARTS
Illus.
No.
Part No. Description
10 W10140539 Drawer
11
Guide, Roller (Includes
Roller)
W10019810 Right
W10019800 Left
12 W10140544 Panel, Drawer
13
Front, Drawer
9761747BL Black
9761747WH White
9761747BT Biscuit
W10140545 Stainless
14
Handle, Drawer
9761573BL Black
9761573WH White
9761573BT Biscuit
9761573SS Stainless
15
Illus.
No.
Part No. Description
15
3196537 Screw
16
8274149 Thermistor, Drawer
17
9760775 Element, Warming
Drawer
18
4449809 Screw
19
9758676 Support, Element
Part No. W10168525 Rev. C
