Web Management User Manual
Industrial Managed Ethernet Switch
Version 1.0
This document applied to models of
MSM-508,MSM-508FC/FCS/FT
©
Co p yr i gh t
IC P D A S C o. , Lt d. , A l l R i gh ts Re s er ve d .
April 29, 2008

Advertisement

Table of Contents
loading

Summary of Contents for ICP DAS USA MSM-508

  • Page 1 Industrial Managed Ethernet Switch Version 1.0 This document applied to models of MSM-508,MSM-508FC/FCS/FT © Co p yr i gh t IC P D A S C o. , Lt d. , A l l R i gh ts Re s er ve d .
  • Page 2: Table Of Contents

    CONTENTS 1. Web Connection ................2 2. Basic Setting ................4 3. Redundant Setting ..............8 4. Port configuration ..............11 5. Relay Alarm ................14 6. Email Alarm ................15 7. VLAN ..................18 8. QoS ................... 20 9. Diagnosis .................. 22 April 29, 2008...
  • Page 3 10.Authentication ................22 April 29, 2008...
  • Page 4: Managed Switch

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Managed Switch Web Management Operation This manual will guide you how to configure ICPDAS Managed Switch through web browser. Connection Web Management support two levels of Basic Setting Redundant Setting authentication : administrator level and user level.
  • Page 5: Web Connection

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Web Connection The default network setting (factory default setting) of Managed Switch is : : 192.168.255.1 Mask : 255.255.0.0 Gateway : 192.168.0.1 Before accessing Managed Switch through web browser, please modify above setting to fit your network environment, you can refer「RS-232 Console Operation」manual for more detail.
  • Page 6 Industrial Ethernet Layer 2 Managed Switch – Web Management Manual For login to Web Management, your browser must support HTTP authentication. It allows a web browser to provide credentials when making a request. April 29, 2008...
  • Page 7: Basic Setting

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Basic Setting This chapter describes how to setting the commonly information on your Managed Switch. Information Module Name: : : : Use to specify the Switch Name, and also displayed as the console prompt. Max. 8 characters.
  • Page 8 Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Only MS Series Switch supports a real time clock. For RS Series Switch, the <Date Time Setting> function is invalid. Network IP Address: : : : IP address is an identifier for a device on a TCP/IP network. It is a 32-bit numeric address consisted as four numbers separated by three dots.
  • Page 9: Serial Port

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Mask: : : : The (subnet) MASK is used to determine the subnet of an IP address. Same as the IP address, a MASK contains four bytes (32 bits) and it is often expressed in the dotted-decimal notation.
  • Page 10 Industrial Ethernet Layer 2 Managed Switch – Web Management Manual COM1 port is the RS232 standard, use for Console Connection. Factory default setting is: Baud Rate : 115200 Data Bit Parity Check : 0 (None) Stop Bit COM2 is the RS485 standard, use for Modbus communication. Factory default setting is: Baud Rate : 115200 Data Bit...
  • Page 11: Redundant Setting

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Redundant Setting Redundant LAN topology is a structure to provide the link failure recovery and escaping network loops. It allows you to setup the redundant loops for supporting backup connections. Managed Switch offers redundancy options for various functions, it is a highly reliability device provides the fast error detection and keeps the non-stop connections 24 hours a day, 365 days a year.
  • Page 12 Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Recovery Time Setting Recovery Time (Cyber-Ring Protocol): : : : Recovery time is the duration of connections that from failure occurred to return to normal. This function allows you to assign the recovery time in millisecond (ms), the variable is from 100ms to 1500ms (1.5 sec).
  • Page 13 Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Forward Time (STP Protocol): : : : Forward delay is the duration time that packages from pre-forwarding state to forward state. Factory default is 10000ms, the variable is from 4000ms to 30000ms (30 sec). Setting is only available on STP Mode.
  • Page 14: Port Configuration

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Port configuration Mirror Mirror Port setting is commonly used to monitor the network traffic, it can help you to collect and trace abnormal packets of each port without interrupting data transmission. User can specify a switch port to receive the packet copies which from another port.
  • Page 15: Port Status

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Trunking This function is used for setting the groups of link aggregation. Port trunking allows user to combine multiple physical ports into a single logical channel. It can increase the link speed and provide the better redundancy availability.
  • Page 16 Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Port Port Number Speed Port transmission speed.(10 Mbps/100 Mbps) Duplex Flow Control Mode. Both Half-duplex and Full-duplex modes are supported. Link Port Link status. ON : Link is up ; OFF : Link is down. Cable Checking This function provides a useful tool to detect the quality of cables.
  • Page 17: Relay Alarm

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Relay Alarm Managed Switch offer a relay contact output on Terminal Block of the Switch equipment. It is able to connect to a light, buzzer …etc. warning device and notify system failures immediately. We also offer the web tool to configure the relay manually.
  • Page 18: Email Alarm

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Email Alarm ICPDAS Managed Switch can notify you by email when the specified event occurred. This chapter will guide you how to setting the related parameters. Alarm Event setting User can specify system and port events that warning emails will be sent. The status of power1 from OFF turns to ON.
  • Page 19 Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Email Setting User can select “Disable Alarm Mail” to stop the email alarm sending (factory default). If email alarm is enabled, there are two methods of email report for you select. The first one is: warning mail is sent immediately when events occur.
  • Page 20 Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Email Record Switch Management can keep the sending date, time and status of each warning emails. But only the latest 50 sending records will be saved. User can click the “Clean Record Table” button to delete all the email sending history. April 29, 2008...
  • Page 21: Vlan

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual VLAN Virtual LANs (VLAN) allows you to setting logical groups of devices, even they are not located on the same physical segment. The logical group called a VLAN, all devices belong to the VLAN has the same network attributes, and it’s isolated from the other network logically.
  • Page 22: Port Based Vlans

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Port based VLANs In this function, user can determine the output ports which this input port can send frames to. For example, in above figure, only the ingress come from Port 4 and Port 8 can be send out from Port 1.
  • Page 23: Qos

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Quality of Service (QoS) provides different priority to different data flow. It can make you to classify and prioritize data frames. ICPDAS Managed Switch support 4 classes of services priority queues. This function allows you to determine the QoS tag priority and specify the priority processing scheme.
  • Page 24: Tag Priority

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual IP ToS/DiffServ Enable/Disable specified ports using the TOS (Type of Service) and/or DiffServ (Differentiated Service) field in IPv4 frame. 802.1p Tag over Tos/DiffServ If <802.1p Tag Priority> and <IP ToS/DiffServ> are both enabled, you have to decide a priority between those two settings.
  • Page 25: Diagnosis

    Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Diagnosis Ping In this function, user can input the IP address and click SUMIT button to check if the IP is reachable. 10. Authentication Account There are two levels of authentication are provided in Switch Management: administrator level and user level.
  • Page 26 Industrial Ethernet Layer 2 Managed Switch – Web Management Manual At the system initial, the default account and password are: Admin and Admin. Accessible IP You can set the remote IP address here to filter the illegal access. Only the IP address in following table can be allowed to access Managed Switch.
  • Page 27 Industrial Ethernet Layer 2 Managed Switch – Web Management Manual Default Setting This function allows you to clean all settings and load the default value to Switch Management. Current factory default values are: Network Setting IP Address : 192.168.255.1 Gateway : 192.168.0.1 Mask : 255.255.0.0...
