➊
...................................................
What's on your package?
1. One MSM Series Switch
2. One companion CD
3. One Quick Start Guide (this document)
4. One RS-232 download cable (CA-090510)
➋
...................................................
Preparing for start-up
1. Power Supply： ： ： ： +12V ~ +48V/DC (EX： ： ： ： PWR-24/110)
http://www.icpdas.com/products/Accessories/power_supply/pwr-24.htm
2. Make sure your PC has workable network settings.
3. Copy 7188xw.exe to your PC.
You can find it from the companion CD（ （ （ （
download the latest version from ICP DAS website.
http://www.icpdas.com/products/Switch/industrial/software.htm
MSM Series Switch Quick Start
MSM Series Switch Quick Start
Industrial Managed Ethernet Switch
Applied to models MSM-508,MSM-508FC/FCS/FT
\Napdos\7188XW \） ） ） ）
- 1 -
Version 1.0, Nov. 2008
T
M
T
M
T
M
,or
