NS-105 5 Port Switch
10/100 Fast Ethernet Switch
Installation Guide
-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS-105 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICP DAS USA NS-105

Summary of Contents for ICP DAS USA NS-105

  • Page 1 NS-105 5 Port Switch 10/100 Fast Ethernet Switch Installation Guide...

  • Page 2: Table Of Contents

    Table of Contents Introduction…………………………………………………… 3 Features………………………………………………………… 4 Specifications…………………………………………………... 5 Installing the Switch………………………………………….. 6 Unpacking……………………………………………………… 6 Checking Power…………………………...…………………… 6 Making Network Connections……………………………….. 7 Network Switched Ports……………………………………….. 7 UTP Cable……………………………………………………... 8 UTP Connections…………...………………………………….. 9 Operating Mode……………………………………………….. LED Indicators……………………………………………….. 11 LED Panel……………………………………………………… 11 Interpretation……………………………………......

  • Page 3: Introduction

    Ethernet network. It is also the good companion of our I-7188EX and I-8000 ethernet embedded controller. The NS-105 comes with multiple ports, each capable of transmitting or receiving information simultaneously at full wire speed to control and allocate the network bandwidth.
  • Page 4 provides a non-disruptive and smooth migration path from Ethernet to a Fast Ethernet network. Easy Installation : With the functions of auto-speed-sensing and auto-negotiation on each port, the switch supports plug-and-play installation which eliminates configuration problems.

  • Page 5: Features

    1.1 Features IEEE 802.3 10BASE-T, and IEEE802.3u 100BASE-TX standards Five 10/100BASE-TX auto-negotiation switched ports for flexible connections to desktop PCs, servers and Ethernet hubs. The 10/100BASE-TX switched support : Auto speed sensing for 100Mbps or 10Mbps connection Auto Configuration with auto-negotiation devices Full-duplex or half-duplex operation Self learning for active MAC addresses Store and forward switching to ensure only good packets are...

  • Page 6: Specifications

    1.2 Specifications Port 1-4 10BASE-T/100BASE-TX connectivity One MDI-X RJ-45 jack 10BASE-T/100BASE-TX connectivity Port 5 One MDI-X RJ-45 / MDI RJ-45 jack (by Push Button setting) 10BASE-T Cat.3,4,5 UTP cable (100meters max.) Cables 100BASE-TX Cat.5 UTP cable (100meters max.) LED indicators Power status Link/Activity/Speed/Duplex/Collision status per port 14,880pps for Ethernet(100BASE-T)

  • Page 7: Installing The Switch

    Installation guide The switch unit 2.2 Checking Power Since NS-105 consume 10 W power, make sure your power supply can meet this demand. Input DC voltage range: 10~30V The screw terminal of the DC power input is located on the front of the switch as shown below : F.G.

  • Page 8: Making Network Connections

    3. Making Network Connections 3.1 Network Switched Ports There are five ports on the switch for connection to five LAN segments. Each segment is an independent shared network in one collision-domain. MDI-X TP Port 1-4 (MDI-X jacks) Five 10/100BASE-TX switched ports Each port consists of one RJ-45 connector and is used for connection to either a 10BASE-T or 100BASE-TX device.

  • Page 9: Utp Cable

    3.2 UTP Cable When making a connection to another device using straight-through UTP cable, make sure MDI-X to MDI connection rule is followed. The following figure illustrates the pin assignments of a straight-through UTP and a crossover UTP cable : RJ-45 plug RJ-45 plug Straight-through UTP...

  • Page 10: Utp Connections

    3.3 UTP Connections The NS-105 switch can support connections to the following devices: 10BASE-T network cards 10/100BASE-TX network cards 10BASE-T hub ports 100BASE-TX hub ports 10/100BASE-TX dual speed hub ports 10/100BASE-TX switch ports Ethernet devices Ethernet Embedded controller, such as I-7188EX, I-7188EA,...

  • Page 11: Operating Mode

    3.4 Operating Mode All switched ports are designed as auto-negotiation capable switched ports. Each port can determine the speed and duplex type used automatically through an auto-negotiation process with the remote connected auto-negotiation device. The auto-negotiation process is performed when the connection is made. When connecting to a non-auto-negotiation device, each TP port also features the capability to auto-sense the connection speed.

  • Page 12: Led Indicators

    4. LED Indicators 4.1 LED Panel The NS-105 switch provides comprehensive LED indicators for diagnosing and monitoring the operation of the unit as shown below : 4.2 Interpretation Each port has three LEDs to indicate the port status including cable link, connection speed, activity, collision and duplex mode.
