What's on your package?
1. One MSM Series Switch
2. One companion CD
3. One Quick Start Guide (this document)
4. One RS-232 download cable
5. One Power cord
6. Mounting Accessory (for 19" Rack Shelf)
➋
...................................................
Preparing for start-up
1. AC Line 100-240V 50-60Hz power supply.
2. Make sure your PC has workable network settings.
3. Copy 7188xw.exe to your PC.
You can find it from the companion CD（ （ （ （
download the latest version from ICP DAS website.
http://www.icpdas.com/products/Switch/industrial/software.htm
MSM Series Switch Quick Start
MSM Series Switch Quick Start
Industrial Managed Ethernet Switch
Applied to models MSM-6226
\Napdos\7188XW \） ） ） ）
- 1 -
Version 1.0, April. 2011
