- Page 1 Operator Interface FSM-510G series 10-Port Managed Industrial Ethernet Switch CLI Command Reference Version Number: Issue: 1.0, Dec 2014...
-
Page 2: Table Of Contents
CONTENTS SCOPE ................................... 9 ................................... 9 COPE ................................9 UDIENCE ............................9 REQUIRED NOWLEDGE ..........................9 CCESS TO ARDWARE NTERFACE .............................. 9 ELATED OCUMENTS OPERATOR INTERFACE ..........................11 ..............................11 NTRODUCTION .............................. 11 ONNECT NTERFACE ............................. 11 CREEN ESCRIPTION ............................... 12 XECUTION ODES .............................. - Page 3 Operator Interface 3.2.26 show qos ..............................21 3.2.27 show queue-shaper............................ 21 3.2.28 show port-shaper............................21 3.2.29 show pvlan isolation [ interface <port_type> [ <port_type_list> ] ]............21 3.2.30 show interface gigabit <portNo> port-isolation..................21 3.2.31 show interface gigabit <portNo> storm-control..................21 3.2.32 show qos storm {unknown-uc|unknown-mc|broadcast} ................
- Page 4 3.3.40 aging <time> ............................30 3.3.41 jumboframe {enable|disable} ........................30 3.3.42 jumboframe mtu <value>.......................... 30 3.3.43 media-type ..............................30 3.3.44 monitor destination interface ........................30 3.3.45 speed................................31 3.3.46 tacacs-server host............................31 3.3.47 tacacs-server key ............................31 3.3.48 tacacs-server timeout ..........................31 3.3.49 traps ................................
- Page 5 Operator Interface 3.7.11 spanning-tree mst priority ......................... 40 3.7.12 spanning-tree mst vlan ..........................40 3.7.13 spanning-tree mst forward-time ........................ 41 3.7.14 spanning-tree mst max-age........................41 3.7.15 spanning-tree mst max-hops........................41 3.7.16 spanning-tree mst name..........................41 ..........................41 ONFIGURE OMMAND 3.8.1 sflow ................................
- Page 6 3.12.7 mvr name <word16> last-member-query-interval <0-31744> ..............50 3.12.8 mvr name <word16> mode........................50 3.12.9 mvr name <word16> type......................... 50 3.12.10 mvr vlan..............................50 3.12.11 mvr vlan <vlan_list> channel ........................50 3.12.12 mvr vlan <vlan_list> frame priority ......................50 3.12.13 mvr vlan <vlan_list> frame tagged......................51 3.12.14 mvr vlan <vlan_list>...
-
Page 7: List Of Tables
Operator Interface 3.18.2 gvrpjoin request vlan..........................58 3.18.3 gvrpleave request vlan..........................58 3.18.4 gvrp max-vlans ............................58 3.18.5 gvrp time { [ join-time <1-20> ] [ leave-time <60-300> ] [ leave-all-time <1000-50>] ......58 3.19 V VLAN C ........................59 OICE ONFIGURE OMMANDS... - Page 8 1. Scope 1.1 Scope 1.2 Audience 1.3 Pre-required Knowledge 1.4 Access to Hardware Interface 1.5 Related Documents...
-
Page 9: Scope
Scope Scope This user guide describes the commands and parameters of the Command Line Interface (CLI) as implemented in the current version of FSM-510G series software. These commands are used to set-up, administer and maintain the system. Audience The guide is intended for Operating personnel (sometimes called craft persons). - Page 10 2. Operator Interface 2.1 Introduction 2.2 Connect Interface 2.3 Authorization Level 2.4 Screen Description 2.5 Execution Modes 2.6 Getting Help 2.7 Terminal Key Function 2.8 Notation Conventions...
-
Page 11: Operator Interface
Operator Interface Operator Interface Introduction Access to the Switch is protected by a logon security system. You can log on to the switch with the user name and password. After three failed logon attempts, the system refuses further attempts. After you log on, the system monitors the interface for periods of inactivity. If the interface is inactive for too long, you are automatically logged off. -
Page 12: Execution Modes
192.0.2.1 Figure 2-1 Screen Description Execution Modes The CLI contains several execution modes. Users will see different set of commands under different execution modes. Table 2-1 lists all the execution modes and their purposes. When users enter a certain execution mode, the corresponding mode prompt will be displayed automatically on the screen. -
Page 13: Terminal Key Function
Operator Interface Terminal Key Function Following is the list of all the terminal keys and their function. Table 2-2 List of Terminal Keys ENTER Run a CLI config script CTRL-M Tab completion. If tab is pressed after a non-whitespace character, complete the word before the Tab. - Page 15 Commands Descriptions 3. Commands Descriptions Initialize Mode Commands Enable Mode Commands Configure Mode Commands VLAN Mode Commands Interface VLAN Mode Commands Ring Group Mode Commands Spanning Tree Configure Commands sFlow Configure Command SNMP Configure Command 3.10 Qos Function Command 3.11 IGMP Functional Commands 3.12 MVR Functional Commands...
-
Page 16: Commands Descriptions
Commands Descriptions Initialize Mode Commands The commands in this section (except ‘enable’ command) can be executed under all command modes. These commands are global commands. 3.1.1 exit Description Exit current mode and quit CLI. Syntax exit Parameter None 3.1.2 configure terminal Description Enter configuration mode. -
Page 17: Enable Mode Commands
Commands Descriptions Enable Mode Commands All the “show - -” commands in this section can also be executed under any other command mode except Initialize Mode. 3.2.1 configure terminal Description Enter configuration mode. Syntax configure Parameter None 3.2.2 disable Description Enter init mode. -
Page 18: Show Mac Address Table Aging-Time
Parameter None 3.2.11 show mac address table aging-time Description Show aging time for MAC learning table (system-wide). Syntax show aging time Parameter None 3.2.12 show mac address table Description Show MAC learning table. Syntax show mac address-table [ conf | static | aging-time | { { learning | count } [ interface <port_type>... -
Page 19: Show Mac Address Table Interface
Commands Descriptions 3.2.13 show mac address table interface Description Show MAC learning table per port. Syntax show mac address-table [ interface <port_type> [ <port_type_list> ] ] Parameter Name Description <portNo> Valid values: 1 ~10(GIE5010) or 1~8(GIE510G8) Type: Mandatory 3.2.14 show mac address vlan <vlanid> Description Show MAC learning table per VLAN index. -
Page 20: Show Interface Port
3.2.19 show interface port <portNo> statistics Description Show Ethernet counter per gigabit port. Syntax show interface <port_type> [ <port_type_list> ] statistics Parameter Name Description <port_type> Port type in Fast, Giga or Tengiga ethernet Valid values: 1 ~ 10 <portNo> Type: Mandatory counter Show Gigabit Ethernet counter.Statistics -
Page 21: Show Qos
Commands Descriptions 3.2.26 show qos Description Show scheduler profile table. Syntax show queue-scheduler profile Parameter None 3.2.27 show queue-shaper Description Show queue shaper information. Syntax show queue-shaper Parameter None 3.2.28 show port-shaper Description Show port shaper information. Syntax show port-shaper Parameter None 3.2.29 show pvlan isolation [ interface <port_type>... -
Page 22: Show Port-Mirror
VLAN. Type: Mandatory unknown-mc Show unknown multicast storm control information by VLAN. Type: Mandatory broadcast Show broadcast storm control information by VLAN. Type: Mandatory 3.2.33 show port-mirror Description Show port mirror information. Syntax show port-mirror Parameter None 3.2.34 show ring-protect Description Show ring protect information Syntax... -
Page 23: Show Interface Gigabit
Commands Descriptions 3.2.40 show interface gigabit <portNo> vlan Description Show vlan information per port Syntax show interface gigabit <portNo> vlan Parameter Name Description <portNo> Gigabit port. Valid values: 1 ~ 10 Type: Mandatory 3.2.41 show vlan-trans Description Show VLAN translation table for all Syntax show vlan-trans Parameter...Vlan -
Page 24: Configure Mode Commands
Configure Mode Commands Commands that can be executed under Configure Mode 3.3.1 interface gigabit <portNo> Description Gigabit Ethernet interface. (enter gigabit interface mode) Syntax interface gigabit <portNo> Parameter Name Description <portNo> Valid values: 1 ~ 10 Type: Mandatory 3.3.2 interface vlan <vlanid> Description Vlan Ethernet interface (enter mode of interface vlan) Syntax... -
Page 25: Clock Summer-Time Set [Start-Time] [End-Time]
Commands Descriptions default Set time zone to default (GMT/UTC). Type: Mandatory 3.3.7 clock summer-time set [start-time] [end-time] Description Set date/time. Syntax clock summer-time <word16> date [ <1-12> <1-31> <2000-2097> <hhmm> <1-12> <1-31> <2000-2097> <hhmm> [ <1-1440> ] ] Parameter Name Description <... -
Page 26: Clearipigmp Snoopingstatistics
Parameter Name Description running-config Currently running configuration startup-config Startup configuration syntax-check Perform syntax check on source configuration Filename File in FLASH or on TFTP server 3.3.12 clearipigmp snoopingstatistics Description clear ipigmpsnoopingstatisti Syntax clear ipigmp snooping [ vlan<vlan_list> ] statistics Parameter Name Description vlan_list... -
Page 27: Editing
Commands Descriptions half Forced half duplex. full Forced full duplex. auto Auto negotiation of duplex mode. [ half | full ] Advertise half /full duplex. 3.3.19 editing Description Enable command line editing Syntax editing Parameter 3.3.20 flowcontrol Description Enable/Disable flow control. Syntax flowcontrol { on | off } Parameter... -
Page 28: Help
3.3.25 help Description Description of the interactive help system Syntax help Parameter 3.3.26 iparp inspection Description iparp inspection Syntax iparp inspection Parameter 3.3.27 iparp inspection translate Description IP ARP inspection entry interface configuration Syntax iparp inspection translate interface <port_type><port_type_id><vlan_id><mac_ucast><ipv4_ucast> ] Parameter Name Description... -
Page 29: Ip Source Binding Interface
Commands Descriptions 3.3.33 ip source binding interface Description IP source binding entry interface configuration Syntax Ip source binding interface <port_type> <port_type_id> <vlan_id> <ipv4_ucast> <mac_ucast> Parameter Name Description port_type Port type in Fast, Giga or Tengigaethernet port_type_id Port ID in the format of switch-no/port-no vlan_id Select a VLAN id to configure ipv4_ucast... -
Page 30: Vlan Disable
Type: Mandatory <name> VLAN Name (0~31) String Size:0~31 Type: Mandatory 3.3.39 vlan disable <vlanid> Description Delete VLAN memberset/setting. Syntax vlan disable <vlanid> Parameter Name Description <vlanid> Valid values: 1 ~ 4094 Type: Mandatory 3.3.40 aging <time> Description Configure aging time for a bridge port. Syntax aging <time>... -
Page 31: Speed
Commands Descriptions <port_type Port type <port_type_id> Port Number 3.3.45 speed Description Configures interface speed. If you use 10, 100, or 1000 keywords with the auto keyword the port will only advertise the specified speeds. Syntax speed { 10g | 2510G | 1000 | 100 | 10 | auto { [ 10 ] [ 100 ] [ 1000 ] } } Parameter Name Description... -
Page 32: Upnp
rmon RMON event 3.3.50 upnp Description Set UPnP's configurations Syntax upnp Parameter 3.3.51 upnp advertising-duration Description Set UPnP's advertising duration Syntax upnp advertising-duration <100-86400> Parameter Name Description 100-86400 advertising duration 3.3.52 upnp ttl Description Set UPnP's TTL value Syntax upnp ttl <1-255> Parameter Name Description... -
Page 33: Flow-Control {Enable|Disble
Commands Descriptions 3.3.53 flow-control {enable|disble} Description Enable/Disable flow-control. Syntax flow-control {enable|disble} Parameter Name Description enable Enable flow-control. disable Disable flow-control. 3.3.54 speed Description Configure gigabit Ethernet speed and Copper/SFP for gigabit port 7~8. (port1~6 Only support copper, no SFP) (port 9, 10 only support auto) Syntax speed {auto|full-l000mbps|full-100mbps|full-10mbps|half-100mbps|half-10mb... -
Page 34: Vlan-Trunking
{ <0x0-0xffffff> | rfc_1042 | snap_8021h } <0x0-0xffff> } | { llc <0x0-0xff> <0x0-0xff> } } group <word16> Parameter Name Description 0x600-0xffff Ether Type(Range: 0x600 - 0xFFFF) Ether Type is ARP Ether Type is IP Ether Type is IPX Ether Type is AppleTalk 0x0-0xffffff SNAP OUI (Range 0x000000 - 0XFFFFFF) rfc_1042... -
Page 35: Switchport Hybrid Egress-Tag
Commands Descriptions Parameter Name Description All VLANs none No VLANs Add VLANs to the current list remove Remove VLANs from the current list except All VLANs except the following vlan_list VLAN IDs of the allowed VLANs when this port is in hybrid mode 3.4.9 switchport hybrid egress-tag Description... -
Page 36: Interface Vlan Mode Commands
Interface VLAN Mode Commands 3.5.1 interface Description Interface configuration Syntax interface <port_type> [ <port_type_list> ] Parameter Name Description port_type Port type in Fast, Giga or Tengigaethernet port_type_list List of Port ID, ex, 1/1,3-5;2/2-4,6 3.5.2 interface vlan Description VLAN interface configurations Syntax interface vlan<vlan_list>... -
Page 37: Ipdhcp Snooping
Commands Descriptions Parameter Name Description vlan_id Vlan ID 3.5.8 ipdhcp snooping Description IP DHCP snooping Syntax ipdhcp snooping Parameter 3.5.9 ipv6 address Description Configure the IPv6 address of an interface Syntax ipv6 address <ipv6_subnet> Parameter Name Description ipv6_subnet IPv6 prefix x:x::y/z 3.5.10 ipv6mtu Description IPv6 Maximum transmission unit... -
Page 38: Ring Group Mode Commands
Ring Group Mode Commands 3.6.1 ring-protect {enable|disable} Description Enable/disable ring protection. Syntax ring-protect {enable|disable} Parameter None 3.6.2 ring-protect {node1|node2} <portNo> Description Set node1/node2 for ring protection. Syntax ring-protect {node1|node2} <portNo> Parameter Name Description <portNo> Port number. Valid values: 1~10 Type: Mandatory 3.6.3 ring-protect role {master| slave} Description Set role to ring protection. -
Page 39: Ring-Group
Commands Descriptions 3.6.8 ring-group <number> Description Entry ring group interface Syntax ring-group <number> Parameter Name Description <number> Ring group index Valid values: 1~2 Type: Mandatory Spanning Tree 3.7.1 spanning-tree Description Enable/disable STP on this interface Syntax spanning-tree Parameter Name Description 3.7.2 spanning-tree aggregation Description Spanning Tree protocol... -
Page 40: Spanning-Tree Mode
3.7.8 spanning-tree mode Description mode STP protocol mode 802.1D Spanning Tree rstp Rabid Spanning Tree (802.1w) mstp Multiple Spanning Tree (802.1s) Syntax spanning-tree mode { stp | rstp | mstp } Parameter Name Description 802.1D Spanning Tree rstp Rabid Spanning Tree (802.1w) mstp Multiple Spanning Tree (802.1s) 3.7.9 spanning-tree mst cost... -
Page 41: Spanning-Tree Mst Forward-Time
Commands Descriptions Name Description <0-7> instance 0-7 (CIST=0, MST2=1...) <vlan_list> Range of VLANs 3.7.13 spanning-tree mst forward-time Description forward-time Delay between port states Syntax spanning-tree mst forward-time <4-30> Parameter Name Description <4-30> Delay between port states 3.7.14 spanning-tree mst max-age Description Max bridge age before timeout. -
Page 42: Sflow Collector-Address
Name Description < ipv4_addr > Ipv4 address < ipv6_addr> ipv6 address 3.8.3 sflow collector-address Description Sflow runtime, see sflow_icli_functions Syntax 3.8.4 sflow collector-address [ receiver <range_list> ] [ <word> ] Parameter Name Description < range_list > Sampler instance 3.8.5 sflow max-datagram-size Description Statistics flow Maximum datagram size. -
Page 43: Snmp Configure Command
Commands Descriptions SNMP Configure Command 3.9.1 snmp-server Description Enable SNMP server Syntax snmp-server Parameter Name Description 3.9.2 snmp-server access Description snmp-server access configuration Syntax snmp-server access < group name > model { v1 | v2c | v3 | any } level { auth | noauth | priv } [ read <word255>... -
Page 44: Snmp-Server Trap
configuration > <200-1468> packet byte [ linkup ] Link up event [ linkdown ] Link down event [ lldp ] LLDP event 3.9.7 snmp-server trap Description Set SNMP server's configurations Syntax snmp-server trap Parameter Name Description 3.9.8 snmp-server user Description Set the SNMPv3 user's configurations Syntax snmp-server user <Username>... -
Page 45: Qos Function Command
Commands Descriptions Name Description Ipv4_ucast IP address of SNMP trap host hostname hostname of SNMP trap host 1-65535 UDP port of the trap messges traps Send Trap messages to this host informs Send Inform messages to this host 3.10 Qos Function Command 3.10.1 qos cos Description Class of service configuration... -
Page 46: Qos Map Dscp-Egress-Translation
Syntax qos map dscp-cos { <0~63> | { be | af11 | af12 | af13 | af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 | cs5 | cs6 | cs7 | ef | va } } cos <0-7>... -
Page 47: Qos Policer
Commands Descriptions cs5 | cs6 | cs7 | ef | va } } Parameter Name Description <0~7> Cos level <0-63> Dscp level Default PHB(DSCP 0) for best effort traffic af11~13 Assured Forwarding PHB 11~13(DSCP 10,12,14) af22~23 Assured Forwarding PHB 22~23(DSCP 20,22) af31~33 Assured Forwarding PHB 31~33(DSCP... -
Page 48: Igmp Functional Commands
Name Description <1-100> every level proportion <unit> Traffic meter 3.11 IGMP Functional Commands 3.11.1 ip igmp host-proxy [ leave-proxy ] Description IGMP proxy for leave configuration Syntax ipigmp host-proxy [ leave-proxy ] Parameter Name Description leave-proxy IGMP proxy for leave 3.11.2 ip igmp snooping Description Snooping igmp... -
Page 49: Ip Igmp Snooping Vlan
Commands Descriptions Parameter Name Description 1-317 1 - 31744 seconds 3.11.9 ip igmp snooping vlan Description ipigmp snooping vlan IDs Syntax ipigmp snooping vlan<vlan_list> Parameter Name Description vlan_list VLAN identifier(s): VID 3.11.10 ip igmp unknown-flooding Description IP IGMP flooding unregistered IPv4 multicast traffic Syntax ipigmp unknown-flooding Parameter... -
Page 50: Mvr Name
Parameter Name Description name <word16> MVR multicast VLAN name 3.12.6 mvr name <word16> igmp-address <ipv4_ucast> Description MVR address configuration used in IGMP Syntax mvr name <word16> igmp-address <ipv4_ucast> Parameter Name Description name <word16> MVR multicast VLAN name <ipv4_ucast> A valid IPv4 unicast address 3.12.7 mvr name <word16>...Igmp-Address -
Page 51: Mvr Vlan
Commands Descriptions 3.12.13 mvr vlan <vlan_list> frame tagged Description Set tagged IGMP/MLD frames will be sent Syntax mvr vlan <vlan_list> frame tagged Parameter Name Description < vlan_list > MVR multicast VLAN list 3.12.14 mvr vlan <vlan_list> igmp-address Description Set tagged IGMP/MLD frames will be sent Syntax mvr vlan <vlan_list>...Frame Tagged -
Page 52: Ipv6Mld Snooping Immediate-Leave
3.13.4 ipv6mld snooping immediate-leave Description IPv6 MLD snooping immediate-leave configuration Syntax ipv6 mld snooping immediate-leave Parameter 3.13.5 ipv6mld snooping last-member-query-interval Description ipv6 mld snooping last member query interval in tenths of seconds Syntax ipv6 mld snooping last-member-query-interval <0-31744> Parameter Name Description 0-31744 0 - 31744 tenths of seconds... -
Page 53: A Uthenticate M Ode C Ommands
Commands Descriptions 3.14 Authenticate Mode Commands 3.14.1 radius-server attribute 4 Description Configure radius-server attribute Syntax radius-server attribute 4 <ipv4_ucast> Parameter Name Description <ipv4_ucast> ipv4_ucast address 3.14.2 radius-server attribute 95 Description Configure radius-server attribute Syntax radius-server attribute 95 <ipv6_ucast> Parameter Name Description <ipv6_ucast>... -
Page 54: Dot1X Feature
3.14.7 tacacs-server deadtime <1-1440> Description Time to stop using a TACACS+ server that doesn't respond Syntax tacacs-server deadtime <1-1440> Parameter Name Description < <1-1440> Time in minutes 3.14.8 tacacs-server deadtime <1-1440> Description Time to stop using a TACACS+ server that doesn't respond Syntax tacacs-server deadtime <1-1440>... -
Page 55: Dot1X Radius-Vlan
Commands Descriptions multi | mac-based } Parameter Name Description force-authorized Port access is allowed force-unauthorized Port access is not allowed auto Port-based 802.1X Authentication single Single Host 802.1X Authentication multi Multiple Host 802.1X Authentication mac-based Switch authenticates on behalf of the client 3.14.14 dot1x radius-vlan Description Enables/disables per-port state of RADIUS-assigned VLAN. -
Page 56: Loop-Protect Tx-Mode
3.15.5 loop-protect tx-mode Description Loop protection actively generate PDUs Syntax loop-protect tx-mode Parameter 3.16 LLDP Configure commands 3.16.1 lldp holdtime Description Sets LLDP hold time (The neighbor switch will discarded the LLDP information after \"hold time\" multiplied with \"timer\" seconds ). Syntax lldp holdtime <2-10>... -
Page 57: Lldp Transmission-Delay
Commands Descriptions 3.16.6 lldp transmission-delay Description Sets LLDP transmision-delay. LLDP transmission delay (the amount of time that the transmission of LLDP frames will delayed after LLDP configuration has changed) in seconds.) Syntax lldp transmission-delay <1-8192> Parameter Name Description <1-8192> transmission-delay seconds 3.16.7 lldp transmit Description Enable/Disabled transmision of LLDP frames. -
Page 58: Gvrpjoin Request Vlan
3.17.5 rfc2544 stop <word32> Description Stop execution of an ongoing test Syntax rfc2544 stop <word32> Parameter Name Description <word32> Report name to stop execution of 3.17.6 show rfc2544 profile [ <word32> ] Description show rfc2544 profile name Syntax show rfc2544 profile [ <word32> ] Parameter Name Description... -
Page 59: Voice Vlan Configure Commands
Commands Descriptions 3.19 Voice VLAN Configure Commands 3.19.1 voice vlan Description Vlan for Voice appliance attributes Syntax voice vlan Parameter 3.19.2 voice vlan aging-time Description Set secure learning aging time for voice traffic Syntax voice vlan aging-time <10-10000000> Parameter Name Description 10-10000000 Aging time, 10-10000000 seconds...
