NS-208
Unmanaged 8-Port Industrial 10/100 Mbps
Ethernet Switch
Quick Start Guide
Product Info:
http://www.icpdas-usa.com/ns_208_ethernet_switch.html
1. Introduction
The NSM-108/NS-208 has 8 Ethernet Switching ports that support
10/100Base-T(X), with a 10/100M auto-negotiation feature and auto
MDI/MDI-X function. It can connect 8 workstations and automatically
switches the transmission speed (10 Mbps or 100 Mbps) for corresponding
connections. The flow control mechanism is also negotiated. LEDs
embedded in RJ-45 jacks make for easy monitoring. Port connectors are
shielded RJ-45. A power source for +10~+30VDC is required.
Figure 1-1 NS-208
-Port Switch
NS-208 8
- QuickStart (Feb/2016)
ICP DAS USA, Inc. |
www.icpdas-usa.com
| 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
1
