A Huffy Company

SAFETY INSTRUCTIONS

FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY RESULT IN
SERIOUS INJURY, PROPERTY DAMAGE AND WILL VOID WARRANTY.
Owner must ensure that all players know and follow these rules for safe
To ensure safety, do not attempt to assemble this system without following the
instructions carefully. Proper and complete assembly, use and supervision is
essential for proper operation and to reduce the risk of accident or injury. A high
probability of serious injury exists if this system is not installed, maintained, and
operated properly. Check entire box and inside all packing material for parts
and/or additional instructional material. Before beginning assembly, read the
instructions and identify parts using the hardware identifier and parts list in this
document.
• If using a ladder during assembly, use extreme caution.
• Two (2) people are recommended for this operation.
• Check base regularly for leakage. Slow leaks could cause system to tip
over unexpectedly.
• Seat the pole sections properly (if applicable). Failure to do so could allow
the pole sections to separate during play and/or transport of the system.
• Climate, corrosion or misuse could result in system failure.
• Minimum operational height is 6' 6" (1.98 m) to the bottom of backboard.
• This equipment is intended for home recreational use only and NOT
excessive competitive play.
• Read and understand the warning label affixed to pole. Label is shown on
page 12.
• The life of your basketball pole depends on many conditions. The climate,
placement of the pole, the location of the pole, exposure to corrosives
such as pesticides, herbicides or salts are all important.
• If technical assistance is required, contact Huffy Sports.
• Adult supervision is recommended when adjusting height
Most injuries are caused by misuse and/or not following instructions.
Use caution when using this system.
For more information on assembly, placement, proper use and maintenance, visit
The American Basketball Council website at http://www.smarthoops.com.
In U.S. and Canada only:
We appreciate your purchasing one of our many fine products. We are sure that you will be very satisfied with your selection. Although
great care and effort have been taken, occasionally problems may occur. To ensure prompt and correct handling of any problems, or to
answer any questions, please contact our Toll-Free Customer Service Number listed below. Service will be quicker if you have your
Model Number (found on carton) and assembly instructions ready when calling. PLEASE WRITE YOUR MODEL NUMBER IN
THE SPACE PROVIDED ABOVE.
Toll-Free Customer Service Number for U.S: 1-800-558-5234 Canada Only: 1-800-284-8339
WRITE IN YOUR MODEL NUMBER:
Portable Basketball System
Owners Manual
operation of the system.
Have questions...don't go back to the store!
Internet Address: http://www.huffysports.com
___________
• Two People
• Tape Measure
• Tape
• Wood Board (Scrap)
• Wrenches: (Two ) 7/16, 1/2, 9/16, 3/4
(9/16 Deep Socket w/Ext. Recommended)
• Pliers
• Sawhorse
• Step Ladder 8 ft. (2.4m)
• Garden Hose or Sand (300-325 lbs.) (136-147 kg)
1
Customer Service Center
N53 W24700 South Corporate Circle
Sussex, WI 53089
U.S.A.
REQUIRED TOOLS AND
MATERIALS:
5/99
P/N 205932

Advertisement

loading

Summary of Contents for Huffy SKM 5200

  • Page 1: Safety Instructions

    MATERIALS: such as pesticides, herbicides or salts are all important. • Two People • If technical assistance is required, contact Huffy Sports. • Tape Measure • Adult supervision is recommended when adjusting height • Tape •...
  • Page 2 WARNING FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. Owner must ensure that all players know and follow these rules for safe operation of the system. • DO NOT HANG on the rim or any part of the system including backboard, support braces or net.
  • Page 3 5/99 P/N 205932...
  • Page 4 IMPORTANT! WRITE DOWN MODEL NUMBER FROM BOX ON PAGE 1 OF THIS OWNERS MANUAL Mark pole sections with tape as shown. BOTTOM MIDDLE 34” (86.4 cm) 5” (13 cm) 5” (13 cm) IMPORTANT! IMPORTANT! Bounce pole top (1) and middle bottom pole section (3) to section (2) together as assembly as shown.
  • Page 5 Install rod (8) thru holes in bottom pole section (3) Insert pole into base assembly as shown. and eyebolt (7) as shown. TOP VIEW OF BASE ASSEMBLY Bring pole foward and secure pole to front panel (4) at 34” (86.4 cm) mark on pole. Tighten nuts evenly until snug.
  • Page 6 IMPORTANT! Test fit bolts into holes of brackets (14) and carefully rock them in a circular motion to ream out paint from holes if necessary. IMPORTANT! Finger tighten nuts and bolts until instructed to fully tighten later. Fit spacer (17) into pawl and fit pin of pawl through end slot of release lever (19).
  • Page 7 Assemble rim bracket (30). Tighten completely. Start with nuts (34) flush against bracket (14), secure rim assembly and bracket (14) to backboard. NOTE: Rim mounting nuts and bolts supplied with rim hardware. Bend bracket (14) to line up with keyhole slots in channel. Loosely assemble bolts (33) and nuts (34) to bracket (14).
  • Page 8 Assemble elevator tubes (23) to backboard bracket. Support pole on sawhorse. Attach backboard assembly to top pole section (1). NOTE: Two people are recommended for this step, use caution, elevator assembly is heavy. Then install pole cap (40). P/N 205932 5/99...
  • Page 9 Roll completed assembly to desired position, fill base with 25 gallons (95 liters) of water or approx. 300-325 lbs. of sand and WARNING snap cap (41) in place. Secure assembly to ground using rope (42) and ground screw DO NOT LEAVE ASSEMBLY (43).
  • Page 10 Install bolt (48) and adjust to level rim. Use Caution Not To Cross-Thread Bolt Push Down to Start Bolt Adjust bolt (48) to level rim. Install net clips (49) and net (50). The Quick Clip™ rapid release net system lets the net pull away from the rim.
  • Page 11: Release Lever

    Apply logo label (51). Then snap cover (37) closed. Adjusting the Height to any of the Seven Positions Insert the end of a broom handle or wooden dowel 3/4”-7/8” (19-22 mm) diameter into the release lever. REGULATION RIM HEIGHT IS 10 FEET (3.05M). (10 fot) i NBA.
  • Page 12 Make final adjustments to level the rim. If the backboard and rim are tipped back, raise front panel (4) until level and tighten completely. NOTE: Equal rotations on each side of u-bolt are necessary. If backboard and rim are tipped forward, lower front panel (4) until level and tighten.
  • Page 13: Parts List

    PARTS LIST Item Qty. Part No. Description Item Qty. Part No. Description 201125 Spring 982416 Top Pole Section, (Black) 900855 Rim Bracket, (Black) 902415 Middle Pole Section, (Black) 900854 Rim Bracket, (Red) 952415 Bottom Pole Section, (Black) 202791 Bolt, Hex Flange, 3/8-16 x 3/4 202422 Front Panel 202793...
  • Page 14 HARDWARE IDENTIFIER (CONTINUED) Item #17 (2) Item #20 (1) Item #21 (1) Item #22 (1) Item #26 (1) Item #13 (1) Item #25 (4) Item #24 (5) Item #33 (2) Item #34 (6) Item #36 (5)* Item #28 (6) Item #35 (4) Item #48 (1) Item #38 (1) YOU MAY...
