Huffy Single Electronic Basketball System Owner's Manual

Single electronic basketball system
Hide thumbs Also See for Single Electronic Basketball System:

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Single Electronic Basketball System
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
TOOLS SUPPLIED:
• 1 Allen Wrench
• Wrench
(4 mm & 6 mm)
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL BEFORE USING
THIS UNIT.
FAILURE TO FOLLOW OPERATING
INSTRUCTIONS COULD RESULT IN
INJURY OR DAMAGE TO PROPERTY.
ADULT ASSEMBLY REQUIRED
Complete assembly before use by children.
Unpacked product and parts must be kept
away from children. Discard all packaging
material and extra parts after assembly.
ELECTRICALLY OPERATED PRODUCT
As with all electric products, precautions
should be taken to prevent electric shock.
Not recommended for children under 6
years of age.
© COPYRIGHT 2004 by HUFFY SPORTS
Owners Manual
Customer Service Center
TOOLS NEEDED:
• 2 People
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Canada: 1-800-284-8339,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
For Australia: 1-800-333 061
Internet Address: http://www.huffysports.com
WARNING!
SHARP OBJECT
INFLATION NEEDLE
KEEP OUT OF REACH OF SMALL
CHILDREN.
NOT FOR CHILDREN UNDER 3 YEARS.
CHOKING HAZARD
SMALL PARTS: INFLATION NEEDLE AND
SMALL HARDWARE.
NOT FOR CHILDREN UNDER 3 YEARS.
KEEP BAGS AWAY FROM BABIES
AND CHILDREN. DO NOT USE IN CRIBS,
BEDS, CARRIAGES OR PLAYPENS.
THE THIN FILM MAY CLING TO NOSE
AND MOUTH AND PREVENT BREATHING.
BEFORE EACH USE, CAREFULLY
INSPECT ADAPTER, PLUG, AND WIRE
FOR SIGNS OF DAMAGE THAT COULD
RESULT IN THE RISK OF FIRE, ELECTRIC
SHOCK OR PERSONAL INJURY. DO NOT
USE SHOULD DAMAGE OCCUR.
CONTACT HUFFY SPORTS COMPANY
FOR IMMEDIATE REPLACEMENT.
1
10/04
P/N 211012
