Chapter 6 LCI Bus Ethernet Interface
6.1 Introduction
The SOM-4486 is equipped with a high-performance 32-bit Ethernet
chipset which is fully compliant with IEEE 802.3 100 Mbps CSMA/CD
standards. It is supported by major network operating systems. It is also
both 100Base-T and 10Base-T compatible.
6.2 Features
• Intel 82562EZ 10/100Base-T Ethernet LAN controller
• Optional Intel 82540 10/100/1000 Base-T Ethernet LAN controller
• Supports Wake-on-LAN remote control function.
• PCI Bus Master complies with PCI Rev. 2.2
• Complies with 100Base-TX, and 10Base-T applications.
• Single RJ-45 connector gives auto-detection of 10 Mbps or 100 Mbps
network data transfer rates and connected cable types.
• Enhancements on ACPI & APM.
• Complies with PCI Bus Power Management Interface Rev. 1.1,
• ACPI Rev. 2.0, and Device Class Power Management Rev. 1.0.
6.3 Installation of Ethernet Driver
Before installing the Ethernet driver, note the procedures below. You
must know which operating system you are using in your SOM-4486, and
then refer to the corresponding installation procedure. Then just follow
the steps described. You will quickly and successfully complete the
installation, even if you are not familiar with instructions for Windows.
.
Note:
SOM-4486 User's Manual
The windows illustrations in this chapter are
examples only. You must follow the flow chart
instructions and pay attention to the instructions
which then appear on your screen.
30
