When the self-clean
cycle ends:
"CIn complete" will scroll in the selected oven text area. After
5 seconds, "Oven cooling" will scroll in the display until the oven
temperature falls below 500°F (260°C).
"Unlocking"
will be displayed until the oven door unlocks and the
lock icon turns off.
To Delay Start Self-Clean:
Before delay starting Self-Clean, make sure the oven door is
completely
closed or it will not lock and the cycle will not begin.
1. Press START TIME.
"Press 1 for Upper Oven" will scroll in the upper text area,
and "Press 2 for Lower Oven" will scroll in the lower text area.
2. Press the "1" or "2" number keypad to select the desired
oven.
"--'--" will be displayed, and "Set starting time. Push START"
will scroll from right to left in the selected oven text area for
2 minutes or until the number keypad is pressed.
3. Use the number keypad to enter the delay start time. The
delay start time is the amount of time by which you want to
delay the start. Press START for the desired oven.
"Select cooking/cleaning
mode" will scroll in the selected
oven text area for 2 minutes or until a cooking cycle is
selected.
4=
Press PRECISE CLEAN.
"Press 1 for Upper Oven" will scroll in the upper oven text
area and "Press 2 for Lower Oven" will scroll in the lower
oven text area.
5. Use the number keypad to select the desired oven.
"Remove Racks" will scroll in the upper oven text area for
5 seconds, followed by "Select option." In the lower oven text
area, "Press 1 .Standard CLN" will scroll from right to left.
6. Press the "1" number keypad.
7. Press START for the desired oven.
"Select level" appears in the upper text display area. Use the
number keypad to select desired cleaning time; see the
following chart.
Number Key
Level
Duration
1
Level 1 (Quick)
2Hr
2
Level 2
2Hr 30 m
3
Level 3
3Hr
4
Level 4 (Reg)
3Hr 30 m
5
Level 5
4Hr
6
Level 6 (Maxi)
4Hr 30 m
8. Press START for the desired oven.
9. "Locking"
will display until the door is locked.
After the door is locked, "CLEAN-UPPER"
or "CLEAN-
LOWER" will scroll in the selected oven text area until the
clean cycle is finished.
When the self-clean cycle ends:
"CIn complete" will scroll in the selected oven text area. After
5 seconds, "Oven cooling" will scroll in the display until the oven
temperature falls below 500°F (260°C).
"Unlocking"
will be displayed until the oven door unlocks and the
lock icon turns off.
Genera
C eanin
9
IMPORTANT:
Before cleaning, make sure all controls are off and
the oven and cooktop are cool. Always follow label instructions
on cleaning products.
Soap, water and a soft cloth or sponge are suggested first unless
otherwise noted.
EXTERIOR PORCELAIN ENAMEL SURFACES
Food spills containing acids, such as vinegar and tomato, should
be cleaned as soon as the entire range is cool. These spills may
affect the finish.
Cleaning
Method:
Glass cleaner, mild liquid cleaner or nonabrasive scrubbing
pad: Gently clean around the model and serial number plate
because scrubbing may remove numbers.
affresh ® Kitchen and Appliance Cleaner Part Number
W10355010 (not included):
See "Assistance
or Service" section to order.
STAINLESS STEEL (on some models)
To avoid damage to stainless steel surfaces, do not use soap-
filled scouring pads, abrasive cleaners, Cooktop Cleaner, steel-
wool pads, gritty washcloths
or abrasive paper towels.
Cleaning
Method:
Rub in direction of grain to avoid damaging.
affresh ®Stainless Steel Cleaner Part Number W10355016
(not included): See "Assistance or Service" section to order.
Liquid detergent or all-purpose cleaner: Rinse with clean
water and dry with soft, lint-free cloth.
PORCELAIN-COATED
GRATES AND CAPS
Food spills containing acids, such as vinegar and tomato, should
be cleaned as soon as the cooktop, grates and caps are cool.
These spills may affect the finish.
To avoid chipping, do not bang grates and caps against each
other or hard surfaces such as cast iron cookware.
Do not reassemble caps on burners while they are wet.
Cleaning
Method:
Nonabrasive plastic scrubbing pad and mildly abrasive
cleanser:
Clean as soon as cooktop, grates and caps are cool.
Dishwasher (grates only, not caps):
Use the most aggressive cycle. Cooked-on soils should be
soaked or scrubbed
before going into a dishwasher.
Gas Grate and Drip Pan Cleaner Part Number 31617A:
See "Assistance
or Service" section to order.
COOKTOP CONTROLS
To avoid damage to the cooktop controls, do not use steel wool,
abrasive cleansers or oven cleaner.
To avoid damage, do not soak knobs.
When removing or replacing knobs, make sure knobs are in the
Off position.
Do not remove seals under knobs, if present.
Cleaning
Method:
Warm, soapy water:
Pull knobs straight away from control panel to remove.
17
