_ZHHJ_._,_E_.,,_,_
The water filter display will help you know when it is time to
Style 2: Digital Controls (on some models)
change your filter. To change the filter, see the "Base Grille Water
Filtration and Monitoring
System" section.
For your convenience,
your controls are preset at the factory.
When installing your refrigerator, make sure that the controls are
still preset to the "mid-settings"
as shown. The digital control
panel is located at the top of the refrigerator compartment
and
enables you to view the temperature
control set points.
NOTE: The factory recommended
set points are 0°F (-18°C) for
the freezer and 37°F (3°C) for the refrigerator.
To turn refrigerator
on and view set points:
Press and hold ON/OFF for 2 seconds.
Cow
FREEZER
REFRI6ERATOR COLD
COLDER
COLDER
INDICATOR:
STATUS:
99 percent
New filter installed
10 percent
Order replacement filter
0 percent OR flow decreases
Replace filter
After replacing the water filter, press RESET and hold for 2
seconds to change the the water filter display to 99 percent.
WATERFILTER
To view the Celsius temperatures:
Press the °C SELECT touch pad. The indicator will light up.
=C
SELECT
NOTE: If the freezer temperature is below zero, the indicator light
next to the freezer display will light up.
Adjusting Digital Controls
(on some models)
To adjust set point temperatures:
Press the refrigerator or freezer up or down arrow until the
desired temperature
is reached.
PERCENT REMAINING
GrecerySavor
TM
The GrocerySavor r_ feature assists with periods of high
refrigerator use, full grocery loads, or temporarily
warm room
temperatures.
Press GrocerySavo¢ Mto set the temperatures
to
-10°F (-23°C) for the freezer and 34°F (1°C) for the
refrigerator. The GrocerySavor r_ indicator light will remain on
for 24 hours unless manually turned off.
REFRIGERATOR COL#
COLDER
NOTE: Wait at least 24 hours between adjustments
and then
re-check the temperatures
before other adjustments
are
made.
The set point range for the freezer is -5°F to 5°F (-21°C to
-15°C) and 33°F to 41°F (1 °C to 5°C) for the refrigerator.
CONDITION/REASON:
TEMPERATURE
ADJUSTMENT:
REFRIGERATOR too cold
REFRIGERATOR
Control 1° higher
REFRIGERATOR too warm
REFRIGERATOR
- High use or room very warm
Control 1° lower
FREEZER too cold
FREEZER Control 1°
higher
FREEZER too warm/too little ice -
FREEZER Control 1°
High use or heavy ice use
lower
NOTE: The temperature display will not change. After 24
hours, the refrigerator returns to the previous temperature set
points.
Accelerated
Ice Production
This feature assists with temporary periods of heavy ice use by
increasing ice production
over a 24-hour period.
Press the accelerated
ice production
touch pad to set the
freezer temperature to -10°F (-23°C). The refrigerator
temperature
will not change. The accelerated
ice setting will
remain on for 24 hours unless manually turned off.
NOTES:
The temperature display will not change. After 24 hours, the
refrigerator returns to the previous temperature set points.
If increased ice production
is desired at all times, set the
Freezer Control to a colder number. Setting the freezer to a
colder temperature
may make some foods, such as ice
cream, harder.
Additional
Digital Control
Panel Features
Additional features are located on the control panel at the top of
the refrigerator compartment.
WATER FILTER Status
& Reset
NOTE: Do not use with water that is microbiologically
unsafe
or of unknown quality without adequate
disinfection before
or after the system.
11
