Figure 2-1 Unpack The Package - Advantech TPC-1260 User Manual

Step 1:
list at the beginning of this manual.
Cushion
(P/N: 2130201590)
Step 2a:
even application programs) on the TPC-1260. Please refer to section
1.2.3 for the boot-up sequence.
As shown in the Figure 2-2, align the 2.5" HDD so that its four screw
holes are upward. Usually this would make the HDD PCBA side
upward too. Put the insulating sheet on the HDD. Carefully install the
four vibration-absorbing cushions on the HDD cover. Fasten these
parts together.
Now the HDD subassembly is done. It is self-aligned that the internal
IDE cable can only be connected in correct direction. Connect the IDE
cable to this subassembly and fasten the subassembly to the rear case
of the system.
1 2 TPC-1260 User's Manual
Unpack the TPC-1260 package. Please check the packing

Figure 2-1 Unpack the package

Install a 2.5" HDD containing certain operating system (and
Accesory Box
(P/N: 2110002150)
Gift Box
(P/N: 2110002430)
