System Upgrades - Compaq AlphaServer GS140 Quick Specification

Q S
UICK
Upgrades
. .
. .
In-Cabinet Upgrades (continued)
. .
. .
In-cabinet CD-ROM
. .
. .
• VAX 7000 requires RRDCD-CA option; CD-ROM requires single-ended SCSI-2 connection from KZMSA-AB in
. .
. .
XMI plug-in unit or KZPBA-CA in
. .
. .
PCI plug-in unit.
. .
. .
• If EISA device support or the RAID Configuration Utility is required, select RRDCD-CA for space to mount
. .
floppy disk drive; floppy drive included with KFE70 or KFE72 option.
. .
. .
• CD-ROM device in StorageWorks shelf operates from PCI SCSI controller; DWZZA-VA is not supported.
. .
. .
• All connections to CD-ROM device will stop at device; additional devices are not supported.
. .
. .
In-cabinet CD-ROM assembly, maximum of one per system; required if no CD-ROM device exists
. .
. .
in system being upgraded; includes CD-ROM device, mounting hardware, BN21H-0H cable
. .
. .
(0.75 m); order longer cable to reach XMI plug-in unit or PCI plug-in unit
. .
. .
. .
. .
In-Cabinet 3-phase Power Expansion
. .
. .
• If VAX/DEC 7000 being upgraded includes one H7263 power regulator, check equivalent power units to
. .
. . determine if second power regulator is required; see Power Configuration Table.
. .
. . 3-phase 48 VDC power regulator with BBU capability; maximum of three per cabinet; second
. .
regulator may be required to supply adequate power depending on configuration; third regulator
. .
. .
assures N+1 power redundancy and higher availability in the event of power regulator failure.
. .
. .
Same as H7263-AA/AB except no built-in battery backup (BBU) capability
. .
. .
. .
. .
VAX/DEC 7000 to AlphaServer GS140 In-Cabinet SMP Upgrades
. .
. .
• Maximum of seven SMP modules (14 CPUs); if more than three modules are in system, a minimum of two
. .
. .
separate memory module should be ordered for optimal system performance
. .
. .
One VAX/DEC 7000 CPU module to GS140 6/525 dual-CPU module with OpenVMS SMP
. .
. . extension license
. .
. . One VAX/DEC 7000 CPU module to GS140 6/525 dual-CPU module with Tru64 UNIX SMP
. .
extension license
. .
. .
Two VAX/DEC 7000 CPU modules to GS140 6/525 dual-CPU module with OpenVMS SMP
. .
. .
extension license
. .
. .
Two VAX/DEC 7000 CPU modules to GS140 6/525 dual-CPU module with Tru64 UNIX SMP
. .
. . extension license
. .
. .
. .
. .
AlphaServer GS140 SMP Expansion Options
. .
. .
• To add additional GS140 CPUs to upgraded system, order the following:
. .
. .
OpenVMS SMP expansion option; GS140 6/525 dual-CPU module, OpenVMS SMP extension
. .
license
. .
. .
Tru64 UNIX SMP expansion option; GS140 6/525 dual-CPU module, Tru64 UNIX SMP extension
. .
. .
license
. .
. .
OpenVMS SMP expansion option; GS140 6/700 dual-CPU module, OpenVMS SMP extension
. .
. .
license
. .
. .
Tru64 UNIX SMP expansion option; GS140 6/700 dual-CPU module, Tru64 UNIX SMP extension
. .
license
. .
. .
. .
. .
. .

System Upgrades

. .
. .
. .
AlphaServer 8200/GS60/GS60E to AlphaServer GS140 Upgrades
. .
. .
• Complete box-swap system upgrades follow; system cabinet is replaced; however, existing 8200/GS60/GS60E
. .
. . CPU, CPU clock module, memory, and I/O modules are transferable see supported options listed in this
. .
QuickSpec
. .
. .
• Upgrades include GS140 system cabinet with 9-slot system bus, 3-phase power subsystem, PCI Plug-in-Unit
. .
. .
with 12-slot PCI shelf, StorageWorks Wide SCSI shelf for inclusion in PCI Plug-in-Unit, and upgrade
. .
. . documentation
. .
. . Dual 8200/GS60/GS60E to GS140 upgrade, Tru64 UNIX
. .
. .
Dual 8200/GS60/GS60E to GS140 upgrade, OpenVMS
. .
. .
Note: AC = 60 Hz, 208V, AD = 50 Hz, 380-416V, AE = 50/60 Hz, 202V (Japan)
. .
. .
. .
. .
. .
. .
. .
. .
.
23 DA-10051-00A-008 — 02.28.2000
PECS
Compaq AlphaServer GS140
DA-75U9A-AC/AD/AE
DY-75U9A-AC/AD/AE
RRDCD-CA
H7263-AA/AB
H7263-AC/AD
3X-76UAA-AX
3X-76UAB-AX
3X-76UBA-AX
3X-76UBB-AX
762P1-AX
762P2-AX
3X-764P1-AX
3X-764P2-AX
