Compaq AlphaServer GS140 Quick Specification page 19

Q S
UICK
Options
. .
. .
Step 20 Recommended Online Power Protection/UPS Solutions for GS140
. .
. .
• For complete protection, UPS products should be used with data line surge protectors
. .
. .
4-wire RJ45 10BaseT, wall plug-in module, add up to four modules per plug in connection
. .
. .
. . 17" din rail with 19" rackmount provisions for mounting up to 32 ports, rack or wall mount
. .
. .
Din rail mount surge protection module, 8-wire RJ45, 10/100BaseT twisted pair UL category 5
. .
. .
. .
. .
Powerware Plus 3-Phase UPS Models
. .
. .
• All models are hardwired on input and rated 50/60 Hz; North American models are rated 176V-256V in,
. .
. .
100/200V, 120/208V, 127/220V out; international models are rated 380-415V in, 380/220V, 400/230V
. .
415/240V out
. .
. .
. .
. .
UPS Models 15 and 18 kVA
. .
. .
• North America 15 and 18kVA models are hardwired on output with optional plug-in receptacle panel
. .
. .
15kVA/10kW, 10 minutes battery time at full load, two batteries, North America or other 60-Hz
. .
. .
applications
. .
. .
18kVA/12kW, seven minutes battery time at full load, two batteries, North America or other 60-
. .
. .
Hz applications
. .
. .
15kVA/10kW, 16 minutes battery time at full load, two batteries, North America or other 60-Hz
. .
applications
. .
. .
18kVA/12kW, 12 minutes battery time at full load, two batteries, North America or other 60-Hz
. .
. .
applications
. .
. .
15 kVA/10kW, 29 minutes of battery time at full load, three batteries, North America or other 60-
. .
. .
Hz applications
. .
. .
18kVA/12kW, 22 minutes of battery time at full load, three batteries, North America or other 60-
. .
Hz applications
. .
. .
15 kVA/10kW, 10 minutes of battery time at full load, two batteries, international or other 50-Hz
. .
. .
applications, hardwired only
. .
. .
18kVA/12kW, seven minutes of battery time at full load, two batteries, international or other 50-
. .
. .
Hz applications, hardwired only
. .
. .
. .
. .
UPS Models 24 and 36kVA
. .
. .
• Models are hardwired on output with optional 30 pole distribution cabinet, wraparound maintenance by-pass
. .
. . and input filter; distribution cabinet accepts Square D circuit breakers
. .
. . 36kVA/24kW, five minutes of battery time at full load, one battery, North America or other 60-Hz
. .
applications
. .
. .
24kVA/16kW, 30 minutes of battery time at full load, two batteries, North America or other 60-Hz
. .
. .
applications
. .
. .
36kVA/24kW, 15 minutes of battery time at full load, two batteries, North America or other 60-Hz
. .
. . applications
. .
. . 24kVA/16kW, 50 minutes of battery time at full load, three batteries, North America or other 60-
. .
Hz applications
. .
. .
36kVA/24kW, 30 minutes of battery time at full load, three batteries, North America or other 60-
. .
. .
Hz applications
. .
. .
. .
. .
15 and 18kVA UPS Receptacle Options, Extended Battery Options (Common configurations shown; other
. .
. .
receptacle options available)
. .
. .
• Choose UPS receptacle option depending on input plug configuration of external storage cabinet used; ESA
. .
10000 requires two L6-30R, SW800 requires two L21-30R, and GS140 Expansion Cabinet requires one L21-
. .
. .
30R
. .
. .
15/18kVA model output receptacle module, two L21-30R, three 5-20R2
. .
. .
15/18kVA model output receptacle module, two L6-30R, two L21-30R, one 5-20R2
. .
. .
15/18kVA model output receptacle module; Module 1 two L21-30R and conduit kit for
. .
. .
connecting Module 1 to Module 2; Module 2 two L21-30R, three 5-20R2
. .
. .
Add-on battery cabinet for 15 and 18kVA models; can be added to Model 4N-AEAAN/P-BD
. .
. .
approximately 12 minutes per cabinet
. .
. .
. .
. .
. .
. .
. .
. .
. .
.
19 DA-10051-00A-008 — 02.28.2000
PECS
Compaq AlphaServer GS140
4N-GA249-CA
4N-GA245-AA
4N-GA245-EA
4N-AEAAN-BA
4N-AEAAP-BA
4N-AEAAN-BC
4N-AEAAP-BC
4N-AEAAN-BD
4N-AEAAP-BD
4N-AEAAN-BE
4N-AEAAP-BE
4N-AEAAS-AA
4N-AEAAR-AB
4N-AEAAS-AB
4N-AEAAR-AC
4N-AEAAS-AC
4N-AEACM-BK
4N-AEACM-BN
4N-AEACM-PA
4N-AEACH-BB
