Compaq AlphaServer GS140 Quick Specification page 6

Q S
UICK PECS
Options
. .
. .
Step 6 Storage Adapters/Controllers
. .
. .
Note: For installed systems that include KFTIA I/O modules, the KFTIA includes one single-ended port and three
. .
. .
fast wide differential ports for a total of four SCSI buses per module.
. .
. .
. .
. .
. .
. .
. .
. .
. .
PCI Fibre Channel adapter (KGPSA-BC) (uses one PCI slot); Tru64
. .
V4.0F and OpenVMS V7.2-1 support eight per system; requires Fibre
. .
. .
Channel cable; (SN-PBXNP-AC not currently supported in same
. .
. .
system under OpenVMS)
. .
. .
Fibre Channel cable (BNGBX-xx) xx=02, 05, 15, 30, 50 meters
. .
. . x=1, 2, 3, 4, 5
. .
. .
. .
. .
PCI 1-port UltraSCSI single-ended adapter (uses one PCI slot)
. .
. .
PCI 1-port UltraSCSI differential host adapter (uses one PCI slot)
. .
. .
1-m VHDCI male-to-68 pin HD male UltraSCSI cable, connects KZPBA-
. .
. .
Cx to BA670 in system cabinet (rear)
. .
. .
2-m VHDCI male-to-68 pin HD male UltraSCSI cable, connects KZPBA-
. .
. .
Cx to BA670 in system cabinet (front)
. .
. .
3-m VHDCI male-to-68 pin HD male UltraSCSI cable, connects KZPBA to
. .
. . I/O expansion cabinet
. .
. .
5-m VHDCI male-to-68 pin HD male UltraSCSI cable, connects KZPBA to
. .
I/O expansion cabinet
. .
. .
. .
. .
. .
PCI 1-port RAID (FWSE) controller (UltraSCSI-ready) with 4-MB cache
. .
memory (uses one PCI slot); allows RAID levels 0, 0+1, 1, 5; includes
. .
. .
RAID Array 230/plus subsystem software and documentation kit; EISA
. .
. .
bridge option with floppy diskette drive required to run RCU; tape and
. .
optical drives not supported; four per PCI, maximum of four per system
. .
. .
PCI 3-port RAID (FWSE) controller (UltraSCSI-ready) with 4-MB cache
. .
. .
memory (uses two PCI slots); allows RAID levels 0, 0+1, 1, 5; includes
. .
. .
RAID/Array 230/plus subsystem software and documentation kit; EISA
. .
bridge option with floppy diskette drive required to run RCU; tape and
. .
. .
optical drives not supported; four per PCI, maximum of four per
. .
. .
system, requires BN31K-0E or KZPAC-SB for third-port connection
. .
. .
PCI 3-port RAID (FWSE) controller (UltraSCSI-ready) with 8-MB cache
. .
memory (uses two PCI slots); allows RAID levels 0, 0+1, 1, 5; includes
. .
. .
RAID/Array 230/plus subsystem software and documentation kit; EISA
. .
. .
bridge option with floppy diskette drive required to run RCU; tape and
. .
optical drives not supported; four per PCI, maximum four per system,
. .
. .
requires BN31K-0E or KZPAC-SB for third-port connection
. .
. .
SCSI cable/bulkhead assembly kit with two ports for KZPAC-CA/CB,
. .
. .
allows connection of two third port outputs using one PCI bulkhead
. .
. . slot.
. .
. .
SCSI cable/bulkhead assembly kit with one port for KZPAC-CA/CB,
. .
allows connection of one third port output using one PCI bulkhead slot
. .
. .
1-m VHDCI male-to-VHDCI male UltraSCSI cable, connects KZPAC to
. .
. .
front-mounted StorageWorks shelf.
. .
. .
2-m VHDCI male-to-VHDCI male UltraSCSI cable, connects KZPAC to
. .
. .
rear-mounted StorageWorks shelf.
. .
. .
Battery backup for cache memory option for KZPAC controller,
. .
. . recommended for all KZPAC controllers
. .
. .
8-MB cache memory option; upgrades KZPAC-CA to KZPAC-CB, field
. .
installable only
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
.
6 DA-10051-00A-008 — 02.28.2000
Compaq AlphaServer GS140
Optional (continued)
Maximum # Supported
Tru64 UNIX
PCI/System
8/8
8/64
8/64
4/4
4/4
4/4
OpenVMS
PCI/System
8/8
380574-001
234457-B2x
8/26
KZPBA-CA
8/26
KZPBA-CB
BN38C-01
BN38C-02
BN38C-03
BN38C-05
4/4
KZPAC-AA
4/4
KZPAC-CA
4/4
KZPAC-CB
KZPAC-SB
BN31K-0E
BN37A-01
BN37A-02
KZPSC-UB
MS100-BB
