Systems/Options
. .
. .
Step 1 Select system
. .
. .
GS140 systems require the mandatory selection of the following items:
. .
. .
• Software media and documentation for first system on-site
. .
. .
• Console terminal (unless available on site)
. .
. .
• Installation or Installation and Startup Services
. .
. .
Notes: Minimum OS support: Tru64 UNIX V4.0E or later or OpenVMS V7.1-2 or V7.2-1 or later
. .
. .
For system integration of any options with 6-3 part numbers, contact CustomSystems
. .
. .
. .
. .
OS CPUs
. .
. .
. .
Tru64 UNIX Two 6/525 MHz
. .
. .
. .
. .
Tru64 UNIX Two 6/700 MHz
. .
. .
. .
. .
OpenVMS Two 6/525 MHz
. .
. .
. .
. .
OpenVMS Two 6/700 MHz
. .
. .
. .
. .
. .
Note: AA=60 Hz, 208V; AB=50 Hz, 416V; AC=50/60 Hz, 202V (Japan)
. .
. .
. .
. .
. .
Step 2 Additional CPU Modules (SMP Expansion)
. .
. .
. .
• Maximum of seven processor modules (14 CPUs)
. .
. .
• All CPU modules must be at same speed on same bus.
. .
. .
• For systems with more than three processor modules, a minimum of two memory modules is recommended for
. .
optimal system performance
. .
. .
• SMP license and end-user product warranty included
. .
. .
GS140 6/700 Tru64 UNIX SMP upgrade
. .
. .
. . GS140 6/700 OpenVMS SMP upgrade
. .
. .
GS140 6/525 Tru64 UNIX SMP upgrade
. .
. .
GS140 6/525 OpenVMS SMP upgrade
. .
. .
. .
. .
. .
Step 3 Memory Optional
. .
. .
. . • Maximum 28-GB memory, maximum of seven memory modules (maximum of seven memory modules is
. .
reduced by one for each additional CPU module and System I/O module added).
. .
. .
• Both 1-GB and 2-GB memory modules have built-in, 2-way interleaving; additional interleaving is
. .
. .
accomplished by adding more memory modules.
. .
. .
• 4-GB memory modules have built-in, 4-way interleaving; optimum performance is achieved when 2-GB
. .
. .
memory modules are paired with one 4-GB module or when one 4-GB memory module is paired with
. .
another 4-GB module. Memory module sets (2 GB x 2 GB and 1 GB x 4 GB) or (2 GB x 4 GB) can be paired
. .
. .
with another 8-GB memory set for a maximum of 16-way memory interleaving.
. .
. .
4-GB memory module
. .
. .
2-GB memory module
. .
. .
1-GB memory module
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
.
4 DA-10051-00A-008 — 02.28.2000
Memory UltraSCSI Disk UltraSCSI Adapter Ethernet Adapter
4 GB 9.1 GB
4 GB 9.1 GB
4 GB 9.1 GB KZPBA-CA
4 GB 9.1 GB KZPBA-CA
Compaq AlphaServer GS140
KZPBA-CA DE500-BA or
3X-DE600-AA
KZPBA-CA DE500-BA or
3X-DE600-AA
DE500-BA or
3X-DE600-AA
DE500-BA or
3X-DE600-AA
Optional
Order No.
DA-393GG-
AA/AB/AC
DA-394GG-
AA/AB/AC
DY-393GG-
AA/AB/AC
DY-394GG-
AA/AB/AC
3X-764P2-AX
3X-764P1-AX
762P2-AX
762P1-AX
MS7CC-GA
MS7CC-FA
MS7CC-EA
