1.4

Jumpers and Connectors

1.4.1

Jumper and Connector Locations

Figure 1-2 shows the jumper and connector locations on the system
board.
Figure 1-2

System Board Jumper and Connector Locations

Jumpers are prefixed "JP". Connectors are
prefixed "CN". The blackened pin of a
jumper represents pin 1.
1-4
User's Guide
