EZ Mode
By default, the EZ Mode screen appears when you enter the BIOS setup program. The EZ
Mode provides you an overview of the basic system information, and allows you to select
the display language, system performance mode and boot device priority. To access the
Advanced Mode, click Exit/Advanced Mode, then select Advanced Mode or press F7 for the
advanced BIOS settings.
The default screen for entering the BIOS setup program can be changed. Refer to the
Setup Mode item in section 2.8 Boot menu for details.
Displays the CPU temperature,
CPU voltage output, DRAM
information and CPU/chassis fan
speed
Selects the
Advanced
mode functions
Selects the boot
device priority
Power saving
mode
The boot device options vary depending on the devices you installed to the system.
The Boot Menu(F8) button is available only when the boot device is installed to the
system.

Advanced Mode

The Advanced Mode provides advanced options for experienced end-users to configure the
BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the
following sections for the detailed configurations.
To access the EZ Mode, click Exit, then select ASUS EZ Mode or press F7.
ASUS H81M-PLUS
Selects the display language
of the BIOS setup program
Normal mode
ASUS Optimal
mode
Displays the
Advanced mode
menus
Exits the BIOS setup program without
saving the changes, saves the changes
and resets the system, or enters the
Advanced Mode
Loads
optimized
default
Displays the system
Selects the boot
properties of the
device priority
selected mode on the
right hand side
2-7
