2.5.25

DRAM DATA REF Voltage on CHA [Auto]

Allows you to set the DRAM DATA REF Voltage on CHA. The values range from 0.3950x to

0.6300x with a 0.0050x interval

2.5.26

DRAM DATA REF Voltage on CHB [Auto]

Allows you to set the DRAM DATA REF Voltage on CHB. The values range from 0.3950x to

0.6300x with a 0.0050x interval

2.6

Advanced menu

The Advanced menu items allow you to change the settings for the CPU and other system

devices.

Be cautious when changing the settings of the Advanced menu items. Incorrect field values

can cause the system to malfunction.

2.6.1

CPU Configuration

The items in this menu show the CPU-related information that the BIOS automatically

detects.

The items shown in submenu may be different due to the CPU you installed.

Intel

Adaptive Thermal Monitor [Enabled]

[Enabled]

[Disabled]

2-24

Enables the overheated CPU to throttle its clock speed to cool down.

Disables the CPU thermal monitor function.

Chapter 2: Getting started
