CPU System Agent Voltage Offset [Auto]
This item allows you to set the CPU system agent voltage offset. Increase the value when
increasing DRAM frequency. The values range from 0.001V to 0.999V with a 0.001V interval.
2.5.19
CPU Analog I/O Voltage Offset Mode Sign [+]
This item allows you to set the CPU analog I/O voltage offset mode sign. Configuration
options: [+] [-].
CPU Analog I/O Voltage Offset [Auto]
This item allows you to set the CPU analog I/O voltage offset. Increase the value when
increasing DRAM frequency. The values range from 0.001V to 0.999V with a 0.001V interval.
2.5.20
CPU Digital I/O Voltage Offset Mode Sign [+]
This item allows you to set the CPU digital I/O voltage offset mode sign. Configuration
options: [+] [-].
CPU Digital I/O Voltage Offset [Auto]
This item allows you to set the CPU digital I/O voltage offset. Increase the value when
increasing DRAM frequency. The values range from 0.001V to 0.999V with a 0.001V interval.
2.5.21
SVID Support [Auto]
Disabling SVID Support stops the processor from commmunicating with the external voltage
regulator. Configuration options: [Auto] [Disabled] [Enabled].
We recommend that you disable this function when overclocking.
The following item appears only when you set SVID Support to [Enabled].
2.5.22
CPU Input Voltage (VCCIN) [Auto]
This item allows you to set the CPU input voltage. The values range from 0.800V to 2.700V
with a 0.010V interval.
2.5.23
DRAM Voltage [Auto]
Allows you to set the DRAM Voltage. The values range from 1.350V to 1.650V with a 0.005V
interval.
According to Intel CPU specifications, DIMMs with voltage requirement over 1.65V may
damage the CPU permanently. We recommend that you install the DIMMs with the voltage
requirement below 1.65V.
2.5.24
DRAM CTRL REF Voltage [Auto]
Allows you to set the DRAM CTRL REF Voltage. The values range from 0.3950x to 0.6300x
with a 0.0050x interval.
ASUS H81M-PLUS
2-23
