H81M-PLUS specifications summary
Rear panel I/O
ports
Internal
connectors/
switches/
buttons
BIOS features
Manageability
Support DVD
Operating
System
Support
Form factor
Specifications are subject to change without notice.
viii
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x DVI port
1 x RGB port
1 x HDMI port
1 x LAN (RJ-45) port
2 x USB 3.0/2.0 ports
4 x USB 2.0/1.1 ports
3 x Audio jacks support 8-channel audio output
1 x USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 ports (19-pin)
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
2 x SATA 6.0 Gb/s connectors
2 x SATA 3.0 Gb/s connectors
1 x CLRTC jumper
1 x 4-pin CPU fan connector
1 x 4-pin Chassis fan connectors
1 x Front panel audio connector (AAFP)
1 x System panel connector
1 x Speaker connector
1 x S/PDIF Header
1 x 24-pin EATX power connector
1 x 4-pin EATX 12V power connector
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI v2.0, WfM2.0, SM BIOS v2.7, ACPI
v2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My
Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions
and ASUS DRAM SPD (Serial Presence Detect) memory information
WfM 2.0, DMI 2.0, WOL by PME, PXE
Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Windows
8 / Windows
®
®
uATX form factor: 9.6"x 7.2" (24.4cm x 18.3cm)
7
