The following two items appear only when you set the CPU Core Ratio to [Sync All
Cores] or [Per Core].
1-Core Ratio Limit [Auto]
Allows you to set the 1-Core Ratio Limit. Select [Auto] to apply the CPU default Turbo
Ratio setting or manually assign a 1-Core Ratio Limit value that is higher than or equal
to the 2-Core Ratio Limit.
2-Core Ratio Limit [Auto]
This item becomes configurable only when you set CPU Core Ratio to [Per Core] and
allows you to set the 2-Core Ratio Limit. Select [Auto] to apply the CPU default Turbo
Ratio setting or manually assign a 2-Core Ratio Limit value that is higher than or equal
to the 3-Core Ratio Limit. 1-Core Limit must not be set to [Auto].
3-Core Ratio Limit [Auto]
This item becomes configurable only when you set CPU Core Ratio to [Per Core] and
allows you to set the 3-Core Ratio Limit. Select [Auto] to apply the CPU default Turbo
Ratio setting or manually assign a 3-Core Ratio Limit value that is higher than or equal
to the 4-Core Ratio Limit. 1-Core/2-Core Ratio Limit must not be set to [Auto].
4-Core Ratio Limit [Auto]
This item becomes configurable only when you set CPU Core Ratio to [Per Core] and
allows you to set the 4 Core Ratio Limit. Select [Auto] to apply the CPU default Turbo
Ratio setting or manually assign a 4-Core Ratio Limit value that is higher than or equal
to the 3-Core Ratio Limit. 1-Core/2-Core/3-Core Limit must not be set to [Auto].
2.5.4
Min CPU Cache Ratio [Auto]
Allows you to set the uncore ratio of the processor to its possible minimum value.
Configuration options: [Auto] [1] ~ [30].
2.5.5
Max CPU Cache Ratio [Auto]
Allows you to set the uncore ratio of the processor to its possible maximum value.
Configuration options: [Auto] [1] ~ [30].
2.5.6
BCLK Frequency : DRAM Frequency Ratio [Auto]
Allows you to set the BCLK frequency to DRAM frequency ratio.
[Auto]
DRAM frequency is set to the optimized settings.
[100:133]
The BCLK frequency to DRAM frequency ratio is set to 100:133.
[100:100]
The BCLK frequency to DRAM frequency ratio is set to 100:100.
2.5.7
DRAM Frequency [Auto]
Allows you to set the memory operating frequency. The configuration options vary with the
BCLK Frequency : DRAM Frequency Ratio item settings.
Selecting a very high memory frequency may cause the system to become unstable! If this
happens, revert to the default setting.
ASUS H81M-PLUS
2-15
