DRAM READ to PRE Time [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
DRAM FOUR ACT WIN Time [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [255 DRAM Clock]
DRAM WRITE to READ Delay [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
DRAM CKE Minimum pulse width [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
DRAM CAS# Write Latency [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [31 DRAM Clock]
RTL IOL control
DRAM RTL initial Value [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [63 DRAM Clock]
DRAM RTL (CHA) [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [63 DRAM Clock]
DRAM RTL (CHB) [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [63 DRAM Clock]
DRAM I0-L (CHA) [Auto]
Configuration options: [Auto] [Delay 1 Clock] - [Delay 15 Clock]
DRAM IO-L (CHB) [Auto]
Configuration options: [Auto] [Delay 1 Clock] - [Delay 15 Clock]
Third Timings
tRDRD [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [7 DRAM Clock]
tRDRD_dr [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
tRDRD_dd [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
tWRRD [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [63 DRAM Clock]
tWRRD_dr [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
tWRRD_dd [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
tWRWR [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [7 DRAM Clock]
tWRWR_dr [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
tWRWR_dd [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock]
ASUS H81M-PLUS
2-17
