Power Current Offset [Auto]
Allows you to set the power current offset. Configuration options: [Auto] [100%] [87.5%]
[75%] [62.5%] [50%] [37.5%] [25%] [12.5%] [0%] [-12.5%] [-25%] [-37.5%] [-50.0%]
[-62.5%] [-75%] [-87.5%] [-100%]
Power Fast Ramp Response [Auto]
Allows you to increase to enhance the response of the voltage regulator during the
load transient. Configurations: [Auto] [0.00] - [1.50].
CPU Internal Power Saving Control
Power Saving Level 1 Threshhold [Auto]
Allows you to set the power saving level 1 threshhold.
Use the <+> and <-> keys to adjust the value.
Power Saving Level 2 Threshhold [Auto]
Allows you to set the power saving level 2 threshhold.
Use the <+> and <-> keys to adjust the value.
Power Saving Level 3 Threshhold [Auto]
Allows you to set the power saving level 3 threshhold.
Use the <+> and <-> keys to adjust the value.
2.5.14
Extreme Over - voltage [Disabled]
By default, this item is set to [Disabled] and helps provide over voltage protection for the
CPU. When you set this item to [Enabled], you can select voltage settings for overclocking,
but this will not guarantee the CPU's lifespan.
2.5.15
CPU Core Voltage [Auto]
Allows you to configure the amount of voltage fed to the cores of the processor. Increase the
amount of voltage when increasing core frequency. Configuration options: [Auto] [Manual
Mode] [Offset Mode]
CPU Core Voltage Override [Auto]
This item appears only when you set the CPU Core Voltage to [Manual Mode] and allows you
to set the CPU core voltage override. The values range from 0.001V to 1.920V with a 0.001V
interval.
Offset Mode Sign [+]
This item appears only when you set the CPU Core Voltage to [Offset Mode] and allows you
to set the offset mode sign. Configuration options: [+] [-]
CPU Core Voltage Offset [Auto]
This item appears only when you set the CPU Core Voltage to [Offset Mode] and
allows you to set the CPU core voltage offset. The values range from 0.001V to 0.999V
with a 0.001V interval.
2.5.16
CPU Cache Voltage [Auto]
This item allows you to set the CPU cache voltage. Increase the cache voltage when
increasing the ring frequency. Configuration options: [Auto] [Manual Mode] [Offset Mode].
ASUS H81M-PLUS
2-21
