Re series e4 electric fryers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Frymaster, a member of the Commercial Food Equipment Service Association, recommends using
CFESA Certified Technicians.
24-Hour Service Hotline 1-800-551-8633
MAY 2009
*8196150*
www.frymaster.com
E-mail:
service@frymaster.com

Advertisement

Table of Contents
loading

Related Manuals for Frymaster FOOTPRINT E4

Summary of Contents for Frymaster FOOTPRINT E4

  • Page 1 Frymaster, a member of the Commercial Food Equipment Service Association, recommends using CFESA Certified Technicians. 24-Hour Service Hotline 1-800-551-8633 MAY 2009 *8196150* www.frymaster.com E-mail: service@frymaster.com...

  • Page 2: Phase

    FROM FRYMASTER DEAN, OR ANY OF ITS AUTHORIZED SERVICE CENTERS, AND/OR THE PART BEING USED IS MODIFIED FROM ITS ORIGINAL CONFIGURATION, THIS WARRANTY WILL BE VOID. FURTHER, FRYMASTER DEAN AND ITS AFFILIATES WILL NOT BE LIABLE FOR ANY CLAIMS, DAMAGES OR EXPENSES INCURRED BY THE CUSTOMER WHICH ARISE DIRECTLY OR INDIRECTLY, IN WHOLE OR IN PART, DUE TO THE INSTALLATION OF ANY MODIFIED PART AND/OR PART RECEIVED FROM AN UNAUTHORIZED SERVICE CENTER.
  • Page 3 Frymaster Factory Authorized Service Center (FASC) for part number 826-0900. Prior to movement, testing, maintenance and any repair on your Frymaster fryer, disconnect all electrical power from the fryer. ELECTRICAL POWER SPECIFICATIONS...

  • Page 4: Table Of Contents

    1.13 Wiring Diagrams ... 1-17 1.13.1.1 Basket Lift Wiring 208-250V ... 1-17 1.13.1.2 Basket Lift Wiring 100-120V ... 1-18 1.13.2.1 Component Wiring Standard ... 1-19 1.13.2.2 Component Wiring Fryer and Half ... 1-20 1.13.3 Tilt Switch Wiring ... 1-21 1.13.4 Component Wiring –...
  • Page 5 RE SERIES E TABLE OF CONTENTS cont. 2.4.3 Drain Valves and Associated Parts (Units without Built-In Filtration) ... 2-15 Electronics and Electrical Components ... 2-16 2.5.1 Component Boxes ... 2-16 2.5.2 Contactor Boxes ... 2-18 2.5.3 Fuse Boxes ... 2-22 2.5.4 Terminal Blocks ...

  • Page 6: Chapter 1: Service Procedures

    CHAPTER 1: SERVICE PROCEDURES 1.1 General Before performing any maintenance on your Frymaster fryer, disconnect the fryer from the electrical power supply. When electrical wires are disconnected, it is recommended that they be marked in such a way as to facilitate re-assembly.
  • Page 7 NOTE: If more room to work is required, the control panel frame assembly may be removed by removing the hex head screws that secure it to the fryer cabinet (see illustration below). If this option is chosen, all control panel assemblies must be removed per steps 1 and 2 above. The cover plate on the lower front of the component box may also be removed if desired.

  • Page 8: Replacing A High-Limit Thermostat

    7. Insert the leads into the 12-pin connector C-6 (see illustration below). For full-vat units or the left half of a dual-vat unit (as viewed from the rear of the fryer) the leads go into positions 1 and 2 of the connector. For the right half of a dual-vat unit (as viewed from the rear of the fryer), the leads go into positions 7 and 8.
  • Page 9 9. Insert the temperature probe leads into the 12-pin connector C-6 (see illustration below). For full-vat units or the right half of a dual-vat unit (as viewed from the rear of the fryer) the red lead goes into position 3 and the white lead into position 4 of the connector. For the left half of a dual-vat unit (as viewed from the rear of the fryer), the red lead goes into position 9 and the white lead into position 10.

  • Page 10: Replacing A Heating Element

    12-pin connector C-6. 3. In the rear of the fryer directly behind the frypot disconnect the 6-pin connector for the left element (as viewed from the front of the fryer) or the 9-pin connector for the right element.

  • Page 11: Replacing Contactor Box Components

    4. For the left half of a dual-vat unit, the red lead goes into position 9 and the white into position 10. NOTE: Right and left refer to the fryer as viewed from the rear. 10. Reconnect the 12-pin connector C-6 of the wiring harness disconnected in Step 2.

  • Page 12: Replacing A Frypot

    3. Remove the two screws securing the cover of the contactor box. The contactor boxes above the filter pan are accessed by sliding under the fryer. They are located to the left and right above the guide rails (see photo below). The contactor boxes of non-filter units or frypots not over the filter pan are accessed by opening the fryer door directly under the affected frypot.
  • Page 13 5. Unplug the wiring harnesses and ground wires from the backs of the controllers. Remove the controllers by lifting them from the hinge slots in the control panel frame. 6. Remove the tilt housing and back panels from the fryer. The tilt housing must be removed first in order to remove the upper back panel.

  • Page 14: Built-In Filtration System Service Procedures

    28. Reinstall controllers in the control panel frame and reconnect the wiring harnesses and ground wires. 29. Reposition the fryer under the exhaust hood and reconnect it to the electrical power supply. 1.9 Built-in Filtration System Service Procedures 1.9.1 Filtration System Problem Resolution One of the most common causes of filtration problems is placing the filter paper on the bottom of the filter pan rather than over the filter screen.

  • Page 15: Replacing The Filter Motor, Filter Pump And Related Components

    If the pump starts after resetting the thermal overload switch, then something is causing the motor to overheat. A major cause of overheating is when several frypots are filtered sequentially, overheating the pump and motor. Allow the pump motor to cool at least 30 minutes before resuming operation. Pump overheating can be caused by: •...
  • Page 16 2. Disconnect the fryer from the electrical power supply and reposition it to gain access to both the front and rear. 3. Disconnect the two flexlines running to the oil-return manifold at the rear of the fryer as well as the pump suction flexline at the end of the filter pan connection (see photo below).

  • Page 17: Replacing The Filter Transformer Or Filter Relay

    11. When proper operation has been verified, reinstall the back panels and the filter pan and lid. 12. Reposition the fryer under the exhaust hood and reconnect it to the electrical power supply to return the fryer to service.
  • Page 18 Timing circuitry in the controller initiates and stops basket lift operation depending upon the variables programmed by the operator. When the product button is pressed, the timing circuitry activates a coil in the basket lift relay to supply power to the lower microswitch. The microswitches stop the motor at the lift’s upper and lower travel limits and reverse the direction of current flow thus reversing the motor direction.
  • Page 19 MOTOR AND GEAR PROBLEMS With the modular basket lift, the most likely problem to be encountered in this category is erratic motion of the lift due to a worn drive gear. Failure to keep the lift rod and bushings properly lubricated will cause unnecessary wear of the gear.

  • Page 20: Interface Board Diagnostic Chart

    1.11 Interface Board Diagnostic Chart The following diagram and charts provide ten quick system checks that can be performed using only a multimeter. PN 106-6664 NOTE – When testing the test points on J1 and J2 test use the illustration above dis- regarding any silk-screened numbers on the board depicting the location of Pin 1.

  • Page 21: Probe Resistance Chart

    1.12 Probe Resistance Chart Probe Resistance Chart For use with fryers manufactured with Minco Thermistor probes only. OHMS OHMS 1059 1204 1070 1216 1080 1226 1091 1237 1101 1247 1112 1258 1122 1268 1133 1278 1143 1289 1154 1299 1164 1309 1174 1320...

  • Page 22: Wiring Diagrams

    1.13 Wiring Diagrams 1.13.1.1 Modular Basket Lift Wiring Diagram 208-250V 1-17...
  • Page 23 1.13.1.2 Modular Basket Lift Wiring Diagram 100-120V 1-18...

  • Page 24: Component Wiring Standard

    1.13.2 Component Wiring 1.13.2.1 Standard Fryers 1-19...

  • Page 25: Component Wiring Fryer And Half

    1.13.2.2 Component Wiring- Fryer and Half 1-20...

  • Page 26: Tilt Switch Wiring

    1.13.3 Tilt Switch Wiring Standard Fryer and half 1-21...

  • Page 27: Component Wiring - Fast Ready

    1.13.4 Component Wiring - Fast Ready 1-22...

  • Page 28: Fast Ready Computer Wiring

    1.13.5 Fast Ready Computer Wiring 1-23...
  • Page 29 1.13.6 Computer Harness - Fast Ready 1-24...
  • Page 30 1.13.7 Control Wiring - Fast Ready 1-25...

  • Page 31: Contactor Box-Delta Configuration

    1.13.8 Contactor – DELTA Configuration 1-26...
  • Page 32 1.13.8 Contactor – DELTA Configuration cont. 1-27...

  • Page 33: Contactor Box-Wye Configuration

    1.13.9 Contactor Box - WYE Configuration Export 1-28...

  • Page 34: Terminal Block Wiring

    1.13.10 Terminal Block Wiring 1-29...

  • Page 35: Oil Disposal Wiring

    1.13.11 Oil Disposal Wiring 1-30...
  • Page 36 1.13.12 Simplified RE14/17/22 Series – Full Vat Wiring 1-31...
  • Page 37 1.13.13 Simplified RE14/17/22 Series – Dual Vat Wiring 1-32...
  • Page 38 1.13.14 Simplified RE14/17/22 Series – Full Vat Wiring (EXPORT) WYE 1-33...
  • Page 39 1.13.15 Simplified RE14/17/22 Series – Dual Vat Wiring (EXPORT) WYE 1-34...

  • Page 40: Simplified Re14/17/22 Full-Vat Epri Wiring

    1.13.16 Simplified RE14/17/22 Series – Full Vat Wiring EPRI 1-35...
  • Page 41 1.13.17 Simplified RE14/17/22 Series – Full Vat Wiring EPRI (EXPORT) WYE 1-36...

  • Page 42: Chapter 2: Parts List

    809-0921 Spacer, Basket Hanger 803-0197 Cleanout Rod, 27-inch 803-0209 Brush, Frypot 823-5772 Connecting Strip, Frypot (use 823-6000 for LH, use 823-5966 for RH Fryer ½) 823-5807 Connecting Strip, Frypot Deep Cabinet 806-3068 Cover, Full-Vat Frypot 806-3071 Cover, Dual-Vat Frypot 106-6349...

  • Page 43: Basket Lift Assembly And Associated Parts

    2.2 Basket Lift Assembly and Associated Parts...
  • Page 44 2.2 Basket Lift Assembly and Associated Parts cont. ITEM PART # 106-1805SP Basket Lift Assembly, 200-220VAC w/Relay 810-1012 Rod, Basket Lift 813-0035 Bushing, Bronze 807-2513 Capacitor, 12.5 μFarad 330VAC 901-8499 Chassis, Left Basket Lift 902-8499 Chassis, Right Basket Lift 807-0159 Connector, 12-Pin Female 900-5529 Gusset, Basket Lift Motor...

  • Page 45: Cabinetry

    2.3 Cabinetry 2.3.1 Back Panels, Control Panel Frames, Doors, Sides, Tilt Housings, and Top Caps...
  • Page 46 Top Cap (Top cap for five station fryer shown) 106-5195 Single Station (Also requires four 809-0079 1/4-20 Nutserts) 106-7060 Fryer ½ Station LH ½ fryer (use 106-6838 for RH ½ fryer) (Also requires four 809- 0079 1/4-20 Nutserts) 106-5196 Two Station (Also requires four 809-0079 1/4-20 Nutserts)
  • Page 47 PART # 106-4067 Pin Assembly, Door 810-0275 Spring, Door Pin 809-0970 Retaining Ring 823-5440 Cove, Element Tilt Housing (use 823-5726 for Fryer ½) 210-5046 Bezel, One-Controller (use 230-1953 for Fryer ½) 210-5623 Bezel, Blank 210-5819 Bezel, Two –Controller 210-6698 Bezel, Three-Controller * Not illustrated.

  • Page 48: Cabinet Bases, Braces And Associated Parts

    2.3.2 Cabinets, Bases, Braces, and Associated Parts See Page 2-34 for filter rails hardware. See Page 2-39 for rear bridge support/oil return manifold. associated The 5-Station cabinet illustrated is typical of most RE Series Electric cabinets. All components used in RE Series cabinets are identified, but not all components are used in every configuration.
  • Page 49 Channel, Base Side 823-5782 Channel, Base Side SCF Deep Cabinet 221-0621 Channel, Base Left Side Single-Station Fryer (use 222-0621 for RH side) 809-0131 Bolt, ¼-20 X ¾-inch Hex Head (also used w/Item 27 to mount filter rails) 810-2970 Caster with Brake...

  • Page 50: Drain System Components

    2.4 Drain System Components 2.4.1 Drain Tube Sections and Associated Parts See next section for Drain Valves...
  • Page 51 2.4.1 Euro-Look Drain Tube Sections and Associated Parts cont. ITEM PART# Drain Tube, Left/Right End Short 823-4625 Full-Vat 823-4624 Dual-Vat 823-5943 Fryer ½, RH ½ Fryer 823-6003 Fryer ½, LH ½ Fryer Drain Tube, Left/Right Open Short 823-4643 Full-Vat 823-4642 Dual-Vat Drain Tube, Right End Long...

  • Page 52: Drain Valves And Associated Parts (Units With Built-In Filtration)

    2.4.2 Drain Valves and Associated Parts (Units with Built-In Filtration) 2.4.2 Drain Valves and Associated Parts (Units with Built-in Filtration) cont. ITEM PART # 809-0540 Nut, ½-13 2-Way Hex Lock 900-2936 Retainer, Full-Vat Nut Drain Valve 824-1602 Handle, Full-Vat Drain Valve 816-0639 Cap, Red Handle 809-0237...
  • Page 53 809-0540 Nut, ½-13 2-Way Hex Lock 900-2936 Retainer, Full-Vat Drain Valve Nut 824-1602 Handle, Full-Vat Drain Valve 824-1740 Handle, Fryer ½ Half Vat 816-0639 Cap, Red Handle 809-0237 Nut, 4-40 Keps Hex 901-2348 Cover, Dual Vat Drain Safety Switch 807-2103...
  • Page 54 2.4.2 Drain Valves and Associated Parts (Units with Built-In Filtration) cont. 2-13...
  • Page 55 2.4.2 Drain Valves and Assoc. Parts (Units with Built-In Filtration) cont. ITEM PART # 816-0639 Cap, Drain Handle 809-0539 Nut, ⅜-16 2-Way Hex Lock 900-2934 Retainer, Dual-Vat Drain Valve Nut 824-1636 Handle, Dual-Vat Right Drain Valve 824-1637 Handle, Dual-Vat Left Drain Valve 809-0237 Nut, 4-40 Keps Hex 901-2348...

  • Page 56: Drain Valves And Associated Parts (Units Without Built-In Filtration)

    2.4.3 Drain Valves and Associated Parts (Units without Built-In Filtration) ITEM PART # 810-1569 Valve, 1.25-inch Non-Filter Full-Vat Drain 806-7915SP Valve, 1-inch Non-Filter Dual-Vat Left Drain 806-7916SP Valve, 1-inch Non-Filter Dual-Vat Right Drain 812-1226 Drain Extension, 1.25-inch 812-1227 Drain Extension, 1-inch COMPONENT 2-15...

  • Page 57: Component Boxes

    2.5 Electronics and Wiring Components 2.5.1 Component Boxes 2-16...
  • Page 58 2.5.1 Component Boxes cont. ITEM PART # 106-5592 Box Assembly, Component Standard 106-6747 Box Assembly, Component Fryer ½ 200-3300 Bracket, Component Box Strain Relief 806-9495SP Terminal Block √ 4 807-0012 Relay, Filter 18 Amp ⅓ HP 24V √ 5 807-0670...

  • Page 59: Contactor Boxes

    2.5.2 Contactor Boxes 2.5.2.1 Left and Right Over the Filter Pan Contactor Box Configurations 2-18...
  • Page 60 PART # 106-5488 Box Assembly, Left Contactor Standard (Over the Filter Pan) 106-7066 Box Assembly, Left Contactor Fryer ½ Half Fryer on Left 823-5736 Box Assembly, Left Contactor EPRI (Over the Filter Pan) 106-5489 Box Assembly, Right Contactor Standard (Over the Filter Pan) 106-6819 Box Assembly, Right Contactor Fryer ½...
  • Page 61 2.5.2.2 Large Center Contactor Box Configurations (Non-Filter, Not over the Filter and Single Units) 2-20...
  • Page 62 Cover, Contactor Box Front 220-1089 Cover, Contactor Box Top (Non-Filter or Not Over the Filter Pan) 220-1175 Cover, Contactor Box Top Full Vat Single-Station Fryer Only 220-1373 Cover, Contactor Box Top Dual Vat Single-Station Fryer Only 220-1152 Cover, Contactor Box Top EPRI (Non-Filter or Not Over the Filter Pan)

  • Page 63: Fuse Boxes

    Cover, RH Fuse Box (Used on Single Station Fryers also) 809-0434 Screw, #10 x ⅜” Hex 823-5585 Box, LH Fuse 823-5557 Box, RH Fuse 823-5797 Box, Single Station Fryer Only 807-3970 Block, 3 Pole 600V 175A Terminal 807-0501 Fuse Block, Buss #2968 3-Pole 807-2240 Fuse, 60 AMP 300VAC 807-0070...

  • Page 64: Terminal Blocks

    PART # 823-5631 Box, LH Rear Terminal Block 823-5632 Box, RH Rear Terminal Block 823-5797 Box, Single Station Fryer Only (see previous page for cover 222-0523) 220-0801 Cover, Rear Terminal Block Box 807-3970 Block, 3 Pole 600V 175A 807-0070 Terminal, Ground Lug...

  • Page 65: Heating Element Assemblies And Associated Parts

    2.5.5 Heating Element Assemblies and Associated Parts 2.5.5.1 Element Assemblies and Hardware NOTE: These elements apply only to the RE series fryers. For the previous model elements see manual PN 819-5990. 2-24...
  • Page 66 Spring, Element Lift Left 810-3031 Spring, Element Lift Right 220-1190 Bracket, Lower Spring Single Foot Print 220-0464 Bracket, Lower Spring 220-1855 Bracket, Lower Spring Fryer ½ 220-0733 Bracket, Lower Spring Mating 810-1233 Handle, Element Lift * Not illustrated. √ Recommended parts. COMPONENT...

  • Page 67: Element Tube Assemblies

    2.5.5.2 Element Tube Assemblies 2-26...

  • Page 68: Controllers

    2.5.5.2 Element Tube Assemblies cont. ITEM PART # 106-7653SP Tube Assembly RE Element, Full-Vat 106-6736 Tube Assembly RE Element Fryer ½ LH Half Fryer (use 106-6061 RH Half Fryer) 106-7654SP Tube Assembly RE Element, Dual-Vat 810-3246 Bushing and Tube Assembly, Dual-Vat 106-5329...

  • Page 69: Wiring

    2.5.6 Controllers cont. ITEM PART # Basket Lift Timer 826-2330 Full-Vat (CE) 106-4366 Dual-Vat (CE) 826-2401 Full-Vat (Non-CE) 826-2402 Dual-Vat (Non-CE) Solid-State (Analog) Controller 826-2538 Full-Vat 106-4334 Dual-Vat 802-2021 Graphic Sheet of Symbols 2.5.7 Wiring 2.5.7.1 Contactor Box Wiring Assemblies – 12-Pin Dual-Vat C-1 ITEM PART # 106-5980SP Contactor Box Harness Assembly Dual Vat...

  • Page 70: Contactor Box Wiring Assemblies 12-Pin Full Vat

    106-6031SP Contactor Box Harness Assembly Full Vat Standard (See wiring diagrams on pages 1-19.) EPRI (uses harness above plus wire kits WIR0733 and WIR0736) (See wiring diagrams on pages 1-26 and 1-27.) 106-7042 Fryer and ½ Contactor Box Harness Assembly COMPONENT 2-29...

  • Page 71: Contactor Box Wiring Assemblies 6-Pin Left Element

    2.5.7.3 Contactor Box Wiring Assemblies – 6-Pin (Left Element) ITEM PART # 106-6768 14/17 kW Standard Mercury 106-7849 22 kW Triac SSR 106-6771 14/17 kW Mechanical Contactor 106-7851 22 kW Mercury and High Amp Mechanical Contactor 2.5.7.4 Contactor Box Wiring Assemblies – 9-Pin (Right Element) ITEM PART # 106-6769...

  • Page 72: Main Wiring Harnesses

    2.5.7.5 Main Wiring Harnesses - Full and Dual Vat 12-Pin Female Connector 15-Pin Male Connector 807-0159 (Rear of Fryer) 807-0804 (Rear of Component Box) 12-Pin Male Connector 807-0160 (Contactor Box) USED ONLY ON DUAL VAT HARNESSES FULL VAT HARNESS 807-4194...
  • Page 73 2.5.7.5 Main Wiring Harnesses – Fryer and ½ FRYER AND ½ HARNESS 807-4364 2-32...

  • Page 74: Component Box, Filter Pump And Basket Lift Wiring Harnesses

    2.5.7.6 Component Box, Filter Pump and Basket Lift Wiring Harnesses ITEM PART # 106-5750 Full Vat Control Harness J4 to J2 (Standard) 106-6639 Full Vat Control Harness J4 to J2 (EPRI) 106-5751 Dual Vat Control Harness J4 to J1 and J2 (Standard) 106-6644 Dual Vat Control Harness J4 to J1 and J2 (EPRI) 106-5935...

  • Page 75: Component Box To Filter Pump Harness

    2.5.7.7 Component Box to Filter Pump Harness 2.5.7.8 Basket Lift Harness 2.5.7.9 Interface Board to Controller Wiring Harness – 15-Pin 2-34...

  • Page 76: Filtration System Components

    2.6 Filtration System Components 2-35...
  • Page 77 Crumb Tray, Fryer ½ 810-2910 Hold-Down Ring for Paper 13.65 x 21.41 Multi-Vat Fryers 823-5774 Hold-Down Ring for Paper 8.98 x 19.39 Single Station Fryer Only 823-5811 Hold-Down Ring for Pad 15.75x 20.02 SCF Deep Cabinet 823-5934 Hold-Down Ring for Paper 8.98 x 21.04 Fryer ½...
  • Page 78 Bridge, Filter Motor Multi-Vat Fryers 824-1705 Bridge Filter Motor Single Station Fryer Only 220-1346 Bridge, Filter Motor SCF Deep Cabinet 220-2080 Bridge, Filter Motor Fryer ½, Half Fryer LH side 220-1837 Bridge, Filter Motor Fryer ½, Half Fryer RH side 813-0003 Tee, ½-Inch 813-0298 Nipple, ½-inch 2.0-inch...
  • Page 79 2.7 Frypot Assemblies and Associated Parts 2-38...
  • Page 80 (does not include Item 6) (for use on EPRI units) (for use on Standard units) (for use on Fryer ½ LH units) (for use on Fryer ½ RH units) (for use on Standard Deep units) (for use on EPRI units)

  • Page 81: Oil Return System Components

    Plumbing for a two-fryer battery is illustrated, but all components except the oil return manifold same regardless of the number of fryers in the battery.
  • Page 82 900-2935 Retainer, Oil Return Valve Nut 813-0460 Nipple, ½-inch X 3.0-inch NPT 813-0907 Cap, 15/16-inch Valve Safety Manifolds 810-3142 Manifold, Fryer ½ Station Fryer 810-3015 Manifold, Two-Station Fryer 810-3016 Manifold, Three-Station Fryer 810-3017 Manifold, Four-Station Fryer 810-3018 Manifold, Five-Station Fryer * Not illustrated.

  • Page 83: Oil Disposal Plumbing

    Oil Disposal Plumbing 2-42...

  • Page 84: Oil Disposal Wand

    Oil Disposal Plumbing cont. ITEM PART # 106-5959 Plumbing, Front Oil Disposal 106-5933 Plumbing, Rear Oil Disposal 106-6033 Valve Assembly, Oil Disposal 220-0922 Rod, Oil Disposal 220-0963 Bracket, Oil Disposal Rod 807-2484 Valve, Solenoid ¼-inch NPT 809-0601 Clip, Clevis Right Rod End 810-0487 Coupling, Male 810-1043...

  • Page 85: Wiring And Pin Connectors

    2.11 Wiring Connectors and Pin Connectors ITEM PART # 807-1068 2-Pin Female 807-0158 6-Pin Female 807-0156 9-Pin Female 807-0159 12-Pin Female 807-0875 15-Pin Female 807-1067 2-Pin Male 807-0157 6-Pin Male 807-0155 9-Pin Male 807-0160 12-Pin Male 807-0804 15-Pin Male 826-1341 Terminal, Female Split Pin (pkg.

  • Page 86: Fasteners

    2.12 Fasteners ITEM PART # 809-0429 Bolt, ¼-inch – 20 x 2.00-inch Hex Head ZP Tap 809-0514 Capscrew, 5/16-inch-18 NC Hex 809-0448 Clip, Tinnerman 826-1366 Nut, 4-40 Keps Hex (Pkg. of 25) (809-0237) 826-1358 Nut, 6-32 Keps Hex (Pkg. of 25) (809-0049) 809-0247 Nut, 8-32 Keps Hex 826-1376...
  • Page 87 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 88 Frymaster, L.L.C., 8700 Line Avenue, Shreveport, Louisiana 71106 TEL 1-318-865-1711 FAX (Parts) 1-318-219-7140 (Tech Support) 1-318-219-7135 819-6150 SERVICE HOTLINE MAY 2009 PRINTED IN THE UNITED STATES 1-800-551-8633...

This manual is also suitable for:
