Installation Instructions
for Front Control Dryers
Inside........................................
Dimensions........................................................................
Before You Start................................................................
Installing the Dryer............................................................
Installer Checklist..............................................
Date Purchased __________________________
Model Number __________________________
Serial Number __________________________
Keep these instructions for future reference.
(If this machine changes ownership, this manual must accompany machine.)
3
4
5
Back Cover
www.comlaundry.com
Part No. 506126R5
September 2009
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Alliance Laundry Systems 506126R5
Summary of Contents for Alliance Laundry Systems 506126R5
-
Page 1: Installation Instructions
Before You Start..............Installing the Dryer............Installer Checklist..........Back Cover Date Purchased __________________________ Model Number __________________________ Serial Number __________________________ Keep these instructions for future reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 506126R5 www.comlaundry.com September 2009... - Page 2 All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126...
- Page 3 23.5 in. 28 in. 26.9 in. (68.3 cm) (59.7 cm) (71.1 cm) DRY2282N GAS DRYERS DRY2282N *With leveling legs turned into base. 3/8 in. NPT Gas Connection © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126...
-
Page 4: Before You Start
For most installations, the basic supplies you will need tools must be performed by a suitably are: qualified service person. W299 D818I Wrench Screwdriver Level Duct Tape Teflon Tape (Gas Models) Figure 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... -
Page 5: Installing The Dryer
*Louvered door with equivalent air openings is acceptable. (Minimum clearances are shown.) **NOTE: For new installations, locate top of wall vent 42 inches (106.7 cm) above floor to make venting easier to connect. Figure 2 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... - Page 6 • The male end of each section of duct must point space under a building or concealed space away from the dryer. of a building. • Use as few elbows as possible. W045 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126...
- Page 7 • Dryer exhausts 220 cfm (measured at back of dryer). • Never install flexible duct in concealed spaces, such as a wall or ceiling. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126...
-
Page 8: Exhaust Direction
NOTE: The maximum length of a 4 in. (10.2 cm) diameter flexible metal duct must not exceed 7.87 ft. (2.4 m), as required to meet UL2158, clause 7.3.2A. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... -
Page 9: Step 3: (Gas Dryer Only) Connect Gas Supply Pipe
Refer to Longer than 20 ft. (6.1 m) – Table 2. Use 1/2 in. (12.7 mm) pipe 3/8 in. NPT Gas Connection Figure 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... -
Page 10: Step 4: (Electric Dryer Only) Connect Electrical Plug
Amperes and labeled as suitable for use in a clothes by a qualified electrician. dryer. NOTE: The wiring diagram is located behind the control panel, inside the control cabinet. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... - Page 11 The power cord connection between wall receptacle and dryer terminal block IS NOT supplied with dryer. Type of power cord and gauge of wire must conform to local codes. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126...
-
Page 12: Connecting Power Cord With Three-Wire Plug
3. Use a strain relief and insert end of power cord through power supply hole. 2. Remove access cover from rear of dryer. D696I D695I Figure 8 Figure 7 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... -
Page 13: Connecting Power Cord With Four-Wire Plug
8. Reinstall access cover and screw. D695I Figure 11 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... - Page 14 D698I 10. Reinstall access cover and screw. D698I Power Cord Ground Wire Figure 14 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126...
-
Page 15: Step 5: Reverse Door, If Desired
8. Using screwdriver, remove two door plugs, and reinstall on opposite side of door opening. DRY1916N DRY1916N 4. Rotate door panel 180 degrees as shown. DRY2052N DRY2052N D273P © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... -
Page 16: Gas Dryer
120 Volts AC (alternating current) 15 Amps. Refer to Figure 18 to determine correct polarity of the wall receptacle. Connect to 30 Amp circuit. D275I Figure 17 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... -
Page 17: Step 8: Recheck Steps
(refer to the User’s Guide supplied with the dryer). After the dryer has operated for three minutes, the exhaust air or exhaust pipe should be warm. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... -
Page 18: Gas Dryers
Adjust the air shutter as follows: D700I Shut-Off Valve Handle 1/8 in. (3.1 mm) Pipe Plug (For checking manifold pressure) Air Shutter Lockscrew Air Shutter Open Position Closed Position © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 506126... -
Page 20: Installer Checklist
Leaks. CHECK D258I CHECK • Check Heat Source. ELECTRIC ONLY • Connect Electrical Cord. D700I CHECK D700I CHECK D699IE0A D699IE0A • Reverse Door, if Desired. CHECK DRY2051N DRY2051N © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
