SmartNode 4960 Series
T1/E1 PRI VoIP Router
Getting Started Guide
Sales Office:
+1 (301) 975-1000
Technical Support:
+1 (301) 975-1007
E-mail:
support@patton.com
WWW:
www.patton.com
Document Number: 13223U1-001 Rev. B
Part Number: 07MSN4960-GS
Revised: November 15, 2006
